FORD FIESTA 2007 Workshop Manual

Engine Cooling - 1.3L Duratec-8V
(Rocam)ll.25L Duratec-1 6V (Sigma)llI4L
303-03A-19 Duratec-1 6V (Sigma)lll6L Duratec-I 6V (Sigma) 303-03A-19
GENERAL PROCEDURES
Cooling System Draining, Filling and Bleeding - 1.3L Duratec-8V
I (Rocam)/l.25L Duratec-1 6V (Sigma)/l.4L Duratec-1 6V
(Sigma)/l.6L Duratec-1 6V (Sigma)(24 122 0)
Draining 5. Install the radiator drain plug.
la AWARNING:~~~~ releasing the cooling 6. Lower the vehicle.
system pressure, cover the coolant
expansion tank cap with a thick cloth to
Filling and Bleeding
prevent the possibility of scalding. Failure 1. Remove the radiator bleed plug (if equipped). to follow this instruction may result in
personal injury.
Release the cooling system pressure by
slowly turning the coolant expansion tank
cap a quarter of a turn.
2. Fill the coolant expansion tank until coolant
is expelled from the radiator bleed point or
stabilizes at the MAX mark (whichever occurs
first).
3. Install the radiator bleed plug (if equipped). 2. Remove the coolant expansion tank cap. 4. Fill the coolant expansion tank to the MAX 3. Raise and support the vehicle.
mark (if necessary).
For additional information, refer to: Lifting
(1 00-02 Jacking and Lifting, Description
and Operation).
4. Drain the cooling system.
Allow the coolant to drain into a suitable
container.
5.
Start and run the engine at 3000 revolutions
per minute (RPM) for two minutes.
6. Fill the coolant expansion tank completely.
7. Install the coolant expansion tank cap.
8. Start and run the engine at 3000 RPM for
another two minutes.
2006.0 Fiesta 1212006 G146259en
procarmanuals.com

Engine Cooling - 1.3L Duratec-8V
(Rocam)ll125L Duratec-I 6V (Sigma)ll14L
Duratec-1 6V (Sigma)/l .6L Duratec-1 6V (Sigma)
GENERAL PROCEDURES
9. Switch the engine off.
2006.0 Fiesta iz1~006 GI 46259en
procarmanuals.com

Engine Cooling - 1.3L Duratec-8V
(Rocam)ll.25L Duratec-1 6V (Sigma)ll.4L
303-03A-21 Duratec-1 6V (Sigma)/l .6L Duratec-1 6V (Sigma) 303-03A-21
REMOVAL AND INSTALLATION
Water Pump - 1.25L Duratec-1 6V (Sigma)/l.4L Duratec-1 6V
(Sigma)/l .6L Duratec-1 6V (Sigma)(24 404 0)
Removal
Vehicles built up to 0412005
Loosen the water pump pulley retaining
bolts.
1. Disconnect the battery ground cable.
For additional information, refer to: Battery
Disconnect
(414-01 Battery, Mounting and
Cables, General Procedures).
2. Remove the air
cleaner.
For additional information, refer to: Air
Cleaner - 1.25L Duratec-1 6V (Sigma)ll.4L
Duratec-1 6V (Sigma)ll .6L Duratec-1 6V
(Sigma) (303-12 Intake Air Distribution and
Filtering, Removal and Installation).
3. Drain the cooling system.
6. Lower the vehicle. For additional information, refer to: Cooling
System Draining, Filling and Bleeding - 1.3~ 7. Disconnect the degas hose from the coolant
Duratec-8V (Rocam)ll.25L Duratec-1 6V expansion tank.
(Sigma)ll.4L Duratec-1 6V (Sigma)ll .6L
Duratec-1 6V (Sigma) (303-03 Engine
Cooling - 1.3L DuratecdV (Rocam)ll.25L
Duratec-1 6V (Sigma)ll.4L Duratec-1 6V
(Sigma)ll .6L Duratec-1 6V (Sigma), General
Procedures).
4. Remove the crankshaft
pulley splash shield.
5m AWARNING:D~ not remove the water pump
pulley retaining bolts at this stage as the
pulley is under tension from the accessory
drive
belt. Failure to follow this instruction
may
result in personal injury. 8.
Detach the
coolant expansion tank and
secure
it to one side.
2006.0 Fiesta 1212006 GI 89080en
procarmanuals.com

Engine Cooling - 1.3L Duratec-8V
(Rocam)ll.25L Duratec-1 6V (Sigma)llI4L
303-03A-22 Duratec-1 6V (Sigma)lIl6L Duratec-1 6V (Sigma) 303-03A-22
REMOVAL AND INSTALLATION
9. Remove the generator.
For
additional information, refer to:
Generator
- 1.25L Duratec-1 6V (Sigma)/l.4L
Duratec-I 6V (Sigma)/l .6L Duratec-I 6V
(Sigma)
(414-02 Generator and Regulator,
Removal and Installation).
10. Remove the water pump pulley.
Discard the gasket.
Vehicles built 0412005 onwards
13. Remove the timing belt.
For additional information, refer to: Timing
Belt (303-01 Engine - 1.25L Duratec-1 6V
(Sigma)ll.4L Duratec-1 6V (Sigma)ll .6L
Duratec-1 6V (Sigma), ln-vehicle Repair).
11. Remove the timing belt cover (cover shown 14. Drain the cooling system,
removed for clarity). For additional information, refer to: Cooling
12' &AUTION:P~~~~~~ the timing belt and
lower cover from contamination by the
coolant.
Remove the water pump. System
Draining,
Filling and Bleeding -
1.3L Duratec-8V (Rocam)ll.25L
Duratec-1 6V (Sigma)ll.4L Duratec-1 6V (,
(Sigma)ll .6L Duratec-1 6V (Sigma) (303-03
Engine
Cooling - 1.3L Duratec-8V
(Rocam)ll.25L Duratec-I 6V (Sigma)/l.4L
Duratec-1 6V (Sigma)ll .6L Duratec-1 6V
(Sigma), General Procedures).
15. Remove the water pump and the timing
belt
tensioner.
Discard the gasket.
2006.0 Fiesta 1212006 GI 89080en
procarmanuals.com

Engine Cooling - 1.3L Duratec-8V
(Rocam)ll.25L Duratec-1 6V (Sigma)ll.4L
303-03A-23 Duratec-1 6V (Sigma)/l .6L Duratec-1 6V (Sigma) 303-0349-23
REMOVAL AND INSTALLATION
16. Remove the timing belt tensioner from the
water pump.
Installation
1. N0TE:lnstall a new water pump gasket.
To install, reverse the removal procedure.
2006.0 Fiesta 1212006 GI 89080en
procarmanuals.com

Engine Cooling - 1.3L Duratec-8V
(Rocam)ll.25L Duratec-1 6V (Sigma)ll.4L
303-03A-24 Duratec-1 6V (Sigma)/l .6L Duratec-1 6V (Sigma) 303-O3A-24
REMOVAL AND INSTALLATION
Thermostat - 1.25L Duratec-1 6V (Sigma)/l.4L Duratec-1 6V
(Sigma)/l .6L Duratec-1 6V (Sigma)(24 454 0)
Special Tool(s) 4. Disconnect the heater hose from the
I Removerllnstaller, Cooling I thermostat housing.
Hose Clamp
303-397 (24-003)
Removal
1. Drain the cooling system.
For additional information, refer to Cooling
System Draining, Filling and Bleeding in
this section.
5. Remove the thermostat housing.
2. Remove the generator. For additional
information, refer to Section
414-02
[Generator and Regulator].
3. Using the special tool, disconnect the
radiator lower hose from the thermostat
housing.
6. N0TE:The thermostat is installed with the
jiggle pin at the top.
Remove the thermostat.
I I, '
Installation
I. To install, reverse the removal procedure.
2006.0 Fiesta 1212006 G210040en
procarmanuals.com

Engine Cooling - 1.3L Duratec-8V
(Rocam)ll.25L Duratec-1 6V (Sigma)ll.4L
Duratec-1 6V (Sigma)Il.GL Duratec-1 6V (Sigma) -- --
REMOVAL AND INSTALLATION
Make sure the rubber seal is located
correctly.
I I
2006.0 Fiesta 1212006 G210040en
procarmanuals.com

Engine Cooling - 1.3L Duratec-8V
(Rocam)llI25L Duratec-1 6V (Sigma)llI4L
3-03A-26 Duratec-I 6V (Sigma)llm6L Duratec-1 6V (Sigma) 303-03A-26
REMOVAL AND INSTALLATION
Radiator(24 254 0) /'
Special Tool@)
I I Remover/lnstaller, Cooling I
2. Push the cooling fan motor and shroud (.
upwards and then downwards to remove.
24003
Removal
Hose Clamp
303-397 (24-003)
1. Disconnect the battery ground cable. For
additional information, refer to
Section 414-01 [Battery, Mounting and
Cables].
5. Using the special tool, disconnect the
2. Drain the cooling system. radiator
upper hose.
For additional information, refer to Cooling
System Draining, Filling and Bleeding in
this section.
3. Disconnect the cooling fan motor and
cooling fan resistor electrical connectors.
4. Remove the cooling fan motor and shroud.
I. Release the cooling fan motor and shroud
from the retaining brackets.
6. Using the special tool, disconnect the
radiator lower hose.
7. Remove the radiator retainers.
1. Remove the radiator retainer locking screws.
2006.0 Fiesta 1212006 ~210041 en
procarmanuals.com

Engine Cooling - 1.3L Duratec-8V
(Rocam)ll.25L Duratec-1 6V (Sigma)ll.4L
Duratec-1 6V (Sigma)/l .6L Duratec-1 6V (Sigma)
REMOVAL AND INSTALLATION
2. Remove the radiator retainers and grommets.
8. Detach the radiator and the air conditioning
(NC) condenser from the support panel.
9m &AUTION:SU~~O~~ the condenser by
positioning it on the support panel.
Slide the
NC condenser to detach it from the
radiator
130. Remove the radiator.
Installation
1. To install, reverse the removal procedure.
2006.0 Fiesta 1212006 ~210041 en
