FORD MUSTANG 1997 4.G Owners Manual
Manufacturer: FORD, Model Year: 1997, Model line: MUSTANG, Model: FORD MUSTANG 1997 4.GPages: 321, PDF Size: 2.81 MB
Page 231 of 321
![FORD MUSTANG 1997 4.G Owners Manual 233 [MC20350(M )04/96]
4.6L SFI engine (check cold)
[MC20355(M )04/96]
NOTE: The brakes on the 4.6L engine vehicles
are powered by power steering fluid
from the power steering pump. The
fluid level in FORD MUSTANG 1997 4.G Owners Manual 233 [MC20350(M )04/96]
4.6L SFI engine (check cold)
[MC20355(M )04/96]
NOTE: The brakes on the 4.6L engine vehicles
are powered by power steering fluid
from the power steering pump. The
fluid level in](/img/11/5204/w960_5204-230.png)
233 [MC20350(M )04/96]
4.6L SFI engine (check cold)
[MC20355(M )04/96]
NOTE: The brakes on the 4.6L engine vehicles
are powered by power steering fluid
from the power steering pump. The
fluid level in the power steering
reservoir will rise and fall due to the
amount of charge in the brake booster
accumulator. Therefore the following is
required.
[MC20400(MBC )12/95]
1. Check the fluid level when the system is
COLD (allow at least one half hour after
driving for the power steering fluid to cool).
[MC20500(MBC )04/96]
2. Locate the power steering reservoir mounted
to the front upper left-hand corner of the
engine.
[MC20550(M )04/96]
NOTE: Brake fluid and power steering fluid
CAN NOT be mixed. Only add brake
fluid to the brake master cylinder
reservoir. Only add power steering
fluid to the power steering reservoir.
[MC20600(MBC )12/95]
3. Visually verify that the fluid level is above
the MIN line adjacent to the reservoir ªsight
window.º
[MC20700(MBC )12/95]
4. If the power steering fluid is below the MIN
line, remove the cap and add fluid in small
amounts until the level is between the MIN
and MAX lines.
[MC20800(MBC )12/95]
5. Reinstall the reservoir cap.
[MC20850(M )03/96]
It is normal for the fluid level to be above the
MAX line after the brake pedal has been pushed
several times with the engine off. (If you want
to double check it; restart engine and turn
steering wheel to full right turn, then full left
turn and then turn engine off and re-check fluid
level. It should be between MIN and MAX line.)
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997
Page 232 of 321
![FORD MUSTANG 1997 4.G Owners Manual 234 [MC20950(M )03/96]
half page art:0011388-AFluid level for power steering
[MC21100(MBC )05/96]
Use only power steering fluid that meets Ford
Specification MerconHATF XT-2-QDX or an
equivalent.
*
[M FORD MUSTANG 1997 4.G Owners Manual 234 [MC20950(M )03/96]
half page art:0011388-AFluid level for power steering
[MC21100(MBC )05/96]
Use only power steering fluid that meets Ford
Specification MerconHATF XT-2-QDX or an
equivalent.
*
[M](/img/11/5204/w960_5204-231.png)
234 [MC20950(M )03/96]
half page art:0011388-AFluid level for power steering
[MC21100(MBC )05/96]
Use only power steering fluid that meets Ford
Specification MerconHATF XT-2-QDX or an
equivalent.
*
[MC21200(MBC )01/96]
NOTE: If the power steering fluid is low, do
not drive your vehicle for a long
period of time before adding fluid.
This can damage the power steering
pump.
%
*
[MC21300( ALL)01/96]
Automatic Transmission Fluid
*
[MC21400( ALL)03/96]
Under normal circumstances, you do not need to
check the fluid level of the transmission, since
your vehicle does not use up transmission fluid.
Refer to theMaintenance Schedulebooklet for
replacement intervals. However, if the
transmission is not working properly Ð for
instance, the transmission may slip or shift
slowly, or you may notice some sign of fluid
leakage Ð the fluid level should be checked.
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997
Page 233 of 321
![FORD MUSTANG 1997 4.G Owners Manual 235 %
*
[MC21500( ALL)01/96]
Checking the Automatic Transmission
Fluid
*
[MC21600( ALL)01/96]
It is preferable to check the transmission fluid
level at normal operating temperature
150ÊF-170ÊF (66Ê FORD MUSTANG 1997 4.G Owners Manual 235 %
*
[MC21500( ALL)01/96]
Checking the Automatic Transmission
Fluid
*
[MC21600( ALL)01/96]
It is preferable to check the transmission fluid
level at normal operating temperature
150ÊF-170ÊF (66Ê](/img/11/5204/w960_5204-232.png)
235 %
*
[MC21500( ALL)01/96]
Checking the Automatic Transmission
Fluid
*
[MC21600( ALL)01/96]
It is preferable to check the transmission fluid
level at normal operating temperature
150ÊF-170ÊF (66ÊC-77ÊC),after approximately 20
miles (30 km) of driving. However, if necessary,
you can check the fluid level without having to
drive 20 miles (30 km) to obtain a normal
operating temperature if outside temperatures
are above50ÊF (10ÊC).
[MC21700( ALL)12/95]
With the vehicle on a level surface, start the
engine and, while fully applying the brake
pedal, move the transmission shift selector
through all of the gear ranges allowing sufficient
time for each position to engage.Securely latch
the transmission shift selector in the P (Park)
position, fully set the parking brake and leave
the engine running.
[MC21900(MBC )12/95]
NOTE: Your vehicle should not be driven if
the fluid level is below the low cold
reading on the dipstick.
*
[MC22000( ALL)01/96]
Wipe off the dipstick cap, pull the dipstick out
and wipe the indicator end clean. Put the
dipstick back into the filler tube and make sure
it is fully seated. Pull the dipstick out and read
the fluid level.
[MC22100(MBC )12/95]
When checking fluid at normal operating
temperature150ÊF-170ÊF (66ÊC-77ÊC), thefluid
level should be within the hot notched area on
the dipstick. When the vehicle has not been
driven, and the fluid is at room temperature
50ÊF-95ÊF (10ÊC-35ÊC), thefluid level should be
within the cold notched area.
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997
Page 234 of 321
![FORD MUSTANG 1997 4.G Owners Manual 236
*
[MC22300( ALL)01/96]
NOTE: If the vehicle has been operated for an
extended period at high speeds or in
city traffic during hot weather, or
pulling a trailer, the vehicle should be
turned off fo FORD MUSTANG 1997 4.G Owners Manual 236
*
[MC22300( ALL)01/96]
NOTE: If the vehicle has been operated for an
extended period at high speeds or in
city traffic during hot weather, or
pulling a trailer, the vehicle should be
turned off fo](/img/11/5204/w960_5204-233.png)
236
*
[MC22300( ALL)01/96]
NOTE: If the vehicle has been operated for an
extended period at high speeds or in
city traffic during hot weather, or
pulling a trailer, the vehicle should be
turned off for about 30 minutes to
allow the fluid to cool before checking.
%*
[MC22400( ALL)01/96]
Adding Automatic Transmission Fluid
[MC22500( ALL)12/95]
Before adding any fluid, be sure that the correct
type will be used. Use only MERCONHfluid.
*
[MC22600( ALL)12/95]
Add fluid in 1/2 pint (.25L) increments through
the filler tube to bring the level to the correct
area on the dipstick. DO NOT OVERFILL. If the
level is above the top hole on the dipstick,
excess fluid should be removed by a qualified
technician.
%*
[MC22700( ALL)05/96]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
[MC22800(MBC )12/95]
one third page art:0011152-A
Detail of the automatic transmission dipstick
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997
Page 235 of 321
![FORD MUSTANG 1997 4.G Owners Manual 237
% [MC23000(M )12/95]
Manual Transmission Fluid
% [MC23100(M )12/95]
The fluid level and quality should not
deteriorate under normal driving conditions.
However, it is suggested that you have the f FORD MUSTANG 1997 4.G Owners Manual 237
% [MC23000(M )12/95]
Manual Transmission Fluid
% [MC23100(M )12/95]
The fluid level and quality should not
deteriorate under normal driving conditions.
However, it is suggested that you have the f](/img/11/5204/w960_5204-234.png)
237
% [MC23000(M )12/95]
Manual Transmission Fluid
% [MC23100(M )12/95]
The fluid level and quality should not
deteriorate under normal driving conditions.
However, it is suggested that you have the fluid
level checked occasionally. If fluid is required,
seeLubricant Specificationsin the Index.
%
*
[MC23200( ALL)01/96]
Battery
*
[MC23300( ALL)01/96]
Your vehicle may have a Motorcraft
maintenance-free battery. When the original
equipment battery is replaced under warranty, it
may be replaced by a Motorcraft
Low-Maintenance Battery.
*
[MC23400( ALL)01/96]
The Low-Maintenance Battery has removable
vent caps for checking the electrolyte level and
for adding water, if necessary. The electrolyte
level should be checked at least every 24 months
or 24,000 miles (40,000 km) in temperatures up
to 90ÊF (32ÊC) andmore often in temperatures
above90ÊF (32ÊC).Keep the electrolyte level in
each cell up to the level indicator. Do not
overfill.
*
[MC23500( ALL)01/96]
If the level gets low, you can add tap water to
the battery, provided the water isn't hard or
doesn't have a high mineral or alkali content.
However, if possible you should refill the battery
with distilled water. If the battery needs water
quite often, have the charging system checked
for a possible malfunction.
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997
Page 236 of 321
![FORD MUSTANG 1997 4.G Owners Manual 238 %
*
[MC23600( ALL)01/96]
Help Us Protect Our Environment
*
[MC23700( ALL)01/96]
Ford Motor Company strongly recommends that
used lead-acid batteries be returned to an
authorized recycling facility FORD MUSTANG 1997 4.G Owners Manual 238 %
*
[MC23600( ALL)01/96]
Help Us Protect Our Environment
*
[MC23700( ALL)01/96]
Ford Motor Company strongly recommends that
used lead-acid batteries be returned to an
authorized recycling facility](/img/11/5204/w960_5204-235.png)
238 %
*
[MC23600( ALL)01/96]
Help Us Protect Our Environment
*
[MC23700( ALL)01/96]
Ford Motor Company strongly recommends that
used lead-acid batteries be returned to an
authorized recycling facility for disposal.
*
[MC23800( ALL)01/96]
one inch art:0000983-A
Battery recycling symbol
% [MC23900(M )12/95]
Because your vehicle's engine is electronically
controlled by a computer, some control
conditions are maintained by power from the
battery. If you ever disconnect the battery, install
a new battery, or experience a dead battery, you
must allow the computer to ªrelearnº its idle
conditions before your vehicle will idle at its
best. To let the engine do this, put the gearshift
in P (Park) (automatic transmission) or Neutral
(manual transmission), turn off all the
accessories, and start the vehicle. Let the engine
idle for at least one minute. (Engine must be
warm in order to ªlearn.º) Also, allow
approximately 10 miles (16 km) of stop and go
traffic for your vehicle's engine to completely
ªrelearnº its idle.
%
*
[MC24300( ALL)02/96]
Wiper Blades
*
[MC24400( ALL)01/96]
Check the windshield wiper blades at least twice
a year. Also check them whenever they seem
less effective than usual. Substances such as tree
sap and some hot wax treatments used by
commercial car washes reduce the effectiveness
of wiper blades.
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997
Page 237 of 321
![FORD MUSTANG 1997 4.G Owners Manual 239
*
[MC24500( ALL)01/96]
If the blades do not wipe properly, clean both
the windshield and the wiper blades. Use
undiluted windshield washer solution or a mild
detergent. Rinse thoroughly with clear FORD MUSTANG 1997 4.G Owners Manual 239
*
[MC24500( ALL)01/96]
If the blades do not wipe properly, clean both
the windshield and the wiper blades. Use
undiluted windshield washer solution or a mild
detergent. Rinse thoroughly with clear](/img/11/5204/w960_5204-236.png)
239
*
[MC24500( ALL)01/96]
If the blades do not wipe properly, clean both
the windshield and the wiper blades. Use
undiluted windshield washer solution or a mild
detergent. Rinse thoroughly with clear water. Do
not use fuel, kerosene, paint thinner, or other
solvents to clean your wiper blades. These will
damage your blades.
*
[MC24600( ALL)01/96]
To make reaching the wiper blades easy, simply
turn the ignition to the ACC position and turn
your wipers on. Wait for them to reach a
vertical position and turn the ignition to the OFF
position. Do not move the wipers manually.
Manually moving the wipers across the
windshield may damage them.
*
[MC24700( ALL)02/96]
Wiper blade replacement
*
[MC24800( ALL)01/96]
If the wiper blades still do not work properly
after you clean them, you may need to replace
the wiper blade assembly or the blade element.
When replacing the wiper blade assembly, blade
refill, or wiper arm always use a Motorcraft part
or equivalent. To replace the blades, follow the
instructions that come with them.
%
*
[MC24900( ALL)01/96]
Tires
%*
[MC25001( ALL)03/96]
Checking Tire Pressure
*
[MC25100( ALL)02/96]
q
Use an accurate tire pressure gauge.
*
[MC25200( ALL)02/96]
q
Check the tire pressure when tires are cold,
after the vehicle has been parked for at least
one hour or has been driven less than 3 miles
(5 km).
*
[MC25400( ALL)03/96]
q
Adjust tire pressure to recommended
specifications found on the Safety Compliance
Certification Label.
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997
Page 238 of 321
![FORD MUSTANG 1997 4.G Owners Manual 240
*
[MC25900( ALL)01/96]
RWARNING
Improperly inflated tires can affect vehicle
handling and can fail suddenly, possibly
resulting in loss of vehicle control.
%*
[MC26000( ALL)01/96]
Tire Rotation
*
FORD MUSTANG 1997 4.G Owners Manual 240
*
[MC25900( ALL)01/96]
RWARNING
Improperly inflated tires can affect vehicle
handling and can fail suddenly, possibly
resulting in loss of vehicle control.
%*
[MC26000( ALL)01/96]
Tire Rotation
*](/img/11/5204/w960_5204-237.png)
240
*
[MC25900( ALL)01/96]
RWARNING
Improperly inflated tires can affect vehicle
handling and can fail suddenly, possibly
resulting in loss of vehicle control.
%*
[MC26000( ALL)01/96]
Tire Rotation
*
[MC26100( ALL)01/96]
Because your vehicle's front and rear tires
perform different jobs, they often wear
differently. To make sure your tires wear evenly
and last longer, rotate them as indicated in the
following diagram.
*
[MC26200( ALL)05/96]
For tire rotation intervals, see theMaintenance
Schedulebooklet. If you notice that the tires wear
unevenly, have them checked.
[MC26300(M )12/95]
half page art:0010378-C
Rotating the tires
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997
Page 239 of 321
![FORD MUSTANG 1997 4.G Owners Manual 241 %
*
[MC26800( ALL)01/96]
Replacing the Tires
*
[MC26900( ALL)01/96]
Replace any tires that show wear bands. When
your tire shows a wear band, it has only 1/16
inch (2 mm) of tread left.
% [MC27000 FORD MUSTANG 1997 4.G Owners Manual 241 %
*
[MC26800( ALL)01/96]
Replacing the Tires
*
[MC26900( ALL)01/96]
Replace any tires that show wear bands. When
your tire shows a wear band, it has only 1/16
inch (2 mm) of tread left.
% [MC27000](/img/11/5204/w960_5204-238.png)
241 %
*
[MC26800( ALL)01/96]
Replacing the Tires
*
[MC26900( ALL)01/96]
Replace any tires that show wear bands. When
your tire shows a wear band, it has only 1/16
inch (2 mm) of tread left.
% [MC27000( ALL)12/95]
one inch art:0001318-A
A worn-out tire
*
[MC27100( ALL)02/96]
Because your vehicle's tires may wear unevenly,
you may need to replace them before a wear
band appears across the entire tread.
*
[MC27200( ALL)01/96]
RWARNING
When replacing full size tires, never mix
radial, bias-belted, or bias-type tires. Use
only the tire sizes that are listed on the
tire pressure decal. Make sure that all tires
are the same size, speed rating, and
load-carrying capacity. Use only the tire
combinations recommended on the decal.
If you do not follow these precautions,
your vehicle may not drive properly and
safely.
*
[MC27300( ALL)01/96]
Tires that are larger or smaller than your
vehicle's original tires may also affect the
accuracy of your speedometer.
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997
Page 240 of 321
![FORD MUSTANG 1997 4.G Owners Manual 242 %
*
[MC27400( ALL)01/96]
Information About Tire Quality Grades
*
[MC27500( ALL)01/96]
New vehicles are fitted with tires that have their
Tire Quality Grade (described below) molded
into the tires FORD MUSTANG 1997 4.G Owners Manual 242 %
*
[MC27400( ALL)01/96]
Information About Tire Quality Grades
*
[MC27500( ALL)01/96]
New vehicles are fitted with tires that have their
Tire Quality Grade (described below) molded
into the tires](/img/11/5204/w960_5204-239.png)
242 %
*
[MC27400( ALL)01/96]
Information About Tire Quality Grades
*
[MC27500( ALL)01/96]
New vehicles are fitted with tires that have their
Tire Quality Grade (described below) molded
into the tire's sidewall. These Tire Quality
Grades are determined by standards that the
United States Department of Transportation has
set.
*
[MC27600( ALL)01/96]
Tire Quality Grades apply to new pneumatic
tires for use on passenger cars. They do not
apply to deep tread, winter-type snow tires,
space-saver or temporary use spare tires, tires
with nominal rim diameters of 10 to 12 inches or
limited production tires as defined in Title 49
Code of Federal Regulations Part 575.104(c)(2).
*
[MC27700( ALL)01/96]
U.S. Department of Transportation Ð Tire
quality grades:The U.S. Department of
Transportation requires Ford to give you the
following information about tire grades exactly
as the government has written it.
%*
[MC27800( ALL)01/96]
Treadwear
*
[MC27900( ALL)01/96]
The treadwear grade is a comparative rating
based on the wear rate of the tire when tested
under controlled conditions on a specified
government test course. For example, a tire
graded 150 would wear one and one-half (1 1/2)
times as well on the government course as a tire
graded 100. The relative performance of tires
depends upon the actual conditions of their use,
however, and may depart significantly from the
norm due to variations in driving habits, service
practices and differences in road characteristics
and climate.
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997
