Spare Tire Location
[ER11100( ALL)02/96]
The spare is stored in the trunk.
[ER11200(M )03/96]
half page art:0010338-D
The spare tire location
%*
[ER11500( ALL)03/96]
To remove the spare tire:
[ER11700(M )03/96]
1. Remove the spare tire cover.
[ER11800(M )03/96]
2. Unscrew the wing-nut holding down the
spare tire.
*
[ER11900(M )03/96]
3. Lift out the spare tire, jack, and lug wrench.
File:10rcerm.ex
Update:Tue Mar 4 10:01:28 1997

194 %
*
[ER12700( ALL)03/96]
Preparing to Change the Tire
[ER12800(M )03/96]
1. Make sure that your vehicle will not move
or roll. If you have an automatic
transmission, put the gearshift in P (Park). If
you have a manual transmission, put the
gearshift in 1 (First). Set the parking brake
and block the wheel that is diagonally
opposite the tire that you are changing.
*
[ER13000(M )03/96]
When one of the back wheels is off the ground,
the transmission alone will not prevent the
vehicle from moving or slipping off the jack,
even if the vehicle is in P (Park) or 1 (First). To
prevent the vehicle from moving when you
change a tire, be sure the parking brake is set,
then block the wheel (both directions) that is
diagonally opposite (other side and end of the
vehicle) to the tire that is being changed.
*
[ER13200( ALL)03/96]
WARNING
If the vehicle slips off the jack, you or
someone else could be seriously injured.
*
[ER13600( ALL)03/96]
WARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
File:10rcerm.ex
Update:Tue Mar 4 10:01:28 1997

195
*
[ER13700( ALL)01/96]
2. Get out the spare tire and jack.
[ER14000(M )12/95]
3. The exposed lug nut wheel cover screws
onto the lug nuts. It is removed by using the
wheel lug nut wrench to turn each lug nut
cover counter-clockwise. This will NOT
loosen the wheel lug nuts. Remove the base
wheel covers with the tapered end of a
wheel nut wrench. Insert the handle of the
wrench and twist it against the inner wheel
cover flange. To remove aluminum wheel
center ornaments, insert the curled end of
lug wrench into pry-off notch and pry
against the wheel. To avoid damage to
aluminum wheel, do not twist wrench. For
more about removing wheel covers, see the
information later in this section.
*
[ER14200(MBC )12/95]
4. Loosen each wheel lug nut one-half turn
counterclockwise, but do not remove them
until the tire is raised off the ground. You
should pull up on the handle rather than
push to develop maximum force to loosen
wheel lug nuts. SeeAnti-Theft Wheel Lug
Nutslater in this chapter for information on
removing anti-theft lug nuts.
%*
[ER14400( ALL)01/96]
Removing and Replacing the Tire
%*
[ER14500(M )01/96]
1. Find the jack notch next to the door of the
tire that you are changing. Put the jack in
the jack notch and turn the handle of the
jack clockwise until the wheel is completely
off the ground.
File:10rcerm.ex
Update:Tue Mar 4 10:01:28 1997

196
*
[ER14800( ALL)01/96]
WARNING
To lessen the risk of personal injury, do
not put any part of your body under the
vehicle while changing a tire. Do not start
the engine when your vehicle is on the
jack. The jack is only meant for changing
the tire.
% [ER14900(M )04/96]
half page art:0010345-C
The notches for the jack
File:10rcerm.ex
Update:Tue Mar 4 10:01:28 1997

197 [ER15000( ALL)12/95]
half page art:0010759-A
The improper lift point
[ER15100( ALL)12/95]
NOTE: Never use the differential housing as a
lift point.
*
[ER15600( ALL)12/95]
2. Turn the jack handle clockwise until the
wheel clears the ground. Remove the wheel
lug nuts.
*
[ER15700(MBC )03/96]
3. Replace the flat tire with the spare tire,
making sure that the air valve stem is facing
outward.
*
[ER15800(MBC )03/96]
4. Reinstall the lug nuts, tightening until the
wheel is snug against the hub. The beveled
edges on the lug nuts face inward. Do not
fully tighten the lug nuts until you lower the
vehicle. If you do, you could force the
vehicle off the jack.
*
[ER15900(MBC )03/96]
5. Lower the vehicle by turning the jack handle
counterclockwise.
File:10rcerm.ex
Update:Tue Mar 4 10:01:28 1997

198
*
[ER16000(MBC )03/96]
6. Remove the jack and fully tighten the lug
nuts in the order shown in the following
illustration. As soon as possible, have your
dealer or a qualified service technician check
the lug nuts for proper torque specifications.
% [ER16100( ALL)12/95]
quarter page art:0010350-A
The lug nuts on the wheel
*
[ER16200(MBC )03/96]
7. Place any wheel covers and ornaments in the
trunk.
*
[ER16300(MBC )03/96]
8. Put the tire, jack, and wrench away. Make
sure the jack is securely fastened so it does
not rattle when you drive.
*
[ER16400(MBC )03/96]
9. Unblock the wheels.
% [ER16600(MBC )12/95]
Aluminum Road Wheel Ornaments
(If equipped)
[ER16700(MBC )12/95]
To remove the ornament, stick the tapered end
of the jack handle between the ornament and
wheel and pry off the ornament.
[ER16800(MBC )12/95]
To replace the ornament, stick one side of the
ornament into the center of the wheel and strike
the other side with the palm of your hand.
[ER18300(M GV)12/95]
Remove the base wheelcover from the wheel
using the flanged end of the wheel nut wrench
by inserting the handle and then prying against
the inner wheelcover flange.
[ER18301(MBC )02/97]
Remove the exposed lug nut wheel cover by
using the wheel lug nut wrench to unscrew each
lug nut cover counter-clockwise.
File:10rcerm.ex
Update:Tue Mar 4 10:01:28 1997

199 [ER18400(M GV)12/95]
Install the wheelcover on the wheel with the
valve stem in the wheel matching the hole in the
wheelcover. Push by hand on the outside edges
of the wheelcover until it is snapped firmly in
place on the wheel.
[ER18302(MBC )02/97]
Install the exposed lug nut wheel cover onto the
wheel with the valve stem in the wheel
matching the hole in the wheel cover. Push the
ornamental lug nut covers over the lug nuts by
hand, and secure the wheel cover by tightening
the lug nut covers clockwise with the wheel lug
nut wrench.
%*
[ER18800(MBC )01/96]
Anti-Theft Wheel Lug Nuts (If equipped)
[ER19000(M )12/95]
The aluminum wheels on Mustang 4.6L engine
vehicles are secured with locking lug nuts. One
of the lug nuts on each wheel must be removed
and installed with a special key. The key and a
registration card are attached to the lug wrench
and stored with the spare tire. If you lose the
key, send the registration card to the
manufacturer (not to the dealer) to get a
replacement key.
*
[ER19100(MBC )12/95]
NOTE: If entire lug wrench/lug nut key
assembly is lost, see your nearest Ford
or Lincoln-Mercury dealer who has
access to a master set of keys.
*
[ER19200(MBC )12/95]
NOTE: DO NOT USE A POWER IMPACT
WRENCH ON THE LUG NUT KEY.
[ER19300(MBC )12/95]
quarter page art:0010357-B
The anti-theft lug nut and key
File:10rcerm.ex
Update:Tue Mar 4 10:01:28 1997

200
*
[ER19400(MBC )12/95]
Removing the anti-theft lug nut
*
[ER19500(MBC )02/96]
Insert the key over the locking lug nut. Make
sure that you hold the key square to the lug nut.
If you hold the key on an angle, you may
damage the key and the lug nut.
*
[ER19600(MBC )12/95]
Place the lug nut wrench over the lug nut key
and apply pressure on the key with the wrench.
Turn the wrench in a counterclockwise direction
to remove the lug nut.
*
[ER19700(MBC )12/95]
Reinstalling the anti-theft lug nut
*
[ER19800(MBC )12/95]
Insert the key over the locking lug nut. Place the
lug nut wrench over the lug nut key and, while
applying pressure on the key, install the lug nut.
%
*
[ER19900( ALL)02/96]
Jump-Starting Your Vehicle
*
[ER19950( ALL)02/96]
Your vehicle's battery may die if you leave the
lights on or any electrical equipment on after
you turn the engine off. If this happens, you
may be able to jump-start your vehicle with a
booster battery.
*
[ER20000( ALL)02/96]
WARNING
The gases around the battery can explode
if exposed to flames, sparks, or lit
cigarettes. An explosion could result in
injury or vehicle damage.
*
[ER20100( ALL)02/96]
WARNING
To protect yourself when charging a
battery, always shield your face and eyes.
Make sure that you can breathe fresh air.
File:10rcerm.ex
Update:Tue Mar 4 10:01:28 1997

201 %
*
[ER20200( ALL)02/96]
WARNING
Applying too much pressure on the ends
when lifting a battery could cause acid to
spill. Lift the battery with a carrier or
with your hands on the opposite corners.
%*
[ER20300( ALL)02/96]
WARNING
Batteries contain sulfuric acid which burns
skin, eyes, and clothing.
*
[ER20400( ALL)02/96]
If the acid touches someone's skin, eyes, or
clothing, immediately flush the area with water
for at least 15 minutes. If someone swallows the
acid, have him or her drink lots of milk or water
first, then Milk of Magnesia, a beaten egg, or
vegetable oil. Call a doctor immediately.
*
[ER20500( ALL)02/96]
To avoid damaging your vehicle or your battery,
and to avoid injury to yourself, follow these
directions for preparing your vehicle to
jump-start and connecting the jumper cables in
the order they are given. If in doubt, call for
road service.
%*
[ER20600( ALL)02/96]
Preparing Your Vehicle
[ER20700( ALL)02/96]
NOTE: also see label on battery.
*
[ER20800( ALL)02/96]
1. Your vehicle has a 12-volt starting system, so
you need to use a 12-volt jumper system.
You will damage your starting motor,
ignition system, and other electrical parts if
you connect them to a 24-volt power supply
(either two 12-volt batteries in series or a
24-volt generator set).
File:10rcerm.ex
Update:Tue Mar 4 10:01:28 1997

202
*
[ER20900( ALL)02/96]
2. Do not disconnect the battery of the disabled
vehicle. You could damage the vehicle's
electrical system.
*
[ER21000( ALL)02/96]
3. Park the booster vehicle close to the hood of
the disabled vehicle.Make sure the vehicles
do not touch each other.Set the parking
brake on both vehicles and stay clear of the
engine cooling fan and other moving parts.
*
[ER21100( ALL)02/96]
4. Check all battery terminals and remove any
excessive corrosion before you attach the
jumper cables.
*
[ER21200( ALL)02/96]
5. Turn on the heater fan in both vehicles.
Turning on the fan helps protect the
electrical system from voltage surges. Turn
off all other switches and lights in both
vehicles to prevent possible damage to either
vehicle's electrical systems.
%*
[ER21300( ALL)02/96]
Connecting the jumper cables
*
[ER21400( ALL)02/96]
1. Connect one end of the first jumper cable to
the positive (+) terminal of the discharged
battery. (You can connect either jumper cable
to the positive (+) terminal, as long as you
use the same cable for both positive
terminals.) Most jumper cables have a red
cable and a black cable. The red cable is
generally used for the positive terminals and
the black for the negative ones.
*
[ER21500( ALL)02/96]
2. Connect the other end of the first cable to
the positive (+) terminal of the booster
battery.
File:10rcerm.ex
Update:Tue Mar 4 10:01:28 1997
