FORD PROBE 1996 2.G Owner's Manual

19 [SR15014(ALL)06/94]
half page art:0032207-D
The location of the air bag and warning labels
*
[SR15070(ALL)05/95]
If a collision occurs, the sensors sense the
severity of the impact and activate the air bags if
necessary. The air bag system is designed to
deploy in frontal and front-angled collisions
more severe than hitting a parked vehicle (of
similar size and weight) head-on at about
28 mph (45 km/h). Because the system senses
the crash severity rather than vehicle speed,
some frontal collisions at speeds above 28 mph
(45 km/h) will not inflate the air bag.
File:prsrp.ex
Update:Fri Jun 23 19:39:12 1995

20
*
[SR15089(ALL)05/95]
When the sensors activate the system, the air
bags inflate rapidly, filling with non-toxic
nitrogen gas in a fraction of a second.
Immediately after inflation, the air bags deflate
by releasing the nitrogen gas through vent holes.
The whole process takes place in a matter of
seconds.
*
[SR15098(ALL)05/95]
RWARNING
Air bag system components get hot after
inflation. Do not touch them after
inflation.
[SR15100(ALL)04/93]
half page art:0032152-A
Inflated driver-side air bag
File:prsrp.ex
Update:Fri Jun 23 19:39:12 1995

21 [SR15110(ALL)05/95]
half page art:0032153-A
Inflated passenger-side air bag
*
[SR15115(ALL)05/95]
RWARNING
If the air bag is inflated, THE AIR BAG
WILL NOT FUNCTION AGAIN AND
MUST BE REPLACED IMMEDIATELY. If
the air bag is not replaced, the unrepaired
area will increase the risk of injury in a
collision.
[SR15120(ALL)05/95]
To ensure that the air bag system will operate as
intended in a crash, the system is equipped with
a diagnostic module. The diagnostic module
monitors its own circuits, the air bag electrical
system, the air bag readiness light, the air bag
power, and the air bag inflators.
File:prsrp.ex
Update:Fri Jun 23 19:39:12 1995

22 %
*
[SR15127(ALL)05/95]
The air bag system uses a readiness light on the
instrument cluster and a tone to indicate the
condition of the system. When you turn the
ignition key to the ON position, this light will
illuminate for approximately six (6) seconds and
then turn off. This indicates that the system is
operating normally. NOTE: Maintenance of the
air bag system is not required.
%*
[SR15129(ALL)05/95]
A problem with the system is indicated by one
or more of the following:
*
[SR15131(ALL)05/95]
q
the readiness light will either flash or stay lit,
*
[SR15133(ALL)05/95]
q
or it will not light immediately after ignition
is turned on,
*
[SR15135(ALL)05/95]
q
or a group of five beeps will be heard. The
tone pattern will repeat periodically until the
problem and light are repaired.
*
[SR15139(ALL)05/95]
If any of these things happen, have the air bag
system serviced at your Ford or Lincoln-Mercury
dealer immediately. Unless serviced, the air bag
supplemental restraint system may not function
properly in the event of a collision.
*
[SR15145(ALL)05/95]
RWARNING
Do not attempt to service, repair, or
modify the Air Bag Supplemental
Restraint System or its fuses. See your
Ford or Lincoln-Mercury dealer.
%*
[SR15150(ALL)05/95]
Disposal of air bags or air bag equipped
vehicles
*
[SR15160(ALL)05/95]
For disposal of air bags or air bag equipped
vehicles, see your local Ford or Lincoln-Mercury
dealer. Air bagsMUSTbe disposed of by
qualified personnel.
File:prsrp.ex
Update:Fri Jun 23 19:39:12 1995

23
%*
[SR15300(ALL)05/95]
Safety Restraints for Children
*
[SR15325(ALL)02/95]
In the U.S. and Canada, you are required by law
to use safety restraints for children. If small
children ride in your vehicle Ð this generally
includes children who are four years old or
younger and who weigh 40 pounds (18 kg) or
less Ð you must put them in safety seats that
are made specially for children. Safety belts
alone do not provide maximum protection for
these children. Check your local and state laws
for specific requirements.
*
[SR15350(ALL)05/95]
RWARNING
Never let a passenger hold a child on his
or her lap while the vehicle is moving.
The passenger cannot protect the child
from injury in a collision.
*
[SR15360(ALL)05/95]
RWARNING
To prevent the risk of injury, make sure
children sit where they can be properly
restrained.
*
[SR15375(ALL)05/95]
RWARNING
Passengers should not be allowed to ride
in the cargo area. Persons not riding in a
seat with a fastened seat belt are much
more likely to suffer serious injury in a
collision. Cargo should always be secured
to prevent it from shifting and causing
damage to the vehicle or harm to
passengers.
File:prsrp.ex
Update:Fri Jun 23 19:39:12 1995

24
*
[SR15500(ALL)05/95]
When possible, put children in the rear seat of
your vehicle. Accident statistics suggest that
children are safer when properly restrained in
the rear seating positions than in the front
seating positions.
*
[SR15600(ALL)05/95]
RWARNING
Carefully follow all of the manufacturer's
instructions included with the safety seat
you put in your vehicle. If you do not
install and use the safety seat properly,
the child may be injured in a sudden stop
or collision.
*
[SR15700(ALL)05/95]
RWARNING
Safety belts and seats can become hot in a
vehicle that has been closed up in sunny
weather; they could burn a small child.
Check seat covers and buckles before you
place a child anywhere near them.
*
[SR15800(ALL)05/95]
RWARNING
Never leave a child unattended in your
vehicle.
File:prsrp.ex
Update:Fri Jun 23 19:39:12 1995

25
*
[SR16500(ALL)01/95]
Safety Seats for Children
*
[SR16600(ALL)01/95]
Use a safety seat that is recommended for the
size and weight of the child. Always follow the
safety seat manufacturer's instructions when
installing and using the safety seat.
*
[SR16620(ALL)02/95]
Ford recommends the use of a child safety seat
having a top tether strap. Install the child safety
seat in a seating position which is capable of
providing a tether anchorage. For more
information on top tether straps seeAttaching
Safety Seats With Tether Strapsin this chapter.
*
[SR16640(ALL)05/95]
When installing a child safety seat, be sure to
use the correct safety belt buckle for that seating
position, and make sure the tongue is securely
fastened in the buckle.
*
[SR16670(ALL)05/95]
Your vehicle is equipped with a right front
passenger air bag. Air bags deploy with great
force, faster than the blink of an eye. Front
passengers, especially children and small adults,
must never sit on the front edge of the seat,
stand near the glove compartment of the
instrument panel, or lean over near the air bag
cover when the vehicle is moving. All occupants
should sit with their backs against the seatback,
move the seat to the most rearward position if
possible and use the safety belts. Children
weighing less than 40 lbs. (18 kg) always should
use child or infant seats.
File:prsrp.ex
Update:Fri Jun 23 19:39:12 1995

26
*
[SR16685(ALL)05/95]
RWARNING
When using forward-facing child seats
move the passenger seat as far back from
the instrument panel as possible. NEVER
SECURE REAR-FACING INFANT SEATS
IN THE FRONT SEAT.
*
[SR16687(ALL)05/95]
THE FORCE OF THE RAPIDLY INFLATING
PASSENGER AIR BAG COULD PUSH THE TOP
OF THE REAR-FACING SEAT AGAINST THE
VEHICLE SEATBACK, ARMRESTS OR
CONSOLE. REAR-FACING INFANT SEATS
MUST ALWAYS BE SECURED IN THE REAR
SEAT.
*
[SR16749(ALL)05/95]
All child restraint systems are designed to be
secured in vehicle seats by lap belts or by the
lap portion of a lap-shoulder belt.
*
[SR16750(ALL)05/95]
RWARNING
If you do not properly secure the safety
seat, the child occupying the seat may be
injured during a collision or sudden stop.
An unsecured safety seat could also injure
other passengers.
*
[SR16800(ALL)05/95]
RWARNING
Carefully follow all of the manufacturer's
instructions included with the safety seat
you put in your vehicle. If you do not
install and use the safety seat properly,
the child may be injured in a sudden stop
or collision.
File:prsrp.ex
Update:Fri Jun 23 19:39:12 1995

27 [SR16860(ALL)05/95]
Installing Child Safety Seats
*
[SR16870(ALL)05/95]
Your vehicle is equipped with a dual locking
mode retractor on the shoulder belt portoin of
the front passenger seat and both rear seats. The
automatic locking modemust be usedwhen
installing a child seat or infant carrier in the
front passenger seat or rear seats.
[SR16875(ALL)05/95]
RWARNING
Never install a rear-facing child seat or
infant carrier in the right front passenger
seat.
*
[SR16880(ALL)03/94]
If you install a child safety seat or infant carrier
in any of the seating positions, you must follow
the proper procedures:
*
[SR16890(ALL)05/95]
1. Position the child seat or infant carrier on
the passenger seat of the vehicle.
[SR16910(ALL)05/95]
2. Pull down on the shoulder belt, then grasp
the shoulder belt and lap belt together.
File:prsrp.ex
Update:Fri Jun 23 19:39:12 1995

28 [SR16912(ALL)05/95]
half page art:0032385-BGrasping lap and shoulder belt together
[SR16915(ALL)05/95]
3. While holding the shoulder and lap belt
portions together, route the tongue through
the child seat according to the child seat
manufacturer's instructions. Be sure the belt
webbing is not twisted.
