FORD PROBE 1996 2.G Workshop Manual

49
*
[ST12000(ALL)05/95]
RWARNING
If you smell exhaust fumes inside your
vehicle, have your dealer inspect your
vehicle immediately. Do not drive if you
smell exhaust fumes.
*
[ST12100(ALL)01/95]
Have the exhaust and body ventilation systems
checked whenever:
*
[ST12200(ALL)02/95]
q
your vehicle is raised for service
*
[ST12300(ALL)02/95]
q
the sound of the exhaust system changes
*
[ST12400(ALL)01/95]
q
your vehicle has been damaged in a collision
*
[ST12500(ALL)01/95]
Improve your ventilation by keeping all air inlet
vents clear of snow, leaves, and other debris.
*
[ST12600(ALL)03/95]
If the engine is idling while you are stopped in
an open area for long periods of time, open the
windows at least one inch (2.5 cm). Also, adjust
the heating or air conditioning to bring in
outside air.
[ST12800(ALL)08/91]
q
If you are using the heater, set the fan speed
on MEDIUM or HIGH with the function
selector control on VENT.
[ST13000(ALL)11/91]
q
If you want to use the air conditioner, set the
function selector control in the NORM A/C
position which brings in fresh air.
File:prstp.ex
Update:Fri Jun 23 19:38:23 1995

51
Warning Lights and
Gauges
*
[LG00600(ALL)01/95]
The instrument panel (dashboard) on your
vehicle is divided into several different sections.
The illustrations on the following pages show
the major parts of the instrument panel that are
described in this chapter. Some items shown
may not be on all vehicles.
*
[LG00700(ALL)06/93]
In your vehicle, the warning lights and gauges
are grouped together on the instrument panel.
We call this grouping a cluster.
[LG00750(ALL)03/95]
To clean the lenses on your instrument panel,
use Ford Glass Cleaner and a soft cloth. Never
use paper towels or abrasive cleaners; they can
scratch the lenses.
*
[LG00800(ALL)01/95]
Your vehicle has a mechanical cluster.
File:prlgp.ex
Update:Fri Jun 23 19:38:06 1995

52
%*
[LG01690(ALL)06/94]
The Mechanical Cluster
[LG01700(ALL)01/92]
full page art:0032080-B
Mechanical cluster
File:prlgp.ex
Update:Fri Jun 23 19:38:06 1995

53 [LG01750(ALL)05/95]
full page art:0032045-I
Warning light locations on the mechanical cluster
File:prlgp.ex
Update:Fri Jun 23 19:38:06 1995

54 [LG01775(ALL)04/93]The mechanical cluster on the Probe GT model is
similar to the one shown. The two exceptions
are: the speedometer on the GT model shows
140 mph (225 km/h) and it has a 7,000 rpm
red-line tachometer.
[LG01780(ALL)01/92]
one third page art:0032087-B
GT model speedometer and tachometer
[LG01800(ALL)01/94]
The following warning lights and gauges are on
the cluster. All of the warning lights and gauges
alert you to possible problems with your vehicle.
The following sections detail what each of these
indicators means.
*
[LG01950(ALL)01/95]
Indicator Lights and Chimes
%*
[LG01975(ALL)05/95]
Safety Belt Warning Light and Chime
[LG01980(ALL)03/94]
This warning light and chime remind you to
fasten your safety belt. If you do not fasten your
safety belt before the ignition is turned to ON,
the chime will sound for 4 to 8 seconds and the
warning light will illuminate for 1 to 2 minutes,
or until the safety belt is fastened. If you fasten
the safety belt before the ignition is turned to
ON, neither the light nor chime will activate.
File:prlgp.ex
Update:Fri Jun 23 19:38:06 1995

55 [LG01995(ALL)01/92]
one inch art:0032097-A
Safety belt light
*
[LG02000(ALL)01/95]
Air Bag Readiness Light
*
[LG02050(ALL)06/93]
This light illuminates for six seconds when the
ignition is turned to the ON position. If the light
fails to illuminate, continues to flash, remains on,
or if a series of five beeps is heard, have the
system serviced as soon as possible.
[LG02100(ALL)01/92]
one inch art:0032051-A
Air bag readiness light
*
[LG02120(ALL)05/95]
RWARNING
If any of these things happen, even
intermittently, have the air bag system
serviced at your Ford or Lincoln-Mercury
dealer immediately.
*
[LG02200(ALL)03/95]
Brake System Warning Light
[LG02300(ALL)02/91]
Your vehicle has a divided brake system. If one
part isn't working, the other part can still work
and stop you. For good braking, though, you
need both systems working well. If the warning
light goes on, there could be a problem. Have
your brake system inspected right away.
File:prlgp.ex
Update:Fri Jun 23 19:38:06 1995

56 [LG02350(ALL)01/94]This light should come on as you start the
vehicle. If it doesn't come on then, have it fixed
so it will be ready to warn you if there's a
problem.
[LG02550(ALL)06/93]
one inch art:0030319-E
Brake system and parking brake light
[LG02600(ALL)01/93]
This light comes on briefly when you turn the
ignition key to START. It normally goes off
shortly after the engine starts and you release
the parking brake, but it may stay on for up to
60 seconds. If the light stays on for longer than
60 seconds or comes on after you have fully
released the parking brake, have the hydraulic
brake system serviced.
*
[LG02650(ALL)02/94]
This light will also come on if the parking brake
does not release fully. If it does stay onafterthe
parking brake is fully released, it means there
may be a brake problem. Pull off the road and
stop carefully. You may notice that the pedal is
harder to push, the pedal may go closer to the
floor, or it may take longer to stop the vehicle.
Try the brakes again after you have stopped.
*
[LG02700(ALL)05/95]
RWARNING
The BRAKE light indicates that the brakes
may not be working properly. Have the
brakes checked immediately.
File:prlgp.ex
Update:Fri Jun 23 19:38:06 1995

57 %
*
[LG02750(ALL)02/95]
Anti-Lock Brake System Warning Light
[LG02760(ALL)01/94]
When the ignition switch is turned to the ON
position, the anti-lock brake system warning
light will come on. When the engine is started,
the anti-lock brake system control unit will
determine if all components of the system are
operating correctly. The warning light could
remain on for two to four seconds.
[LG02771(ALL)06/95]
one inch art:0032359-C
The anti-lock brake system warning light
*
[LG02780(ALL)05/95]
RWARNING
If the anti-lock brake system warning
light remains on or comes on while
driving, have the braking system checked
by a qualified service technician as soon
as possible.
*
[LG02785(ALL)06/95]
NOTE: If a fault occurs in the anti-lock
system, and the brake warning light is
not lit, the anti-lock system is disabled
but normal brake function remains
operational.
*
[LG02790(ALL)09/93]
NOTE: If your vehicle must be jump-started
because of a low battery, the anti-lock
brake system warning light could
remain on. This is due to low battery
voltage and does not indicate a
malfunction in the system. Under these
circumstances, you should drive your
vehicle only after the battery has had
time to charge and the light has gone
out.
File:prlgp.ex
Update:Fri Jun 23 19:38:06 1995

58 [LG04360(ALL)04/95]The Low Fuel Light
[LG04375(ALL)08/91]
This light comes on when fuel level in your tank
has reached approximately 2-3 gallons (7-10
liters).
[LG04395(ALL)01/92]
one inch art:0032048-A
Low fuel light
*
[LG04500(ALL)01/95]
High Beam Light
*
[LG04600(ALL)03/95]
This light comes on when the headlamps are
turned to high beam or when you flash the
lights.
*
[LG04700(ALL)01/92]
one inch art:0030174-A
High beam light
%*
[LG05300(ALL)03/95]
Check Engine Warning Light
*
[LG05400(ALL)05/95]
This light comes on when the electronic engine
control system is not working properly. This is
the computer system that controls the operating
conditions of the engine.
*
[LG05450(ALL)09/93]
one inch art:0030175-B
Check engine warning light
File:prlgp.ex
Update:Fri Jun 23 19:38:06 1995

59
*
[LG05600(ALL)05/95]
This light comes on briefly when you turn the
ignition to the ON position, but should turn off
when the engine starts. If the light does not
come on when you turn the ignition to the ON
position or if it comes on and stays on when
you are driving, have your vehicle serviced as
soon as possible. This indicates a possible
problem with one of the engine's emission
control systems.You do not need to have your
vehicle towed in.
*
[LG05800(ALL)05/95]
If the light turns on and off briefly while you
are driving, it means that the condition is no
longer present.
[LG05885(ALL)06/93]
O/D OFF Light (If equipped)
[LG05886(ALL)05/95]
This light tells you that the overdrive off (O/D
OFF) button on the shift selector has been
pushed. When the light is on, the transaxle will
not shift into overdrive. Depressing the button
on the shift selector again will return the vehicle
to ªoverdrive onº mode. The transaxle will be in
the ªoverdrive onº mode when the vehicle is
started even if the O/D OFF mode was selected
when the vehicle was last shut off.
[LG05888(ALL)06/93]
If the light does not come on when the O/D
OFF button is pressed, or if the light flashes
when you are driving, have your vehicle
serviced at the first opportunity. If this condition
persists, damage could occur to the transaxle.
[LG05889(ALL)01/94]
one inch art:0032053-A
Overdrive OFF light
File:prlgp.ex
Update:Fri Jun 23 19:38:06 1995
