70 [IP07550(ALL)01/95]Because MAX A/C uses recirculated air, MAX is
usually more efficient than NORM A/C. You
can switch to outside air (NORM A/C) at any
time, especially after the vehicle has cooled
down.
[IP07560(ALL)11/91]
You will notice a slight odor when using the
MAX A/C position. This is normal. If the odor
becomes annoying, switch the function selector
to NORM A/C.
[IP07575(ALL)08/91]
To provide the most quiet operation when using
MAX A/C, reduce the fan speed after a
comfortable temperature has been reached.
[IP07800(ALL)04/95]
NORM A/C
[IP08025(ALL)01/94]
When maximum air conditioning is not needed,
you can use the NORM A/C position to cool
your vehicle with outside air. Cooling your
vehicle this way brings in outside air and is
quieter, but it is less efficient.
[IP08050(ALL)05/95]
To cool your vehicle using outside air:
[IP08075(ALL)08/91]
1. Turn the function selector control to NORM
A/C.
[IP08150(ALL)08/91]
2. Turn the temperature control all the way to
left to the blue (cool) area.
*
[IP08175(ALL)10/93]
3. Set the fan at the desired speed.
[IP08400(ALL)01/95]
In mild weather, setting the function selector
control in the VENT position will add cool air to
your vehicle without using the air conditioning.
You will get better fuel economy without using
the air conditioning.
File:pripp.ex
Update:Fri Jun 23 19:37:35 1995

71
*
[IP13850(ALL)02/91]
Engine Idle Speed Control System
*
[IP13875(ALL)02/91]
Genuine Ford air conditioning (either
factory-installed or dealer-installed) has an
engine idle speed control system that
compensates for engine speed loss that may
occur when the air conditioning compressor is
running. This idle speed control holds the engine
idle essentially constant, regardless of whether
the air conditioning system is on or off.
[IP13890(ALL)01/95]
NOTE: Whenever service to the air
conditioning system is required, make
sure the service facility uses a
refrigerant recycling system. These
systems will capture the refrigerant for
reuse. Releasing certain refrigerants
into the atmosphere is hazardous to the
environment.
*
[IP13900(ALL)12/93]
Rear Window Defroster (If equipped)
(Standard in Canada)
[IP14000(ALL)06/94]
quarter page art:0032068-D
Rear window defroster button
[IP14200(ALL)01/95]
The defroster for the rear window clears frost,
fog, or thin ice from both the inside and outside
of the rear window. The rear window defroster
button is located on the lower right of the
instrument panel below the climate control
panel. This button is also used to activate your
heated power mirrors (if equipped).
File:pripp.ex
Update:Fri Jun 23 19:37:35 1995

72
*
[IP14300(ALL)02/95]
To defrost the rear window:
*
[IP14400(ALL)02/95]
1. Clear any snow from the rear window.
*
[IP14500(ALL)09/93]
2. Get in your vehicle and start the engine.
[IP14600(ALL)03/91]
3. Press the rear defrost button. The indicator
light turns on.
[IP14800(ALL)01/92]
The defroster turns off automatically after 15 to
25 minutes. If the window is not clear, turn on
the defroster again. It will also automatically
shut off any time the engine is shut off.
%*
[IP14900(ALL)03/94]
NOTE: Never use sharp instruments or
window cleaners with abrasives to
clean the inside of your rear window.
If you do, you may damage the heating
elements that are bonded to the inside
of the rear window and cause damage
to the rear window defroster.
*
[IP17700(ALL)01/92]
Interior Lights
*
[IP20500(ALL)01/95]
Lighting Up the Interior and Instrument
Panel
*
[IP20600(ALL)01/92]
With the parking lamps or headlamps on, the
brightness of the instrument panel lighting can
be adjusted.
*
[IP20700(ALL)09/93]
To brighten or dim the instrument panel
lighting, rotate the dimmer control thumbwheel
as desired.
[IP20800(ALL)01/94]
quarter page art:0030050-B
Dimmer control thumbwheel
File:pripp.ex
Update:Fri Jun 23 19:37:35 1995

73 [IP20900(ALL)01/94]
The dimmer control thumbwheel is located to
the left of the steering wheel on the instrument
panel.
[IP21800(ALL)02/91]
Dome Lamp
[IP22950(ALL)05/95]
The dome lamp illuminates whenever one of the
front doors is opened and turns off
automatically when the doors are closed. You
may turn the dome lamp on and off while the
doors are closed by using the ON/OFF switch
located on the interior/map lamp control panel.
[IP23100(ALL)05/95]
half page art:0030286-L
Interior/map lamp control panel
[IP23125(ALL)04/95]
Map lamps (if equipped)
[IP23150(ALL)01/95]
The map lamps can be turned on by using the
interior/map lamp control panel located between
the sun visors.
[IP23200(ALL)01/95]
There are two map lamps, one for the driver
and one for the passenger. To turn on the map
lamp, push the button that is next to the lamp.
File:pripp.ex
Update:Fri Jun 23 19:37:35 1995

74Push the buttons again to turn the map lamps
off.
[IP23210(ALL)05/95]
half page art:0032392-A[IP23225(ALL)04/95]
Cleaning the Interior Lamps
*
[IP23250(ALL)04/95]
Your interior dome lamps and map lamps are
plastic and should be cleaned with a mild
detergent diluted in water. Rinse them with clear
water.
*
[IP23300(ALL)04/95]
Fog Lamps (If equipped)
[IP23400(ALL)05/93]
The fog lamps only operate when the headlamps
are on low beam. To activate fog lamps, push
the button on the control panel below the
climate controls. An indicator light on the button
will illuminate. Push the button again to turn
the fog lamps off.
File:pripp.ex
Update:Fri Jun 23 19:37:35 1995

75 [IP23500(ALL)05/95]
quarter page art:0032079-E
Fog lamp button
*
[IP24200(ALL)05/95]
Radio
*
[IP24300(ALL)04/95]
For information about the radio in your vehicle,
refer to theFord Electronic Sound Systems
Operating Guidein this Owner Guide.
*
[IP24400(ALL)04/95]
Clock Controls on Electronic
Radios
*
[IP24500(ALL)05/94]
The electronic radios have a built-in clock. For
complete operating instructions, refer to theFord
Electronic Sound Systems Operating Guidein this
owner guide.
*
[IP24550(ALL)05/92]
Radio Antenna
[IP24600(ALL)05/92]
The radio antenna is mounted on the rear
passenger side quarter panel of the vehicle. It is
a fixed mast antenna and cannot be retracted.
File:pripp.ex
Update:Fri Jun 23 19:37:35 1995

77
Steering Column Controls
*
[SC00300(ALL)01/95]
The controls on the steering column and wheel
are designed to give you easy access to the
controls while you are driving.
*
[SC00400(ALL)01/95]
The Turn Signal Lever
*
[SC00500(ALL)01/95]
You can use the turn signal lever on the left side
of the steering column to:
*
[SC00600(ALL)08/91]
q
operate the headlamps and parking lamps
*
[SC00700(ALL)03/95]
q
operate the turn signals and cornering lamps
*
[SC00800(ALL)01/95]
q
turn the high beams on/off
*
[SC00900(ALL)05/95]
q
flash the lamps
*
[SC00950(ALL)08/91]
Headlamps and Parking Lamps
*
[SC00975(ALL)01/92]
To turn the parking lamps or headlamps on,
twist the knob at the end of the turn signal
lever.
[SC01000(ALL)05/95]
FIRST STOP Ð Turning the knob to the first
stop (g) will turn on the the license plate
lamps, parking lamps, side marker lamps, tail
lamps and instrument panel lamps.
[SC01050(ALL)05/95]
SECOND STOP Ð Turning the knob to the
second stop (B) will turn on the headlamps,
license plate lamps, parking lamps, side marker
lamps, tail lamps and instrument panel lamps.
File:prscp.ex
Update:Fri Jun 23 19:37:07 1995

78 [SC01105(ALL)08/91]
quarter page art:0032032-AHeadlamp control
*
[SC01110(ALL)01/95]
Daytime Running Light System
*
[SC01115(ALL)03/95]
(Canadian vehicles only)
*
[SC01120(ALL)05/95]
In Canada, certain regulations require vehicles to
be driven with lights illuminated during daytime
operation. It is for that reason that the daytime
running lights are automatically illuminated
when the ignition switch is turned to the ON
position. The daytime running lights are
switched off under the following conditions:
*
[SC01130(ALL)05/95]
q
when the headlamps are switched on
*
[SC01140(ALL)01/92]
q
when the parking brake is applied
*
[SC01150(ALL)01/92]
q
when the flash-to-pass system is used
*
[SC01175(ALL)05/95]
RWARNING
The Daytime Running Light (DRL) system
will not illuminate the tail lamps and
parking lamps. Turn on your headlamps
at dusk. Failure to do so may result in a
collision.
File:prscp.ex
Update:Fri Jun 23 19:37:07 1995

79 [SC01200(ALL)08/91]
Raising the Headlamps Manually
[SC01250(ALL)01/95]
If the power headlamp door system becomes
inoperative, your vehicle has a manual retractor
system that allows you to raise the headlamps
manually (the headlamps will not turn on). The
retractors are located under the hood and behind
each headlamp. Remove the cap and turn the
knob. Each headlamp must be raised separately.
[SC01255(ALL)02/92]
Before using the manual retractors to raise your
headlamps, the RETRA fuse must be removed.
[SC01260(ALL)03/94]
Open the main fuse panel. Refer to the
underhood fuse panel inServicing Your Probe
later in this owner guide. Pull the RETRA (20A)
fuse straight out.
[SC01270(ALL)02/92]
Inspect the removed fuse. If it is blown, replace
it with a new one of the same rating. If it isn't
blown or if a new fuse does not solve the
problem, remove it and operate the headlamp
manually.
[SC01280(ALL)05/95]
RWARNING
Always remove the RETRA (20A) fuse
before manually operating a headlamp
retractor or attempting to remove anything
from the headlamp. Failure to remove the
RETRA fuse could cause injury to a hand
or fingers.
[SC01290(ALL)05/95]
RWARNING
When reinstalling the RETRA fuse, make
sure nothing is near the headlamp
retractor. It may move suddenly while the
fuse is being inserted, causing injury to
hands and fingers.
File:prscp.ex
Update:Fri Jun 23 19:37:07 1995

80 [SC01300(ALL)02/92]
half page art:0032085-BManual headlamp retractors located behind the headlamps
*
[SC02075(ALL)05/95]
High Beams and Flashing the Lamps
*
[SC02080(ALL)05/95]
To turn on the high beams, turn the headlamp
control knob to the headlamp ON position and
push the turn signal lever away from you until
it latches. When the high beams are ON, the
high beam indicator light on the instrument
panel comes on.
*
[SC02085(ALL)05/95]
To turn off the high beams, pull the lever
toward you until it latches. The high beam
indicator light turns off.
