FORD PROBE 1997 2.G Owners Manual

219
quality fuels that optimize the performance of
your vehicle. We recommend the use of
gasolines that meet the AAMA specification if
they are available.
*
[MC32500(ALL)05/96]
It should not be necessary to add any
aftermarket products to your fuel tank if you
continue to use a high-quality fuel.
*
[MC32600(ALL)05/96]
Cleaner Air
*
[MC32700(ALL)05/96]
Ford approves the use of gasolines to improve
air quality, including reformulated gasolines that
contain oxygenates such as a maximum of 10%
ethanol or 15% MTBE. There should be no more
than 5% methanol with cosolvents and additives
to protect the fuel system.
%*
[MC33800(ALL)01/96]
Safety Information Relating to Automotive
Fuels
*
[MC33900(ALL)01/96]
RWARNING
Automotive fuels can cause serious injury
or death if misused or mishandled.
*
[MC34000(ALL)05/96]
q
Turn vehicle off when refueling.
*
[MC34100(ALL)08/95]
q
Do not smoke when refueling. Fuels are
extremely flammable.
*
[MC34200(ALL)08/95]
q
Do not siphon any fuel by mouth.
*
[MC34300(ALL)02/96]
RWARNING
Gasoline or gasoline blended with
methanol can cause blindness and
possible death when swallowed. If any
fuel is swallowed, call a physician or
poison control center immediately.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

220
*
[MC34350(ALL)08/95]
q
Avoid breathing vapors while refueling.
*
[MC34400(ALL)08/95]
q
If fuel is splashed on the skin, wash with
soap and water.
*
[MC34500(ALL)08/95]
q
If fuel is splashed in the eyes, remove contact
lenses (if worn), flush with water for 15
minutes, and seek medical attention.
*
[MC34600(ALL)01/96]
Gasoline and gasoline blends may contain small
amounts of carcinogens, such as benzene.
Long-term exposure to unleaded gasoline vapors
has caused cancer in laboratory animals.
*
[MC34700(ALL)01/96]
If you are taking the medication ªAntabuseº or
other forms of disulfiram for the treatment of
alcoholism, vapor or skin contact with a
gasoline-methanol blend may cause the same
kind of adverse reaction as drinking an alcoholic
beverage. In sensitive individuals, serious
personal injury or sickness could result. Consult
a physician promptly if you experience an
adverse reaction.
%*
[MC34800(ALL)01/96]
Running Out of Fuel
*
[MC34900(ALL)08/95]
NOTE: Avoid running out of fuel because this
situation may have an adverse effect on
modern powertrain components.
*
[MC35000(ALL)01/96]
You may need to crank the engine several times
before the fuel system starts to pump fuel from
the tank to the engine.
%*
[MC35100(ALL)03/96]
Fuel Economy
*
[MC35150(ALL)01/96]
Fuel economy is an estimate of the efficiency of
your vehicle and can be calculated as Miles Per
Gallon (MPG) or Liters Per 100 Kilometers
(L/100K).
*
[MC35200(ALL)01/96]
Do not calculate fuel economy during your
vehicle's break-in period. This would not be an
accurate estimate of how much fuel your vehicle
will normally use.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

221
*
[MC35300(ALL)01/96]
To calculate fuel economy:
*
[MC35400(ALL)01/96]
1. Fill the tank completely and record the
initial odometer reading.
*
[MC35500(ALL)01/96]
2. Every time you buy fuel record the
amount (in gallons or liters) purchased.
*
[MC35600(ALL)01/96]
3. After at least three to five tankfuls, fill the
fuel tank and record the final odometer
reading.
*
[MC35700(ALL)01/96]
4. Use these equations to calculate your fuel
economy:
*
[MC35800(ALL)01/96]
q
English: MPG = (total miles driven)v
(gallons used)
*
[MC35900(ALL)01/96]
q
Metric: L/100k = (liters used)v
(100 kilometers)
*
[MC36000(ALL)01/96]
Comparisons With EPA Estimates
*
[MC36100(ALL)05/96]
EPA fuel economy figures are obtained from
laboratory tests under simulated road conditions
and may not reflect the actual conditions you
experience or your style of driving. The EPA
fuel economy estimate is not a guarantee that
you will achieve the fuel economy shown.
*
[MC36200(ALL)01/96]
The following decrease fuel economy:
*
[MC36300(ALL)01/96]
q
Lack of regular, scheduled maintenance
*
[MC36400(ALL)01/96]
q
Rapid acceleration and excessive speed
*
[MC36500(ALL)01/96]
q
Driving with your foot on the brake
*
[MC36550(ALL)01/96]
q
Sudden stops
*
[MC36600(ALL)01/96]
q
Extended engine idling
*
[MC36660(ALL)01/96]
q
Using speed control in hilly terrain
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

222
*
[MC37000(ALL)01/96]
q
Extended use of the A/C, defroster, rear
window defroster and other accessories
*
[MC37100(ALL)01/96]
q
Underinflated tires
*
[MC37200(ALL)01/96]
q
Heavy loads
*
[MC37300(ALL)01/96]
q
Aftermarket add-ons such as bike, ski or
luggage racks, bug deflectors, etc.
[MC38000(ALL)01/96]
Air Conditioning Refrigerant
[MC38100(ALL)01/96]
Whenever service to the air conditioning system
is required, make sure the service facility uses a
refrigerant recycling system. These systems will
capture the refrigerant for reuse. Releasing
certain refrigerants into the atmosphere can
damage our environment.
%
*
[MC38200(ALL)01/96]
Emission Control System
*
[MC38300(ALL)01/96]
Your vehicle is equipped with a catalytic
converter which enables your vehicle to comply
with applicable exhaust emission requirements.
*
[MC38400(ALL)05/96]
RWARNING
Exhaust leaks may result in the entry of
harmful and potentially lethal fumes into
the passenger compartment. Under
extreme conditions excessive exhaust
temperatures could damage the fuel
system, the interior floor covering, or
other vehicle components, possibly
causing a fire.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

223
*
[MC38500(ALL)01/96]
To make sure that the catalytic converter and the
other emission control parts continue to work
properly:
*
[MC38600(ALL)01/96]
q
Use only unleaded fuel.
*
[MC38700(ALL)01/96]
q
Avoid running out of fuel.
*
[MC38800(ALL)01/96]
q
Do not turn off the ignition while your
vehicle is moving, especially at high speeds.
*
[MC38900(ALL)01/96]
q
Do not push start your vehicle.
*
[MC38950(ALL)03/96]
q
Have the services listed in yourMaintenance
Schedulebooklet performed according to the
specified schedule.
*
[MC39000(ALL)01/96]
RWARNING
Do not park, idle, or drive your vehicle in
dry grass or other dry ground cover. The
emission system heats up the engine
compartment and exhaust system, which
can start a fire.
*
[MC39100(ALL)01/96]
Watch for fluid leaks, strange odors, smoke, loss
of oil pressure, the charge warning light, the
check engine light, or the temperature warning
light. These sometimes indicate that the emission
system is not working properly.
*
[MC39200(ALL)01/96]
Do not make any unauthorized changes to your
vehicle or engine. Changes that cause more
unburned fuel to reach the exhaust system can
increase the temperature of the engine or
exhaust system.
%*
[MC39300(ALL)01/96]
In general, maintenance, replacement, or service
of the emission control devices or systems in
your new Ford Motor Company vehicle or
engine may be performed at your expense by
any automotive repair establishment or
individual using automotive parts equivalent to
those with which your vehicle or engine was
originally equipped.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

224
*
[MC39400(ALL)01/96]
By law, anyone who manufactures, repairs,
services, sells, leases, trades vehicles, or
supervises a fleet of vehicles is not permitted to
intentionally remove an emission control device
or prevent it from working. In some of the
United States and in Canada, vehicle owners
may be liable if their emission control device is
removed or is prevented from working.
*
[MC39500(ALL)08/95]
Never use a metal exhaust collector when you
service your vehicle. If the metal collector
contacts any of your vehicle's plastic trim or
bumper parts they could melt or deform.
*
[MC39600(ALL)01/96]
Do not drive your vehicle if it does not operate
properly. See your dealer if the engine runs on
for more than five seconds after you shut it off
or if it misfires, surges, stalls, or backfires.
%*
[MC39700(ALL)01/96]
Information about your vehicle's emission
control system is on the Vehicle Emission
Control Information decal located on or near the
engine. This decal identifies engine displacement
and gives some tune-up specifications.
%*
[MC39800(ALL)03/96]
How to Prepare Your Vehicle for
Inspection/Maintenance (I/M) Testing
*
[MC39900(ALL)05/96]
In some localities it may become a legal
requirement to pass an
Inspection/Maintenance (I/M) test of the
On-Board Diagnostic (OBD) II system. If the
vehicle's powertrain system or its battery has
just been serviced, the OBD II system is reset to
a not ready for I/M testing condition. To
prepare for I/M testing, the law specifies that
additional mixed city and highway driving is
required to complete the check of the OBD II
system.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

225
*
[MC39910(ALL)03/96]
The driving modes required to reach the ready
condition consist of a minimum of 30 minutes of
city and highway driving as described below.
*
[MC39920(ALL)03/96]
q
20 minutes of driving in stop and go
city-type traffic with at least four idle periods.
*
[MC39930(ALL)03/96]
q
10 minutes of driving on an expressway or
highway
*
[MC39940(ALL)05/96]
Before completing the above driving modes, the
engine must be warmed up and at operating
temperature. Once started, the vehicle must not
be turned off during the above driving modes. If
the vehicle owner is unable to meet the I/M
requirements by using these driving patterns, an
authorized service center can perform a detailed
OBD II drive cycle as it would any other type of
repair work.
%
*
[MC42000(ALL)03/96]
Lights and Bulb Replacement
*
[MC42100(ALL)01/96]
It is a good idea to check the operation of the
following lights frequently:
*
[MC42200(ALL)01/96]
q
headlamps
*
[MC42400(ALL)01/96]
q
tail lamps
*
[MC42500(ALL)01/96]
q
brakelamps
*
[MC42600(ALL)01/96]
q
hazard flasher
*
[MC42700(ALL)01/96]
q
turn signals
*
[MC42800(ALL)01/96]
q
side markers
*
[MC42900(ALL)05/96]
q
license plate lamps
[MC43000(ALL)01/96]
q
fog lamps (GT model)
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

226 %
*
[MC43100(ALL)01/96]
The alignment of your headlamps should be
checked if:
*
[MC43200(ALL)01/96]
q
oncoming motorists frequently signal you to
turn off your vehicle's high beams when you
do not have the high beams on
*
[MC43300(ALL)01/96]
q
the headlamps do not seem to give you
enough light to see clearly at night
*
[MC43400(ALL)01/96]
q
the headlamp beams are pointed substantially
away from a position slightly down and to
the right
%*
[MC43500(ALL)01/96]
Headlamp Bulb
[MC43600(ALL)01/96]
Your vehicle has retractable halogen headlamps.
If you need to replace a headlamp, have it done
by a Ford service technician.
% [MC43700(ALL)04/96]
High-Mount Brakelamp Bulb
[MC43800(ALL)01/96]
To replace the bulb:
[MC43900(ALL)01/96]
1. Remove the two side trim liftgate panels.
[MC44000(ALL)01/96]
2. Remove the liftgate trim clip and the liftgate
trim.
[MC44100(ALL)01/96]
3. Remove the bulb from the socket by pushing
it in and turning it counterclockwise.
[MC44200(ALL)01/96]
4. Install the bulb by pushing straight into the
lamp socket and turning it clockwise until it
locks in place.
[MC44300(ALL)01/96]
5. Replace the liftgate trim and trim clip.
[MC44400(ALL)01/96]
6. Replace the two side trim liftgate panels.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

227 [MC44500(ALL)01/96]
one third page art:0032061-B
High-mount brakelamp
% [MC46000(ALL)01/96]
Rear Lamp Bulbs
[MC46100(ALL)01/96]
To replace a bulb:
[MC46200(ALL)01/96]
1. Remove the attaching screw and the rear
lens cover.
[MC46300(ALL)01/96]
one third page art:0032120-A
Removing the attaching screw and lens
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

228 [MC46400(ALL)01/96]2. Partially remove the rear lens by pulling the
lock tabs out of the slots.
[MC46500(ALL)01/96]
half page art:0032121-C
Pulling out the lock tabs
[MC46600(ALL)01/96]
3. Turn the socket counterclockwise to remove
it from the lens.
[MC46700(ALL)01/96]
4. Remove the bulb from the socket by pushing
it in and turning it counterclockwise.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996
