Interior Lights
%*
[CF10300(ALL)01/96]
Lighting Up the Interior and Instrument
Panel
*
[CF10400(ALL)01/96]
With the parking lamps or headlamps on, the
brightness of the instrument panel lighting can
be adjusted.
*
[CF10500(ALL)01/96]
To brighten or dim the instrument panel
lighting, rotate the dimmer control thumbwheel
as desired.
[CF10600(ALL)01/96]
quarter page art:0030050-B
Dimmer control thumbwheel
[CF10700(ALL)01/96]
The dimmer control thumbwheel is located to
the left of the steering wheel on the instrument
panel.
[CF10800(ALL)01/96]
Dome Lamp
[CF10900(ALL)01/96]
The dome lamp illuminates whenever one of the
front doors is opened and turns off
automatically when the doors are closed. You
may turn the dome lamp on and off while the
doors are closed by using the ON/OFF switch
located on the interior/map lamp control panel.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
Page 62 of 288
59 [CF11000(ALL)01/96]
half page art:0030286-L
Interior/map lamp control panel
[CF11100(ALL)01/96]
Map lamps (if equipped)
[CF11200(ALL)01/96]
The map lamps can be turned on by using the
interior/map lamp control panel located between
the sun visors.
[CF11300(ALL)01/96]
There are two map lamps, one for the driver
and one for the passenger. To turn on the map
lamp, push the button that is next to the lamp.
Push the buttons again to turn the map lamps
off.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
Page 63 of 288
60 [CF11400(ALL)05/96]
half page art:0032392-A
*
[CF11800(ALL)01/96]
Radio
*
[CF11900(ALL)01/96]
For information about the radio in your vehicle,
refer to theElectronic Sound Systemschapter in
this Owner Guide.
*
[CF12000(ALL)01/96]
Clock Controls on Electronic
Radios
*
[CF12100(ALL)01/96]
The electronic radios have a built-in clock. For
complete operating instructions, refer to the
Electronic Sound Systemschapter in this Owner
Guide.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
Page 64 of 288
61
*
[CF15100(ALL)01/96]
Ignition
%*
[CF15200(ALL)01/96]
Understanding the Positions of the Ignition
[CF15300(ALL)01/96]
one third page art:0032054-A
Ignition lock cylinder
*
[CF15400(ALL)01/96]
LOCK locks the steering wheel. It also locks the
gearshift lever in P (Park) (automatic transaxle).
*
[CF15500(ALL)01/96]
LOCK is the only position that allows you to
remove the key. The LOCK feature helps to
protect your vehicle from theft.
[CF15600(ALL)01/96]
To remove the key if you have a manual
transaxle, push the key in while turning it to the
LOCK position.
*
[CF15700(ALL)01/96]
If your key is stuck in the LOCK position and
will not turn, move your steering wheel left or
right until the key turns freely.
[CF15800(ALL)01/96]
ACC (Accessory) allows some of your vehicle's
electrical accessories to operate while the engine
is not running.
*
[CF15900(ALL)01/96]
ON allows you to test your vehicle's warning
lights (except the brake system warning light) to
make sure they work before you start the
engine. The key returns to the ON position once
the engine is started and remains in this position
while the engine runs.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
Page 65 of 288
62
*
[CF16000(ALL)01/96]
START cranks the engine. Release the key once
the engine starts so that you do not damage the
starter. The key should return to ON when you
release it. The START position also allows you
to test the brake warning light.
%
*
[CF16010(ALL)02/96]
The Turn Signal Lever
*
[CF16020(ALL)02/96]
You can use the turn signal lever on the left side
of the steering column to:
*
[CF16030(ALL)02/96]
q
operate the headlamps and parking lamps
*
[CF16040(ALL)02/96]
q
operate the turn signals and cornering lamps
*
[CF16050(ALL)03/96]
q
turn the high beams on/off
*
[CF16060(ALL)03/96]
q
flash the lamps
*
[CF16070(ALL)02/96]
Headlamps and Parking Lamps
*
[CF16080(ALL)02/96]
To turn the parking lamps or headlamps on,
twist the knob at the end of the turn signal
lever.
[CF16100(ALL)01/96]
FIRST STOP Ð Turning the knob to the first
stop (g) will turn on the the license plate
lamps, parking lamps, side marker lamps, tail
lamps and instrument panel lamps.
[CF16200(ALL)03/96]
SECOND STOP Ð Turning the knob to the
second stop (B) will turn on the headlamps,
license plate lamps, parking lamps, side marker
lamps, tail lamps, and instrument panel lamps.
[CF16300(ALL)01/96]
quarter page art:0032032-A
Headlamp control
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
Page 66 of 288
63
WARNING
TheDaytim eRunnin gLigh t(DRL )system
Page 67 of 288
64
WARNING
Alwaysremov eth eRETR A(20A )fuse
WARNING
Whe nreinstallin gtheRETR Afuse ,make
Page 68 of 288
65 [CF17800(ALL)01/96]
half page art:0032085-B
Manual headlamp retractors located behind the headlamps
*
[CF17900(ALL)08/95]
High Beams and Flashing the Lamps
*
[CF18000(ALL)01/96]
To turn on the high beams, turn the headlamp
control knob to the headlamp ON position and
push the turn signal lever away from you until
it latches. When the high beams are ON, the
high beam indicator light on the instrument
panel comes on.
*
[CF18100(ALL)01/96]
To turn off the high beams, pull the lever
toward you until it latches. The high beam
indicator light turns off.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
Page 69 of 288
66 %
*
[CF18200(ALL)01/96]
Flashing the Lights
*
[CF18300(ALL)01/96]
To flash the headlamps, pull the lever toward
you for a moment and then release it. The
headlamps will flash whether the headlamp
knob is in the on or off position.
[CF18400(ALL)01/96]
quarter page art:0032034-A
Highbeam and flash-to-pass operation
[CF18500(ALL)01/96]
If the headlamps are retracted when you pull
the lever toward you, they will pop up and
flash.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
Page 70 of 288
67 %
*
[CF18600(ALL)01/96]
Turn Signals
*
[CF18700(ALL)01/96]
Move the lever up to signal a right turn. Move
it down to signal a left turn. The corresponding
indicator light in the instrument cluster will
flash.
[CF18800(ALL)01/96]
If the turn signal stays on after you turn, move
the lever back to the center (OFF) position.
*
[CF18900(ALL)01/96]
For lane changes, move the lever far enough to
signal but not to latch. The lever will return to
the off position when you release it.
[CF19000(ALL)01/96]
half page art:0032033-A
Turn signal
File:05prcfp.ex
