Driving
211
*
[GF36500(R)05/96]
Preparing to Tow
*
[GF36550(R)05/96]
For your safety and for the good of your vehicle, use the right
equipment for the type of trailer you tow. Also, make sure that
all towing equipment is properly attached to your vehicle. If
you are not certain that you are using the right equipment in
the proper manner, see your Ford or Lincoln-Mercury dealer.
%*
[GF36600(R)01/96]
Hitches
*
[GF36650(R)01/96]
For towing trailers up to 2,000 lb (907 kg), use a weight
carrying hitch and ball which uniformly distributes the trailer
tongue loads through the underbody structure. Use a
frame-mounted weight distributing hitch for trailers over 2,000
lb (907 kg).
*
[GF36800(R)01/96]
Do not install a single or multi-clamp type bumper hitch, or a
hitch which attaches to the axle. Underbody mounted hitches
are acceptable if installed properly. Follow towing instructions
of a reputable rental agency.
*
[GF37000(R)01/96]
Whenever a trailer hitch and hardware are removed, make sure
all mounting holes in the underbody are properly sealed to
prevent noxious gases or water from entering.
File:09ungfr.ex
Update:Thu Mar 20 08:55:24 1997

212
WARNING
Do no tconnec ta trailer' shydrauli cbrak esyste mdirectly

Driving
213
WARNING
Alwaysreplac eafusewit hon etha tha sth especified

214
*
[GF38800(R)03/96]
When descending a steep grade with a trailer, operate in Drive
rather than Overdrive. If additional braking is needed, shift the
automatic transmission gearshift into the 2 (Second) or 1 (Low)
position.
[GF38925(R)05/96]
Servicing Your Vehicle If You Tow
*
[GF38950(R)05/96]
If you tow a trailer for a long distance, your vehicle will need
to be serviced more frequently than usual. Refer to the
Maintenance Schedulebooklet for additional information.
[GF39000(R)01/96]
Trailer towing tips
*
[GF39100(R)01/96]
Before starting on a trip, practice turning, stopping and backing
in an area away from heavy traffic. Get to know the ªfeelº of
the vehicle/trailer combination.
*
[GF39200(R)01/96]
Practice backing up. Back up very slowly, with someone outside
at the rear of your trailer to guide you. Place your hand at the
bottom of the steering wheel and move it in the direction you
want the rear of the trailer to swing. Slight movement of the
steering wheel results in a much larger movement of the rear of
the trailer.
*
[GF39300(R)01/96]
Allow more room for stopping with a trailer attached. Trailer
brakes should be applied first, whether manually or
automatically controlled, when approaching a stop.
*
[GF39400(R)01/96]
For a good handling truck-trailer combination, the trailer tongue
load should be approximately 10-15% of the loaded trailer
weight.
*
[GF39500(R)01/96]
Make a thorough check of your equipment before starting out
on the road. After you have traveled about 50 miles (80 km)
stop in a protected area and double-check your hitch and
electrical connections. Also check trailer wheel lug nuts for
tightness.
*
[GF39600(R)01/96]
When turning, drive slightly beyond the normal turning point
so the trailer wheels will clear curbs or other obstructions.
File:09ungfr.ex
Update:Thu Mar 20 08:55:24 1997

Driving
215
WARNING
Do no tto w atraile rwhe nusin gatemporar yspar etire.

216
WARNING
Do no tus ethi svehicl efo rsnowplowing.

217
Roadside Emergencies
%*[ER00200(R)03/96]Hazard Flasher
*[ER00210(R)01/96]The hazard flasher is used to alert other drivers to hazardous
situations.
*[ER00212(R)03/96]The flashers will flash and the high-mount brakelamp will stay
on steadily (not flash) with the brake pedal depressed.
*[ER00214(R)01/96]The flashers work whether your vehicle is running or not. The
flashers work for up to two hours when the battery is fully
charged and in good condition without draining the battery
excessively. If the flashers run for longer than two hours or if
the battery is not fully charged, the battery power can be
drained.
*[ER00216(R)01/96]To use the hazard flasher:
*[ER00218(R)01/96]1.Push in the flasher button; it will pop out and the lamps will
begin to flash.
*[ER00220(R)01/96]2.To stop the flashers, push in the flasher button again.
*[ER00230(R)01/96]NOTE: The flasher button will be sticking up slightly higher
when on than when off.
[ER00250(R)01/96]
10-1/2 pica
art:0020079-D
Hazard flasher
File:10unerr.ex
Update:Thu Mar 20 08:56:46 1997

218
*
[ER00300(R)01/96]
The Fuel Pump Shut-off Switch
*
[ER00400(R)05/96]
If the engine cranks but does not start or if you have had a
collision, the fuel pump shut-off switch may have been
triggered. The shut-off switch is a device that stops the fuel
pump when your vehicle has been involved in a substantial jolt.
*
[ER00500(R)05/96]
For information on how to check and reset the fuel pump
shut-off switch, seeFuel pump shut-off switchin the Index.
%*
[ER00700(R)01/96]
Fuses
[ER00800(R)01/96]
Fuses protect your vehicle's electrical system from overloading.
If electrical parts in your vehicle are not working, the system
may have been overloaded and blown a fuse. Before you
replace or repair any electrical parts, check the appropriate
fuses.
[ER00900(R)01/96]
The following charts tell you which fuses protect each electrical
part of your vehicle. If a fuse blows, all the parts of your
vehicle that use that circuit will not work.
*
[ER01000(R)01/96]
Once you have determined which fuses to check, follow the
procedures underChecking and replacing fuseslater in this
chapter.
File:10unerr.ex
Update:Thu Mar 20 08:56:46 1997

Roadside Emergencies
219
[ER01100(R)01/96]
17-1/2 pica
art:0021207-B
Fuse panel (located left side of instrument panel)
