FORD TAURUS 1996 Owners Manual

264 %
*
[SV05075(ALL)04/95]
Cleaning the Engine
*
[SV06000(ALL)07/95]
A clean engine is more efficient because the
engine is able to cool properly. A build up of
grease and dirt acts as an insulator, keeping the
engine warmer than normal.
*
[SV06020(ALL)07/95]
q
Extreme care must be used if a power washer
is used to clean the engine. The high pressure
fluid could penetrate sealed parts and
assemblies causing damage or malfunctions.
*
[SV06040(ALL)08/95]
q
In order to avoid possible cracking of the
engine block or fuel injection pump, do not
spray a hot engine or injection pump with
cold water.
*
[SV06060(ALL)07/95]
q
The alternator, distributor and air intake must
be covered. Covering these components will
help prevent water damage.
*
[SV06080(ALL)04/95]
q
Never wash or rinse the engine while it is
running. Water getting into the engine may
cause internal damage.
%
*
[SV06100(ALL)03/95]
Filling the Fuel Tank
[SV06800(ALL)04/95]
1. Turn the engine off. After opening the fuel
door, remove the cap carefully and slowly
by turning it counterclockwise 1/4 turn until
it stops. Pull to remove the cap. A tether
attaches the cap to the fuel filler pipe.
[SV06825(ALL)04/95]
one inch art:0001470-AFile:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

265 [SV06850(ALL)04/95]
RWARNING
The fuel system may be under pressure. If
the fuel cap is venting vapor or if you
hear a hissing sound, wait until it stops
before completely removing the cap.
Otherwise, fuel may spray out and injure
you or others.
*
[SV06900(ALL)05/95]
2. Make sure that you pump unleaded fuel and
put the nozzle all the way inside the fuel
filler pipe.
[SV06950(ALL)09/95]
NOTE: To help reduce early nozzle shutoffs
and fuel spillage, park your vehicle so
that the fuel filler door is not
downhill. Do not tilt or turn the nozzle
upside down when filling. Avoid
excessively fast fuel dispensing rates
(over 10 gallons [38 liters] per minute).
*
[SV07150(ALL)08/95]
NOTE: If you spill any fuel on the body of
your vehicle, clean it off immediately.
The fuel may dull or soften the paint
if you do not wash it off.
[SV07200(ALL)10/95]
3. To replace the fuel cap, align the tabs on the
cap with the notches on the filler pipe. Turn
it clockwise until it stops.
*
[SV07250(ALL)10/95]
4. Push the fuel door closed.
[SV07275(ALL)04/95]
If the Service Engine Soon warning light comes
on and stays on when you start the engine, the
fuel cap may not be properly seated. Turn off
the engine, remove the fuel cap and replace it,
being careful to align the cap properly. For more
information, seeWarning lightsin the Index.
*
[SV07290(ALL)07/95]
If you lose the fuel cap, replace it with an
authorized Motorcraft or equivalent part.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

266 %
*
[SV07300(ALL)05/95]
RWARNING
If you do not use the proper fuel cap, the
pressure in the fuel tank can damage the
fuel system or cause it to work improperly
in a collision.
*
[SV07350(ALL)05/95]
NOTE: If you replace your fuel cap with an
aftermarket fuel filler cap, the customer
warranty may be void for any damage
to the fuel tank and/or fuel system.
%*
[SV07500(ALL)06/95]
Choosing the Right Fuel
[SV07601(ALL)12/95]
Use only UNLEADED FUEL. Using leaded fuel
is prohibited by federal law. Any vehicle
damage may not be covered by your warranty.
%*
[SV08725(ALL)05/95]
Octane Recommendations
[SV08750( T)02/95]
All models except SHO 3.4L
[SV08800(ALL)04/95]
Your vehicle is designed to use regular fuel
with an octane rating of 87.In most cases it is
not necessary to use a fuel with an octane rating
higher than 87. At service stations, the octane
rating is displayed in a label on the pumps.
*
[SV08900(ALL)06/95]
one inch art:0060001-C
Typical octane rating label
[SV09000(ALL)12/95]
We do not recommend gasolines labeled
ªregularº that are sold with octane ratings of 86
or even less in high altitude areas.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

267 [SV09100(ALL)12/95]
Do not be concerned if your vehicle sometimes
knocks lightly. However, if it knocks heavily
under most driving conditions on the
recommended octane rating fuel, see your dealer
or a qualified service technician to prevent any
engine damage.
[SV09455( T)02/95]
SHO 3.4L engine
[SV09460( T)02/95]
The SHO 3.4L engine has been designed to
operate using premium unleaded fuel with an
octane rating of 91 or higher. Regular unleaded
fuel with an octane rating of 87 may be used if
necessary. For optimum performance and
driveability, it is recommended that you use
premium unleaded fuel.
[SV09470( T)12/95]
In some high altitude areas, ªpremiumº fuels are
sold with octane ratings of less than 91. It is
recommended that you use only those
ªpremiumº fuels with an octane rating of 91 or
higher.
%*
[SV09490(ALL)08/95]
Fuel quality
[SV09601(ALL)12/95]
Ford approves the use of gasolines, including
those reformulated, that contain oxygenates such
as ethanol (10% maximum) and MTBE (15%
maximum). If methanol is used, the gasoline
should contain no more than 5% with
cosolvents.
[SV09701(ALL)12/95]
If you are experiencing starting, rough idle or
hesitation problems, try a different brand of fuel.
If the condition persists, see your dealer or a
qualified service technician.
*
[SV09800(ALL)06/95]
It should not be necessary to add any
aftermarket products to your fuel tank if you
continue to use a high-quality fuel.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

268 %
*
[SV10185(ALL)06/95]
Safety Information Relating to Automotive
Fuels
*
[SV10195(ALL)05/95]
RWARNING
Automotive fuels can cause serious injury
or death if misused or mishandled.
*
[SV10200(ALL)08/95]
Gasoline and other automotive fuels are
extremely flammable. Turn your vehicle off and
do not smoke while refueling your vehicle. Keep
sparks and other sources of ignition away from
fuels.
[SV10205(ALL)08/95]
Automotive fuels can be harmful or fatal if
swallowed.Never attempt to siphon any fuel
by mouth.
*
[SV10210(ALL)08/95]
If any fuel is swallowed, call a physician or
poison control center immediately.Do not delay
calling a physician merely because no adverse
effects are noticed at first; the toxic effects of
fuels may not become apparent for many
hours.
*
[SV10213(ALL)08/95]
If gasoline is swallowed, do not induce
vomiting. If a gasoline-methanol blend is
swallowed, induce vomiting under the direction
of a physician or poison control center.
*
[SV10215(ALL)08/95]
Gasoline and gasoline blends may contain small
amounts of carcinogens, such as benzene.
Long-term exposure to unleaded gasoline vapors
has caused cancer in laboratory animals.
*
[SV10220(ALL)08/95]
Fuels can also be harmful if absorbed through
the skin. Be careful not to splash fuel on
yourself or your clothing. If fuel is splashed on
the skin, promptly remove contaminated clothing
and wash the skin thoroughly with soap and
water.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

269
*
[SV10225(ALL)08/95]
Fuels can cause severe eye irritation and possibly
eye damage. If fuel is splashed in the eyes,
remove contact lenses (if worn), flush with large
amounts of water for 15 minutes, and seek
medical attention.
*
[SV10230(ALL)08/95]
If you are taking the medication ªAntabuseº or
other forms of disulfiram for the treatment of
alcoholism, vapor or skin contact with a
gasoline-methanol blend may cause the same
kind of adverse reaction as drinking an alcoholic
beverage. In sensitive individuals, serious
personal injury or sickness could result. Consult
a physician promptly if you experience an
adverse reaction.
[SV10250(ALL)05/95]
Fuel line service
[SV10270(ALL)11/94]
Fuel injection systems operate with pressurized
fuel. The fuel lines are under pressure even
when the engine is off. This system should be
serviced by an authorized dealer using only
Ford approved parts. Using other materials may
be hazardous or allow hydrocarbon emissions
above the legal levels set by the Federal
Government.
%*
[SV11300(ALL)05/95]
Running Out of Fuel
[SV11500(ALL)05/91]
If your vehicle runs out of fuel, try to stop on
level ground away from traffic. Add at least one
gallon (four liters) of fuel to start your vehicle
again. If your vehicle is not on level ground,
you may need as much as five gallons (20 liters)
of fuel to start it.
*
[SV11550(ALL)07/95]
You may need to crank the engine several times
before the fuel system starts to pump fuel from
the tank to the engine.
*
[SV11575(ALL)08/95]
If the engine does not start, check the fuel pump
shut-off switch and reset as required. SeeFuel
pump shut-off switchin the Index.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

270
*
[SV11580(ALL)01/95]
RWARNING
Never pour fuel in the throttle body or
attempt to start the engine with the air
cleaner removed. Doing so could result in
fire and personal injury.
%*
[SV13505(ALL)05/95]
Fuel Economy
*
[SV13510(ALL)07/95]
Fuel economy is an estimate of the efficiency of
your vehicle and can be calculated as Miles Per
Gallon (MPG) or Liters Per 100 Kilometers
(L/100K).
*
[SV13515(ALL)05/95]
To calculate fuel economy:
*
[SV13521(ALL)06/95]
1. Fill the tank completely and record the
initial odometer reading.
*
[SV13526(ALL)06/95]
2. Every time you buy fuel record the
amount (in gallons or liters) purchased.
[SV13530(ALL)09/95]
Keep a record for at least a month. This will
give you a more accurate estimate than
figuring the fuel economy based on only one
or two readings.
*
[SV13535(ALL)07/95]
3. After at least three to five tankfuls, fill the
fuel tank and record the final odometer
reading.
*
[SV13537(ALL)10/95]
4. Use these equations to calculate your fuel
economy:
*
[SV13538(ALL)10/95]
q
English: MPG = (total miles driven)
v(gallons used)
*
[SV13539(ALL)10/95]
q
Metric: L/100k = (liters used)
v(100 kilometers)
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

271 %
*
[SV13540(ALL)08/95]
Comparisons With Environmental
Protection Agency (EPA) and Transport
Canada (TC) Fuel Economy Estimates
*
[SV13545(ALL)05/95]
EPA fuel economy figures are obtained from
laboratory tests under simulated road conditions
and may not reflect the actual conditions you
experience or your style of driving. The EPA
fuel economy estimate is not a guarantee that
you will achieve the fuel economy shown.
%*
[SV13555(ALL)08/95]
Improving Fuel Economy
*
[SV13561(ALL)05/95]
Fuel economy is affected by a number of
variables which can reduce efficiency. You can
improve fuel economy by understanding these
variables and minimizing their effect.
*
[SV13564(ALL)05/95]
The following decrease fuel economy:
*
[SV13568(ALL)05/95]
q
Lack of regular, scheduled maintenance
*
[SV13572(ALL)05/95]
q
Excessive speed
*
[SV13576(ALL)05/95]
q
Rapid acceleration and excessive speed
*
[SV13581(ALL)05/95]
q
Driving with your foot on the brake
*
[SV13584(ALL)05/95]
q
Sudden stops
*
[SV13589(ALL)05/95]
q
Extended engine idling
*
[SV13591(ALL)05/95]
q
Using speed control in hilly terrain
*
[SV13593(ALL)05/95]
q
Extended use of the A/C, defroster, rear
window defroster and other accessories
*
[SV13596(ALL)05/95]
q
Underinflated tires
*
[SV13598(ALL)05/95]
q
Heavy loads
*
[SV13599(ALL)05/95]
q
Aftermarket add-ons such as bike, ski or
luggage racks, bug deflectors, etc.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

272
*
[SV13605(ALL)02/95]
Self-Service Pointers
*
[SV13611(ALL)01/95]
If you choose to do your own fueling, you
should also perform a few simple maintenance
routines. This extra effort will save you
additional money and contribute to the driving
efficiency of your vehicle.
*
[SV13615(ALL)01/95]
The following procedures require only a tire
gauge, a rag, an oil can spout and windshield
washer fluid.
*
[SV13620(ALL)01/95]
q
Check the engine oil at every refueling stop
*
[SV13625(ALL)01/95]
q
Clean the windshield, outside mirrors and
headlights
*
[SV13630(ALL)01/95]
q
Check windshield washer fluid
*
[SV13633(ALL)02/95]
q
Check tires for excessive wear or worn edges
*
[SV13636(ALL)01/95]
q
Check the tire pressure at least monthly
%
*
[SV13638(ALL)02/95]
Engine Oil Recommendations
*
[SV13639(ALL)09/95]
We recommend using Motorcraft oil or an
equivalent oil meeting Ford Specification
WSS-M2C153-F and displaying the American
Petroleum Institute CERTIFICATION MARK on
the front of the container.
*
[SV13650(ALL)03/95]
one third page art:0060021-E
The API Certification Mark
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

273
*
[SV13670(ALL)01/95]
Neveruse:
*
[SV13680(ALL)01/95]
q
ªNon-Detergentº oils
*
[SV13690(ALL)04/95]
q
Oils labeled API SA, SB, SC, SD, SE, SF or SG
%*
[SV13700(ALL)01/95]
q
Additional engine oil additives, oil treatments
or engine treatments
% [SV13710(ALL)02/95]
Engine oils with an SAE 5W-30 viscosity are
PREFERREDfor your vehicle. They provide the
best engine performance, fuel economy and
engine protection for all climates down to-15ÊF
(-25ÊC).
%*
[SV13770(ALL)03/95]
Synthetic engine oils which are CERTIFIED and
of the preferred viscosity may be used in your
engine. The engine oil and oil filter must still be
changed according to the maintenance schedule.
%*
[SV13775(ALL)01/95]
Checking and Adding Engine Oil
*
[SV13800(ALL)03/95]
Since the proper amount of engine oil is
important for safe engine operation, check the oil
using the dipstick each time you put fuel in
your vehicle. Remember the engine must be off,
the oil must be warm and the vehicle must be
parked on level ground.
%*
[SV13900(ALL)04/95]
Checking the engine oil level:
*
[SV14000(ALL)02/95]
1. Turn the engine off after it has warmed up
and allow a few minutes for the engine oil
to drain back into the oil pan.
*
[SV14025(ALL)03/95]
2. Set the parking brake, making sure the
gearshift is securely latched in P (Park).
*
[SV14100(ALL)02/95]
3. Open the hood. Protect yourself from engine
heat.
*
[SV14200(ALL)03/95]
4. Locate the engine oil dipstick (highlighted in
yellow) and carefully pull it out of the
engine.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com
