FORD WINDSTAR 1997 1.G Owners Manual

160
WARNING
Checkto seetha tth esea tan dseatbac kare latched

Seating and Safety Restraints
161
[SS08000(ALL)01/96]
27-1/2 pica art:0050169-F
Figure 1: Second row detachable anchor Ð detached position
File:06wnsss.ex
Update:Thu Jul 18 11:00:49 1996

162
[SS08100(ALL)01/96]2.
Using the clip attached to the end of the shoulder belt, clip
the end of the belt to the stationary portion of the shoulder
belt (see Figure 2). The end of the shoulder beltmustbe
clipped in order to keep it from striking anything during
vehicle operation.
[SS08200(ALL)01/96]
24 pica art:0050170-D
Figure 2: Securing the detachable shoulder belt
File:06wnsss.ex
Update:Thu Jul 18 11:00:49 1996

Seating and Safety Restraints
163
[SS08300(ALL)01/96]
Refer to Figure 3 for steps 3-6.
[SS08400(ALL)01/96]3.
Release the seatback by pulling the lever located at the back
of the seat on the right hand side. Fold the seatback forward
and latch it in the down position (except for bench seat
equipped with built-in child safety seat).
[SS08500(ALL)01/96]4.
Locate the seat latch handles at the rear of the seat near the
floor. For the second row bench seat, lift the latch handles
up and rearward. For the third row bench seat, just lift the
latch handles. The latch hooks will disengage from the rear
floor attachments.
[SS08600(ALL)01/96]5.
While still lifting the handles, lift seat at rear and rotate
entire seat assembly forward, pivoting on the front floor
attachments. When the rear seat latches are clear of floor
attachments, release the latch handles.
[SS08700(ALL)01/96]6.
Pull the seat rearward to disengage it from the front floor
pins.
File:06wnsss.ex
Update:Thu Jul 18 11:00:49 1996

164
[SS08800(ALL)01/96]
17-1/2 pica
art:0050171-A
Figure 3: Removal and installation of the second and third bench seats
*
[SS08900(ALL)01/96]
Be careful that the latches are not damaged when the seats are
stored.
*
[SS09000(ALL)01/96]
To install the seat assembly:
*
[SS09100(ALL)01/96]1.
Clear the area of debris around the seat floor attachments.
[SS09200(ALL)01/96]2.
With the seatback in a folded and latched position (except
for bench seats equipped with built-in child safety seat),
place the seat assembly in your vehicle. Tip the seat
assembly forward and engage the front seat hooks onto the
forward attachment pins in the floor wells.
*
[SS09300(ALL)01/96]3.
Rotate the seat downward and engage the latch into the rear
floor attachment. Lifting of the latch handles is not required
for installation.
File:06wnsss.ex
Update:Thu Jul 18 11:00:49 1996

Seatingan dSafet yRestraints
165
WARNING
Whe nreinstallin garea rsea tin you rvehicl eit mus tbe

166
[SS10100(ALL)01/96]
27-1/2 pica
art:0050212-D
Proper stowage of shoulder safety belt
File:06wnsss.ex
Update:Thu Jul 18 11:00:49 1996

Seatingan dSafet yRestraints
167
WARNING
Neve radjus tth edriver' ssea tor seatbac kwhe nthe
WARNING
Alway slatc hthevehicl esea tto thefloor ,whethe rthe
WARNING
Befor eusin gtheseat ,mak esur etha tth elatc hhook sare

168
[SS10900(ALL)01/96]
17-1/2 pica
art:0050042-A
The underseat storage compartment
[SS11000(ALL)04/96]
Safety Belts
[SS11100(ALL)04/96]
The use of safety belts helps to restrain you and your
passengers in case of a collision. In most states and in Canada,
the law requires their use. We strongly recommend that you use
them every time you travel in your vehicle.
*
[SS11200(ALL)02/96]
Safety belts provide best restraint when:
*
[SS11300(ALL)02/96]
n
the seatback is upright
*
[SS11400(ALL)02/96]
n
the occupant is sitting upright (not slouched)
*
[SS11500(ALL)02/96]
n
the lap belt is snug and low on the hips
*
[SS11600(ALL)02/96]
n
the shoulder belt is snug against the chest
*
[SS11700(ALL)02/96]
n
the knees are straight forward
File:06wnsss.ex
Update:Thu Jul 18 11:00:49 1996

Seatingan dSafet yRestraints
169
WARNING
Mak esur etha tyo uan dyou rpassengers ,including
WARNING
Carg oshoul dalway sbe secure dto preven tit from
WARNING
Eac hseatin gpositio nin you rvehicl eha sa specifi csafety
WARNING
Alway sdriv ean drid ewit hyou rseatbac kuprigh tand
WARNING
Childre nshoul dalway srid ewit htheseatbac kin the
