FORD WINDSTAR 1997 1.G Owners Manual

140
*
[CF45700(ALL)05/96]
The system will work with up to four remotes. Your vehicle
came with two remotes. Additional remotes can be ordered
from your dealer.
*
[CF45800(ALL)01/96]
The remote entry features only operate with the ignition in the
OFF position.
[CF45900(ALL)01/96]
10-1/2 pica
art:0050158-B
The remote entry transmitter
% [CF46000(ALL)07/96]
Unlocking the Doors
*
[CF46100(ALL)04/96]
To unlock the driver's door, press the UNLOCK control.
*
[CF46200(ALL)04/96]
To unlock the other doors, press the UNLOCK control a second
time within five seconds of unlocking the driver's door.
*
[CF46300(ALL)04/96]
Locking the doors
*
[CF46400(ALL)04/96]
To lock all the doors, press the LOCK control.
[CF46500(ALL)01/96]
If you would like a signal that the doors have been locked,
press the LOCK button again within five seconds. The doors
will lock again and the horn will beep.
File:05wncfs.ex
Update:Wed Jul 31 15:55:37 1996

Controls and Features
141
%*
[CF46600(ALL)03/96]
Activating the remote personal alarm
[CF46700(ALL)01/96]
If you wish to activate the remote personal alarm, press the
PANIC button. This will honk the horn and flash the tail lamps
for approximately two minutes and forty-five seconds. You can
turn it OFF by pressing the PANIC button again on the same
transmitter or by turning the ignition key to the RUN position.
If the alarm does not turn off, move the transmitter closer to the
vehicle and press the button again.
[CF46800(ALL)01/96]
When you use the remote entry UNLOCK, or PANIC buttons,
the illuminated entry system turns on the interior lights for 25
seconds. You can turn these lights off with the LOCK button or
by turning the ignition to the RUN position.
[CF46900(ALL)07/96]
Replacing the batteries
*
[CF47000(ALL)05/96]
The remote is powered by two coin type three-volt lithium 2016
batteries (included) that should last for several years of normal
use. If you notice a significant decrease in operating range, the
batteries should be replaced. Replacement batteries can be
purchased at most pharmacies, watch stores or at your Ford or
Lincoln-Mercury dealer.
*
[CF47100(ALL)01/96]
NOTE: The operating range of the remote entry system can
also be affected by weather conditions (such as very
cold temperatures) or structures around the vehicle
(buildings, other vehicles, radio towers, etc.). Typical
operating range will allow you to be up to 33 feet (10
meters) away from your vehicle.
File:05wncfs.ex
Update:Wed Jul 31 15:55:37 1996

142
[CF47200(ALL)01/96]
7-1/2 pica art:0050159-A
Replacing the batteries
*
[CF47300(ALL)05/96]
The remote can be snapped apart to replace the batteries by
twisting a thin coin between the two halves of the remote. DO
NOT TAKE THE FRONT PART OF THE REMOTE APART.
When installing the new batteries, be sure to place the positive
(+) side down as marked. Snap the two halves back together.
%*
[CF47400(ALL)05/96]
Replacement/additional remotes
*
[CF47500(ALL)05/96]
In the event a remote is lost, return the remaining remotes to
your dealer for reprogramming of your remote entry system.
This is necessary to prevent further unauthorized use of the lost
remote.
*
[CF47600(ALL)05/96]
Additional remotes may be purchased from your dealer (remote
entry system will work with up to four remotes). Return your
existing remotes to your dealer so the remote entry system can
be reprogrammed with your new and existing remotes.
*
[CF47700(ALL)01/96]
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC
RULES. OPERATION IS SUBJECT TO THE FOLLOWING
TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST
ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
File:05wncfs.ex
Update:Wed Jul 31 15:55:37 1996

Controls and Features
143
%*
[CF47800(ALL)01/96]
Illuminated Entry System (If equipped)
*
[CF47900(ALL)01/96]
This system will provide illumination of the vehicle's interior
courtesy lamps when either outside front door handle is pulled
or when the remote entry system is used to unlock the door or
sound the personal alarm. The system will automatically turn
off after approximately 25 seconds or when the ignition is
turned to the RUN or ACC position.
[CF48000(ALL)01/96]
NOTE: The illuminated entry timer will not turn off the
courtesy lamps if they have been turned on by the
door and or dimmer switch.
% [CF48100(ALL)01/96]
Autolock
[CF48200(ALL)01/96]
The Autolock feature is part of your remote entry system and is
enabled at the factory. With the Autolock feature enabled, all of
the doors will automatically lock when:
[CF48300(ALL)01/96]
n
the vehicle doors and liftgate are closed
*
[CF48400(ALL)05/96]
n
the ignition key is turned to the ON position
[CF48500(ALL)04/96]
n
the brake pedal is pressed
[CF48600(ALL)05/96]
n
you shift through R (Reverse)
[CF48700(ALL)04/96]
n
one second has elapsed after the brake pedal is released
*
[CF48800(ALL)05/96]
The Autolock feature will repeat when:
[CF48900(ALL)01/96]
n
a door is opened and then all doors and the liftgate are
closed
[CF49000(ALL)04/96]
n
one second has elapsed after the brake pedal is released
[CF49100(ALL)01/96]
On vehicles with Keyless Entry, you can deactivate the system
by using the buttons for the keyless entry system if you do not
want to use the Autolock feature.
File:05wncfs.ex
Update:Wed Jul 31 15:55:37 1996

144
[CF49200(ALL)04/96]
The doors may not lock automatically at the correct time if the
driver:
[CF49300(ALL)04/96]
n
shifts through gears without pressing the brake
[CF49400(ALL)04/96]
n
shifts through gears quickly after starting the vehicle
[CF49500(ALL)04/96]
n
releases their foot from the brake while someone has stepped
out of the vehicle for a moment
*
[CF49600(ALL)05/96]
To deactivate the Autolock system:
*
[CF49700(ALL)05/96]1.
Enter your permanent five-digit entry code (not the user
code you may have set).
*
[CF49800(ALL)01/96]2.
Within five seconds, press and hold 7/8.
[CF49900(ALL)01/96]3.
Within five more seconds, press and release 3/4.
*
[CF50000(ALL)05/96]4.
Release 7/8.
[CF50100(ALL)04/96]
To reactivate the Autolock system, simply repeat the instructions
for deactivating the system. By re-entering the code that
deactivates the Autolock, the keyless entry system reinstates the
Autolock feature.
% [CF50200(ALL)01/96]
Anti-Theft System (if equipped)
*
[CF50300(ALL)01/96]
When armed, this system helps protect your vehicle against
break-ins or theft.
%*
[CF50400(ALL)01/96]
When an unauthorized entry occurs, the system triggers and
will:
*
[CF50500(ALL)03/96]
n
flash the parking lamps, and alarm indicator lamp
*
[CF50600(ALL)01/96]
n
honk the horn
*
[CF50700(ALL)01/96]
n
disable the starting circuit to prevent the vehicle from being
started
File:05wncfs.ex
Update:Wed Jul 31 15:55:37 1996

Controls and Features
145
%*
[CF50800(ALL)07/96]
Arming the System
*
[CF50900(ALL)01/96]1.
Remove the key from the ignition. The hood must be closed
to arm the system.
*
[CF51000(ALL)05/96]2.
Open any door. The alarm indicator light will start flashing
to remind you to arm the system.
[CF51100(ALL)04/96]3.
Lock the doors by using the power door lock switch. The
alarm indicator light will now glow steadily.
[CF51200(ALL)01/96]4.
Close all doors. The alarm indicator light will then remain
on steadily for 30 seconds and then go out. When the light
goes out, the system is armed.
*
[CF51300(ALL)01/96]
NOTE: Be sure to close all doors completely. If not, the alarm
indicator light will remain on. Remember, your
anti-theft system is armed only after the alarm
indicator light remains on steadily for approximately
30 seconds after the last door is closed, and then goes
out.
*
[CF51400(ALL)01/96]
You can also arm the anti-theft system with the factory installed
remote entry system or the keyless entry system by following
this sequence:
*
[CF51500(ALL)01/96]1.
Remove the key from the ignition. The hood must be closed
to arm the system.
*
[CF51600(ALL)01/96]2.
Close all of the doors.
[CF51700(ALL)01/96]3.
Press the remote entry transmitter LOCK button or use the
keyless entry system by pressing 7/8 and 9/0 at the same
time. The alarm indicator will come on for 30 seconds to
show the alarm is arming and then turn off to show that it
has armed.
[CF51800(ALL)01/96]
The anti-theft system is designed to work with the factory
installed remote keyless entry system. It may not work with
other remote entry systems.
File:05wncfs.ex
Update:Wed Jul 31 15:55:37 1996

146
%*
[CF51900(ALL)03/96]
Disarming an Untriggered Anti-Theft System
[CF52000(ALL)01/96]
You can disarm the system by unlocking either front door or
the liftgate with your door key. Turn the key all the way to the
end of travel or the system will not disarm.
[CF52100(ALL)01/96]
You can also disarm the system by unlocking the driver's door
by using the UNLOCK button of the remote entry transmitter or
by using the five-digit unlock code on the keyless entry system
keypad.
[CF52200(ALL)04/96]
If the system is armed and you remain in your vehicle, simply
insert the key into the ignition and turn it to ON. This disarms
the system and allows you to open the door and exit without
triggering the system.
%*
[CF52300(ALL)03/96]
Disarming a Triggered System
*
[CF52400(ALL)01/96]
The alarm can be disarmed by:
[CF52500(ALL)04/96]
n
unlocking any door with the key, or
*
[CF52600(ALL)04/96]
n
using the UNLOCK control on the remote entry transmitter
[CF52700(ALL)01/96]
n
using the five-digit unlock code on the keyless entry keypad
[CF52800(ALL)01/96]
NOTE: The flashing lights and honking horn will shut off
automatically approximately two minutes and 45
seconds after the system is triggered. It will trigger
again if another intrusion occurs. However, the starter
circuit remains disabled until the system is disarmed.
File:05wncfs.ex
Update:Wed Jul 31 15:55:37 1996

147
%
WARNING
Neveradjus tth edriver' ssea tor seatbac kwhe nthe
WARNING
Do no tpil ecarg ohighe rtha ntheseatback sto avoid
WARNING
Alway sdriv ean drid ewit hyou rseatbac kuprigh tand
WARNING
Childre nshoul dalway srid ewit htheseatbac kin the

148
% [SS01400(ALL)01/96]
Using the power seats (if equipped)
[SS01500(ALL)01/96]
If your vehicle has the power seat option, you can adjust it in
several directions. The controls are on the outboard side of the
driver's seat.
[SS01600(ALL)01/96]
17-1/2 pica
art:0050103-A
The power controls on the driver's seat
File:06wnsss.ex
Update:Thu Jul 18 11:00:49 1996

Seating and Safety Restraints
149
% [SS01700(ALL)01/96]
Power lumbar support, driver/passenger seat
(If equipped)
[SS01800(ALL)01/96]
If your vehicle is equipped with this option, you can inflate a
lumbar support pad in the seat back. To inflate the lumbar pad,
push the raised side of the rocker switch. To deflate, push the
recessed side of the switch.
[SS01900(ALL)01/96]
17-1/2 pica
art:0050102-A
The power lumbar switch on the passenger seat
[SS02000(ALL)01/96]
Reclining Bucket Seats
[SS02100(ALL)01/96]
Your vehicle is equipped with reclining front bucket seats and
may have optional reclining second row buckets. To recline
your seat:
[SS02200(ALL)01/96]1.
On the left sides (front seats) or window seat sides (second
row buckets) of the seats, find the handle for the recliner.
*
[SS02300(ALL)01/96]2.
Lift the handle up and hold it in place.
File:06wnsss.ex
Update:Thu Jul 18 11:00:49 1996
