GMC YUKON 1999 Owner's Manual

yellowblue
2-47 Automatic Headlamp System
When it is dark enough outside, your automatic
headlamp system will turn on your headlamps at the
normal brightness along with other lamps such as the
taillamps, sidemarker, parking lamps and the instrument
panel lights.
To idle your vehicle with the automatic headlamp
system off, set the parking brake while the ignition is
off. Then start the vehicle. The automatic headlamp
system will stay off until you release the parking brake.
The headlamp switch can always be used to turn on the
regular lamps. As with any vehicle, you should turn on
the regular headlamp system when you need it.
Headlamps-On Reminder
A chime will sound when your headlamps are turned on
and your ignition is in OFF, LOCK or ACCESSORY.
Daytime Running Lamps
Daytime Running Lamps (DRL) can make it easier for
others to see the front of your vehicle during the day.
DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset.The DRL system will make your headlamps come on at
a reduced brightness when:

the ignition is on,

the headlamp switch is off,

the parking brake is released and

it is bright enough outside and the automatic
headlamps are off.
When the DRL are on, only your headlamps will be on.
The taillamps, sidemarker and other lamps won't be on.
Your instrument panel won't be lit up either.
When it begins to get dark, your DRL will turn off. Your
headlamps will come on automatically.
When it begins to get bright, the regular lamps will go
off, and your headlamps will change to the reduced
brightness of DRL.
To idle your vehicle with the DRL off, set the parking
brake. The DRL will stay off until you release the
parking brake.
As with any vehicle, you should turn on the regular
headlamp system when you need it.

yellowblue
2-48 Fog Lamps
Your vehicle has fog lamps. Use them for better vision
in foggy or misty conditions. Your parking lamps and/or
low
-beam headlamps must be on for your fog lamps
to work.
The fog lamp switch is
located to the right of the
instrument panel cluster.
Press the ribbed top part of the switch to turn the fog
lamps on. Press the bottom of the switch to turn them
off. An indicator light will illuminate in the switch when
the fog lamps are on.
Remember, fog lamps alone will not give off as much
light as your headlamps. Never use your fog lamps in
the dark without turning on your headlamps.Fog lamps will go off whenever your high
-beam
headlamps come on. When the high
-beams are off, the
fog lamps will come on again.
Headlamp Delay
Your vehicle is equipped with a headlamp delay feature
that holds the headlamps on for a short period of time
after the ignition is turned off.
The HEADLAMP DELAY button is located on the
lower left side of the inside rearview mirror.

yellowblue
2-49
The length of time that the headlamps stay on after the
ignition is turned off can be adjusted by pressing and
holding the HEADLAMP DELAY button. The
delay can be varied in five steps (0, 15, 30, 60 and
90 seconds). When the HEADLAMP DELAY button is
held in, the Light Emitting Diode (LED) on the mirror
will show five step changes in brightness. When the
LED is at its brightest the headlamp delay will be
90 seconds, and when it is most dim the delay will be
zero seconds.
Interior Lamps
Instrument Panel Intensity Control
The instrument panel intensity control is located next to
the parking/headlamp switch. Turn the thumbwheel up
to adjust the instrument panel lights. Turn the
thumbwheel up to the first notch to return the radio
display and gear shift indicator LED display to full
intensity when the headlamps or parking lamps are on.
To turn on the dome lamps (with the vehicle doors
closed) turn the thumbwheel up to the second
notch position.
Exit Lighting and Delayed Illumination
With this feature, your interior lamps will come on and
stay on for up to 25 seconds when entering the vehicle
and up to 5 seconds when leaving your vehicle.
When the doors are opened, the dome lamps will only
come on if the dome lamp button is in the out position.
When all doors are closed or the dome lamp button is
pressed in, the lamps will stay on for a short period of
time and will then fade out.
Dome Lamps
The dome lamps will come on when you open the doors.
You can also turn the dome lamps on by turning the
thumbwheel, located next to the parking/headlamps
switch knob, all the way up to the second notch. In this
position, the dome lamps will remain on whether the
doors are opened or closed.

yellowblue
2-50
You can use the DOME OVERRIDE button, located
below the parking/headlamp knob, to set the dome
lamps to come on automatically when the doors are
opened, or remain off. To turn the lamps off, press the
button once. With the button in this position, the dome
lamps will remain off when the doors are open. To
return the lamps to automatic operation, press the button
again and return it to the ªoutº position. With the button
in this position, the dome lamps will come on when you
open the door.
Reading Lamps
Your vehicle has reading
lamps. Press the button next
to the lamp to turn the
lamp on.
The lamps can be adjusted to point in the direction
you want.
Press the button again to turn the lamp off.
Battery Rundown Protection
This feature shuts off the dome, courtesy, vanity,
reading, glove box and underhood lamps if they are left
on for more than 20 minutes when the ignition is off.
This will keep your battery from running down.

yellowblue
2-51
Mirrors
Electrochromic Inside Rearview Mirror
with Compass, Temperature Display and
Headlamp Delay
Your vehicle has electrochromic inside and outside
rearview mirrors. Your vehicle also has a headlamp
delay feature. See ªHeadlamp Delayº in the Index for
more information.
When on, an electrochromic mirror automatically dims
to the proper level to minimize glare from lights behind
you after dark.
The mirror also includes an eight-point compass display
in the upper right corner of the mirror face. When on,
the compass automatically calibrates as the vehicle
is driven.
The mirror also includes a display in the upper right
corner of the mirror. This can be used as a compass or to
indicate outside air temperature.

yellowblue
2-52
Temperature Display
The temperature can be displayed by pressing the TEMP
switch. Pressing the TEMP switch once briefly will
toggle the temperature reading on and off. To alternate
the temperature reading between Fahrenheit and Celsius,
press and hold the TEMP switch for three seconds until
the display shows only F
or C
. Press and release the
TEMP switch to toggle between the Fahrenheit and
Celsius readings. After five seconds of inactivity, the
display will return to normal in the temperature scale
you have selected.The normal display will show a temperature reading in
degrees Fahrenheit or Celsius. If an abnormal reading is
displayed, please consult your dealer.
Electrochromic Mirror Operation
The TEMP side of the switch, located at the bottom of
the mirror, also turns the electrochromic inside and
outside mirrors on and off. An indicator light, located to
the right of the TEMP switch, will come on when the
electrochromic mirrors are turned on. To turn the
mirrors on, press and hold the TEMP switch for eight
seconds. The mirrors will darken and remain dark until
the button is released. To turn the mirrors off, press and
hold the TEMP switch for eight seconds.
Compass Operation
Press the COMP switch once briefly to turn the compass
on or off.
When the ignition and the compass feature are on, the
compass will show two character boxes for
approximately two seconds. After two seconds, the
mirror will display the compass heading.

yellowblue
2-53
Cleaning the Mirror
When cleaning the mirror, use a paper towel or similar
material dampened with glass cleaner. Do not spray
glass cleaner directly on the mirror as that may cause the
liquid cleaner to enter the mirror housing.
Compass Calibration
If, after five seconds, the display does not show a
compass heading (ªNº for North, for example), there
may be a strong magnetic field interfering with the
compass. Such interference may be caused by a
magnetic antenna mount, magnetic note pad holder
or a similar magnetic item. If the letter ªCº should ever
appear in the compass window, the mirror may
need calibration.
The mirror can be calibrated in one of two ways:

Drive the vehicle in two circles at 5 mph (8 km/h) or
less until the display reads a direction, or
Drive the vehicle on your everyday routine and after
several turns the compass will become calibrated and
will display a direction.
Compass Variance
The mirror is set in zone eight upon leaving the factory.
It will be necessary to adjust the compass to compensate
for compass variance if you live outside zone eight.
Under certain circumstances, as during a long distance
cross
-country trip, it will be necessary to adjust for
compass variance. Compass variance is the difference
between earth's magnetic north and true geographic
north. If not adjusted to account for compass variance,
your compass could give false readings.
To adjust for compass variance:
1. Press and hold the COMP switch, located at the
bottom of the mirror, for three seconds until a zone
number appears in the display.

yellowblue
2-54
2. Find your current location and variance zone number
on the following zone map.
3. Press the COMP switch on the bottom of the mirror
until the new zone number appears in the display.
After you stop pressing the switch in, the display
will show a compass direction within a few seconds.
Electric Outside Rearview Mirrors
The electric mirrors can be adjusted to point where you
want from inside the vehicle.
Select the mirror you want
to move by moving the
center of the switch, located
on the driver's door armrest,
to L (left) or R (right).
Then, adjust the mirror angle by pressing the outer
arrows on the switch until the mirror is adjusted where
you want it. The center position turns the electric
mirrors off.
Electrochromic Heated Outside
Rearview Mirrors
The outside rearview mirrors feature auto-dimming and
defrost modes.

yellowblue
2-55
To turn on the auto-dimming feature, press and hold the
inside rearview mirror TEMP button for eight seconds.
See ªElectrochromic Inside Rearview Mirror with
Compass, Temperature Display and Headlamp Delayº in
the Index for further information.
To turn on the defrost feature, press the rear window
defrost button. See ªRear Window Defoggerº in the
Index for further information.
Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from the
driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder before
changing lanes.
Storage Compartments
Your vehicle has a variety of storage compartments
designed to store small items.
Glove Box
To open your glove box, move the release button toward
the passenger's side and pull the door open.
Center Overhead Console
Your vehicle has an overhead console. It has storage
compartments inside it. Your vehicle also has a
Universal Transmitter. See ªUniversal Transmitterº in
the Index.
Sunglasses Compartment
The center overhead compartment can be used to
conveniently store your sunglasses.
To open the center compartment, press the release
button located at the rear of the compartment door.
Place your sunglasses in the compartment door with the
lenses facing out.

yellowblue
2-56
Rear Compartment
The rear compartment can be used to store a small item,
like a book.
To open the rear compartment, press the release button
located at the rear of the compartment door.
Instrument Panel Cupholder
Your vehicle has a cupholder in the middle of the
instrument panel.
To use the cupholder, pull
the handle and slide the
cupholder tray open.
To close the cupholder, slide it back into the
instrument panel.
Center Floor Console
Your vehicle has a console compartment between the
bucket seats.
To open it, insert the console key into the lock and
unlock the console. Press the button in and swing the
console lid upward.
The console key is for use on the storage compartment only.
The console has a small storage bin covered by a lid.
When open, the lid provides a writing surface. The
dealer installed OnStar

cellular telephone option
replaces the writing surface.
The console has two cupholders and two storage trays
for the front passenger and driver to use.
