HONDA ACCORD 2007 CL7 / 7.G Manual PDF

µ
µ
µ µ
µ µ
µ µ
µ
MIST
OFF
INT Intermittent
LO Low speed
HI High speed
Windshield washers Push the right lever up or down to
select a position.
The wipers run at high
speed until you release the lever.
The wipers are not activated. The wipers run at low speed.
The wipers run at high speed.
Pull the
wiper control lever toward you, and
hold it. The washers spray until you
release the lever. The wipers run at
low speed, then complete one more
sweep after you release the lever.
The length of the wiper
interval is varied automatically
according to the vehicle’s speed.
Vary the delay by turning the INT
TIME ring. If you turn it to the
shortest delay, the wiper speed will
increase to low speed operation
when the vehicle speed exceeds 12
mph (20 km/h).
1.2.3.4.5.6.
Except U.S. VP
Windshield Wiper
MIST
OFFLO HI
Windshield Washer
INT
Wipers and Washers
68
 — —
y

y
( y  y

µ
µ µ
Turn signal
Of f
Parking and interior lights
Headlight on
High beams
Flashhighbeams Push down on the
lef t lever to signal a lef t turn and up
to signal a right turn. To signal a lane
change, push lightly on the lever in
the proper direction and hold it. The
lever will return to center when you
release it or complete a turn.
Turning the switch
on the lef t lever to the position
turns on the parking lights, taillights,
side marker lights, rear license plate
lights and lights-on indicator.
Turning the switch to the position turns on the
headlights. If you leave the lights on
with the ignition switch in
ACCESSORY (I) or LOCK (0), you
will hear a reminder chime when you
open the driver’s door.
When the light switch is in either of
these positions, the lights-on
indicator comes on as a reminder. To turn on the high
beams, push the lever f orward until
you hear a click. The blue high beam
indicator will come on (see page ).
To turn of f the high beams, pull the
lever back. To flash the high beams,
pull the lever f arther back, and then
release it. The high beams remain on
until the lever is released.
1.2.3.4.5.6. 62
Turn Signal and Headlights Turn Signal
HeadlightsHigh Beams
Turn Signal, Headlights
Inst rument s and Cont rols
69
 — —
y
  y
( y  y

This f eature turns of f the headlights,
parking lights, side marker lights,
taillights, and rear license plate lights
within 15 seconds of removing the
key f rom the ignition switch and
closing the driver’s door.
This feature activates if you leave
the headlight switch in the orposition, remove the key, then
open and close the driver’s door. If you remove the key f rom the
ignition switch with the headlight
switch on, but do not open the door,
the lights will turn of f af ter 10
minutes.
The lights will turn on again when
you unlock or open the driver’s door.
If you unlock the door, but do not
open it within 15 seconds, the lights
will go off. With the driver’s door
open, you will hear a lights-on
reminder chime.
With the headlight switch off, the
high beam headlights and the high
beam indicator come on with
reduced brightness when you turn
the ignition switch to the ON (II)
position and release the parking
brake. They remain on until you turn
the ignition switch of f , even if you
set the parking brake.
The headlights revert to normal
operation when you turn them on
with the switch.
Except U.S. VP and Canadian DX-G
A utomatic L ighting Of f Feature, Daytime Running L ights
Automatic Lighting Of f Feature
Daytime Running Lights
70
 — —
y
 y
( y  y

Push the button between the center
vents to turn on the hazard warning
lights (f our-way f lashers). This
causes all f our outside turn signals
and both turn indicators in the
instrument panel to f lash. Use the
hazard warning lights if you need to
park in a dangerous area near heavy
traf f ic, or if your vehicle is disabled.T he selec t/ reset kno bon the
instrument panel controls the
brightness of the instrument panel
lights. Turn the knob to adjust the
brightness.
The instrument panel will illuminate
with reduced brightness when you
unlock and open the driver’s door.
The brightness will increase slightly
when you insert the key in the
ignitionswitch,thengotonormal brightness when you turn the
ignition switch to the ON (II)
position.
If you do not insert the key in the
ignition switch af ter opening the
driver’s door, the illumination turns
of f about 30 seconds af ter you close
the door.
If you insert the key but do not turn
the ignition switch to the ON (II)
position, the illumination turns of f in
about 10 seconds.
To reduce glare at night, the instru-
ment panel illumination dims when
you turn the light switch to or
. Turning th
e selec t/ reset
knob f ully to the right until you hear
a click will cancel the reduced bright-ness. Hazard Warning
Instrument Panel Brightness
Instrument Panel Brightness, Hazard Warning
Inst rument s and Cont rols
71
U.S. model shown
SELECT/RESET KNOB
 — —
y
 y
( y  y

The rear window def ogger will clear
fog, frost, and thin ice from the
window. Push the def ogger button to
turn it on and off. The indicator
above/in the button comes on to
show the def ogger is on. It also shuts
of f when you turn of f the ignition
switch. You have to turn the
def ogger on again when you restart
the vehicle.Make sure the rear window is clear
and you have good visibility bef ore
starting to drive.
The def ogger and antenna wires on
the inside of the rear window can be
accidentally damaged. When
cleaning the glass, always wipe side
to side.
Rear Window Def ogger
72
Manual A/C type shown
Auto A/C type shown Vehicles with navigation system
 — —
y
 y
( y  y

Insert the key in the ignition
switch, and unlock the steering
column.
Push the lever under the steering
column all the way down.Move the steering wheel up or
down, and in or out to the desired
position. Make sure you can see
the instrument panel gauges and
the indicator lights.
Make any steering wheel adjustment
bef ore you start driving.
1. 2.
3.
Steering Wheel A djustment
Inst rument s and Cont rols
73
Adjusting the steering wheel
position while driving may
cause you to lose control of the
vehicle and be seriously injured
inacrash.
Adjust the steering wheel only
when the vehicle is stopped.
 — —
y
 y
( y  y

Push the lever up to lock the
steering wheel in that position.
Make sure you have securely
locked the steering wheel in place
by trying to move it up, down, in,
and out.The master key fits all the locks on
your vehicle. The valet key works
only in the ignition and the door
locks. You can keep the trunk
release handle, rear seat trunk
access, and glove box locked when
you leave your vehicle and the valet
key at a parking f acility. Youshouldhavereceivedakey
number tag with your keys. You will
need this key number if you ever
have to get a lost key replaced. Use
only Honda-approved key blanks.
These keys contain electronic
circuits that are activated by the
immobilizer system. They will not
work to start the engine if the
circuits are damaged.
Protect the keys f rom direct
sunlight, high temperature, and
high humidity.
Keep the keys away f rom liquids.
If they get wet, dry them
immediately with a sof t cloth.
Donotdropthekeysorsetheavy
objects on them.
4. 5.
Keys and Locks
Steering Wheel A djustment, K eys and L ocks
74
VALET KEY
(LIGHT GREY)
KEY
NUMBERTAG MASTER
KEY WITH
REMOTE
TRANSMITTER
 — —
y
 y
( y  y

If the system repeatedly does not
recognize the coding of your key,
contact your dealer.
Do not attempt to alter this system
or add other devices to it. Electrical
problems could result that may make
your vehicle undrivable.
If you lose your key and you cannot
start the engine, contact your dealer.
The immobilizer system protects
your vehicle f rom thef t. If an
improperly-coded key (or other
device) is used, the engine will not
start.
When you turn the ignition switch to
the ON (II) position, the immobilizer
system indicator should come on f or
a f ew seconds, then go of f . If the
indicator starts to blink, it means the
system does not recognize the
coding of the key. Turn the ignition
switch to the LOCK (0) position,
remove the key, reinsert it, and turn
the ignition switch to the ON (II)
position again.
The system may not recognize your
key’s coding if another immobilizer
key or other metal object (i.e. key
f ob) is near the ignition switch when
you insert the key.As required by the FCC:
This device complies with Part 15 of the FCC rules. Operation is subject to thef ollowing two conditions: (1) This device
may not cause harmf ul interf erence, and (2) this device must accept any
interf erence received, includinginterf erence that may cause undesired
operation.
Changes or modif ications not expresslyapproved by the party responsible f or
compliance could void the user’s authority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing two
conditions: (1) this device may not causeinterf erence, and (2) this device must
accept any interf erence that may cause undesired operation of the device.
Immobilizer Syst em
Inst rument s and Cont rols
75
 — —
y
  y
( y   y

µµµ
µ
You can insert or
remove the key only in this position.
To turn the key, the shift lever must
be in Park, and you must push the
key in slightly. If the f ront wheels
are turned, the anti-thef t lock may
make it difficult to turn the key.
Firmly turn the steering wheel to the
left or to the right as you turn thekey.
The ignition switch has f our
positions: LOCK (0), ACCESSORY
(I), ON (II), START (III) You can
operate the audio system and the
accessory power sockets in this
position.
This is the normal key
position when driving. Several of the
lights on the instrument panel come
on as a test when you turn the
ignition switch f rom the
ACCESSORY (I) to the ON (II)
position.
Use this position
only to start the engine. The switch
returns to the ON (II) position when
you let go of the key.
L OCK (0) A CCESSORY (I)
ON (II)
ST A RT (III)
Ignition Switch
76
 — —
y

 y
( y
y

You will hear a reminder beeper if
you leave the key in the ignition
switch in the LOCK (0) or the
ACCESSORY (I) position and open
thedriver’sdoor.Removethekeyto
turn of f the beeper.
If your vehicle has an automatic
transmission, the shif t lever must be
in Park bef ore you can remove the
key f rom the ignition switch.Each f ront door has a power door
lock master switch. Either switch
locks and unlocks all doors. Push the
top of the switch to lock all doors;
push the bottom to unlock them.Each door has a lock tab on it. Push
down the tab to lock the door and
pull it up to unlock. When you push
down the tab on the driver’s door, all
the doors lock.
To lock any passenger’s door when
getting out of the vehicle, push the
lock tab down, and close the door.
All doors can be locked f rom the
outsidebyusingthekeyinthe
driver’s door. To unlock only the
driver’s door, insert the key, turn it
clockwise, and release it. The
remaining doors unlock when you
turn the key a second time within a
f ew seconds.
Door L ocks
Ignit ion Swit ch, Door L ocks
Inst rument s and Cont rols
77
top
bottom
POWER DOOR LOCK MASTER SWITCH
Removing the key from the
ignition switch while driving
locks the steering. This can
cause you to lose control of thevehicle.
Remove the key from the
ignition switch only whenparked.
 — —
y

y
( y  y
