HONDA CIVIC 1991 Owners Manual

If towing is necessary, contact a professional towing service. Your
authorized Honda dealer can assist you with detailed towing

instructions.

Never use tow chains or rope to tow a car; your ability to safely
control the car may be adversely affected.
We recommend the following: Flat Bed Equipment —Entire car is winched on a flat bed vehicle.
This is the best way of transporting your Honda.
Wheel Lift Type—Tow with the front wheels off the ground.

If the car can only be towed with the front wheels on the ground:

make sure the transmission is full of fluid (see pages 78 — 79) and
tow with the transmission in neutral (N) and the ignition key in the 1
position.

CAUTION:

To avoid serious damage on automatic transmission cars, first
start the engine and shift to D4, then to N and shut the engine off. If the engine does not run or the transmission cannot be shifted
while the engine is running, the car must be transported on flat
bed equipment.
Check local regulations for towing.

CAUTION:
Do not exceed 35 mph (55 km/h) or tow for distances of more
than 50 miles (80 km).
If a sling type tow is used, the tow truck driver should position
wood spacer blocks between your car's frame and the chains
and lift straps to avoid damaging the bumper and the body. Do not use the bumpers to lift the car or to support the car's
weight while towing. TowingProCarManuals.comMain Menu s t

If Your Car Gets Stuck
If your car gets stuck in sand, mud, or snow, call a professional
towing service for assistance in getting your car out.
CAUTION: Do not rev up the engine and allow the wheels to spin freely at
high speed. Severe transmission damage may result if the wheels are allowed to spin for more than a few seconds.DO NOT try to free a car with automatic transmission from
snow, etc. by rocking the car alternately between forward and
reverse gears. Severe transmission damage may result from
shifting into gear with the wheels moving.ProCarManuals.comMain Menu s t

Shoulder Belt Buckle (Sedan)
Proceed as follows if the shoulder belt buckle stalls. 1. Lift the hood and remove the cover from the fuse case (for the automatic shoulder belt buckle motor) located on the battery's
terminal.
2. Remove the fuse for the automatic ("passive") shoulder belt buckle motor that does not work.
LEFT MOTOR
RIGHT MOTOR

BLOWN
3. If the fuse has blown, replacing it
with a new fuse of the same am-perage should allow the shoulder
belt buckle motor to work. How-
ever, if the fuse hasn't blown, or if a new fuse did not solve theproblem, remove the fuse and
operate the motor manually.

CAUTION:

Always remove the fuse before manually operating the shoulder belt buckle motor, otherwise the motor may suddenly activate.

(cont'd)ProCarManuals.comMain Menu s t

5. Set the wrench extension into the wrench grip (both provided in
the tool bag) then insert the wrench into the socket and turn it
counterclockwise until the shoulder belt buckle reaches its rear locked position.

WRENCHEXTENSION WRENCH

NOTE:

After the manual operation, make sure that the seat belt warning light is off and the shoulder belt buckle is seated properly in its
locked position.
6. Replace the cover on the center pillar.7. Reinstall the fuse, the fuse remover and both fuse box covers.

Shoulder Belt Buckle (cont'd) (Sedan)

4. Remove the cover located on the center pillar.

COVER

WRENCH GRIPProCarManuals.comMain Menu s t

Specifications(Hatchback)*1 Excluding the coolant in the reserve tank and that remaining in the en\
gine:

0.4 (0.11 US gal, 0.09 Imp gal)

*
2
Excluding the oil remaining in the engine but including that remaining \
in the oil filter.
(cont'd)
ProCarManuals.comMain Menu s t

Specifications (cont'd) (Hatchback)

page 87.ProCarManuals.comMain Menu s t

ProCarManuals.comMain Menu s t

Specifications (Sedan)
*
1
Excluding the coolant in the reserve tank and that remaining in the eng\
ine:

0.4 (0.11 US gal, 0.09 Imp gal)

*
2
Excluding the oil remaining in the engine but including that remaining \
in the oil filter.
ProCarManuals.comMain Menu s t

(cont'd)

page 87.ProCarManuals.comMain Menu s t

Specifications (cont'd) (Sedan)ProCarManuals.comMain Menu s t
