The XM satellites are in orbit over
the equator; therefore, objects south
of the vehicle may cause satellite
reception interruptions. To help
compensate f or this, ground-based
repeaters are placed in major
metropolitan areas.
Satellite signals are more likely to be
blocked by tall buildings and
mountains the f arther north you
travel f rom the equator. Carrying
large items on a roof rack can also
block the signal.
Depending on where you drive, you
may experience reception problems.
Interf erence can be caused by any of
these conditions:Driving on the north side of an
east/west mountain road.
Driving on the north side of a
large commercial truck on an
east/west road. Driving in tunnels.
Driving on a road beside a vertical
wall, steep clif f , or hill to the south
of you.
Driving on the lower level of a
multi-tiered road. Driving on a single lane road
alongside dense trees taller than
50 ft. (15 m) to the south of you.
Large items carried on a roof rack.
CONT INUED
Playing the XMRadio
(Models without navigation system)
147
Signal may be blocked by
mountains or large obstacles to
the south. Signal weaker in
these areas.
SATELLITE GROUND REPEATER

Features

2012 Crosstour

There may be other geographic
situations that could af f ect XM Radio
reception.After you’ve registered with XM
Radio, keep your audio system in the
XM Radio mode while you wait f or
activation. This should take about
If your XM Radio service has expired
or you purchased your vehicle f rom
a previous owner, you can listen to a
sampling of the broadcasts available
on XM Radio. With the ignition
switch in the ACCESSORY (I) or the
ON (II) position, press the
button. A variety of music
types and styles will play. While waiting f or activation, make
sure your vehicle remains in an open
area with good reception. Once your
audio system is activated,
‘‘CATEGORY’’ or ‘‘CHANNEL’’ will
appear in the display, and you’ll be
able to listen to XM Radio broadcasts.
XM Radio will continue to send an
activation signal to your vehicle f or
at least 12 hours from the activation
request. If the service has not been
activated after 36 hours, contact
XM
Radio. In Canada, contact
.
If you decide to purchase XM radio
service, contact XM Radio at
,orat
1-800-852-9696. In Canada, contact
XM CANADA
at , or
at 1-877-209-0079. You will need to
give them your radio I.D. number
and your credit card number. To get
your radio I.D. number, press the button, then turn the
selector knob until ‘‘CH 000’’ appears
in the display. Your I.D. will appear
in the display.
As required by the FCC:
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
www.siriusxm.comwww.xmradio.ca
This Category II radiocommunication
device complies with Industry CanadaStandard RSS-310.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence, includinginterf erence that may cause undesiredoperation of the device.
Receiving XM Radio Service
Playing the XMRadio (Models without navigation system)
148

Features
XM CANADA
30 minutes.

2012 Crosstour

Playing Discs(Models without navigation system)
Without XMRadio
With XMRadio
149
SCAN
BUTTON
MENU BUTTONSKIP BAR
POWER/VOLUME KNOB
TITLE BUTTON
FOLDER BAR SELECTOR
KNOB PRESET
BUTTONS
RETURN BUTTON MP3/WMA INDICATOR
DISC LOAD
BUTTON
DISC SLOTCD BUTTON
DISC
EJECT
BUTTONSCAN
BUTTON
MENU BUTTONSKIP BAR
POWER/VOLUME KNOB
TITLE BUTTON
SELECTOR
KNOB PRESET
BUTTONS
RETURN BUTTON MP3/WMA INDICATOR
DISC LOAD
BUTTON
DISC
EJECT
BUTTON
DISC SLOT
CD/AUX BUTTON
CATEGORY BAR
U.S. models are shown.

Features

2012 Crosstour

To load or play discs, the ignition
switch must be in the ACCESSORY
(I) or ON (II) position.
You operate the disc changer with
the same controls used f or the radio.
To select the disc changer, press the
CD/AUX or CD button. You will see
‘‘CD’’ in the display. The disc and
track numbers, and the elapsed time
areshowninthedisplay.Youcan
also select the displayed inf ormation
with the TITLE button (see page). The system will continuously
play a disc until you change modes. This audio system can also play
CD-Rs and CD-RWs compressed in
MP3 or WMA f ormats. The numbers
of the f older and track playing are
showninthedisplayonthedisc
player. A disc can support more than
99 folders, and each folder can hold
more than 255 playable f iles. A disc
canholdupto999filesintotal.
Video CDs and DVDs do not work in
this unit. Depending on the sof tware the f iles
were made with, it may not be
possible to play some f iles, or display
some text data.
Your vehicle’s in-dash disc changer
holdsuptosixdiscs.
If a f ile on a WMA disc is protected
by digital rights management
(DRM), the audio unit displays
UNSUPPORTED, and then skips to
the next f ile. Press the LOAD button until you
hear a beep and see ‘‘LOAD’’ in
the display. To load only one disc,
press and release the LOAD
button.
The disc number f or an empty
position begins blinking.
Insert the disc into the disc slot
when the green disc load indicator
comes on. Insert it only about
half way; the drive will pull it in the
rest of the way. You will see
‘‘BUSY’’ in the display while the
disc load indicator turns red and
blinks as the disc is loaded.
153 1.
2.
3.
To Play a Disc
Playing Discs
(Models without navigation system)
L oading Discs
150
NOTE:
Do not use discs with adhesive labels.
The label can curl up and cause the
disc to jam in the unit.

Features

2012 Crosstour

CONT INUED
You cannot load and play 3-inch
(8-cm) discs in this unit.
When the disc load indicator turns
green and ‘‘LOAD’’ appears in the
display again, insert the next disc
in the slot. Do not try to insert a
disc until ‘‘LOAD’’ appears. You
could damage the audio unit.
Repeat this until all six positions
are loaded. If you are not loading
all six positions, the system begins
playing the last disc loaded.
You can also load a disc into an
empty position while a disc is playing
by pressing the appropriate preset
button. The system stops playing the
current disc and starts the loading
sequence. It then plays the disc just
loaded. Each time you press the TITLE
button, the display shows you the
text, if the disc was recorded with
text data.
You can see the album, artist, and
track name in the display. If a disc is
recorded in MP3 or WMA, you can
see the f older and f ile name, and the
artist, album, and track tag.
With the f older name, you will see
the FOLDER indicator in the display.
The TRACK indicator is shown with
the file or track name.
When you press and release the
TITLE button while a disc without
text data is playing, you will see ‘‘NO
INFO’’ on the display.
The display shows up to 16
characters of selected text data (the
f older name, f ile name, etc.).If the text data has more than 16
characters, you will see the first 16
characters and the indicator in
the display. Press and hold the
TITLE button until the next 16
characters are shown. You can see
up to 32 characters of the text data.
If youpressandholdtheTITLE
button again, the display shows the
f irst 16 characters again.
If any letter is not available, it is
replaced with ‘‘ . ’’ (dot) in the display.
When the disc has no text data, you
will see ‘‘NO INFO’’ on the display.
4.
5.
Playing Discs
(Models without navigation system)
T ext Data Display Function
151

Features

2012 Crosstour

In MP3 or WMA mode, you can also
select a f older or track/f ile f rom the
list by using the selector knob. Push
the selector knob (ENTER) to
switch the display to the list
displayed with three segments, then
turn the knob to select a f older.
Press the selector knob (ENTER) to
change the display to the track/file
list, then turn the same knob to
select a track/f ile. Press the selector
knob (ENTER) to set your selection.
Use the SKIP bar while a disc is
playing to select passages and
change tracks (files in MP3 or
In MP3 or WMA mode, use the
FOLDER bar (CATEGORY bar on
models with XM Radio) to select
f olders in the disc and use either
side of the skip bar to change f iles.
To select a dif f erent disc, use the
appropriate preset buttons (1
through 6). If you select an empty
position, the system will go into the
loading sequence (see page ).
When you insert a disc, and the
system begins to play. When a new folder, file, or track
When you change the audio mode
to play a disc with text data or in
MP3 or WMA.
You will also see some text data
under these conditions:
When playing a CD-DA with text
data, the album and track name are
showninthedisplay.Withadiscin
MP3 or WMA, the display shows the
f older and f ile name.
151
Playing Discs
(Models without navigation system)
T o Change or Select T racks/Files
152
Folder Selection
Track Selection Press ENTER.

Features
is selected.
WMA mode).

2012 Crosstour

µµ
ÛÝ
Û
Ý
CONT INUED
Each time you press and
releasethe sideof theSKIPbar,
the player skips forward to the
beginning of the next track (f ile in
MP3 or WMA mode). Press and
releasethe sideof thebarto
skip backward to the beginning of
the current track. Press it again to
skip to the beginning of the previous
track.
To move rapidly within a track or f ile,
press and hold either side ( or ) of the SKIP bar. To
select a dif f erent f older, press either
side ( or ) of the FOLDER bar
(CATEGORY bar on models with
XM Radio) to move to the beginning
of the next f older. Press the side
to skip to the next folder, and press
the side to skip to the beginning
of the previous f older.
You can select any type of repeat,
random and scan modes by using the
MENU button and the selector knob.
Push the MENU button to display
themenuitems,thenturnthe
selector knob to select ‘‘PLAY
MODE.’’ Press the selector knob
(ENTER) to set the selection.In MP3 or WMA mode
Playing Discs(Models without navigation system)
SK IP
FOLDER SELECTIONTo Select Repeat, Random
153
MENU ITEMS

Features
or Scan Mode:

2012 Crosstour

µµ
µ µ
Turn the selector knob to select an
appropriate repeat, random or scan
mode, then press the selector knob
(ENTER) to set your selection.
To cancel the selected mode, press
MODE,’’ then press the To
continuously replay a track (f ile in
MP3 or WMA mode), select
REPEAT ONE TRK f rom the menu
items. You will see REPEAT in the
display. Select normal play to turn This feature
continuously replays the current disc.
To activate disc repeat, select
REPEAT DISC from the menu items.
You will see D-REPEAT in the
display. Select normal play to turn
This feature,
when activated, replays all the f iles
on the selected folder in the order
they are compressed in MP3 or
WMA. To activate folder repeat
mode, select REPEAT ONE FLD
from the menu items. You will see
F-REPEAT in the display. The
system continuously replays the
current f older. Select normal play to
turn it of f . Selecting a dif f erent
folder with the FOLDER bar
(CATEGORY bar on models with
XM Radio) also turns off the repeat
feature. Pressing either side of the SKIP bar
also turns of f the repeat f eature. This feature,
when activated, plays the f iles within
the current f older in random order,
rather than in the order they are
compressedinMP3orWMA.To
activate folder random play, select
RANDOM IN FLD f rom the menu
items. You will see F-RANDOM in
the display. The system will then
select and play f iles randomly. This
continues until you deactivate f older
random play by selecting normal play,
or you select a dif f erent f older with
the FOLDER bar (CATEGORY bar
on models with XM Radio).
In MP3 or WMA mode In MP3 or WMA mode
Playing Discs
(Models without navigation system)
REPEAT ONE TRK REPEAT DISC
REPEAT ONE FLD RANDOM IN FLD
154
PLAY MODE ITEMS

Featuresit off.
press the MENU button to show
‘‘PLAY
selector knob (ENTER). When you
see ‘‘NORMAL PLAY,’’ press
ENTER again. it off.

2012 Crosstour

µµµ
CONT INUED
This feature
plays the tracks within a disc (the
f iles in MP3 or WMA mode) in
random order. To activate random
play, select RANDOM IN DISC f rom
the menu items. You will see
RANDOM in the display. Select
normal play to return to normal play. The SCAN f unction
samples all the tracks on the disc in
the order they are recorded on the
disc (all f iles in the selected f older in
MP3 or WMA mode). To activate the
scan feature, press and release the
SCAN button. You will see SCAN in
the display. You will get a 10 second
sampling of each track/f ile in the
disc/f older. Press and hold the
SCAN button to get out of scan
mode and play the last track sampled. This f unction
samples the f irst f ile in each f older in
the order they are stored. To
activate the folder scan feature,
press and release the SCAN button
repeatedly. You will see F-SCAN in
the display. You will get a 10 second
sampling of the f irst f ile in each
folder.PressandholdtheSCAN
button to get out of the f older scan
mode and play the last f ile sampled.
You can also select the scan feature
from the menu items with the
selector knob (see page ). You can also select the folder scan
f eature f rom the menu items with
the selector knob (see page ).
Pressing either side of the skip bar,
or selecting a dif f erent disc (using
the preset buttons) or f older (using
the FOLDER or CATEGORY bar)
turns off the SCAN or F-SCAN
feature.
154
154In MP3 or WMA modeRANDOM IN DISCSCAN T RK
SCAN FL D
Playing Discs(Models without navigation system)
155

Features

2012 Crosstour

µThis f eature, when
activated, samples the first track on
each disc in order (the f irst f ile in
themainfolderoneachdiscinMP3
or WMA mode). To activate the disc
scan feature, press and release the
SCAN button repeatedly until
D-SCAN shows in the display. The
system will then play the f irst track/
f ile in the f irst main f older on the
f irst disc f or about 10 seconds. If you
do nothing, the system will then play
the f ollowing f irst track/f ile f or 10
seconds each. When it plays a track/
file that you want to continue
listening to, press and hold the
SCAN button again. Each time you press and release
the SCAN button, the mode
changes from scan, disc scan,
then to normal play.
Each time you press and release the
SCAN button, the mode changes
f rom f ile scan, f older scan, disc scan,
then to normal play. When the f irst track on the last disc,
or the f irst f ile in the last main f older
in the last disc begins to play, the
disc scan mode will be canceled.
Pressing either side of the skip bar
or selecting a dif f erent f older with
the FOLDER or CATEGORY bar
also turns off the scan feature.
You can also select the disc scan
f eature f rom the menu items with
the selector knob (see page ).Press the eject button ( ) to
remove the disc. If you eject the
disc, but do not remove it from the
slot, the system will automatically
reload the disc after 10
seconds and begin playing.
You can also eject the disc when the
ignition switch is of f .
To play the radio when a disc is
playing,presstheAM,FMorXM(if
equipped) button. Press the CD
(CD/AUX on models with XM
Radio) button again to switch back to
the disc changer.
You can also press the MODE
buttononthesteeringwheelto
change modes.
154
In MP3 or WMA mode
D-SCAN To Stop Playing a Disc
Playing Discs(Models without navigation system)
156

Features

2012 Crosstour
