When a child reaches the
recommended weight or height limit
for a forward-facing child seat, the
child should sit in a back seat on a
booster seat and wear a lap/shoulder
belt.
The f ollowing pages give
instructions on how to check proper
seat belt f it, what kind of booster
seat to use if one is needed, and
important precautions f or a child
who must sit in f ront.To determine if a lap/shoulder belt
properly f its a child, have the child
put on the seat belt, then ask
yourself :Does the child sit all the way back
against the seat?
Do the child’s knees bend
comf ortably over the edge of the
seat?
1.
2.
CONT INUED
Protecting L arger Children
Checking Seat Belt Fit
Driver and Passenger Saf ety
49
Allowing a child age 12 or under
to sit in front can result in injury
or death if the passenger’s front
airbag inflates.
If a child must ride in front,
move the vehicle seat as far
back as possible, use a booster
seat if needed, have the child
sit up properly and wear the
seat belt properly.

Does the shoulder belt cross
between the child’s neck and arm?
Is the lap part of the belt as low as
possible, touching the child’s
thighs?
Will the child be able to stay
seated like this for the whole trip?
If you answer yes to all these
questions, the child is ready to wear
the lap/shoulder belt correctly. If
you answer no to any question, the
child needs to ride on a booster seat. A child who has outg rown a forward-
facing child seat should ride in a
back seat and use a booster seat
until the lap/shoulder belt fits them
properly without the booster. Some
states and Canadian provinces
also require children to use a booster
seat until they reach a given age or
weight (e.g., 6 years or 60 lbs). Be
sure to check current laws in the
states or provinces where you intend
to drive.
Booster seats can be high-back or
low-back. Whichever style you select,
make sure the booster seat meets
f ederal saf ety standards (see page ) and that you f ollow the booster
seat maker’s instructions.
3.
4.
5.
35
Protecting L arger Children
Using a Booster Seat
50

If a child who uses a booster seat
must ride in front, move the vehicle
seat as far back as possible and be
sure the child is wearing the seat
belt properly.
A child may continue using a booster
seat until the tops of their ears are
even with the top of the vehicle’s or
booster’s seat-back. A child of this
height should be tall enough to use
the lap/shoulder belt without a
booster seat. If
the passenger’s front airbag
inflates in a moderate to severe
frontal collision, the airbag can cause
serious injuries to a child who is
unrestrained, improperly restrained,
sitting too close to the airbag, or out
of position.
A side airbag also poses risks. If any
part of a larger child’s body is in the
path of a deploying side airbag, the
child could receive possibly serious
injuries. Of
course, children vary widel y. And
while age may be one indicator of
when a child can safely ride in front,
there are other important f actors you
should consider.
Physically, a child must be large
enough f or the lap/shoulder belt to
properly f it (see pages and ). If
the seat belt does not f it properly,
with or without the child sitting on a
booster seat, the child should not sit
in f ront.
To saf ely ride in f ront, a child must
be able to f ollow the rules, including
sitting properly, and wearing the seat
belt properly throughout a ride.
The National Highway Traffic Safety
Administration and Transport
Canada recommend that all children
age 12 and under be properly
restrained in a back seat.
14 49
CONT INUED
Protecting L arger Children
When Can a L arger Child Sit in
Front
Physical Size
Maturity
Driver and Passenger Saf ety
51

If you decide that a child can saf ely
ride up f ront, be sure to:Caref ully read the owner’s manual,
and make sure you understand all
seat belt instructions and all saf ety
inf ormation.
Have the child sit up straight, back
against the seat, and feet on or
near the f loor. Move the vehicle seat to the rear-
most position. Devices intended to
improve a child’s comf ort or
reposition the shoulder part of a
seat belt can make the belt less
ef f ective and increase the chance
of serious injury in a crash.
This could result
in serious neck injuries during a
crash.
Check that the child’s seat belt is
properly and securely positioned. If they do, they could be very seriously injured in a
crash.This could
cause very serious injuries during
a crash. It also increases the
chance that the child will slide
under the belt in a crash and be
injured.
Supervise the child. Even a mature
child sometimes needs to be
reminded to f asten the seat belt or
sit properly.Do not put any accessories on a seat belt.
Do not let a child wear a seat belt
across t he neck.
T wo children should never use thesame seat belt .
Do not let a child put the shoulder
part of a seat belt behind t he backor under t he arm.Additional Saf ety Precautions
Protecting L arger Children
52

Your vehicle’s exhaust system
contains carbon monoxide gas.
Carbon monoxide should not enter
the vehicle in normal driving if you
maintain your vehicle properly and
f ollow the inf ormation on this page.
Have the exhaust system inspected
f or leaks whenever:High levels of carbon monoxide can
collect rapidly in enclosed areas,
such as a garage. Do not run the
engine with the garage door closed.
Even with the door open, run the
engine only long enough to move the
vehicle out of the garage.
The vehicle is raised f or an oil
change.
You notice a change in the sound
of the exhaust.
The vehicle was in an accident
that may have damaged the
underside. With the tailgate open, airflow can
pull exhaust gas into your vehicle’s
interior and create a hazardous
condition. If you must drive with the
tailgate open, open all the windows
and set the heating and cooling
system as shown below.
If you must sit in your parked vehicle
with the engine running, even in an
unconf ined area, adjust the heating
and cooling system as f ollows:
Select the f resh air mode.
Select the mode.
Turn the f an on high speed.
Set the temperature control to a
comfortable setting.
1.
2.
3.
4.
Carbon Monoxide Hazard
Driver and Passenger Saf ety
53
Carbon monoxide gas is toxic.
Breathing it can cause
unconsciousness and even kill
you.
Avoid any enclosed areas or
activities that expose you to
carbon monoxide.

These labels are in the locations
shown. They warn you of potential
hazards that could cause serious
injury or death. Read these labels
caref ully.
If a label comes of f or becomes hard
to read (except for the U.S.
dashboard label which may be
removed by the owner), contact your
dealer f or a replacement.
U.S. models onlyCanadian models
U.S. models
Saf ety L abels
54
DASHBOARD SUN VISORS

Canadian models
U.S. models
U.S. models
Canadian models
Saf ety L abels
Driver and Passenger Saf ety
55
HOOD RADIATOR CAPDOORJAMBS

This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your vehicle. All the essential
controls are within easy reach............................
Control Locations .58
............................
Instrument Panel .59
..........
Instrument Panel Indicators .60
.............................................
Gauges .66
...................................
Trip Meter .66
.....................................
Odometer .67
..................................
Fuel Gauge .67
..........
Check Fuel Cap Indicator .67
..................
Maintenance Minder .68
Controls Near the Steering ...........................................
Wheel .69
.
Windshield Wipers and Washers .70
.........
Turn Signals and Headlights .71
........
Instrument Panel Brightness .73
.................
Hazard Warning Button .73
.................
Rear Window Def ogger .73
..........
Steering Wheel Adjustment .74
...............................
Keys and Locks .75
........................
Immobilizer System .76
................................
Ignition Switch .77
......................................
Door Locks .78
......................
Power Door Locks .78
..............
Childproof Door Locks .79
............................................
Tailgate .80
.......................
Remote Transmitter .82
.................................................
Seats .85 ..............................
Power Windows .93
.............................................
Mirrors .94
.................................
Parking Brake .95
...........
Interior Convenience Items .96
.......................
Beverage Holders .97
....................................
Glove Box .97
...........
Accessory Power Socket .98
......................................
Sun Visor .98
.................................
Interior Lights .98
Instruments and Controls
Inst rument s and Cont rols
57

Î
Î
Î : If equipped
Control Locations
58
HOOD RELEASE
HANDLE
ACCESSORY POWER
SOCKET
GAUGES
AUDIO
SYSTEM
HAZARD
WARNING
BUTTON
PARKING BRAKE HEATING/COOLING
CONTROLS
PASSENGER AIRBAG
OFF INDICATOR AUTOMATIC
TRANSMISSION
MANUAL TRANSMISSION
PASSENGER’S
FRONT
AIRBAG
DRIVER’S
FRONT AIRBAG
(P.9, 25)
(P.94) MIRROR
CONTROLS
POWER WINDOW
SWITCH POWER
DOOR
LOCK MASTER
SWITCH
(P.78)
(P.93)
(P.134)
(P.31) (P.98)(P.95)
(P.149) (P.151)(P.100) (P.105)
(P.73)
INSTRUMENT
PANEL
INDICATORS (P.60)
(P.66)
(P.9, 31)
