Page 671 of 1413

HONDA INTEGRA 1994 4.G Workshop Manual Steering Gearbox
Installation (contd)
10. Install the steering joint cover with the clamps andcliDs.
STEERING JOINT COVER
11. Connect the fluid lines to the valve bodv unit.
CLIP
RETURN HOSE
17-64
38

Page 672 of 1413

HONDA INTEGRA 1994 4.G Workshop Manual 15.Thread the right and lefi tie-rod ends onto the rack
an eoual number of turns.
TIE-ROO ENDTIE.ROD LOCKNUT
R€connect the tie-rod ends to the steering knuckles,
tighten the castle nut to the specif

Page 673 of 1413

HONDA INTEGRA 1994 4.G Workshop Manual

Page 674 of 1413

HONDA INTEGRA 1994 4.G Workshop Manual

Page 675 of 1413

HONDA INTEGRA 1994 4.G Workshop Manual

Page 676 of 1413

HONDA INTEGRA 1994 4.G Workshop Manual

Page 677 of 1413

HONDA INTEGRA 1994 4.G Workshop Manual

Page 678 of 1413

HONDA INTEGRA 1994 4.G Workshop Manual

Page 679 of 1413

HONDA INTEGRA 1994 4.G Workshop Manual

Page 680 of 1413

HONDA INTEGRA 1994 4.G Workshop Manual
