display HONDA ODYSSEY 2014 RC1-RC2 / 5.G Navigation Manual

55

Routing
Avoided Area
System Setup
Avoided AreaHSETTINGS button
 Navi Settings
 Routing
 Avoided Area
Specify up to five areas to avoid (e.g., road construction, closures), if possible, when
the system calculates routes to your destination.
1.Move r and rotate i to select
New Area, or rotate i to select
an existing area to edit.
2.Rotate i to select Name to label
the area to avoid. Press u.
3.Enter a name or title. Move r to
select OK.
4.Rotate i to select Area to define
the area to avoid. Press u.
The following options are available (after an area is set):
•View Area: Displays the selected avoid area on the map.
•Delete: Deletes the selected avoid area.
1Avoided Area
The maximum size of an “avoid area” is
approximately 1 square mile.
If your selected area contains a freeway, you are
asked “Do you want to avoid freeways?”
Answering “No” allows you to use a route
through an avoid area on a freeway without any
pop-up messages.
You can select areas to avoid, however you
cannot select roads or areas that you want the
system to use for routing.
You can enter up to 25 characters for the name.

56

Routing
Avoided Area
System Setup
5.Rotate i to select a method for
specifying the area. Press u.
The following options are available:
•Address: Specify the general area by entering an address.
2
Address
P. 86
•Map Input: Specify the general area by map input.
2
Map Input
P. 105
6.If you select Map Input, scroll the
map to position the cursor over
your desired start point, adjusting
the map scale as necessary. Press
u to mark the start point.

To redo the area selection, press
the BACK button.
7.Scroll the map to “draw” the area.
Press u to mark the end point.
8.Press u to select OK.

The area you specify is displayed
in the list of areas to avoid.
1Avoided Area
Avoid area can be set in the 1/20, 1/8, or
1/4 mile map scales.
Cursor
Avoid area

57System Setup
GuidanceHSETTINGS button
 Navi Settings
 Guidance
Choose various settings that determine the navigation system functionality during
route guidance.
Rotate i to select an item. Press u.
The following items are available:
•Guidance Mode: Sets whether to display only the map screen or a split map-
guidance screen.
2
Guidance Mode
P. 58
•Street Name Guidance: Sets whether to read out the street names during voice
guidance.
2
Street Name Guidance
P. 60
•Non-map screens (models without LaneWatch): Sets whether the guidance
screen interrupts the screen display.
2
Non-map screens
P. 61
•Next Maneuver Pop Up (models with LaneWatch): Sets whether to display the
guidance information to the destination or the next waypoint.
2
Next Maneuver Pop up
P. 62
•Guidance Point: Sets whether to display the guidance information to the
destination or the next waypoint.
2
Guidance Point
P. 63
•Estimated Time: Sets whether to display the remaining time or arrival time to the
guidance point.
2
Estimated Time
P. 64

58

Guidance
Guidance Mode
System Setup
Guidance ModeHSETTINGS button
 Navi Settings
 Guidance
 Guidance mode
Select the display mode for the map and guidance screens.
Rotate i to select an option. Press
u.
The following options are available:
•Map (factory default): Displays only the map screen. When you approach a
guidance point, the next guidance point appears.
1Guidance Mode
The guidance mode can also be selected from
the map menu.
2Map Menu P. 116
Press the NAV button to switch between the
map, next guidance direction, and a list of
guidance directions.
Near the next
guidance point Map screen Next Maneuver screen
Next guidance point

59

Guidance
Guidance Mode
System Setup
•Direction List: Displays the map and direction list simultaneously on the map
screen. When you approach a guidance point, the next guidance point appears.
•Next Maneuver: Displays the map and next guidance point simultaneously on
the map screen.
Guidance direction listNear the next
guidance point
Next guidance point Direction List screenNext Maneuver screenNext guidance pointNear the next
guidance point Next Maneuver screenNext Maneuver screen

61

Guidance
Non-map screens
System Setup
Non-map screensHSETTINGS button
 Navi Settings
 Guidance
 Non-map screens
The navigation system temporarily interrupts the screen display to view the guidance
screen as you approach a guidance point.
Rotate i to select an option. Press
u.
The following options are available:
•On: The guidance screen interrupts other mode screens (e.g., audio, phone, etc,
except the rear view camera mode).
•Off (factory default): Disables the feature.
Models without LaneWatch

62

Guidance
Next Maneuver Pop up
System Setup
Next Maneuver Pop upHSETTINGS button
 Navi Settings
 Guidance
 Next Maneuver Pop up
The navigation system temporarily interrupts the screen display to view the guidance
screen as you approach a guidance point.
Rotate i to select an item. Press u.
The following items are available:
•LaneWatch: Sets whether to view the guidance screen while displaying the
LaneWatch screen.
On (factory default): The guidance screen interrupts the LaneWatch screen.
Off: Disables the feature.
•Non-map Screens: Sets whether to view the guidance screen while displaying
other mode (e.g., audio, phone, etc.) screen.
On: The guidance screen interrupts other mode screens (except the rear view
mode).
Off (factory default): Disables the feature.
Models with LaneWatch

63

Guidance
Guidance Point
System Setup
Guidance PointHSETTINGS button
 Navi Settings
 Guidance
 Guidance Point
Set the guidance point to display on the map screen.
Rotate i to select an option. Press
u.
The following options are available:
•Destination (factory default): Displays the remaining/arrival time and distance to
the destination.
•Next Point: Displays the remaining/arrival time and distance to the next
waypoint.

64

Guidance
Estimated Time
System Setup
Estimated TimeHSETTINGS button
 Navi Settings
 Guidance
 Estimated Time
Select the estimated time to display on the screen.
Rotate i to select an option. Press
u.
The following options are available:
•Arrival: Displays the arrival time to the destination or the next waypoint.
•Remaining (factory default): Displays the remaining time to the destination or the
next waypoint.

65System Setup
MapHSETTINGS button
 Navi Settings
 Map
Select the landmark icons to display on the map, change the orientation of the map,
display your current location, and learn the meaning of the icons, colors, and
symbols displayed on the map.
Rotate i to select an item. Press u.
The following items are available:
•Show Icon on Map: Selects the icons to display on the map.
2
Showing Icons on Map
P. 67
•Color (Day): Selects the color of the map for the Day mode.
2
Color
P. 69
•Color (Night): Selects the color of the map for the Night mode.
2
Color
P. 69
•View: Selects the map orientation (North-up, Heading-up, or 3D map).
2
View (Map Orientation)
P. 72
•3D Angle Adjustment: Adjusts the viewing angle for the 3D map.
2
3D Angle Adjustment
P. 73
•Straight Line Guide: Sets whether to display a straight guideline to the
destination or waypoint.
2
Straight Line Guide
P. 73
Continued
