248Owner Assistance
If you believe that your vehicle
has a defect which could cause a
crash or could cause injury or
death, you should immediately
inform the National Highway
Traffic Safety Administration
(
NHTSA) in addition to notifying
American Honda Motor Co., Inc.
If
NHTSA receives similar
complaints, it may open an
investigation, and if it finds that a
safety defect exists in a group of
vehicles, it may order a recall and
remedy campaign. However,
NHTSA cannot become involved
in individual problems between
you, your dealer, or American
Honda Motor Co., Inc. To contact
NHTSA, you may
either call the Auto Safety Hotline
toll free at 1-800-424-9393 (or
202-366-0123 in the Washington,
D.C. area) or write to:
NHTSA
U.S. Department of Transportation
Washington, D.C. 20590
You can also obtain other
information about motor vehicle
safety from the Hotline. The burning of gasoline in your
vehicle’
s engine produces several
by-products. Some of these are
carbon monoxide (
CO), oxides of
nitrogen (
NOx), and hydrocarbons
(
HC). Gasoline evaporating from
the tank also produces
hydrocarbons. Controlling the
production of
NOx, CO, and HC is
important to the environment.
Under certain conditions of
sunlight and climate,
NOx and HC
react to form photochemical
“smog.” Carbon monoxide does
not contribute to smog creation,
but it is a poisonous gas.
The Clean Air Act
The United States Clean Air Act
sets standards for automobile
emissions. It also requires that
automobile manufacturers explain
to owners how their emissions
controls work and what to do to
Emissions ControlsReporting Safety Defects

249Owner Assistance
maintain
them. This section
summarizes how the emissions
controls work. Scheduled
maintenance is on page 204.
Crankcase Emissions
Control System
Your vehicle has a Positive
Crankcase Ventilation System.
This keeps gasses that build up in
the engine ’s crankcase from going
into the atmosphere. The Positive
Crankcase Ventilation valve routes
them from the crankcase back to
the intake manifold. They are then
drawn into the engine and burned.
Evaporative Emissions
Control System
As gasoline evaporates in the fuel
tank, an evaporative emission
control canister filled with
charcoal adsorbs the vapor. It is
stored in this canister while the engine is off. After the engine is
started and warmed up, the vapor
is drawn into the engine and
burned during driving.
Onboard Refueling Vapor
Recovery
The Onboard Refueling Vapor
Recovery (ORVR) system captures
the fuel vapors during refueling.
The vapors are adsorbed in a
canister filled with activated
carbon. While driving, the fuel
vapors are drawn into the engine
and burned off.
Exhaust Emissions Controls
The exhaust emission controls
include four systems: Fuel
Injection, Ignition Timing Control,
Exhaust Gas Recirculation, and
Three-Way Catalytic Converter.
These four systems work together
to control the engine
’s combustion and minimize the amount of HC,
CO, and NOx that comes out the
tailpipe. The exhaust emission
control systems are separate from
the crankcase and evaporative
emission control systems.
Fuel Injection System
The Fuel Injection System uses
sequential multiport fuel injection.
It has three subsystems: Air
Intake, Engine Control, and Fuel
Control. The Engine Control
Module (
ECM) uses various
sensors to determine how much
air is going into the engine. It then
controls how much fuel to inject
under all operating conditions.
Ignition Timing Control System
This system constantly adjusts the
ignition timing, reducing the amount
of HC, CO and NOx produced.

250Owner Assistance
Exhaust Gas Recirculation (EGR)
System
The Exhaust Gas Recirculation
(
EGR) system takes some of the
exhaust gas and routes it back into
the intake manifold. Adding
exhaust gas to the air/fuel mixture
reduces the amount of NOx
produced when the fuel is burned.
Three-Way Catalytic Converter
The Three-Way Catalytic
Converter is in the exhaust
system. Through chemical
reactions, it converts HC, CO, and
NOx in the engine’ s exhaust to
carbon dioxide (CO
2), dinitrogen
(N
2), and water vapor. Replacement Parts
The emissions control systems are
designed and certified to work
together in reducing emissions to
levels that comply with the Clean
Air Act. To make sure the
emissions remain low, you should
use only new Honda genuine
replacement parts or their
equivalent for repairs. Using
lower quality parts may increase
the emissions from your vehicle.
The emissions control systems are
covered by warranties separate
from the rest of your vehicle.
Read your warranty manual for
more information.
The tires on your vehicle meet all
U.S. Federal Safety
Requirements. All tires are also
graded for treadwear, traction, and
temperature performance
according to Department of
Transportation (
DOT) standards.
The following explains these
gradings.
Uniform Tire Quality
Grading
Quality grades can be found
where applicable on the tire
sidewall between the tread
shoulder and the maximum
section width. For example:
Treadwear 200
Traction AA
Temperature A
All passenger car tires must
conform to Federal Safety
Requirements in addition to these
grades.
DOT Tire
Quality Grading

251Owner Assistance
Treadwear
The treadwear grade is a
comparative rating based on the
wear rate of the tire when tested
under controlled conditions on a
specified government test course.
For example, a tire graded 150
would wear one-and-a-half
(1-1/2) times as well on the
government course as a tire
graded 100. The relative
performance of tires depends
upon the actual conditions of their
use, however, and may depart
significantly from the norm due to
variation in driving habits, service
practices and differences in road
characteristics and climate.
Traction – AA, A, B, C
The traction grades from highest
to lowest are AA, A, B, and C.
Those grades represent the tire’sability to stop on wet pavement as
measured under controlled
conditions on specified
government test surfaces of
asphalt and concrete. A tire
marked C may have poor traction
performance.
Warning: The traction grade
assigned to this tire is based on
straight-ahead braking traction
tests, and does not include
acceleration, cornering,
hydroplaning, or peak traction
characteristics.
Temperature – A, B, C
The temperature grades are A (the
highest), B and C, representing
the tire’
s resistance to the
generation of heat and its ability
to dissipate heat when tested
under controlled conditions on a specified indoor laboratory test
wheel. Sustained high temperature
can cause the material of the tire
to degenerate and reduce tire life
and excessive temperature can
lead to sudden tire failure. The
grade C corresponds to a level of
performance which all vehicle
tires must meet under the Federal
Motor Vehicle Safety Standard
No. 109. Grades B and A
represent higher levels of
performance on the laboratory test
wheel than the minimum required
by law.
Warning: The temperature grade
for this tire is established for a tire
that is properly inflated and not
overloaded. Excessive speed,
underinflation, or excessive
loading either separately or in
combination, can cause heat
build-up and possible tire failure.

253
Purchasing Factory-Authorized Manuals
The following publications covering the operation and
servicing of your vehicle can be obtained from Helm
Incorporated, either by filling out the form or, for
credit card holders, by calling toll free. For manuals
prior to the year shown below, contact Helm
Incorporated, P.O. Box 07280, Detroit, MI 48207 or
call 1-800-782-4356.
Publication
Form
NumberForm DescriptionPrice
Each *
61S3L082002 Passport Service Manual$68.00
61S3L092002 Passport Fuel & Emissions
Supplement$35.00
61S3L08EL2000–02 Passport Electrical
Troubleshooting Manual$48.00
31S3L6402002 Passport Owner’s Manual**$34.00
HON-ROrder form for previous years –
Indicate year and model desired.FREE
* Prices are subject to change without notice and without incurring obligation.
**Includes Off-Road Driving Information
ORDER TOLL FREE: 1-800-782-4356
(NOTE: For Credit Card Holder Orders Only)
Monday – Friday 8:00 a.m. – 6:00 p.m. EST
MINIMUM CREDIT CARD PURCHASE $10.00
OR
By completing this form you can order the materials
desired. You can pay by check or money order or charge
to your credit card. Mail to Helm, Incorporated at the
address shown on the back of the order form.
PUBLICATION FORMVEHICLE MODELQTYPRICETOTALPUBLICATION FORMNUMBERNAMEYEARQTY.PRICE EACH*TOTALPRICE
*Prices are subject to change withoutTOTAL MATERIAL*Prices are subject to change without
notice and without incurring obligation.
O d il d ithi 10 d
MICH. PURCHASES ADD
6% SALES TAX
Orders are mailed within 10 days.Pleaseallow adequate time for delivery.HANDLING CHARGE$6.00Please allow adequate time for delivery.GRAND TOTAL
Authorized Manuals

254Service Manual
This manual covers maintenance and recommended
procedures for repair to engine and chassis
components. It is written for the journeyman
mechanic, but is simple enough for most mechanically
inclined owners to understand.
Electrical Troubleshooting Manual
This manual complements the Service Manual by
providing in-depth troubleshooting information for
each electrical circuit in your car.
NOTE: Dealers and Companies please provide dealer or company name and also th\
e name of the
person to whose attention the shipment should be sent. For purchases out\
side U.S.A. please write to
the address below for quotation.
(CUSTOMER NAME)
(ATTENTION)
(CITY) (STREET ADDRESS – NO P.O. BOX NUMBERS)
(APT. NO.)
(STATE) (ZIP CODE)
DAYTIME TELEPHONE NO. AREA
CODE
()
Check or money order enclosed payable to Helm, Inc.
MasterCardVISACheck here if your billing address is different
from the shipping address shown above.
Account
Number
Expiration Mo-Yr
(CUSTOMER SIGNATURE) (DATE)
These publications cannot be returned for credit without receiving advan\
ce authorization within 14 days of
delivery. On returns, a restocking fee may be applied against the original order\
.
P.O. BOX 07280 •DETROIT, MI 48207 •1-800-782-4356
(U.S. funds only – do not send cash.)

255
A
ABS.
See Anti-Lock Brake
System
Accessories, Installation
173. . . .
ACCESSORY
(Ignition Key Position)101. . . . .

\b
\b\f

 117
\b\b\b\b\b
Adults\b

 10
\b\b\b\b\b\b\b\b\b\b\b
Airbags (SRS)7. . . . . . . . . . . . .
\f\b\b
\b 19
\b\b\b\b
Air Cleaner Filter170, 214. . . . . .
Air Conditioning Maintenance
221. . . . . . . . . . .
Usage
120. . . . . . . . . . . . . . . . .
Air Filter. See Air Cleaner Filter
Air Outlets (Vents)
124. . . . . . . . .
Air Pressure, Tires
239. . . . . . . . . Alcohol and Driving
4. . . . . . . .
Alcohol in Gasoline
200. . . . . . . .
Alternator Belt. See Drive Belts
Antifreeze
217. . . . . . . . . . . . . . . .
Anti-Lock Brake System Indicator
67. . . . . . . . . . . . . . .
Operation
159. . . . . . . . . . . . . .
Anti-Theft Steering Column Lock
102. . . .
System
152. . . . . . . . . . . . . . . .
Appearance Care. See Cleaning
Ashtray
116. . . . . . . . . . . . . . . . . .
Assist Grip
115. . . . . . . . . . . . . . .
Audio System
125. . . . . . . . . . . . .
Automatic Transmission
76. . . .
Capacity, Fluid
237. . . . . . . . . .
Driving Pattern Selector
81. .
Fluid Temperature Indicator
70
Oil Temperature Indicator70.
Shift Lever Position Indicator
76. . . . . . .
Shift Lock
78. . . . . . . . . . . . .
Transfer Control, 4
WD80. . .
B
Battery198. . . . . . . . . . . . . . . . . .
Charging System Indicator
62
Jump Starting184. . . . . . . . . . .
Maintenance
198. . . . . . . . . . .
Specifications
238. . . . . . . . . .
Before Driving
156. . . . . . . . . . . .
Belts, Seat
6. . . . . . . . . . . . . . . .
Additional Information
41. . .
Beverage Holder
113. . . . . . . . . .
Body Repair
225. . . . . . . . . . . . . .
Brakes Anti-Lock Brake System
159. .
Brake System Indicator
61. . .
Index

256
Break-in158. . . . . . . . . . . . . . .
Fluid
219. . . . . . . . . . . . . . . . . .
Parking
86. . . . . . . . . . . . . . . .
Power
161. . . . . . . . . . . . . . . . .
Wear Indicators
162. . . . . . . . .
Break-in, New Vehicle
158. . . . . .
Brightness Control, Instrument Panel. See Illumination Control
Brights, Headlights
62. . . . . . . .
Bulb Replacement Specifications
243. . . . . . . . . . . .
C
Capacity Charts235. . . . . . . . . . .
Carbon Monoxide Hazard
47. . .
Care and Maintenance
195. . . . . .
Cargo Loading
233. . . . . . . . . . . . . . .
Carrying
17 . . . . . . . . . . . . . . . Cassette Player
Care
141. . . . . . . . . . . . . . . . . .
Operation
128. . . . . . . . . . . . . .
Catalytic Converter, Three-Way
172. . . . . . . . . . . . . .
CAUTION, Explanation ofiv. . .
CD Changer131. . . . . . . . . . . . . .
Certification Label
234. . . . . . . . .
Chains, Tire
168. . . . . . . . . . . . . .
Changing Oil How to
212. . . . . . . . . . . . . . . .
When
204, 205, 211. . . . . . . . .
Changing a Flat Tire
186. . . . . . .
Lifting Points
187. . . . . . . . . . .
Changing Engine Coolant
218. . .
Charging System Indicator
62. .
Check Engine Light
63. . . . . . . .
Checklist, Before Driving
156. . . Children, Protecting
18. . . . . . . .
Child-Safe Door Locks
105. . . . .
Child Seats, General Guidelines
22. . . . . . .
Cigarette Lighter
116. . . . . . . . . .
Circuit Breaker, Checking the
108
Cleaner, Air214. . . . . . . . . . . . . .
Cleaning Exterior
224. . . . . . . . . . . . . . .
Interior
226. . . . . . . . . . . . . . . .
Seat Belts
229. . . . . . . . . . . . . .
Vinyl
229. . . . . . . . . . . . . . . . .
Clock, Setting the
153. . . . . . . . . .
Clutch Fluid
223. . . . . . . . . . . . . .
CO in the Exhaust
47, 249. . . . . .
Consumer Information
246. . . . . .
Control Locations
56. . . . . . . . .
Controls, Instruments and
55. . .

257

Controls Near
the Steering Wheel
Hazard Warning
76. . . . . . . . .
Headlights
72. . . . . . . . . . . . .
Illumination Control
73. . . . .
Rear Window Defogger
74. . .
Steering Wheel Adjustment
115
Turn Signals75. . . . . . . . . . . .
Windshield Wiper/Washer
70.
Rear Window Wiper/ Washer
74. . . . . . . . . . . .
Coolant Adding
218. . . . . . . . . . . . . . . .
Capacity
236. . . . . . . . . . . . . . .
Checking
217. . . . . . . . . . . . . .
Proper Solution
218. . . . . . . . .
Temperature Gauge
60. . . . . .
Corrosion Protection
225. . . . . . .
Courtesy Lights
112. . . . . . . . . . . Crankcase Emissions
Control System
249. . . . . . . . . .
Cruise Control Operation
147. . . .
Customer Relations Information
246. . . . . . . . . . . . .
D
DANGER, Explanation ofiv. . . .
Dashboard
56. . . . . . . . . . . . . . .
Defects, Reporting Safety
248. . .
Defogger, Rear Window
74. . . .
Defrosting the Windows
122. . . .

\b 153
\b\b\b\b\b\b\b\b\b\b\b\b\
\b\b\b
Dimensions243. . . . . . . . . . . . . .
Dimming the Headlights
72. . . .
Dipstick, Engine Oil
200, 213. . .
Directional Signals
75. . . . . . . . . Disc Brake Wear Indicators
162. .
Dome Light
111. . . . . . . . . . . . . .
Door Locks
9. . . . . . . . . . . . . . . .
Power
104. . . . . . . . . . . . . . . . .
Doors, Close and Lock
10. . . . . .
DOT Tire Quality Grading
251. . .
Downshifting, 5-Speed Manual Transmission
84. . . . .
Drive Belts
222. . . . . . . . . . . . . . .
Driving, On-Road Fuel Economy
170. . . . . . . . . .
In Bad Weather
168. . . . . . . . .
In Foreign Countries
173. . . . .
On Slippery Surfaces
162. . . . .
E
Economy, Fuel170. . . . . . . . . . . .
EGR System
250. . . . . . . . . . . . . .
Emergency Brake
86. . . . . . . . . .
