238Technical Data
Front Suspension
Independent wishbone arms, torsion bar springs with
stabilizer bar.
Front Wheel Alignment
Toe-in2

2 mm (0.08 in.)–
Camber0°
30No more than 30
side-to-side variation
Caster2
30
45No more than 30
side-to-side variation
Rear Suspension
5-link, coil spring type with stabilizer bar and direct
double-acting shock absorbers.
Rear Wheel Alignment
Toe-in0
5 mm (0.2 in.)
Camber0°
1°
Toe-Axis
1

Steering
Rack and pinion.
Service Brake
Hydraulic Front: Disc brake.
Rear: Self-adjusting drum brake, leading-trailing (2
WD model).
Disc brake (4
WD model).
Parking Brake
Mechanical, operating on rear wheels (2
WD model).
Mechanical, drum in disc, duo-servo, manual-adjusting,
operating on rear wheels (4
WD model).
Battery
Voltage (V)12
Cold-cranking performance (Amp)600
Reserve capacity (Min.)125
BCI group no.24

Technical Data239
Rear Axle
Models2WD4WDModels2WD4WD
Gear ratio4 3004 300Gear ratio4.3004.300
Lubricant capacity1.87 U.S. quarts(1.77 liters)
Front Axle (4WD Model)
Gear ratio4.300
Lubricant capacity1.6 U.S. quarts (1.5 liters)
Shift-on-the-Fly System
Lubricant capacity0.13 U.S. quarts (0.12 liters)
Wheels and Tires
Tire size225/75R16245/70R16
Wheel size16 x 7 JJ16 x 7 JJ
Tire pressure29 psi (200 kPa)26 psi (180 kPa)
Wheel nut
tightening torque87 lb.ft (118 N.m )

240Technical Data
Fuses
Fuse boxes are installed on the left side of the
instrument panel and the right side of the engine
compartment. Each fuse box contains spare fuse
cartridges.
Replacing a fuse with one that has a higher rating
greatly increases the chances of damaging the
electrical system. If you do not have a replacement
fuse with the proper rating for the circuit, install one
with a lower rating.

Technical Data241
Fuse Box: Instrument Panel
AmperageApplicability
120AAccessory power sockets
2––––
315ACigarette lighter
415ADash/parking lights
510AInterior lights
615ABrake lights, cruise control
720APower door locks
810AMirror defoggers
915ARear window defogger
1015ARear window defogger
1115AGauges, indicators
1215ACharging system, fuel injection
1315AIgnition system
1415ATurn signals, backup lights
1515AABS, 4WD, cruise control
1620AWindshield wiper/washer
1710ARear wiper/washer
1810ASecurity & keyless entry
1915AAudio system
2020AStarter
2130APower windows, moonroof
2210ASRS
23––––

242Technical Data
Fuse Box: Engine Compartment
AmperageApplicability
115AHazard Warning Light
210AHorn
3––––
420ABlower
510AAir conditioner
6––––
7––––
810AHeadlight; left
910AHeadlight; right
1015AFog lights
1110AO2 Sensor
1220AFuel pump
1315AECM
14––––
1560APower distribution
16100AMain
1760AABS
1830ACondenser fan
19––––

Technical Data243
Light Bulbs
ApplicationBulb No.QuantityRating
Candlepower
Front Lights
Headlight – Halogen
Fog
Turn signal & Parking light
Sidemarker9004
10342
2
265/45 watts
55 watts 21/5
Rear LightsBack-up
License
Tail, Stop & Sidemarker
Turn signal
High-mounted stop light1156
–
1157
1156 –2
2
2
2
427 watts
5 watts
27/8 watts
27
5 watts
Interior Illumination A/C-heater cont.
Dome light
Instrument cluster
Stop light
Luggage light
Step light74
–
158/74 –
–
–1
1
3/6 or 2 2
1
41.4
7 watts 2/1.4
5 watts
5 watts
5 watts
Dimensions and Weights
Model2WD4WD
Wheelbase–106.4 in. (2,702 mm)
Overall
Spare tire:
under floor178.2 in. (4,525 mm)OverallLengthSpare tire: tailgate184.2 in. (4,678 mm)
OverallLX, EX70.4 in. (1,784 mm)OverallWidthEX-L71.1 in. (1, 805 mm)
OverallHeightP225/75R1668.6 in. (1,743 mm)Height
(At curb Wt.)P245/70R1668.8 in. (1,748 mm)
Tread Front59 6 in (1 515 mm)Tread Front59.6 in. (1,515 mm)
Tread Rear59 8 in (1 520 mm)Tread Rear59.8 in. (1,520 mm)
GVWR–4,950 lb
(2,250 kg)5,200 lb
(2,360 kg)
Note: GVWR—Gross Vehicle Weight Rating
