Hyundai Accent 2006 Owner's Guide

1
FEATURES OF YOUR HYUNDAI
7
!
DOOR LOCKS
NOTE: If the engine dies while driving after limp home procedure, you can start your engine within 8 seconds with-out limp home procedure again.
5. If the immobilizer indicator blinks for five seconds, you have to try the limp home procedure again from the beginning.
After doing the limp home procedure,you have to consult with your autho-rized Hyundai dealer as soon as pos- sible.
! CAUTION:
o If you fail to try the limp home procedure with the sequence of three times, you have to wait for about one hour to do the limp home procedure again.
o If you cannot start your engine in spite of limp home procedure, haveyour vehicle towed by an autho-rized Hyundai dealer.
B040A02Y-AAT B040B01A-AAT
Locking and Unlocking Front Doors With a Key
WARNING:
o Unlocked doors can be danger- ous. Before you drive away (espe- cially if there are children in the car), be sure that all the doors are securely closed and locked sothat the doors cannot be inadvert- ently opened from the inside. This helps ensure that the doors willnot be opened accidentally. Also, when combined with the proper use of seat belts, locking the doors helps keep occupants from being ejected from the car incase of an accident.
o Before opening the door, always
look for and avoid oncoming traf-fic.
o In case of accident, the door is
unlocked automatically (If In-stalled). o The door can be locked or unlocked
with a key.
o Lock the door by turning the key
toward the front of the vehicle and unlock it by turning the key toward the rear.
LOCK
UNLOCK
OMC025005

1FEATURES OF YOUR HYUNDAI
8
B040D01S-GAT Locking From the Inside To lock the doors from the inside, sim- ply close the door and push the lock switch to the "LOCK" position. Whenthis is done, neither the outside nor the inside door handle can be used.B040E04A-AAT Child-protector Rear Door Lock (If Installed) Your Hyundai is equipped with a "child- protector" rear door lock assembly.When the lock mechanism is engaged, the rear door cannot be opened from the inside. Its use is recommended when-ever there are small children in the rear seat.
NOTE: When the door is locked, the red mark on the switch is not visible.
B040C01MC-AAT Locking From the Outside The doors can be locked without a key. To lock the doors, first push the inside lock switch to the "LOCK" position sothat the red mark on the switch is not visible, then close the door. NOTE:
o If your vehicle is equipped with
central door locking system, the door will not lock if the key is leftin the ignition switch when the front doors are closed.
o When locking the door this way, be careful not to lock the door withthe ignition key left in the vehicle.
B040C04MC o To protect against theft, always
remove the ignition key, close all windows, and lock all doors and the trunk lid (4 Door)/tail gate (3 Door) when leaving your vehicleunattended.UNLOCKLOCK
OMC025006B040E01MC

1
FEATURES OF YOUR HYUNDAI
9THEFT-ALARM SYSTEM
To engage the child-protector feature so the door cannot be opened from theinside, move the child-protector lever to the " " position and close the door. Move the lever to the " " positionwhen normal door operation is desired. If you wish to be able to open the door from the outside, the outside door handle will function normally.
B070A01A-AAT (If Installed) This system is designed to provide protection from unauthorized entry intothe car. This system is operated in three stages: the first is the "Armed" stage, the second is the "Alarm" stage,and the third is the "Disarmed" stage. If triggered, the system provides an au- dible alarm with blinking of the turnsignal lights.NOTE:
o When pushing the front portion of the driver's door lock switch, all vehicle doors will lock. If any dooris open when the switch is de- pressed, the door will remain locked when closed.
o When pushing the rear portion of the switch, all vehicle doors willunlock.
o The central door locking is oper- ated by turning the key in thedriver's door lock toward the frontor rear of the vehicle.
B040G02HP-AAT Central Door Locks (If Installed) The central door locking switch is lo- cated on the driver's arm rest. It is operated by depressing the door lock switch.
B040G02MC

1FEATURES OF YOUR HYUNDAI
10
B070C01MC-GAT Alarm Stage The alarm will be activated if any of the following occurs while the car is parkedand the system is armed.
1) Any door, tail gate (3 Door) included,is opened without using the trans- mitter.
2) The trunk lid (4 Door) is opened without using the key.
3) The engine hood is opened. The alarming horn will sound and the turn signal lights will blink continuously for 27 seconds (E.C, Mideast only/Except E.C : This happens 3 times). To turn off the system, unlock the door with the transmitter.
NOTE:
1) If any door, trunk lid (4 Door)/tail gate (3 Door) or engine hood re- mains open, the system will notbe armed. If this happens, rearm the system as previously described.
2) Once the system is armed, only the trunk lid (4 Door) may be un-locked using the ignition key with-out disarming the system.
B070B01MC-GAT Armed Stage
B070B01MC
Park the car and stop the engine. Arm the system as described in the follow- ing paragraph.
1) Remove the ignition key from the ignition switch.
2) Make sure that the engine hood and trunk lid (4 Door)/tail gate (3 Door) are closed and latched.
3) Lock the doors using the transmitter of the keyless entry system.
After completion of the steps above, the turn signal lights will blink once to indicate that the system is armed. CAUTION:
Do not arm the system until all pas-sengers have left the car. If the sys- tem is armed while a passenger(s)remains in the car, the alarm may be activated when the remaining passenger(s) leaves the car.
!
CAUTION:
Avoid trying to start the engine while the system is armed.
!

1
FEATURES OF YOUR HYUNDAI
11
B070D01MC-GAT Disarmed Stage
The system will be disarmed when the driver's or passenger's door is unlocked by depressing the button on the trans- mitter after the system was armed. After completion of the step above, the turn signal lights will blink twice toindicate that the system is disarmed. If any door, trunk lid(4 Door)/tail gate(3 Door) or engine hood is not opened within 30 seconds, the system will be rearmed. B070D02AMC
NOTE: When the system is disarmed with the interior light switched to "DOOR", the interior light will illuminate for 30seconds.
B070F02A-GAT Keyless Entry System (If Installed) Locking doors
1. Close all doors.
2. Push the button on the transmitter.
3. At the same time all doors lock, the
turn signal lights will blink once toindicate that the system is armed.
Unlocking doors 1. Push the button on the transmitter once more after all doors were locked.
2. At the same time all doors unlock,
the turn signal lights will blink twice to indicate that the system is dis- armed.
CAUTION:
Only the transmitter can disarm the armed stage. If the transmitter does not disarm the system, it is neces- sary to take the following steps;
1. Unlock the door with the key, which will cause the alarm to be acti- vated.
2. Insert the key in the ignition key
cylinder and turn the ignition keyto "ON" position.
3. Wait for 30 seconds. After completing the steps above, the system will be disarmed.
!

1FEATURES OF YOUR HYUNDAI
12
!
WINDOW GLASS
B050A01A-AAT
To raise or lower the window, turn the window regulator handle clockwise or counterclockwise. WARNING:
When opening or closing the win- dows, make sure your passenger'sarms, hands and body are safely out of the way.
3. Remove the battery cover with a
coin.
4. Remove the old battery from the case and note the polarity. Make sure the polarity of the new batteryis the same (+side facing up), then insert it in the transmitter.
3FDA2015
B070E01MC-AAT Replacing the battery When the transmitter's battery begins to get weak, it may take several pusheson the button to lock or unlock the doors, and the LED will not light. Re- place the battery as soon as possible. Battery type : CR1220 Replacement instructions:
1. Remove the screw with a phillipsscrewdriver.
2. Carefully separate the case with a flat-head screwdriver. OMC025004

1
FEATURES OF YOUR HYUNDAI
13
!
B060A01MC-GAT POWER WINDOWS (If Installed)
The power windows operate when the ignition key is in the "ON" position. The main switches are located on the driver's
armrest and control the front (4/3 Door)
and rear windows (4Door) on both sides of
the vehicle. The windows may be openedby depressing the appropriate window switch and closed by pulling up the switch. To open the window on the driver's side,press the switch(1) halfway down. The window moves as long as the switch is operated. To fully open the driver's win-dow automatically, press the switch fully down. In automatic operation, the window will fully open even if you let go of theswitch. To stop at the desired opening, pull up and release the switch.
4 Door 3 Door
In order to prevent operation of the passenger front (4/3 Door) and rear windows (4Door), a window lockswitch(2) is provided on the armrest of
the driver's door. To disable the power windows, press the window lock switch.To revert to normal operation, press the window lock switch a second time. NOTE: The power windows can be operated for 30 seconds after the ignition key is turned to the "ACC" or "LOCK"positions, or removed from the igni- tion switch. If the front doors are opened during this 30 second pe-riod, the power windows can no longer be operated without the igni- tion key turned to the "ON" position. WARNING:
1) Be careful that someone's head, hands and body are not trappedby a closing window.
2) Never try to operate the main
switch on the driver's door andthe individual door window switch in opposing directions at the same time. If this is done, the windowwill stop and cannot be opened or closed.
3) Do not leave children alone in the car. Always remove the ignitionkey for their safety.
B060A01MC
B060A02MCOMC025015

1FEATURES OF YOUR HYUNDAI
14SEATS
Driver’s seat 1. Seat forward/rearward lock releaselever
2. Seatback recliner control lever 3. Seat cushion height control lever
(If Installed)
4. Seat warmer switch (If Installed) Front passenger’s seat 5. Seat forward/rearward lock release
lever
6. Seatback recliner control lever 7. Seat warmer switch (If Installed) Rear seats
8. Seatback folding lever (If Installed)
9. Armrest (If Installed)
B080A01MC-GAT
OMC025025A
4 Door3 Door

1
FEATURES OF YOUR HYUNDAI
15
!
!
To recline the seatback, lean forward to take your weight off it, then pull up on the recliner control lever at the outsideedge of the seat. Now lean back until the desired seatback angle is achieved. To lock the seatback into position,release the recliner control lever.
B080C01A-AAT Adjusting Seatback Angle
To move the seat toward the front or rear, pull the lock release lever upward. This will release the seat on its track so you can move it forward or rearward tothe desired position. When you find the position you want, release the lever and slide the seat forward or rearward on itstrack until it locks into the desired position and cannot be moved further. WARNING:
To ensure the seat is locked se-curely, attempt to move the seat for- ward or rearward without using thelock release lever.
B080A01FC-GAT ADJUSTABLE SEATS
B080B02FC-GAT FRONT SEATS Adjusting Seat Forward andRearward
WARNING:
Never attempt to adjust the seat while the vehicle is moving. This could result in loss of control or an acci-dent which may cause death, seri- ous injury, or property damage.
OMC025026
OMC025027

1FEATURES OF YOUR HYUNDAI
16
!!WARNING:
To minimize risk of severe injury in the event of a collision or a sudden stop, both the driver and passenger seatbacks should always be in anupright position while the vehicle is in motion. The protection provided by the seat belts and airbags in afrontal collision may be reduced sig- nificantly when the seatbacks are reclined. There is greater risk thatthe driver and passenger will slide under the seat belt which may result in serious injury if a crash occurswhen the seatbacks are reclined. The seat belt cannot provide full protec- tion to an occupant if the seatback isreclined. B080D02JM-AAT Adjustable Headrests
Headrests are designed to help reduce the risk of neck injuries. To raise the headrest, pull it up. To lower it, push it down while pressing thelock knob. To remove the headrest, raise it as far as it can go then press the lock knob while pulling upward. Thisshould only be done when the seat is not occupied. WARNING:
o For maximum effectiveness in case of an accident the headrest shouldbe adjusted so the middle of the headrest is at the same height asthe top of the occupant's eyes. For this reason, the use of a cushion that holds the body away from theseatback should not be recom- mended.
o Do not operate the vehicle with the headrests removed as severe in-jury to an occupant may occur in the event of an accident. Head-rests may provide protection against severe neck injuries when properly adjusted. B080D01JM
B080D02MC
Lock Knob
