Hyundai Azera 2005 Owner's Guide

1FEATURES OF YOUR HYUNDAI
4KEYS
B030A01NF-GAT For greater convenience, your Hyundai has two master keys and a sub key.The master keys will open all locks on your vehicle. The sub key will only function in the ignition and the doorlocks. Leaving your sub key with a parking attendant will ensure that your vehicle's trunk, trunk lid release, glove box com- partment and rear trunk access maynot be unlocked in your absence. NOTE: Before leaving your sub key with a parking attendant, make sure that the lock knobs of the rear seat backlock and the trunk lid lock are switched to the "LOCK" position.
B030A01TG
Master key
Sub key
B031A01LZ-GAT Before leaving sub key with park- ing attendant When leaving sub key with parking attendant, the following procedures will ensure that your vehicle's trunk and glove box can not be unlocked in yourabsence. 1. Unlock the glove box with the master
key and open it.
2. Set the trunk lid control button in the
glove box to the "OFF" position (not depressed). In the "OFF" position, the trunk can not be unlocked with either the trunk release lever or trunkopen button of transmitter.
B541A01TG

1
FEATURES OF YOUR HYUNDAI
5
B030B01NF-GAT Record Your Key Number A code number is attached on the number tag that came with the keys to your Hyundai. This key number tagshould not be left with the keys but kept in a safe place, not in the vehicle. The key number should also be re-corded in a place where it can be found in an emergency. If you need additional keys, or if youshould lose your keys, your authorized Hyundai dealer can make new keys if you can supply the key number. B030B01TG
3. Close the glove box, and lock the
glove box using the master key.
4. Leave the sub key with the atten- dant. Trunk and glove box are se-cured because sub key only allowsengine start and door lock and un- lock.
IMMOBILIZER SYSTEM
B880A01A-GAT (If Installed) The immobilizer system is an anti-theft device, designed to deter automobiletheft. B880B01NF-GAT Two Types of Keys For greater convenience, your Hyundai has two types of keys as shown in the illustration.
1) Master key This key is for general use. It will open all locks on your vehicle. One side of the key has the Hyundai logo and the other side has the "M" symbol. B880B01TG
Sub key
Master key

1FEATURES OF YOUR HYUNDAI
6
!
2) Sub key
Similar to the master key, this key will only function in the ignition and the door locks, but it will not operate the trunk and the glove box. Oneside of the key has the Hyundai logo and the other side has an "S" sym- bol.Leaving your sub key with a parking attendant will ensure that your vehicle's trunk, trunk lid release,glove box compartment and rear trunk access may not be unlocked in your absence.
NOTE:
o Before leaving your sub key with a parking attendant, make sure that the lock knobs of the seatback lock and the trunk lid lock are switched to the "LOCK" posi- tion.
o If you make your own duplicate key, you will not be able to cancelthe system or start the engine. CAUTION:
When staring the engine, do not use the key with other immobilizer keys around. Otherwise the enginemay not start or may stop soon after it starts. Keep each key separately not tohave any malfunction after you re- ceive your new vehicle.
B031A01LZ-GAT Before leaving sub key with park- ing attendant When leaving sub key with parking attendant, the following procedures will ensure that your vehicle's trunk and glove box can not be unlocked in yourabsence. 1. Unlock the glove box with the master key and open it.
2. Set the trunk lid control button in the
glove box to the "OFF" position (not depressed). In the "OFF" position, the trunk can not be unlocked with either the trunk release lever or trunkopen button of transmitter.
B541A01TG

1
FEATURES OF YOUR HYUNDAI
7
3. Close the glove box, and lock the glove box using the master key.
4. Leave the sub key with the atten- dant. Trunk and glove box are se- cured because sub key only allowsengine start and door lock and un- lock.
In the interest of security, the number tag attached to the keys which bearsthe key number should be removed from the key string after you receive your new vehicle. In addition, key num-bers cannot be provided by Hyundai for security reasons. If you need additional keys or if youshould lose your keys, your authorized Hyundai dealer can make new keys if you can supply the key number andmaster key.
B880C01NF-GAT Key Numbers The vehicle key number is recorded upon a number tag attached to the keys when the vehicle is first deliveredto you. The key number should be recorded and kept in a safe place in case theneed to order further keys arises. New keys are available from any Hyundai dealer by quoting the relevant keynumber.
B880C01TG

1FEATURES OF YOUR HYUNDAI
8
B880D01TG-GAT Limp Home Procedures 2. Wait for 3~10 seconds.
3. You may set the remaining number
of digits by following the same pro- cedures 1 and 2.
4. If all of four digits have been tried
successfully, turn the ignition key"ON" and check that the immobi- lizer indicator illuminates. From thistime, you have to start your engine within 30 seconds. If you start your engine after 30 seconds, your en-gine will not start.
NOTE: If the engine dies while driving after limp home procedure, you can startyour engine within 3 seconds with- out limp home procedure again.
5. If the immobilizer indicator blinks for five seconds, you have to try the limp home procedure again fromthe beginning.
After doing the limp home procedure,you have to consult with your autho- rized Hyundai dealer as soon as pos- sible.
HTG3012
In case the immobilizer warning indica-tor blinks for five seconds when theignition key is turned to "ON" position, this indicates that the immobilizer sys- tem is out of order. And you cannotstart the engine without the limp home procedures with ignition key. The following procedure is how to startthe engine with the function of the limp home (0, 1, 2, 3 as a sample pass- word). NOTE: You can get the limp home pass- word when the vehicle is first deliv- ered to you. If you do not have thepassword, consult your authorized Hyundai dealer.
1. To set the password you may turn
the ignition key "ON" and then turn it "OFF" according to the digit num-bers, then the immobilizer indicator will blink along with the operation of the ignition key. For example, turnthe ignition key once for digit num- ber "1", and twice for "2", and so on. However, for the digit number "0",you must turn the ignition key for 10 times.
B880D01TG
Conventional Type
Supervision Type

1
FEATURES OF YOUR HYUNDAI
9
B030C01JM-AAT ILLUMINATED IGNITION SWITCH Whenever either front door is opened, the ignition switch will be illuminatedfor your convenience, provided the ignition switch is not in the "ON" posi- tion.The light will go off approximately 10 seconds after closing the door or when the ignition switch is turned on. B030C01E
CAUTION:
o If you fail to try the limp home procedure with the sequence ofthree times, you have to wait forabout one hour to do the limp home procedure again.
o If you cannot start your engine in
spite of limp home procedure,have your vehicle towed by an authorized Hyundai dealer.
!!
DOOR LOCKS
B040A01NF-GAT
WARNING:
o Unlocked doors can be danger- ous. Before you drive away (es- pecially if there are children inthe car), be sure that all the doors are securely closed and locked so that the doors cannot be inad-vertently opened from the inside. This helps ensure that doors will not be opened accidentally. Also,when combined with the proper use of seat belts, locking the doors will keep occupants frombeing ejected from the car in case of an accident.
o Before opening the door, always
look for and avoid oncoming traffic.
o In case of accident, the door is
unlocked automatically (If In- stalled).
o Do not lock the door using the key
or the transmitter until all passen-gers have left the car because the door is not unlocked by the door lock switch when locking the doorusing the key or the transmitter (If Installed).

1FEATURES OF YOUR HYUNDAI
10
!
B040B01TG-AAT Locking and Unlocking Front Doors With a Key
o The door can be locked or unlocked
with a key.
o Lock the door by turning the key toward the front of the vehicle and unlock it by turning the key toward the rear. B040C02Y-AAT Locking from the Outside The doors can be locked without a key. To lock the doors from the outside, first push the inside lock switch to the"LOCK" position, so that the red mark on the switch is not visible, then close the door.The door will not lock if the key is left in the ignition switch when the front doors are closed. This is normal.
HTG2008 B040C01TG
LOCK UNLOCK
Leaving children, helpless adults,or pets in an enclosed vehicle isdangerous. They can be overcome by the extreme heat and suffer permanent injuries or even deathfrom heat stroke.
WARNING:
Do not lock the door using the key or the transmitter until all passengers have left the car because the door isnot unlocked by the door lock switch when locking the door using the key or the transmitter (If Installed). Leav-ing children, helpless adults, or pets in an enclosed vehicle is dangerous. They can be overcome by the ex-treme heat and suffer permanent in- juries or even death from heat stroke.

1
FEATURES OF YOUR HYUNDAI
11
NOTE:
o When locking the door this way, be careful not to lock the door with the ignition key left in thevehicle.
o To discourage theft, always re-
move the ignition key, close allwindows and lock all doors when leaving your vehicle unattended.
B040D01NF-AAT Locking from the Inside To lock the doors from the inside, sim- ply close the door and push the lock switch to the "LOCK" position. NOTE:
o When the door is locked, the redmark on the switch is not visible.
o The driver's and front passenger's doors can be opened by pulling the inside door handle even if theinside lock switch is pushed to the "LOCK" position. HTG2009
LOCK
UNLOCK
WARNING:
Be careful not to pull the inside door handle while driving. If you pull the inside door handle, the door can beopened and you may be ejected from the vehicle and can be injured or killed.!

1FEATURES OF YOUR HYUNDAI
12
!
Your Hyundai is equipped with a "child- protector" rear door lock assembly. When the lock mechanism is engaged,the rear door cannot be opened from the inside. Its use is recommended whenever there are small children inthe rear seat. To engage the child-protector feature so that the door cannot be opened from the inside, move the child-protec- tor lever to the "
" position and close
the door. Move the lever to the "
"
position when normal door operation is desired. If you wish to be able to open the door from the outside, the outside door handlewill function normally.
B040E04A-AAT Child-Protector Rear Door Lock
HTG2011-1
o The driver's and front passenger's
doors can be opened by pulling the inside door handle even if the front portion of the driver's or front passenger's central door lockingswitch has been depressed to lock the doors.
WARNING:
Be careful not to pull the inside door handle while driving. If you pull the inside door handle, the door can be opened and you may be ejected fromthe vehicle and can be injured or killed.B040G01NF-AAT Central Door Locks
The central door locking switch is lo- cated on the driver's and front passenger's armrest. It is operated bydepressing the door lock switch. If any door is open when the switch is de- pressed to the "LOCK" position, thedoor will remain locked when closed. NOTE:
o When pushing the front portion of the driver's or front passenger's door lock switch, all vehicle doors will lock.
o When pushing the rear portion of these switches, all vehicle doorswill unlock. B040G01TG
Driver's side
Front passenger's side
LOCK
UNLOCKLOCK
UNLOCK

1
FEATURES OF YOUR HYUNDAI
13THEFT-ALARM SYSTEM
B070A01A-AAT (If Installed) This system is designed to provide protection from unauthorized entry intothe car. This system is operated in three stages: the first is the "Armed" stage, the second is the "Alarm" stage,and the third is the "Disarmed" stage. If triggered, the system provides an audible alarm with blinking of the turnsignal lights.
B070B01TG-AAT Armed Stage
B070B01TG1) Remove the ignition key from the
ignition switch.
2) Make sure that the engine hood and trunk lid are closed and latched.
3) Lock the doors using the transmitter
of the keyless entry system.
If the steps are completed as above, the security LED lamp on the passenger’s crash pad will illuminate for about 30 seconds, and then thelamp will blink continuously when the system is entered into the armed stage. The turn signal lights will blink once toindicate that the system is armed. NOTE:
1) If any door, trunk lid or engine hood remains open, the system will not be armed.
2) If this happens, rearm the system
as previously described.
Lock
Unlock
Trunk Unlock
Park the car and stop the engine. Arm the system as described below.
! CAUTION:
Do not arm the system until all pas- sengers have left the car. If the sys- tem is armed while a passenger(s)remains in the car, the alarm may be activated when the remaining passenger(s) leaves the car.
