Hyundai Coupe 2007 Owner's Manual

1
CONTROLS AND EQUIPMENT
63SUNSHADE
B470A01GK-EAT (Not all models) The sunshade can be opened and closed by sliding it forward or rearward when the sunroof is closed. The sunshadewill open automatically when the sunroof is opened, but it must be closed manu- ally. OGK046019
!WARNING:
Never adjust the sunshade whilst driving. This could result in loss of control and an accident that may cause death, serious injury, or prop-erty damage.
SUNROOF
B460A01S-EAT (Not all models) The sunroof can be operated with the ignition key in the "ON" position.
B460B03GK-GAT Opening the Sunroof System The sunroof can be electrically opened or closed with the ignition key in the"ON" position. The sunroof is moved to its fully open position by pushing the " " button, and to stop at the desiredposition, push in any buttons (
, ,
Up, Down). To close, press and hold the " " button.
OGK046017
Switch position
0 0 1 2
3Loading condition Driver only Driver + front passengerFull passengers (including driver) Full passengers(including driver) + full boot loading (or light trailer loading)Driver + full boot loading (or maximum trailer load- ing)

1CONTROLS AND EQUIPMENT
64
!
Release the button when the sunroof reaches the desired position.
WARNING:
Be careful that someone’s head,hands and body are not trapped by aclosing sunroof.
OGK046018
!WARNING:
o Do not close a sunroof if anyone's hands, arms or body are between the sliding glass and the sunroof sash, as this could result in injury.
o Do not place your head or arms out of the sunroof opening at anytime.
o Whilst the vehicle is moving, al- ways keep the head, hands andother parts of the body of all occu-pants away from the roof opening. Otherwise, you could be seriously injured if the vehicle stops sud- denly or if the vehicle is involved in an accident.
B460C01GK-EAT Tilting the Sunroof System To use the auto tilt feature, press the UP button on the overhead console. The sunroof will tilt all the way open. Tostop the sunroof tilting at any point, press any sunroof control button. To close the sunroof, press the DOWN button on the overhead console and hold it until the sunroof is closed. NOTE: After washing the car or after there is rain, be sure to wipe off any waterthat is on the sunroof before operat- ing it.

1
CONTROLS AND EQUIPMENT
65
2. Insert the hexagonal head wrench provided with the vehicle into the socket. This wrench can be found in the vehicle's boot or glove box.
3. Push and turn the wrench clockwise
to open or counter-clockwise to closethe sunroof.
OGK046021
B460D03GK-EAT Manual Operation of Sunroof If the sunroof does not electrically op- erate:
1. Remove the cap located in the rear
roof panel by using a coin or driver.
OGK046020
! CAUTION:
o Do not open the sunroof in se- verely cold temperature or when it is covered with ice or snow.
o Periodically remove any dirt that
may have accumulated on theguide rails.
o Do not press any sunroof control
button longer than necessary.Damage to the motor or system components could occur.

1CONTROLS AND EQUIPMENT
66
B460E03GK-GAT Resetting the Sunroof System If the battery has been recharged, disconnected or if the sunroof is oper-ated with the hexagonal head wrench manually, you may need to reset the sunroof. To do this;
1. Turn the ignition switch "OFF".
2. With pressing " " "up" button at thesame time, turn the ignition switch"ON". The resetting is failed when the ignition key to the "OFF" within1.5 seconds.
3. If the sunroof is set like this, the sunroof is reset with tilting up/down automatically once for all.
CAUTION:
If the sunroof is not reset, it may not be operated properly.
!
MAP LIGHT
B480A02GK-EAT
(1) Push in the map light switch to turn on the front passenger side light.
(2) In the "DOOR" position, the interior courtesy light comes on when any door is opened regardless of theignition key position. The light goes out gradually 6 seconds after the door is closed.
(3) Push in the map light switch to turn on the driver side light. OGK046034L-1SPECTACLE CASE
B491A03O-EAT (Not all models) The spectacle case is located on the front overhead console. Push the end of cover to open thespectacle case. OGK046076

1
CONTROLS AND EQUIPMENT
67
!
GLOVE BOX
B500A01A-EAT
WARNING:
To avoid the possibility of injury, the glove box lid must be keptclosed whilst the vehicle is in mo- tion.
o To open the glove box, pull the glove box release lever. OGK046075R
!WARNING:
o Do not keep objects such as sharp or unsuitable things inside the spectacle case. Such objects canbe thrown out in the event of a sudden stop or an accident, pos- sibly injuring the passengers inthe vehicle.
o Do not open the spectacle case
whilst the vehicle is moving. Therear view mirror of the vehicle can be blocked by an open spectacle case. B500B01NF-GAT Illuminated Glove Box Opening the glove box will automati- cally turn on the light when the multi-function switch is turned to the first position.

1CONTROLS AND EQUIPMENT
68
!
!
To adjust the position of either mirror:
1. Move the selecting switch to the
right or left to activate the adjustable mechanism for the corresponding door mirror.
2. Adjust mirror angle by depressing
the appropriate perimeter switch asillustrated.
CAUTION:
o Do not operate the switch con- tinuously for an unnecessarylength of time.
o Scraping ice from the mirror face
could cause permanent damage.To remove any ice, use a sponge, soft cloth or approved de-icer.
WARNING:
Be careful when judging the size ordistance of any object seen in the passenger side rearview mirror. It is a convex mirror with a curved sur-face. Any objects seen in this mirror are closer than they appear.
EXTERIOR REARVIEW MIR- ROR
YB270B2-E Electric Type The outside rearview mirrors can be adjusted in any direction to give the maximum rearview vision.The remote control outside rearview mirror switch controls the adjustments for both right and left door mirror. OGK046026R-1 B510C01HP-EAT OUTSIDE REARVIEW MIRROR HEATER (Not all models)
The outside rearview mirror heater is actuated in connection with heated rear window. So, to heat the outside rear- view mirror glass, push in the switch forheated rear window. The rearview mirror glass will be heated for defrosting or defogging and will giveyou improved rear vision in all weather conditions.
OGK046054-1
Type A Type B

1
CONTROLS AND EQUIPMENT
69
!
B510C01A-EAT FOLDING THE OUTSIDE REAR- VIEW MIRRORS To fold the outside rearview mirrors, push them towards the rear.The outside rearview mirrors can be folded rearward for parking in restricted areas.
WARNING:
Do not adjust or fold the outsiderearview mirrors whilst the vehicle is moving. This could result in loss of control, and an accident causingdeath, serious injury or property damage. HGK2055M
DAY/NIGHT INSIDE REARVIEW MIRROR
SB370A1-E The interior mirror is of the day/night type to enable the glare of headlampsfrom following vehicles to be elimi- nated during night time driving. The tab located at the bottom of themirror should be set to the position nearest the windscreen for normal day time driving, and flipped towards therear of the vehicle to eliminate glare during night time driving. To adjust the field of vision, the mirror may be movedby hand upon the mounting. NOTE: The mirror should always be ad- justed prior to setting the vehicle in motion.
OGK046024
Push the switch again to turn the heater off.The outside rearview mirror heater au- tomatically turns itself off after 20 min- utes.

1CONTROLS AND EQUIPMENT
70
!
PARKING BRAKE
B530A03A-EAT The parking brake must always be set when the vehicle is to be left unattended.When the parking brake is applied, and the ignition key is at the "ON" position, the parking brake warning light will be
illuminated. Before driving the vehicle, the parking brake must be fully released and the warning light extinguished.
Applying the parking brake To engage the parking brake, first apply the foot brake and then without press- ing the release button in, pull the park- ing brake lever up as far as possible.
B520B02O-EAT Electric type (Not all models) The electric type day/night inside rear- view mirror automatically controls the glare of headlights of the car behindyou.
1. Pressing the button turns the auto-dimming function OFF which is indicated by the green Status Indica- tor LED turning off.
2. Pressing the button again turns the auto-dimming function ON whichis indicated by the green Status Indi-cator LED turning on.
NOTE: The mirror defaults to the "ON" posi- tion each time the vehicle is started. OGK046025In addition it is recommended that when parking the vehicle on a gradient, theshift lever should be positioned in the appropriate low gear on manual transaxle vehicles or in the P (Park) position onautomatic transaxle vehicles.
OGK056005UK
CAUTION:
Driving with the parking brake ap- plied will cause excessive brake pad (or lining) and brake rotor wear. Releasing the parking brake To release the parking brake, first apply the foot brake and pull up the parking brake lever slightly. Secondly, depress the release button and lower the parkingbrake lever whilst holding the button.
WARNING:
Whenever leaving or parking the ve-hicle, always apply the parking brake fully and engage the appropriate low gear (Park position for automatictransmission models). Failure to apply the parking brake correctly could result in the vehicle movinginadvertently.
!

1
CONTROLS AND EQUIPMENT
71HIGH-MOUNTED REAR STOP LIGHTFRONT DOOR EDGE WARN- ING LIGHT
SB410A1-E The red door edge warning light which serves to indicate an open door tofollowing traffic in conditions of dark- ness illuminates whenever the door is open. B620A01GK-EBONNET RELEASE
B570A01GK-EAT
1. Pull the release lever to unlatch the bonnet.
Bonnet Release Lever
OGK046011R
B550A01S-DAT In addition to the lower-mounted rear stopl ights on either side of the car, thehigh mounted rear stop light in the centre of the rear window or inserted in the rear spoiler also comes on whenthe brakes are applied.Type A
OGK016550L
Type B Type C
2. Press the safety hook lever up andlift the bonnet.
3. Raise the bonnet by hand. OGK046012L

1CONTROLS AND EQUIPMENT
72
!WARNING:
o Always double check to be sure that the bonnet is firmly latched before driving away. If it is not latched, the bonnet could fly openwhilst the vehicle is being driven, causing a total loss of visibility, which might result in an acci-dent.
o Do not move the vehicle with the
bonnet in the raised position, asvision is obstructed and the bon- net could fall or be damaged.
When closing the bonnet, slowly close the bonnet and make sure it locks intoplace.
REMOTE FUEL FILLER FLAP RELEASE
B560A01MC-EAT The fuel filler flap may be opened from inside the vehicle by pulling up on thefuel filler flap release. NOTE: If the fuel-filler flap will not open because ice has formed around it,lightly tap or push on the lid to break the ice and release the lid. Do not lever the flap. If necessary, sprayaround the flap with an approved de- icer fluid (do not use radiator anti- freeze) or move the vehicle to awarmer area and allow the ice to melt.
OGK046013R
!WARNING:
o Fuel vapors are dangerous. Be- fore refueling, always stop the en- gine and never allow sparks oropen flames near the filler area. If you need to replace the filler cap, use a genuine Hyundai replace-ment part. If you open the fuel filler cap dur- ing high ambient temperatures, aslight "pressure sound" may be heard. This is normal and not a cause for concern.Whenever you open the fuel filler cap, turn it slowly.
OGK046014
