Hyundai Ioniq Hybrid 2017 Quick Reference Guide

Quick Reference Guide I 39
38 I Quick Reference Guide
IONIQ HYBRID HYUNDAI
DRIVING
VIRTUAL ENGINE SOUND SYSTEM(VESS)The Virtual Engine Sound System generates engine sound for
pedestrians to hear vehicle sound because there is limited sound while
motor power is used.
ESC automatically selects the ON
position when the engine is started.To turn off Traction ControlPress the ESC OFF button shortly.To turn off Traction & Stability
ControlPress the ESC OFF button for more
than 3 seconds.The ESC system is an electronic
system designed to help the driver
maintain vehicle control under
adverse conditions.
ELECTRONIC STABILITY CONTROL (ESC)
NOTE:
Dual Clutch Transmission characteristics
The new technology of the Dual Clutch Transmission is different from a
traditional automatic or manual transmission:
• The Dual Clutch Transmission is an automatically shifting manual
transmission.
• Dual Clutch Transmission utilizes two clutches connected to a
computer-controlled manual gearbox. It provides the convenience of
a transmission that shifts automatically, with the efficiency of a manual
transmission.
• When you turn the engine on and off, you may hear clicking sounds as
the system goes through a self test.
This is a normal sound for the Dual Clutch Transmission.
• When you stop on a hill, if you remove your foot from the brake pedal,
the vehicle will remain stationary for approximately two seconds to help
prevent the vehicle from rolling backwards. If you depress the
accelerator pedal during the two second interval, the vehicle will
accelerate.
If you wait more than two seconds, the vehicle will enter creep mode
and may roll backwards if the hill is steep.
Caution• You should always use the foot brake to hold the car on a hill until you
are ready to drive. Using creep mode to hold the car on a hill may
damage the clutch.
• If the clutch becomes overheated by excessive use of the clutch to hold
on a hill, you may notice a shudder feeling and a blinking display on
the instrument cluster. When this occurs, the clutch is disabled until the
clutch cools to normal temperatures. If this occurs, pull over to a safe
location, shift into P (Park) and apply the foot brake for a few minutes.

Quick Reference Guide I 41
40 I Quick Reference Guide
IONIQ HYBRID HYUNDAI
LANE DEPARTURE WARNING SYSTEM (LDWS)
The Lane Departure Warning System
detects the lane on the road and
warns the driver if the vehicle leaves
the lane. The system operates when
the vehicle speed is over 40 mph.
• To turn on the LDWS, press the
LDWS switch.
• To turn off the LDWS, press the
switch again.
2
The BSD (Blind Spot Detection)
system uses a radar sensor to alert
the driver while driving.
It monitors the rear area of the vehicle
and provides information to the driver.1 Blind Spot Detection2 Lane Change Assist3 Rear Cross Traffic Alert
The system will activate if vehicle speed exceeds 20 mph.• To turn on the BSD, press the BSD
button (indicator illuminated).
• To turn off the BSD, press the BSD
button again.
When the vehicle is in R (Reverse), the system provides an alert if a
vehicle is approaching from the sides.Rear Cross Traffic AlertBLIND SPOT DETECTION SYSTEM (BSD)
3
1
DRIVING
AUTONOMOUS EMERGENCY BRAKING (AEB)
The Autonomous Emergency Braking (AEB)
system is designed to detect and monitor the
vehicle ahead or detect a pedestrian in the
roadway through radar signals and camera
recognition to warn the driver that a collision is
imminent, and if necessary, apply emergency
braking.
To activate the system,Cluster type ASelect “User Settings
Driving Assist
Forward Collision Warning

Autonomous Emergency Braking”
Cluster type BSelect “User Settings
Driving Assist
Autonomous Emergency Braking”
The system deactivates, when the system
setting is cancelled.
Type A
Type B

Quick Reference Guide I 43
42 I Quick Reference Guide
IONIQ HYBRID HYUNDAI
DRIVING
1 To turn on/off the cruise control.2 To resume or increase the cruise
control speed.3 To set or decrease the cruise
control speed.4 To cancel the cruise control. The Cruise Control system allows you to
program the vehicle to maintain a
constant speed without depressing the
accelerator pedal.
If your vehicle is equipped with Smart Cruise Control and you wish to eliminate
the vehicle distance function, you can change cruise control setting to a
standard setting. Press the Cruise Control button on the steering wheel to turn
on the Cruise Control. Then press and hold the vehicle distance button for
more than 2 seconds to toggle between the Smart Cruise Control (SCC) and
Cruise Control (CC) mode. Please refer to your Owner’s Manual for more
information.
CRUISE CONTROL / SMART CRUISE CONTROL
Setting Vehicle Distance (Smart
Cruise Control only)This system allows you to program
the vehicle to maintain constant
speed and distance without
depressing the accelerator or brake
pedal.
The vehicle to vehicle distance
1 will
automatically activate when you set
the cruise speed
2.
Each time the vehicle distance set
button is pressed, the vehicle to
vehicle distance changes as
following:
2
1
Distance 2 Distance 3 Distance 4
(Longest)
Distance 1(Shortest)
2341
The following tips may help benefit you to maximizing fuel economy and
experience Hybrid vehicle driving.
Set headlight switch to AUTO or OFF
when not in use. This will help preserve
vehicle battery charge.
Use the DRIVER ONLY button with no
front passenger. This will help reduce
energy consumption.
Try to drive in an eco-friendly manner
and maintain EV Mode indicator to
illuminate as much as possible. Common practice:
• Check tire pressure
• Roll windows up when driving
• Properly maintain your vehicle
• Turn A/C off
Driving suggestions to improve fuel economy:• Drive smoothly.
• Accelerate at moderate speed.
• Try to maintain your speed with traffic to prevent unnecessary
speed adjustments.
• Always maintain a safe driving distance from the vehicle in
front of you so you can avoid unnecessary braking.
+
HYBRID DRIVING TIPS

MENO
IONIQ CUSTOMER DELIVERY CHECKLIST CUSTOMER NAME DEALERSHIP NAME SALES CONSULTANT DATE VIN ☐

SET TIRE PRESSURE LF

RF
RR
LR
☐
VERIFY VEHICLE IS CLEAN, IN GOOD CONDITION,
FREE OF CHIPS AND SCRATCHES · CLEAN WINDSHIELD
AND BACK WINDOW
☐ ENSURE FLOOR MATS ARE SNAPPED INTO PLACEBEFORE DELIVERY Sales Consultant Date Sales Manager Date
Customer Date
Email
HYUNDAI VEHICLE OWNER PRIVACY POLICY
Your Hyundai vehicle may be equipped with technologies and services
that use information collected, generated, recorded or stored by the
vehicle. Hyundai has created a Vehicle Owner Privacy Policy to explain
how these technologies and services collect, use, and share this
information.
You may read our Vehicle Owner Privacy Policy on the Hyundaiusa.com
website at https://www.hyundaiusa.com/owner-privacy-policy.aspx
If you would like to receive a hard copy of our Vehicle Owner Privacy
Policy, please contact our Customer Connect Center at:
Hyundai Motor America
Hyundai Customer Connect Center
P.O. Box 20850
Fountain Valley, CA 92728-0850
800-633-5151 [email protected]
Hyundai's Customer Connect Center representatives are available
Monday through Friday, between the hours of 5:00 AM and 7:00 PM
PST and Saturday and Sunday between 6:30 AM and 3:00 PM PST
(English). For Customer Connect Center assistance in Spanish or
Korean, representatives are available Monday through Friday between
6:30 AM and 3:00 PM PST.
