1FEATURES OF YOUR HYUNDAI
2
OCM051001R
Unleaded petrol with a Pump Octane Rating of 87 (Research Octane Num-ber 91) or higher must be used in your Hyundai. If leaded petrol is used, it will cause the catalytic converter to become ineffec- tive and the emission control system tomalfunction. This can also result in increased maintenance expense. To avoid accidental use of leaded fuel,the larger nozzle used with leaded petrol at service stations cannot be inserted into the fuel tank opening of your Hyundai.
B010A02CM-DAT Use Unleaded Petrol
FUEL RECOMMENDATIONS
UNLEADED FUEL ONLY
!
Use Diesel Diesel fuel Diesel engine must be operated only on commercially available diesel fuel that complies with EN 590 or comparablestandard. (EN stands for "European Norm"). Do not use marine diesel fuel, heating oils, or non-approved fuel addi-tives, as this will increase wear and cause damage to the engine and fuel system. The use of non-approved fuelsand / or fuel additives will result in a limitation of your warranty rights. Diesel fuel of 52 to 54 cetane is thecorrect rating to use in your Hyundai. If two types of diesel fuel are available, use summer or winter fuel properlyaccording to the following temperature conditions.
o Above -5°C (23°F) ... Summer type
diesel fuel.
o Below -5°C (23°F) ... Winter type diesel fuel.
Watch the fuel level in the tank very carefully : If the engine stops through fuel failure, the circuits must be com- pletely purged to permit restarting. CAUTION:
o Do not let any petrol or water enter the tank. This would make it nec- essary to drain it out and to bleed the lines to avoid jamming theinjection pump and damaging the engine.
o In winter, in order to cut down
incidents due to freezing, paraffinoil may be added to the fuel if the temperature drops to below -10°C.Never use more than 20% paraffin oil.
Biodiesel Commercially supplied biodiesel blends of no more than 5% biodiesel, com- monly known as "B5 biodiesel" may be used in your vehicle if it meets EN14214 or equivalent specifications. (EN stands for "European Norm"). The use of biofuels made from rapeseed methylester (RME), fatty acid methyl ester (FAME), vegetable oil methyl ester (VME) etc. or mixing diesel withbiodiesel will cause increased wear or damage to the engine and fuel system.
CM-aust-1a.p65 5/21/2008, 2:04 PM
2

1
FEATURES OF YOUR HYUNDAI
45
1. Low Windshield Washer Fluid Level Warning Light
2. Malfunction Indicator Light (MIL)
3. Door/Tail Gate Open Display (If installed)
4. 4WD System Warning Light
5. 4WD Lock Indicator Light
6. Odometer / Tripmeter / Trip Computer (If installed)
7. Fuel Gauge
8. Low Fuel Warning Light
9. Seat Belt Warning Light (Driver's Side)
10. Parking Brake/Low Brake Fluid Level Warning Light 11.Charging System Warning Light
12. Coolant Temperature Gauge 13.Low Oil Pressure Warning Light 14.Supplemental Restraint (AirBag) System Service Reminder Indicator (SRI) 15.Tail Gate Open Warning Light 16.Door Ajar Warning Light
17. Automatic Transaxle Position Indicator Light (If installed)
18. High Beam Indicator Light
19. Cruise SET Indicator Light (If Installed) 20.Cruise Indicator Light (If installed)
21. ABS Service Reminder Indicator
22. Turn Signal Indicator Light
23. Speedometer
24. Electronic Stability Program (ESP) Indicator Light
(If Installed)
25. Immobiliser Warning Light
26. Tachometer
CM-aust-1a.p65 5/21/2008, 2:06 PM
45

1
FEATURES OF YOUR HYUNDAI
47
1. Low Windshield Washer Fluid Level Warning Light
2. Malfunction Indicator Light (MIL) (If installed)
3. Door / Tail Gate Open Display (If installed)
4. 4WD System Warning Light
5. 4WD Lock Indicator Light
6. Odometer / Tripmeter / Trip Computer (If installed)
7. Fuel Gauge
8. Low Fuel Warning Light
9. Seat Belt Warning Light (Driver's Side)
10. Parking Brake/Low Brake Fluid Level Warning Light 11.Charging System Warning Light
12. Coolant Temperature Gauge13.Low Oil Pressure Warning Light 14.Supplemental Restraint (AirBag) System Service Reminder Indicator (SRI) 15.Tail Gate Open Warning Light 16.Door Ajar Warning Light
17. Fuel Filter Warning Light
18. Automatic Transaxle Position Indicator Light (If installed)
19. Diesel Preheat Indicator Light
20. High Beam Indicator Light
21. Cruise SET Indicator Light (If Installed) 22.Cruise Indicator Light (If installed)
23. ABS Service Reminder Indicator
24. Turn Signal Indicator Light
25. Speedometer
26. Electronic Stability Program (ESP) Indicator Light
(If Installed)
27. Immobiliser Warning Indicator Light
28. Tachometer
CM-aust-1a.p65 5/21/2008, 2:06 PM
47

2DRIVING YOUR HYUNDAI
24
C160H01A-DAT Use Approved Anti-Freeze in Window Washer System To keep the water in the window washer system from freezing, add an approvedanti-freeze solution in accordance with instructions on the container. Window washer anti-freeze is available fromHyundai dealers and most auto parts outlets. Do not use engine coolant or other types of anti-freeze as these maydamage the paint finish.
C160G01A-DAT To Keep Locks from Freezing To keep the locks from freezing, squirt an approved de-icer fluid or glycerineinto the key opening. If a lock is cov- ered with ice, squirt it with an approved de-icing fluid to remove the ice. If thelock is frozen internally, you may be able to thaw it out by using a heated key. Handle the heated key with care toavoid injury. NOTE: The proper temperature for using the immobiliser key is from -40°C to 80°C. If you heat the immobiliser key over 80°C to open a frozen lock, itmay cause damage to the transpon- der in its head.
C160E01A-AAT Change to "Winter Weight" Oil if Necessary In some climates it is recommended that a lower viscosity "winter weight" oilbe used during cold weather. See Sec- tion 9 for recommendations. If you aren't sure what weight oil you should use,consult your Hyundai dealer. C160F01A-AAT Check Spark Plugs and Ignition System Inspect your spark plugs as described in Section 6 and replace them if neces- sary. Also check all ignition wiring and components to be sure they are notcracked, worn or damaged in any way.
CM-aust-2.p65
5/19/2008, 6:35 PM
24

4CORROSION PREVENTION AND APPEARANCE CARE
6CLEANING THE INTERIOR
E030E01A-AAT Maintaining Bumpers Special precautions must be observed to preserve the appearance of thebumpers on your Hyundai. They are:
o Be careful not to spill battery electro- lyte or hydraulic brake fluid on the bumpers. If you do, wash it off immediately with clear water.
o Be gentle when cleaning the bumper surfaces. They are made of softplastic and the surface can be dam-aged if mistreated. Do not use abra- sive cleaners. Use warm water and mild soap or car-washing solution.
o Do not expose the bumpers to high temperatures. For example, if youhave your car repainted, do not leavethe bumpers on the car if the car is going to be placed in a high-tempera- ture paint booth. E040A01A-DAT To Clean the Vinyl Upholstery To clean the vinyl upholstery, first re- move loose dirt and dust with a vacuumcleaner. Then apply a solution of mild soap or detergent and water using a clean sponge or soft cloth. Allow this tostay on the surface to loosen the dirt, then wipe with a clean damp sponge or cloth. If all the dirt stains are not re-moved, repeat this procedure until the upholstery is clean. Do not use petrol, solvent, paint thinner or other strongcleaners.
E040B01A-DAT To Clean the Leather Upholstery (If Installed) In the normal course of use, leather upholstered surfaces will, like any ma-terial, pick-up dust and dirt. This dust and dirt must be cleaned off or it may work into the surface of the leather,causing damage. Fine leather needs care, and should be cleaned when necessary. Washing leather thoroughly with soap and water will keep your leather lustrous, beautifuland ensure you have many years of wear. Take a piece of cheese cloth and using any mild soap and lukewarm water, work up a good lather. Thoroughly washthe leather. Wipe clean with a slightly damp cloth and dry with soft cloth. Do this as often as the leather becomessoiled. Consult your Hyundai dealer for recom- mended leather treatment products.

5VEHICLE MAINTENANCE REQUIREMENTS
10
F070F01A-AAT
o Brake Hoses and Lines
Visually check for proper installation,
chafing, cracks, deterioration and any leakage. Replace any deteriorated or damaged parts immediately.
F070G02A-AAT
o Brake Fluid
Check brake fluid level in the brake
fluid reservoir. The level should be between "MIN" and "MAX" marks on the side of the reservoir. Use onlyhydraulic brake fluid conforming to DOT 3 or DOT 4. F070J01A-AAT
o Brake Pads, Calipers and
Rotors
Check the pads for excessive wear, discs for run out and wear, and cali- pers for fluid leakage. F070K01A-AAT
o Exhaust Pipe and Muffler
Visually inspect the exhaust pipes, muffler and hangers for cracks, dete- rioration, or damage. Start the engine and listen carefully for any exhaust gas leakage. Tighten connections or replace parts as necessary. F070L01A-AAT
o Suspension Mounting Bolts
Check the suspension connections for looseness or damage. Retighten to the specified torque.
F070H01CM-AAT
o Parking Brake
Inspect the parking brake system in-
cluding the parking brake lever (or theparking brake pedal) and cables. Fordetailed service procedures, refer to the Shop Manual.
F070D01A-AAT
o Manual Transaxle Oil
Inspect the manual transaxle oil ac- cording to the maintenance schedule. NOTE: If the oil level is low, check for possible leaks before adding oil. Do not overfill. F070E01CM-AAT
o Automatic Transaxle Fluid The fluid level should be in the "75°C" range of the dipstick, after the engine and transaxle are at normal operating temperature. Check the automatictransaxle fluid level with the engine running and the transaxle in neutral, with the parking brake properly ap-plied. Use Hyundai Genuine ATF SP- III, DIAMOND ATF SP-III, SK ATF SP-III or other brands approved byHyundai Motor Co., when adding or changing fluid.
CM-aust-5.p65 5/19/2008, 6:37 PM
10

6
DO-IT-YOURSELF MAINTENANCE
7
NOTE:
o For good fuel economy, SAE 5W- 20 (5W-30), ILSAC GF-3 engine oil is preferred regardless of regional option and engine variation.
o If SAE 5W-20, ILSAC GF-3 engine oil is not available, secondaryrecommended engine oil for cor- responding temperature rangecan be used. G030B02CM-DAT
Recommened Oil Diesel Engine The engine oil quality should meet the following classification:
API Class ACEA ClassEngine
With C.P.F* 2
-
C3
Class
Without C.P.F*
2
CH4 or ABOVE B4
V.G.T* 1
* 1
V.G.T - Variable Geometry Turbocharger
* 2
C.P.F - Catalyzed Particulate Filter
OCM055020L-D
Engine oil is essential to the perfor-
mance and service of the engine.
It is suggested that you check the oil
level every 500km or before starting a long trip and more often if you are on a trip or driving in severe conditions. NOTE: SAE 0W-30 oil is for extra cold zone and to be restricted by driving con- dition and dealing area. (Especially, not recommended for sustained high loaded & high speed operation.)
CM-aust-6.p65
5/19/2008, 6:38 PM
7

6DO-IT-YOURSELF MAINTENANCE
26
!
POWER STEERING FLUID LEVELCHECKING ELECTRIC COOLING FANS
G220A01A-AAT
WARNING:
The cooling fan is controlled by engine coolant temperature and maysometimes operate even when the engine is not running. Use extreme caution when working near theblades of the cooling fan, so that you are not injured by a rotating fan blade. As the coolant temperaturedecreases the fan will automatically shut off. This is a normal condition.
G220B01A-AAT
Checking Engine Cooling Fan
The engine coolant fan should come
on automatically if the engine coolant temperature is high. G220C01A-AAT Checking Condenser Cooling Fan The condenser cooling fan should come on automatically whenever the air con- ditioning is in operation. G230A03A-GAT The power steering fluid level should
be checked regularly. To check the power steering fluid level, be sure theignition is "OFF", then check to make certain that the power steering fluid level is between the "MAX" and "MIN"level markings on the fluid reservoir.
OCM055027L NOTE: Grinding noise from the power steer-
ing pump may be heard immedi- ately after the engine is started in extremely cold conditions (below - 20°C). If the noise stops during warmup, there is no abnormal function in the system. It is due to a power steering fluid characteristic in ex-tremely cold conditions. Recommended Fluid
Use PSF-3 type fluidNOTE: Do not start the engine when the
power steering oil reservoir is empty.
CM-aust-6.p65 5/19/2008, 6:38 PM
26

6
DO-IT-YOURSELF MAINTENANCE
29
G290B01CM-DAT
Adjustment After Headlight Assembly Replacement
If the vehicle has had front body repair and the headlight assembly has been replaced, the headlight aiming shouldbe checked using an aiming screen as shown in the illustration. Turn on the headlight switch (Low Beam Positionor High Beam Position).
1. Adjust headlights so that main axis of light is parallel to centre line ofthe body and is aligned with point"P" shown in the illustration.
2. Dotted lines in the illustration show the centre of headlights. SPECIFICATION: "H" Horizontal centre line of headlightsfrom ground : Low Beam : 883 mm (34.76 in.) High Beam : 869 mm (34.21 in.) "W" Distance between each headlight centre : Low Beam : 1,402 mm (55.19 in.) High Beam : 1,144 mm (45.03 in.) "L" Distance between the headlights and the wall that the lights are tested against : 3,000 mm (118.1 in.)
G290B01TG-R
Low Beam
LW
H Cut-off line
"P"
Horizontal line
Ground line 30 mm
Vertical line
H
REPLACEMENT OF LIGHT BULBS
G260A01CM-DAT Before attempting to replace a bulb, be
sure the switch is turned to the "OFF" position.
The next paragraph shows how to
reach the light bulbs so they may bechanged. Be sure to replace the burned-out bulb with one of the same number and wattage rating.
All bulbs are available from your Hyundai
dealers Parts Department.
CAUTION:
o Keep the lamps out of contact with petroleum products, such asoil, petrol, etc.
o After heavy, driving rain or wash- ing, headlight and taillight lensescould appear frosty. This condi- tion is caused by the temperaturedifference between the lamp in- side and outside. This is similar to the condensation on your win-dows inside your vehicle during the rain and doesn’t indicate a problem with your vehicle. If thewater leaks into the lamp bulb circuitry, have the vehicle checked by an authorised Hyundai dealer.
!
CM-aust-6.p65 5/19/2008, 6:39 PM
29

3
10
INDEX
D Demisting/Defogging
................................................. 1-105
Door Central door locks .................................................... 1-9
Door locks ................................................................ 1-6
Front door edge warning light ..................................1-92
Locking, unlocking front doors with a key ................. 1-7
Drink Holder ................................................................ 1-71
Driving Driving for economy ................................................ 2-21
Smooth cornering .................................................... 2-22
Winter driving .......................................................... 2-23
EEmission Control System ............................................ 7-2
Engine Before starting the engine ........................................ 2-3Compartment ........................................................... 6-2
Coolant .................................................................... 6-9
Coolant temperature gauge .....................................1-54
If the engine overheats ............................................. 3-4
Number .................................................................... 8-2
Oil ............................................................................ 6-6Starting .................................................................... 2-6
Engine Exhaust Can Be Dangerous ............................. 2-2FFan Speed
Control .................................................... 1-100
Fog Light Front ....................................................................... 1-66
Rear ........................................................................ 1-67
Front Seats Adjustable front seats ............................................. 1-15
Adjustable headrests .............................................. 1-16
Adjusting seat forward and rearward ........................ 1-15
Adjusting seatback angle .. ......................................1-15
Fuel Capacity .................................................................. 9-2
Gauge ..................................................................... 1-54
Recommendations ................................................... 1-2
Fuel Filler Lid Remote release ....................................................... 1-88
Fuel Filter .................................................................... 6-27
Full-time 4 WD Operation ............................................. 2-16
Fuse Panel Description ............................................... 6-38
Fuses ......................................................................... 6-21
GGeneral Checks ........................................................... 6-5
Glove Box ................................................................... 1-78
CM-aust-10.p65 5/19/2008, 6:41 PM
