TROUBLE DIAGNOSIS
Revision: 2004 November 2004 FX35/FX45
How to Perform Trouble Diagnosis for Quick and Accurate RepairAJS0014K
WORK FLOW
SYMPTOM TABLE
*1ATC-61, "Operational Check"
SHA900E
Symptom Reference Page
A/C system does not come on. Go to Trouble Diagnosis Procedure for A/C System.AT C - 6 3 , "
Power
Supply and Ground
Circuit for Auto
Amp."
A/C system cannot be controlled.Go to Integrated Display System.
Go to Navigation System.AV-78, "
Trouble
Diagnosis Chart by
Symptom" (Without
navigation system)
or AV-84, "
A/C and
AV Switch Does Not
Operate" (With nav-
igation system)
Air outlet does not change.
Go to Trouble Diagnosis Procedure for Mode Door Motor. (LAN)AT C - 7 0 , "
Mode
Door Motor Circuit"Mode door motor does not operate normally.
Discharge air temperature does not change.
Go to Trouble Diagnosis Procedure for Air Mix Door Motor.
(LAN)ATC-73, "
Air Mix
Door Motor Circuit"Air mix door motor does not operate nor-
mally.
Intake door does not change.
Go to Trouble Diagnosis Procedure for Intake Door Motor. (LAN)ATC-76, "
Intake
Door Motor Circuit"Intake door motor does not operate nor-
mally.
Blower motor operation is malfunctioning.
Go to Trouble Diagnosis Procedure for Blower Motor.ATC-79, "
Blower
Motor Circuit"Blower motor operation is malfunctioning
under out of starting fan speed control.
Magnet clutch does not engage. Go to Trouble Diagnosis Procedure for Magnet Clutch.ATC-84, "
Magnet
Clutch Circuit"
Insufficient coolingGo to Trouble Diagnosis Procedure for Insufficient Cooling.AT C - 9 1 , "
Insufficient
Cooling"
Go to Diagnostic Procedure for Insufficient Cooling.AT C - 9 8 , "
DIAG-
NOSTIC PROCE-
DURE FOR
INSUFFICIENT
COOLING"
Insufficient heating Go to Trouble Diagnosis Procedure for Insufficient Heating.ATC-100, "Insuffi-
cient Heating"
Noise Go to Trouble Diagnosis Procedure for Noise.ATC-101, "Noise"
Self-diagnosis cannot be performed. Go to Trouble Diagnosis Procedure for Self-diagnosis.ATC-102, "Self-
diagnosis"
Memory function does not operate. Go to Trouble Diagnosis Procedure for Memory Function.ATC-103, "Memory
Function"
TROUBLE DIAGNOSIS
ATC-51
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2004 November 2004 FX35/FX45
Auto Amp. Terminals and Reference ValueAJS0014O
Measure voltage between each terminal and ground by following ter-
minals and reference value for unified meter and A/C amp.
PIN CONNECTOR TERMINAL LAYOUT
TERMINALS AND REFERENCE VALUE FOR UNIFIED METER AND A/C AMP.
RJIA1965E
RJIA1966E
Terminal
No.Wire
colorItemIgnition
switchConditionVoltage
(V)
1 L CAN H - - -
11 R C A N L - - -
21 R/W Power supply for BATT OFF - Battery voltage
22 G/R Power supply for IGN ON - Battery voltage
29 B Ground (Power) ON - Approx. 0
30 B Ground ON - Approx. 0
35 LG/R Power supply for ACC ON - Battery voltage
39 Y Ambient sensor - - -
40 BR/W In-vehicle sensor - - -
41 P Intake sensor - - -
42 R/Y Compressor ON signal ONA/C switch: ON Approx. 0
A/C switch: OFF Approx. 5
43 G/B A/C LAN signal ON -
45 PU/WECV (Electric Control Valve)
signalON -
HAK0652D
RJIA1606E
