SERVICE DATAPFP:00030
Road WheelNES000HB
TireNES000HC
Unit: kPa (kg/cm2 , psi)
Kind of wheel Aluminum Steel (for emergency use)
Maximum radial runout limit Lateral deflection Less than 0.3 mm (0.012 in) Less than 1.5 mm (0.059 in)
Vertical deflection Less than 0.3 mm (0.012 in) Less than 1.5 mm (0.059 in)
Maximum allowable unbalance Dynamic (At rim flange) Less than 5.0 g (0.2 oz) (per side) —
Static (At rim flange) Less than 20 g (0.7 oz) —
Tire size Air pressure
Front Rear
P265/60R18 109V 220 (2.2, 32) 220 (2.2, 32)
P265/50R20 106V 220 (2.2, 32) 220 (2.2, 32)
T175/90D18 110M 420 (4.2, 60) 420 (4.2, 60)
Page 4402 of 4462
WT-40
SERVICE DATA
Revision: 2006 December 2006 FX35/FX45
Page 4403 of 4462
WW-1
WIPER, WASHER & HORN
K ELECTRICAL
CONTENTS
C
D E
F
G H
I
J
L
M
SECTION WW
A
B
WW
Revision: 2006 December 2006 FX35/FX45
WIPER, WASHER & HORN
PRECAUTION ....................................................... ..... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 3
FRONT WIPER AND WASHER SYSTEM ............. ..... 4
Components Parts and Harness Connector Loca-
tion ...................................................................... ..... 4
System Description ............................................. ..... 4
OUT LINE ......................................................... ..... 4
LOW SPEED WIPER OPERATION ................. ..... 5
HI SPEED WIPER OPERATION ...................... ..... 5
INTERMITTENT OPERATION ......................... ..... 5
AUTO STOP OPERATION ............................... ..... 6
WASHER OPERATION .................................... ..... 6
MIST OPERATION ........................................... ..... 6
FAIL-SAFE FUNCTION .................................... ..... 7
COMBINATION SWITCH READING FUNCTION ..... 8
CAN Communication System Description ........... ... 10
CAN Communication Unit ................................... ... 10
Schematic ........................................................... .... 11
Wiring Diagram — WIPER — ............................. ... 12
Terminals and Reference Values for BCM .......... ... 15
Terminals and Reference Values for IPDM E/R .. ... 18
How to Proceed With Trouble Diagnosis ............. ... 19
Preliminary Check ............................................... ... 19
CHECK POWER SUPPLY AND GROUND CIR-
CUIT ................................................................. ... 19
CONSULT-II Functions (BCM) ............................ ... 20
CONSULT-II BASIC OPERATION .................... ... 20
WORK SUPPORT ............................................ ... 20
DATA MONITOR .............................................. ... 20
ACTIVE TEST .................................................. ... 21
CONSULT-II Functions (IPDM E/R) .................... ... 22
CONSULT-II BASIC OPERATION .................... ... 22
DATA MONITOR .............................................. ... 22
ACTIVE TEST .................................................. ... 22
Front Wiper Does Not Operate ........................... ... 23
Front Wiper Does Not Return to Stop Position .... ... 25
Only Front Wiper Low Does Not Operate ........... ... 26
Only Front Wiper Hi Does Not Operate ............... ... 28 Only Front Wiper Intermittent Does Not Operate ... 29
Front Wiper Interval Time Is Not Controlled by Vehi-
cle Speed ............................................................. ... 29
Front Wiper Intermittent Operation Switch Position
Cannot Be Adjusted ............................................. ... 30
Wiper Does Not Wipe When Front Washer Operates ... 30
After Front Wiper Operate for 10 Seconds, They
Stop for 20 Seconds, and After Repeating the Oper-
ations Five Times, They Become Inoperative ..... ... 31
Front Wiper Does Not Stop .................................. ... 32
Removal and Installation of Front Wiper Arms,
Adjustment of Wiper Arms Stop Location ............ ... 33
REMOVAL ........................................................ ... 33
INSTALLATION ................................................ ... 33
ADJUSTMENT ................................................. ... 33
Removal and Installation of Front Wiper Drive
Assembly ............................................................. ... 33
REMOVAL ........................................................ ... 33
INSTALLATION ................................................ ... 33
Disassembly and Assembly of Front Wiper Drive
Assembly ............................................................. ... 34
DISASSEMBLY ................................................ ... 34
ASSEMBLY ...................................................... ... 34
Washer Nozzle Adjustment ................................. ... 34
Washer Tube Layout ........................................... ... 36
Removal and Installation of Front Washer Nozzle ... 36
Removal and Installation of Front Washer Tube
Joint ..................................................................... ... 36
REMOVAL ........................................................ ... 36
INSTALLATION ................................................ ... 36
Inspection of Washer Nozzle ............................... ... 36
CHECK VALVE ................................................. ... 36
Removal and Installation of Front Wiper and Washer
Switch .................................................................. ... 37
REMOVAL ........................................................ ... 37
INSTALLATION ................................................ ... 37
Removal and Installation of Washer Tank ........... ... 37
REMOVAL ........................................................ ... 37
Page 4404 of 4462
WW-2Revision: 2006 December 2006 FX35/FX45 INSTALLATION .................................................
... 38
Removal and Installation of Washer Pump .......... ... 38
REMOVAL ........................................................ ... 38
INSTALLATION ................................................. ... 38
REAR WIPER AND WASHER SYSTEM ............... ... 39
Component Parts and Harness Connector Location ... 39
System Description .............................................. ... 39
REAR WIPER OPERATION ............................. ... 39
INTERMITTENT OPERATION ......................... ... 40
AUTO STOP OPERATION ............................... ... 40
WASHER OPERATION .................................... ... 40
BCM WIPER SWITCH READING FUNCTION . ... 40
Wiring Diagram — WIP/ R — .............................. ... 41
Terminals and Reference Values for BCM ........... ... 43
How to Proceed With Trouble Diagnosis ............. ... 45
Preliminary Check ............................................... ... 45
CHECK POWER SUPPLY AND GROUND CIR-
CUIT ................................................................. ... 45
CONSULT-II Functions (BCM) ............................. ... 46
CONSULT-II BASIC OPERATION .................... ... 46
DATA MONITOR ............................................... ... 46
ACTIVE TEST .................................................. ... 46
Rear Wiper Does Not Operate ............................ ... 47
Rear Wiper Does Not Return to Stop Position ..... ... 48
Only Rear Wiper ON Does Not Operate .............. ... 49
Only Rear Wiper INT Does Not Operate ............. ... 49
Wiper Does Not Wipe When Rear Washer Operates ... 49
Rear Wipers Do Not Stop .................................... ... 50
Removal and Installation of Rear Wiper Arm, Adjust-
ment of Wiper Arms Stop Location ...................... ... 51
REMOVAL ........................................................ ... 51
INSTALLATION ................................................. ... 51
Removal and Installation of Rear Wiper Motor .... ... 51
REMOVAL ........................................................ ... 52 INSTALLATION .................................................
... 52
Removal and Installation of Rear Wiper Blade .... ... 52
REMOVAL ......................................................... ... 52
INSTALLATION ................................................. ... 52
Washer Nozzle Adjustment .................................. ... 53
Removal and Installation of Washer Nozzle ........ ... 53
REMOVAL ......................................................... ... 53
INSTALLATION ................................................. ... 53
Washer Tube Layout ............................................ ... 54
Check Valve ......................................................... ... 54
Removal and Installation of Rear Wiper and Washer
Switch .................................................................. ... 54
Removal and Installation of Washer Tank ............ ... 54
Removal and Installation of Washer pump .......... ... 54
POWER SOCKET .................................................. ... 55
Wiring Diagram — P/SCKT — ............................. ... 55
Removal and Installation of Front Power Socket – 1 ... 56
REMOVAL ......................................................... ... 56
INSTALLATION ................................................. ... 56
Removal and Installation of Front Power Socket – 2 ... 56
REMOVAL ......................................................... ... 56
INSTALLATION ................................................. ... 56
Removal and Installation of Rear Power Socket .. ... 56
REMOVAL ......................................................... ... 56
INSTALLATION ................................................. ... 56
Removal and Installation of Luggage Room Power
Socket .................................................................. ... 57
REMOVAL ......................................................... ... 57
INSTALLATION ................................................. ... 57
HORN ..................................................................... ... 58
Wiring Diagram — HORN — ............................... ... 58
Removal and Installation ...................................... ... 59
REMOVAL ......................................................... ... 59
INSTALLATION ................................................. ... 59
Page 4405 of 4462
PRECAUTION WW-3
C
D E
F
G H
I
J
L
M A
B
WW
Revision: 2006 December 2006 FX35/FX45
PRECAUTIONPFP:00011
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
NKS00325
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Page 4406 of 4462
WW-4
FRONT WIPER AND WASHER SYSTEM
Revision: 2006 December 2006 FX35/FX45
FRONT WIPER AND WASHER SYSTEMPFP:28810
Components Parts and Harness Connector LocationNKS00326
System DescriptionNKS00327
All front wiper relays (HI, LO) are included in IPDM E/R (intelligent power distribution module engine
room).
Wiper switch (combination switch) is composed of a combination of 5 output terminals and 5 input termi-
nals. Terminal combination status is read by BCM (body control module) when switch is turned ON.
BCM controls front wiper LO, HI, and INT (intermittent) operation.
IPDM E/R operates wiper motor according to CAN communication signals from BCM.
OUT LINE
Power is supplied at all times
through 50 A fusible link (letter M, located in fuse, fusible link and relay box.)
to BCM terminal 55,
through 15 A fuse [No. 22, located in fuse block (J/B)]
to BCM terminal 42,
through 30 A fuse (No. 73, located in IPDM E/R)
to front wiper relay, located in IPDM E/R,
through 15 A fuse (No. 78, located in IPDM E/R) and
through 10 A fuse (No. 71, located in IPDM E/R)
to CPU located in IPDM E/R.
When the ignition switch is ON or START position, power is supplied
to ignition relay located in IPDM E/R, from battery direct,
through 15 A fuse [No. 1, located in fuse block (J/B)]
to BCM terminal 38,
through ignition relay, located in IPDM E/R
PKIC9701E
Page 4407 of 4462
FRONT WIPER AND WASHER SYSTEM WW-5
C
D E
F
G H
I
J
L
M A
B
WW
Revision: 2006 December 2006 FX35/FX45
to front wiper relay, located in IPDM E/R
to front wiper high relay, located in IPDM E/R and
to CPU located in IPDM E/R,
through 10 A fuse (No. 84, located in IPDM E/R)
through IPDM E/R terminal 44
to combination switch terminal 14.
Ground is supplied
to BCM terminals 49 and 52
through grounds M35, M45 and M85,
to IPDM E/R terminals 38 and 60
through grounds E21, E50 and E51,
to combination switch terminal 12
through grounds M35, M45 and M85.
LOW SPEED WIPER OPERATION
When wiper switch is in LOW position, BCM detects low speed wiper ON signal by BCM wiper switch reading
function.
BCM sends front wiper request signal (LO) with CAN communication line
from BCM terminals 39 and 40
to IPDM E/R terminals 48 and 49.
When IPDM E/R receives front wiper request signal (LO), it turns ON front wiper relay located in IPDM E/R,
power is supplied
to front wiper motor terminal 1
through IPDM E/R terminal 21 and front wiper relay and front wiper high relay.
Ground is supplied
to front wiper motor terminal 2
through grounds E21, E50 and E51.
With power and ground supplied, the front wiper motor operates at low speed.
HI SPEED WIPER OPERATION
When wiper switch is in HI position, BCM detects high speed wiper ON signal by BCM wiper switch reading
function.
BCM sends front wiper request signal (HI) with CAN communication line
from BCM terminals 39 and 40
to IPDM E/R terminals 48 and 49.
When IPDM E/R receives front wiper request signal (HI), it turns ON front wiper relay (located in IPDM E/R),
power is supplied
to front wiper motor terminal 4
through IPDM E/R terminal 31 and front wiper relay and front wiper high relay.
Ground is supplied
to front wiper motor terminal 2
through grounds E21, E50 and E51.
With power and ground supplied, the front wiper motor operates at high speed.
INTERMITTENT OPERATION
Front wiper intermittent operation delay interval is determined from a combination of 3 switches (intermittent
operation dial position 1, 2, and 3) and vehicle speed signal.
Speed dependent wiper controlled mode can be changed by the function setting of CONSULT-ll or display.
During each intermittent operation delay interval, BCM sends front wiper request signal to IPDM E/R.
Page 4408 of 4462
WW-6
FRONT WIPER AND WASHER SYSTEM
Revision: 2006 December 2006 FX35/FX45
Wiper Dial Position Setting
Example: For wiper intermittent dial position 1
Using combination switch reading function, BCM detects ON/OFF status of INT VOLUME 1, 2, and 3.
When combination switch status is as listed below, BCM determines that it is wiper intermittent dial position 1.
INT VOLUME 1: ON (Continuity exists between combination switch output 3 and input 1.)
INT VOLUME 2: ON (Continuity exists between combination switch output 5 and input 1.)
INT VOLUME 3: ON (Continuity exists between combination switch output 4 and input 2.)
BCM determines front wiper intermittent operation delay interval from wiper intermittent dial position 1 and
vehicle speed, and sends wiper request signal (INT) to IPDM E/R.
AUTO STOP OPERATION
With wiper switch turned OFF, wiper motor will continue to operate until wiper arms reach windshield base.
When wiper arms are not located at base of windshield with wiper switch OFF, ground is provided
from IPDM E/R terminal 21
to front wiper motor terminal 1, in order to continue wiper motor operation at low speed.
When wiper arms reach base of windshield, front wiper motor terminals 5 and 2 are connected,
and Ground is supplied
to IPDM E/R terminal 32
through front wiper motor terminals 5 and 2
through grounds E21, E50 and E51.
Then the IPDM E/R sends auto stop operation signal to BCM with CAN communication line.
When the BCM receives auto-stop operation signal, BCM sends wiper stop signal to IPDM E/R with CAN com-
munication line.
IPDM E/R stops wiper motor. Wiper motor will then stop wiper arms at the STOP position.
WASHER OPERATION
When wiper switch is in front wiper washer position with ignition switch on, BCM detects front wiper switch is
on the washer position by BCM wiper switch reading function (Refer to WW-8, "
COMBINATION SWITCH
READING FUNCTION" ), combination switch (wiper switch) ground is supplied
to combination switch terminal 13
through front and rear washer pump terminal 1
to front and rear washer pump terminal 2
through combination switch terminal 11
to combination switch terminal 12
through grounds M35, M45 and M85.
With ground supplied, front and rear washer pump is operated.
When BCM detects that front and rear washer pump has operated for 0.4 seconds or linger, BCM operates
front wiper motor for low speed.
When BCM detects washer switch is OFF, low speed operation cycles approximately 2 times and stops.
MIST OPERATION
When wiper switch is turned to MIST position, wiper low speed operation cycles once and then stops.
For additional information about wiper operation under this condition, Refer to WW-5, "
LOW SPEED WIPER
OPERATION" .
Wiper intermittent dial position Intermittent operation
interval Combination switch
INT VOLUME 1 INT VOLUME 2 INT VOLUME 3
1 Short
↑
↓
Long ON ON ON
2ONONOFF
3ONOFFOFF
4 OFF OFF OFF
5OFFOFFON
6 OFF ON ON
7 OFF ON OFF
Page 4409 of 4462
FRONT WIPER AND WASHER SYSTEM WW-7
C
D E
F
G H
I
J
L
M A
B
WW
Revision: 2006 December 2006 FX35/FX45
If switch is held in MIST position, low speed operation continues.
FAIL-SAFE FUNCTION
If an abnormality occurs in CAN communications, IPDM E/R holds the condition just before fail-safe status is
initiated until ignition switch is turned OFF. (If wipers were operating in LO just before the initiation of fail-safe
status, they continue to operate in LO until ignition switch is turned OFF.)
Page 4410 of 4462
WW-8
FRONT WIPER AND WASHER SYSTEM
Revision: 2006 December 2006 FX35/FX45
COMBINATION SWITCH READING FUNCTION
Description
BCM reads combination switch (wiper) status, and controls related systems such as head lamps and wip-
ers, according to the results.
BCM reads information of a maximum of 20 switches by combining five output terminals (OUTPUT 1-5)
and five input terminals (INPUT 1-5).
Operation Description
BCM activates transistors of output terminals (OUTPUT 1-5) periodically and, and allows current to flow in
turn.
If any (1 or more) switches are turned ON, circuit of output terminals (OUTPUT 1-5) and input terminals
(INPUT 1-5) becomes active.
At this time, transistors of output terminals (OUTPUT 1-5) are activated to allow current to flow. When volt-
age of input terminals (INPUT 1-5) corresponding to that switch changes, interface in BCM detects volt-
age change, and BCM determines that switch is ON.
PKIC9702E
