BCS-1
BODY CONTROL SYSTEM
K ELECTRICAL
CONTENTS
C
D E
F
G H
I
J
L
M
SECTION
A
B
BCS
Revision: 2006 July 2007 FX35/FX45
BODY CONTROL SYSTEM
PRECAUTIONS .......................................................... 2
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 2
BCM (BODY CONTROL MODULE) ...................... ..... 3
System Description ............................................. ..... 3
BCM FUNCTION .............................................. ..... 3
COMBINATION SWITCH READING FUNCTION ..... 3
CAN COMMUNICATION CONTROL ............... ..... 5
BCM STATUS CONTROL ................................ ..... 6
SYSTEMS CONTROLLED BY BCM DIRECTLY ..... 7
SYSTEMS CONTROLLED BY BCM AND IPDM
E/R ................................................................... ..... 7
SYSTEMS CONTROLLED BY BCM AND COM-
BINATION METER ........................................... ..... 7
SYSTEMS CONTROLLED BY BCM AND INTEL- LIGENT KEY UNIT ...........................................
..... 7
SYSTEMS CONTROLLED BY BCM, COMBINA-
TION METER AND IPDM E/R .......................... ..... 7
MAJOR COMPONENTS AND CONTROL SYS-
TEM .................................................................. ..... 8
CAN Communication Unit .................................... ..... 9
Schematic ............................................................ ... 10
CONSULT-II Function (BCM) .............................. ... 12
CONSULT–II INSPECTION PROCEDURE ...... ... 12
ITEMS OF EACH PART ................................... ... 12
WORK SUPPORT ............................................ ... 13
CAN Communication Inspection Using CONSULT-
II (Self-Diagnosis) ................................................ ... 13
Removal and Installation of BCM ........................ ... 14
REMOVAL ........................................................ ... 14
INSTALLATION ................................................ ... 14
Page 804 of 4366
BCS-6
BCM (BODY CONTROL MODULE)
Revision: 2006 July 2007 FX35/FX45
BCM STATUS CONTROL
BCM changes its status depending on the operation status in order to save power consumption.
1. CAN communication status
With ignition switch ON, CAN communicates with other control units normally.
Control by BCM is being operated properly.
When ignition switch is OFF, switching to sleep mode is possible.
Even when ignition switch is OFF, if CAN communication with IPDM E/R and combination meter is
active, CAN communication status is active.
2. Sleep transient status
This status shuts down CAN communication when ignition switch is turned OFF.
It transmits sleep request signal to IPDM E/R and combination meter.
2 seconds after CAN communication of all control units stops, sleep transient status is switched to CAN
communication inactive status.
3. CAN communication inactive status
With ignition switch OFF, CAN communication is not active.
With ignition switch OFF, control performed only by BCM is active.
3 seconds after CAN communication of all control units stops, CAN communication inactive status is
switched to sleep status.
4. Sleep status
BCM is activated with low power mode.
CAN communication is not active.
When CAN communication operation is detected, it switches to CAN communication status.
When a state of the following switches changes, it switches to CAN communication state.
–Key switch
–Hazard switch
–Door lock/unlock switch
–Front door switch (driver side, passenger side)
–Rear door switch (LH, RH)
–Back door opener switch
–Combination switch (passing, lighting switch 1ST position, front fog lamp)
–Key fob (lock/unlock signal)
–Key cylinder switch
When control performed only by BCM is required by switch, it shifts to CAN communication inactive
mode.
Operation mode of combination switch reading function is changed.
Page 805 of 4366
BCM (BODY CONTROL MODULE) BCS-7
C
D E
F
G H
I
J
L
M A
B
BCS
Revision: 2006 July 2007 FX35/FX45
SYSTEMS CONTROLLED BY BCM DIRECTLY
NOTE:
Power supply only. No system control.
SYSTEMS CONTROLLED BY BCM AND IPDM E/R
SYSTEMS CONTROLLED BY BCM AND COMBINATION METER
SYSTEMS CONTROLLED BY BCM AND INTELLIGENT KEY UNIT
SYSTEMS CONTROLLED BY BCM, COMBINATION METER AND IPDM E/R
System Reference
Power door lock system BL-21, "
POWER DOOR LOCK SYSTEM"
Remote keyless entry systemBL-54, "REMOTE KEYLESS ENTRY SYSTEM"
Power window system NOTEGW-15, "POWER WINDOW SYSTEM"
Sunroof NOTERF-10, "SUNROOF"
Room lamp timerLT-152, "INTERIOR ROOM LAMP"
Rear wiper and washer systemWW-39, "REAR WIPER AND WASHER SYSTEM"
System Reference
Panic alarm
BL-54, "REMOTE KEYLESS ENTRY SYSTEM"
BL-86, "INTELLIGENT KEY SYSTEM"
Theft warning system BL-180, "VEHICLE SECURITY (THEFT WARNING) SYSTEM"
IVIS (NATS)BL-205, "IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS)"
HeadlampLT- 6 , "HEADLAMP - XENON TYPE -"
Daytime light systemLT-38, "DAYTIME LIGHT SYSTEM"
Auto light systemLT-55, "AUTO LIGHT SYSTEM"
Front fog lampLT-78, "FRONT FOG LAMP"
Parking, license plate, side marker and tail lamps
Exterior lamp battery saver control LT-131, "PARKING, LICENSE PLATE AND TAIL LAMPS"
Front wiper and washer system
WW-4, "FRONT WIPER AND WASHER SYSTEM"
Rear window defoggerGW-67, "REAR WINDOW DEFOGGER"
System Reference
Warning chime DI-56, "
WARNING CHIME"
Turn signal and hazard warning lampsLT-90, "TURN SIGNAL AND HAZARD WARNING LAMPS"
Tire pressure monitoring systemWT-11, "TIRE PRESSURE MONITORING SYSTEM"
System Reference
Intelligent Key system BL-86, "
INTELLIGENT KEY SYSTEM"
System Reference
Oil pressure warning lamp DI-38, "
WARNING LAMPS"
Page 806 of 4366
BCS-8
BCM (BODY CONTROL MODULE)
Revision: 2006 July 2007 FX35/FX45
MAJOR COMPONENTS AND CONTROL SYSTEM
System Input Output
Remote control entry system Key fob
All-door locking actuator
Fuel lid Lock actuator
Turn signal lamp (LH, RH)
Combination meter
Intelligent key system Intelligent key unit
All-door locking actuator
Fuel lid Lock actuator
Turn signal lamp (LH, RH)
Combination meter
Power door lock system
Power window main switch
(door lock and unlock switch)
Power window sub switch (passenger side)
(door lock and unlock switch) All-door locking actuator
Power supply (IGN) to power window, sunroof Ignition power supply Power window and sunroof system
Power supply (BAT) to power window, sunroof
and power seat Battery power supplyPower window, sunroof system and
power seat
Panic alarm
Key switch
Key fob IPDM E/R
Theft warning system
All-door switch
Hood switch
Key fob
Power window main switch (door lock and
unlock switch)
Power window sub switch (passenger side)
(door lock and unlock switch)
IPDM E/R
Security indicator lamp
Auto light system
Optical sensor
Combination switch
Ignition switch IPDM E/R
Exterior lamp battery saver control
Ignition switch
Combination switch IPDM E/R
Headlamp Combination switch IPDM E/R
Daytime light system
Combination meter
ECM
Combination switch
Ignition switch IPDM E/R
Parking, license plate, side marker and tail
lamps Combination switch IPDM E/R
Front fog lamp Combination switch IPDM E/R
Turn signal lamp
Combination switch
Ignition switch
Turn signal lamp
Combination meter
Hazard lamp Hazard switch
Turn signal lamp
Combination meter
Room lamp timer
Key switch
Key fob
Power window main switch (door lock and
unlock switch)
Front door switch driver side
All-door switch Interior room lamp
Page 807 of 4366
BCM (BODY CONTROL MODULE) BCS-9
C
D E
F
G H
I
J
L
M A
B
BCS
Revision: 2006 July 2007 FX35/FX45
CAN Communication UnitNKS00340
Refer to LAN-49, "CAN System Specification Chart" .
Key warning chimeKey switch
Front door switch driver side Combination meter
(warning buzzer)
Light warning chime
Combination switch
Key switch
Front door switch driver side Combination meter
(warning buzzer)
Seat belt warning chime
Combination meter [Seat belt buckle
(driver side) switch]
Ignition switch Combination meter
(warning buzzer)
Front wiper and washer system
Combination switch
Combination meter
Ignition switch IPDM E/R
Rear wiper and washer system
Combination switch
Ignition switch Rear wiper motor
Rear window defogger
Rear window defogger switch
Ignition switch IPDM E/R
A/C switch signal Unified meter and A/C amp. ECM
Blower fan switch signal Unified meter and A/C amp. ECM
Low tire pressure warning system Remote keyless entry receiver Combination meter System Input Output
Page 810 of 4366
BCS-12
BCM (BODY CONTROL MODULE)
Revision: 2006 July 2007 FX35/FX45
CONSULT-II Function (BCM)NKS00342
CONSULT-II can display each diagnostic item using the diagnostic test mode shown following.
CONSULT–II INSPECTION PROCEDURE
Refer to GI-38, "CONSULT-II Start Procedure" .
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
ITEMS OF EACH PART
NOTE:
CONSULT-II displays systems equipped in the vehicle.
× :Applicable
BCM Diagnostic test item Check item, diagnostic test mode Content
Inspection by part WORK SUPPORT Changes setting of each function.
SELF-DIAG RESULTS BCM performs self-diagnosis of CAN communication.
DATA MONITOR Displays the input data of BCM in real time.
CAN DIAG SUPPORT MNTR The transmit/receive diagnosis result of CAN communication can be
read.
ACTIVE TEST Gives a drive signal to a load to check the operation.
ECU PART NUMBER ECM part number can be read.
CONFIGURATION (Not be used)
System and item CONSULT-II display Diagnostic test mode (Inspection by part)
WORK SUP-
PORT SELF
−
DIAG
RESULTS DATA
MONI- TOR CAN
DIAG SUP-
PORT
MNTR ACTIVE
TEST ECU
PA R T
NUM- BER CONFIG-
URATION
BCM BCM ×× × ×
×
NOTE 1
Power door lock system DOOR LOCK ×××
Rear window defogger REAR DEFOGGER ××
Warning chime BUZZER ××
Room lamp timer INT LAMP ×××
Remote keyless entry sys-
tem
NOTE 2MULTI REMOTE
ENT ×××
Headlamp HEAD LAMP ×××
Wiper WIPER ×××
Turn signal lamp
Hazard lamp FLASHER
××
Blower fan switch signal
A/C switch signal AIR CONDITONER
×
Intelligent Key system
NOTE 3INTELLIGENT KEY ×
Combination switch COMB SW ×
NVIS IMMU ××
Room lamp battery saver BATTERY SAVER ×× ×
Trunk lid TRUNK
NOTE 4××
Vehicle security system THEFT ALM ×××
Retained power control RETAINED PWR ×××
Oil pressure switch SIGNAL BUFFER ××
Page 811 of 4366
BCM (BODY CONTROL MODULE) BCS-13
C
D E
F
G H
I
J
L
M A
B
BCS
Revision: 2006 July 2007 FX35/FX45
NOTE:
1: This item is displayed, but should not be used.
2: Vehicle with remote keyless entry system display this item.
3: Vehicle with Intelligent Key system display this item.
4: This item is displayed, but does not function.
WORK SUPPORT
Operation Procedure
1. Touch “BCM” on “SELECT TEST ITEM” screen.
2. Touch “WORK SUPPORT” on “SELECT DIAG MODE” screen.
3. Touch item on “SELECT WORK ITEM” screen.
4. Touch “START”.
5. Touch “CHANGE SET”.
6. The setting will be changed and “RESETTING COMPLETED” will be displayed.
7. Touch “END”.
Display Item List
CAN Communication Inspection Using CONSULT-II (Self-Diagnosis)NKS00343
1. CHECK SELF-DIAGNOSTIC RESULT
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
1. Connect to CONSULT-II, and select “BCM” on “SELECT SYSTEM” screen.
2. Select “BCM control unit ” on “SELECT WORK ITEM” screen, and select “SELF-DIAG RESULTS”.
3. Check display content in self-diagnostic results.
Contents displayed
No malfunction>> INSPECTION END
Malfunction in CAN communication system>> After printing the monitor items, go to “CAN System”. Refer to
LAN-49, "
CAN System Specification Chart" .
Low tire pressure warning
system AIR PRESSURE
MONITOR ××× ×
Panic system PANIC ALARM ×
System and item CONSULT-II display
Diagnostic test mode (Inspection by part)
WORK SUP-
PORT SELF
−
DIAG
RESULTS DATA
MONI- TOR CAN
DIAG SUP-
PORT
MNTR ACTIVE
TEST ECU
PA RT
NUM- BER CONFIG-
URATION
Item Description
RESET SETTING VALUE Return a value set with WORK SUPPORT of each system to a default value in factory shipment.
CONSULT-II display code Diagnosis item
U1000 INITIAL DIAG
TRANSMIT DIAG ECM
IPDM E/R
METER/M&A I-KEY
Page 812 of 4366
BCS-14
BCM (BODY CONTROL MODULE)
Revision: 2006 July 2007 FX35/FX45
Removal and Installation of BCMNKS00344
REMOVAL
1. Remove the dash side finisher (LH). Refer to EI-38, "BODY
SIDE TRIM" .
2. Disconnect BCM connector.
3. Remove bracket mounting screws (3) to remove BCM and fuse block with bracket.
4. Raise the pawl of fuse block and remove bracket from fuse block to remove BCM.
INSTALLATION
Installation is the reverse order of removal.
NOTE:
When replacing BCM perform initialization of NATS system and registration of all NATS ignition key IDs.
SKIA4964E
SKIA4965E
Page 813 of 4366
BL-1
BODY, LOCK & SECURITY SYSTEM
I BODY
CONTENTS
C
D E
F
G H
J
K L
M
SECTION
A
B
BL
Revision: 2006 July 2007 FX35/FX45
BODY, LOCK & SECURITY SYSTEM
PRECAUTIONS .......................................................... 5
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 5
Precautions Necessary for Steering Wheel Rotation
After Battery Disconnect ..................................... ..... 5
OPERATION PROCEDURE ............................ ..... 5
Precautions for Work ........................................... ..... 5
PREPARATION ...................................................... ..... 6
Special Service Tools .......................................... ..... 6
Commercial Service Tools ................................... ..... 6
SQUEAK AND RATTLE TROUBLE DIAGNOSIS . ..... 7
Work Flow ........................................................... ..... 7
CUSTOMER INTERVIEW ................................ ..... 7
DUPLICATE THE NOISE AND TEST DRIVE .. ..... 8
CHECK RELATED SERVICE BULLETINS ...... ..... 8
LOCATE THE NOISE AND IDENTIFY THE
ROOT CAUSE ................................................. ..... 8
REPAIR THE CAUSE ...................................... ..... 8
CONFIRM THE REPAIR .................................. ..... 9
Generic Squeak and Rattle Troubleshooting ...... ..... 9
INSTRUMENT PANEL ..................................... ..... 9
CENTER CONSOLE ........................................ ..... 9
DOORS ............................................................ ..... 9
TRUNK ............................................................. ... 10
SUNROOF/HEADLINING ................................ ... 10
SEATS .............................................................. ... 10
UNDERHOOD .................................................. ... 10
Diagnostic Worksheet ......................................... .... 11
HOOD .................................................................... ... 13
Fitting Adjustment ............................................... ... 13
LONGITUDINAL AND LATERAL CLEARANCE
ADJUSTMENT ................................................. ... 13
FRONT END HEIGHT ADJUSTMENT ............ ... 13
SURFACE HEIGHT ADJUSTMENT ................ ... 13
Removal and Installation of Hood Assembly ....... ... 14
REMOVAL ........................................................ ... 15
INSTALLATION ................................................ ... 15
Removal and Installation of Hood Lock Control .. ... 15
REMOVAL ........................................................ ... 15 INSTALLATION ................................................
... 16
Hood Lock Control Inspection ............................. ... 16
RADIATOR CORE SUPPORT ............................... ... 18
Removal and Installation ..................................... ... 18
REMOVAL ........................................................ ... 18
INSTALLATION ................................................ ... 19
FRONT FENDER ................................................... ... 20
Removal and Installation ..................................... ... 20
REMOVAL ........................................................ ... 20
INSTALLATION ................................................ ... 20
POWER DOOR LOCK SYSTEM ........................... ... 21
Component Parts and Harness Connector Location ... 21
System Description .............................................. ... 22
OUTLINE .......................................................... ... 23
CAN Communication System Description ........... ... 24
CAN Communication Unit .................................... ... 24
Schematic/With Intelligent Key ............................ ... 25
Wiring Diagram — D/LOCK —/With Intelligent Key ... 26
Schematic/Without Intelligent Key ....................... ... 31
Wiring Diagram — D/LOCK —/Without Intelligent
Key ...................................................................... ... 32
Terminals and Reference Value for BCM ............ ... 36
Terminals and Reference Value for Intelligent Key
Unit (With Intelligent Key System) ....................... ... 36
Work Flow ............................................................ ... 37
CONSULT-II Function (BCM) .............................. ... 37
CONSULT-II START PROCEDURE ................. ... 37
CONSULT-II APPLICATION ITEMS ................. ... 37
Trouble Diagnosis Chart by Symptom ................. ... 38
Check BCM Power Supply and Ground Circuit ... ... 39
Check Door Switch .............................................. ... 40
CHECK DOOR SWITCH (EXCEPT BACK DOOR
SWITCH) .......................................................... ... 40
CHECK BACK DOOR SWITCH ....................... ... 42
Check Key Switch ................................................ ... 44
Check Door Lock and Unlock Switch .................. ... 46
Check Door Lock Actuator (Driver Side) ............. ... 48
Check Door Lock Actuator (Passenger Side and
Rear LH/RH) ........................................................ ... 49
Check Fuel Lid Lock Actuator .............................. ... 50
Page 814 of 4366
BL-2Revision: 2006 July 2007 FX35/FX45
Check Front Door Key Cylinder Switch (Lock) ....
... 51
Check Front Door Key Cylinder Switch (Unlock) . ... 52
Check Select Unlock Relay Circuit ...................... ... 53
REMOTE KEYLESS ENTRY SYSTEM .................. ... 54
Component Parts and Harness Connector Location ... 54
System Description .............................................. ... 55
INPUTS ............................................................ ... 55
OPERATED PROCEDURE .............................. ... 56
CAN Communication System Description ........... ... 57
CAN Communication Unit .................................... ... 57
Schematic ............................................................ ... 58
Wiring Diagram — KEYLES — ............................ ... 59
Terminals and Reference Value for BCM ............. ... 62
Terminals and Reference Value for IPDM E/R ..... ... 63
CONSULT-II Function (BCM) ............................... ... 64
CONSULT-II INSPECTION PROCEDURE ....... ... 64
CONSULT-II APPLICATION ITEMS ................. ... 64
Work Flow ............................................................ ... 66
Trouble Diagnosis Chart by Symptom ................. ... 67
Check Key Fob Battery and Function .................. ... 69
Check ACC Switch .............................................. ... 70
Check Door Switch .............................................. ... 71
CHECK DOOR SWITCH (EXCEPT BACK DOOR
SWITCH) .......................................................... ... 71
CHECK BACK DOOR SWITCH ....................... ... 73
Check Key Switch ................................................ ... 75
Check Remote Keyless Entry Receiver ............... ... 76
Check IPDM E/R Operation ................................. ... 79
Check Hazard Warning Lamp Function ............... ... 80
Check Horn Function ........................................... ... 80
Check Headlamp Function .................................. ... 80
Check Map Lamp and Ignition Keyhole Illumination
Function ............................................................... ... 80
ID Code Entry Procedure .................................... ... 81
KEY FOB ID SET UP WITH CONSULT-II ........ ... 81
KEY FOB ID SET UP WITHOUT CONSULT-II . ... 83
Removal and Installation of Remote keyless Entry
receiver ................................................................ ... 84
REMOVAL ........................................................ ... 84
INSTALLATION ................................................. ... 84
Key Fob Battery Replacement ............................. ... 85
INTELLIGENT KEY SYSTEM ................................ ... 86
Component Parts and Harness Connector Location ... 86
System Description .............................................. ... 88
DOOR LOCK FUNCTION ................................ ... 88
REMOTE CONTROL ENTRY FUNCTIONS ..... ... 89
ENGINE STARTUP FUNCTION ....................... ... 90
WARNING AND ALARM FUNCTION ............... ... 91
CHANGE SETTINGS FUNCTION .................... ... 94
INTELLIGENT KEY REGISTRATION ............... ... 94
STEERING LOCK UNIT REGISTRATION ....... ... 94
CAN Communication System Description ........... ... 95
CAN Communication Unit .................................... ... 95
Schematic ............................................................ ... 96
Wiring Diagram — I/KEY — ................................ ... 98
Terminals and Reference Value for INTELLIGENT
KEY UNIT ............................................................ ..111
Terminals and Reference Value for Steering Lock
unit ....................................................................... .113 Terminals and Reference Value for BCM .............
.113
Terminals and Reference Value for IPDM E/R ..... .114
Diagnosis Procedure ............................................ .115
WORK FLOW ................................................... .115
CONSULT-II Functions (INTELLIGENT KEY) ...... .116
CONSULT-II Start Procedure ............................... .116
CONSULT-II Application Items ............................. .116
WORK SUPPORT ............................................ .116
SELF-DIAGNOSTIC RESULTS ........................ .116
DATA MONITOR ............................................... .117
ACTIVE TEST ................................................... .117
List of Operation Related Parts ............................ .118
Trouble Diagnosis Symptom Chart ...................... .119
ALL FUNCTIONS OF THE INTELLIGENT KEY
ARE NOT OPERATING .................................... .119
REMOTE CONTROL ENTRY FUNCTION MAL-
FUNCTION ....................................................... .119
DOOR LOCK FUNCTION MALFUNCTION ...... .120
ENGINE START FUNCTION MALFUNCTION . .121
WARNING CHIME FUNCTION MALFUNCTION .121
Check CAN Communication System Inspection .. .124
Check Intelligent Key Unit Power Supply and
Ground Circuit ...................................................... .124
Check Key Switch (Intelligent Key Unit Input) ...... .125
Check Key Switch (BCM Input) ............................ .126
Check Ignition Knob Switch ................................. .127
Check Door Switch .............................................. .129
CHECK DOOR SWITCH (EXCEPT BACK DOOR
SWITCH) ........................................................... .129
CHECK BACK DOOR SWITCH ........................ .130
Check Unlock Sensor .......................................... .131
Check Door Request Switch ................................ .133
Check Intelligent Key Warning Buzzer ................. .134
Check Outside Key Antenna ................................ .135
Check Inside Key Antenna ................................... .138
Check Steering Lock Unit ..................................... .139
Check Stop Lamp Switch ..................................... .141
Check Park Position Switch ................................. .142
Check Select Unlock Relay .................................. .144
Check Hazard Function ....................................... .145
Check Horn Function ........................................... .145
Check Headlamp Function ................................... .145
Check IPDM E/R Operation ................................. .145
Removal and Installation of Intelligent Key Unit ... .146
REMOVAL ......................................................... .146
INSTALLATION ................................................. .146
Intelligent Key Battery Replacement .................... .147
INTELLIGENT KEY BATTERY INSPECTION .. .147
DOOR ..................................................................... .148
Fitting Adjustment ................................................ .148
FRONT DOOR .................................................. .148
REAR DOOR .................................................... .148
STRIKER ADJUSTMENT ................................. .149
Removal and Installation of Front Door ............... .149
REMOVAL ......................................................... .149
INSTALLATION ................................................. .150
Removal and Installation of Rear Door ................ .150
REMOVAL ......................................................... .150
