AT-122
< SERVICE INFORMATION >
DTC P0735 A/T 5TH GEAR FUNCTION
DTC P0735 A/T 5TH GEAR FUNCTION
DescriptionINFOID:0000000001375132
This malfunction is detected when the A/T does not shift into 5th gear position as instructed by TCM. This is
not only caused by electrical malfunction (circuits open or shorted) but also by mechanical malfunction such
as control valve sticking, improper solenoid valve operation.
On Board Diagn osis LogicINFOID:0000000001375133
Diagnostic trouble code “P0735 A/T 5TH GR FNCTN” wit h CONSULT-III or 22nd judgment flicker without
CONSULT-III is detected when TCM detects any inconsistency in the actual gear ratio.
Possible CauseINFOID:0000000001375134
 Harness or connectors
(Solenoid circuits are open or shorted.)
 Input clutch solenoid valve
 Front brake solenoid valve
 Direct clutch solenoid valve
 High and low reverse clutch solenoid valve
 Each clutch
 Hydraulic control circuit
DTC Confirmation ProcedureINFOID:0000000001375135
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, alw ays turn ignition switch OFF and
wait at least 10 seconds before performing the next test.
After the repair, perform the following proc edure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Start the engine and select “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III.
2. Make sure that “ATF TEMP 1” is within the following range. ATF TEMP 1: 20 °C – 140 °C
If out of range, drive vehicle to warm ATF or stop engine to cool ATF.
3. Select “5TH GR FNCTN P0735” of “DTC WORK SUPPORT” mode for “TRANSMISSION” with CON-
SULT-III.
4. Drive vehicle and maintain the following conditions.
VEHICLE SPEED: 10 km/h (6 MPH) or more
ACCELE POSI: 0.6/8 or more
ENGINE SPEED: TURBINE REV − 50 rpm or more
TURBINE REV: 300 rpm or more
GEAR: “5” position
MANU MODE SW: ON
5. Keep the current driving status for at least 5 consecutive seconds if CONSULT-III screen changes from
“OUT OF CONDITION” to “TESTING”.
CAUTION:
If “TESTING” does not ap pear on CONSULT-III for a long ti me, select “SELF-DIAG RESULTS”. In
case a 1st trip DTC other than P0735 is shown, refer to “ AT-84, "
CONSULT-III Function (TRANSMIS-
SION)"”.
If “COMPLETED RESULT NG” is detected, go to AT-123, "
Diagnosis Procedure".
If “STOP VEHICLE” is detect ed, go to the following step.
6. Stop vehicle.
7. Drive vehicle in “D” position allowing it to shift fr om 1st to 5th gear and check shift timing and shift shock.
- Touch “OK” to complete the inspection when normally shifted from the 1st to 5th gear.
- Touch “NG” when an unusual shift shock, etc. occurs in spite of shifting from the 1st to 5th gear. Go to AT-
49, "Inspections Before Trouble Diagnosis".
- Perform AT-84, "
CONSULT-III Function (TRANSMISSION)" when not shifted from the 1st to 5th gear.
(Neither “OK” nor “NG” are indicated.)
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

AT-124
< SERVICE INFORMATION >
DTC P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE
DTC P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE
DescriptionINFOID:0000000001327209
 The torque converter clutch solenoid va lve is activated, with the gear in D5, M3, M4 and M5 by the TCM in
response to signals sent from the vehicle speed sensor and accelerator pedal position sensor (throttle posi-
tion sensor). Torque converter clutch piston operation will then be controlled.
 Lock-up operation, however, is prohibited when A/T fluid temperature is too low.
 When the accelerator pedal is depressed (less than 1. 0/8) in lock-up condition, the engine speed should not
change abruptly. If there is a big jump in engine speed, there is no lock-up.
CONSULT-III Reference Value in Data Monitor ModeINFOID:0000000001327210
On Board Diagnosis LogicINFOID:0000000001327211
Diagnostic trouble code “P0740 TCC SOLENOID/CIRC” with CONSULT-III or 3rd judgement flicker without
CONSULT-III is detected under the following conditions.
 When TCM detects an improper voltage drop when it tries to operate the solenoid valve.
 When TCM detects as irregular by comparing target value with monitor value.
Possible CauseINFOID:0000000001327212
 Torque converter clutch solenoid valve
 Harness or connectors (Solenoid circuit is open or shorted.)
DTC Confirmation ProcedureINFOID:0000000001327213
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
After the repair, perform the following proc edure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “SELECTION FROM MENU” in “DATA MONI TOR” mode for “TRANSMISSION” with CONSULT-III
and check monitor “VHCL/S SE-A/T”, “ACCELE POSI” and “SLCT LVR POSI”.
3. Touch “START”.
4. Start engine and maintain the following conditions for at least 5 consecutive seconds. VHCL/S SE-A/T: 80 km/h (50 MPH) or more
ACCELE POSI: 0.5/8 - 1.0/8
SLCT LVR POSI: “D” position
Driving location: Driving the vehicle uphill (increased engine load) will help maintain the driving
conditions required for this test.
5. If DTC is detected go to AT-124, "
Diagnosis Procedure".
WITH GST
Follow the procedure “WITH CONSULT-III”.
Diagnosis ProcedureINFOID:0000000001327214
1.CHECK INPUT SIGNAL
With CONSULT-III
1. Turn ignition switch ON.
Item name Condition Display value (Approx.)
TCC SOLENOID Slip lock-up is active 0.2 - 0.4 A
Lock-up is active 0.4 - 0.6 A
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

DTC P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE
AT-125
< SERVICE INFORMATION >
D E
F
G H
I
J
K L
M A
B
AT
N
O P
2. Select “MAIN SIGNALS” in “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III.
3. Start engine.
4. Read out the value of “TCC SOLENOID” while driving.
OK or NG
OK >> GO TO 4.
NG >> GO TO 2.
2.CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer to AT-160
.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3.DETECT MALFUNCTIONING ITEM
Check A/T assembly harness connector pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace the control valve with TCM. Refer to AT-215, "Control Valve with TCM and A/T Fluid Tem-
perature Sensor 2".
NG >> Repair or replace damaged parts.
4.CHECK DTC
Perform AT-124, "
DTC Confirmation Procedure".
OK or NG
OK >> INSPECTION END
NG >> GO TO 2.
Item name Condition Display value (Approx.)
TCC SOLENOID Slip lock-up is active 0.2 - 0.4 A
Lock-up is active 0.4 - 0.6 A
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

AT-126
< SERVICE INFORMATION >
DTC P0744 A/T TCC S/V FUNCTION (LOCK-UP)
DTC P0744 A/T TCC S/V FUNCTION (LOCK-UP)
DescriptionINFOID:0000000001327215
This malfunction is detected when the A/T does not shift into 5th gear position or the torque converter clutch
does not lock-up as instructed by the TCM. This is not only caused by electrical malfunction (circuits open or
shorted) but also by mechanical malfunction such as control valve sticking, improper solenoid valve operation,
etc.
CONSULT-III Reference Value in Data Monitor ModeINFOID:0000000001327216
On Board Diagn osis LogicINFOID:0000000001327217
Diagnostic trouble code “P0744 A/T TCC S/V FNCTN” wit h CONSULT-III or 3rd judgement flicker without
CONSULT-III is detected under the following conditions.
 When A/T cannot perform lock-up even if electrical circuit is good.
 When TCM detects as irregular by comparing difference value with slip rotation.
Possible CauseINFOID:0000000001327218
 Harness or connectors (Solenoid circuit is open or shorted.)
 Torque converter clutch solenoid valve
 Hydraulic control circuit
DTC Confirmation ProcedureINFOID:0000000001327219
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, alw ays turn ignition switch OFF and
wait at least 10 seconds before performing the next test.
After the repair, perform the following proc edure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Start engine.
2. Select “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III.
3. Drive vehicle and maintain the following conditions for at least 30 consecutive seconds. ACCELE POSI: More than 1.0/8
SLCT LVR POSI: “D” position
TCC SOLENOID: 0.4 - 0.6 A
VEHICLE SPEED: 80 km/h (50 MPH) or more
Driving location: Driving the vehicle uphill (increased engine load) will help maintain the driving
conditions required for this test.
4. If DTC is detected, go to AT-126, "
Diagnosis Procedure".
WITH GST
Follow the procedure “WITH CONSULT-III”.
Diagnosis ProcedureINFOID:0000000001327220
1.CHECK INPUT SIGNAL
With CONSULT-III
1. Turn ignition switch ON.
2. Select “MAIN SIGNALS” in “DATA MONITO R” mode for “TRANSMISSION” with CONSULT-III.
3. Start the engine.
Item name Condition Display value (Approx.)
TCC SOLENOID Slip lock-up is active 0.2 - 0.4 A
Lock-up is active 0.4 - 0.6 A
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

AT-128
< SERVICE INFORMATION >
DTC P0745 LINE PRESSURE SOLENOID VALVE
DTC P0745 LINE PRESSURE SOLENOID VALVE
DescriptionINFOID:0000000001327221
The line pressure solenoid valve regulates the oil pump discharge pressure to suit the driving condition in
response to a signal sent from the TCM.
CONSULT-III Reference Value in Data Monitor ModeINFOID:0000000001327222
On Board Diagnosis LogicINFOID:0000000001327223
Diagnostic trouble code “P0745 L/PRESS SOL/CIRC” with CONSULT-III or 4th judgement flicker without
CONSULT-III is detected under the following conditions.
 When TCM detects an improper voltage drop when it tries to operate the solenoid valve.
 When TCM detects as irregular by comparing target value with monitor value.
Possible CauseINFOID:0000000001327224
 Harness or connectors (Solenoid circuit is open or shorted.)
 Line pressure solenoid valve
DTC Confirmation ProcedureINFOID:0000000001327225
NOTE:
If “DTC Confirmation Procedure” has been previously performed, alw ays turn ignition switch OFF and
wait at least 10 seconds before performing the next test.
After the repair, perform the following proc edure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “MAIN SIGNALS” in “DATA MONITO R” mode for “TRANSMISSION” with CONSULT-III.
3. Touch “START”.
4. Engine start and wait at least 5 seconds.
5. If DTC is detected, go to “ AT-128, "
Diagnosis Procedure".
WITH GST
Follow the procedure “WITH CONSULT-III”.
Diagnosis ProcedureINFOID:0000000001327226
1.CHECK INPUT SIGNAL
With CONSULT-III
1. Turn ignition switch ON.
2. Select “MAIN SIGNALS” in “DATA MONITO R” mode for “TRANSMISSION” with CONSULT-III.
3. Start engine.
4. Read out the value of “LINE PRES SOL” while driving.
OK or NG
OK >> GO TO 4.
NG >> GO TO 2.
2.CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer to AT-160
.
Item name Condition Display value (Approx.)
LINE PRES SOL During driving 0.2 - 0.6 A
Item name Condition Display value (Approx.)
LINE PRES SOL During driving 0.2 - 0.6 A
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

AT-130
< SERVICE INFORMATION >
DTC P1705 THROTTLE POSITION SENSOR
DTC P1705 THROTTLE POSITION SENSOR
DescriptionINFOID:0000000001327227
Electric throttle control actuator consists of throttle control motor, accelerator pedal position sensor, throttle
position sensor, etc. The actuator sends a signal to the ECM, and ECM sends signals to TCM with CAN com-
munication.
CONSULT-III Reference Value in Data Monitor ModeINFOID:0000000001327228
On Board Diagn osis LogicINFOID:0000000001327229
Diagnostic trouble code “P1705 TP SEN/CIRC A/T” with CO NSULT-III or 15th judgement flicker without CON-
SULT-III is detected when TCM does not receive the proper accelerator pedal position signals (input by CAN
communication) from ECM.
Possible CauseINFOID:0000000001327230
Harness or connectors
(Sensor circuit is open or shorted.)
DTC Confirmation ProcedureINFOID:0000000001327231
NOTE:
If “DTC Confirmation Procedure” has been previously performed, alw ays turn ignition switch OFF and
wait at least 10 seconds before performing the next test.
After the repair, perform the following proc edure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “ECU INPUT SIGNALS” in “DATA MONI TOR” mode for “TRANSMISSION” with CONSULT-III.
3. Touch “START”.
4. Start engine and let it idle for 1 second.
5. If DTC is detected, go to AT-130, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001327232
1.CHECK CAN COMMUNICATION LINE
With CONSULT-III
 Perform the self-diagnosis.
Without CONSULT-III
 Perform the self-diagnosis. Refer to AT-91, "
Diagnosis Procedure without CONSULT-III".
Is a malfunction in the CAN communication indicated in the results?
YES >> Check CAN communication line. Refer to AT- 9 4.
NO >> GO TO 2.
2.CHECK DTC WITH TCM
With CONSULT-III
1. Turn ignition switch ON.
2. Select “ECU INPUT SIGNALS” in “DATA MONI TOR” mode for “TRANSMISSION” with CONSULT-III.
3. Depress accelerator pedal and read out the value of “ACCELE POSI”.
Item name Condition Display value (Approx.)
ACCELE POSI Released accelerator pedal. 0.0/8
Fully depressed accelerator pedal. 8.0/8
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

DTC P1705 THROTTLE POSITION SENSORAT-131
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
4. Select “SELF-DIAG RESULTS” mode for “T RANSMISSION” with CONSULT-III. Refer to AT-84, "CON-
SULT-III Function (TRANSMISSION)".
OK or NG
OK >> GO TO 4.
NG >> GO TO 3.
3.CHECK DTC WITH ECM
With CONSULT-III
1. Turn ignition switch ON.
2. Select “SELF-DIAG RESULTS” mode for “ENGINE” with CONSULT-III. Refer to EC-117, "
CONSULT-III
Function (ENGINE)" (for VQ35DE) or EC-695, "CONSULT-III Function (ENGINE)" (for VK45DE).
OK or NG
OK >> GO TO 4.
NG >> Check the DTC detected item. Refer to EC-117, "
CONSULT-III Function (ENGINE)" (for
VQ35DE) or EC-695, "
CONSULT-III Function (ENGINE)" (for VK45DE).
 If CAN communication line is detected, go to AT- 9 4
.
4.CHECK DTC
Perform AT-130, "
DTC Confirmation Procedure".
OK or NG
OK >> INSPECTION END
NG >> GO TO 5.
5.CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer to AT-160
.
OK or NG
OK >> GO TO 6.
NG >> Repair or replace damaged parts.
6.DETECT MALFUNCTIONING ITEM
Check A/T assembly harness connector pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace the control valve with TCM. Refer to AT-215, "Control Valve with TCM and A/T Fluid Tem-
perature Sensor 2".
NG >> Repair or replace damaged parts.
Item name Condition Display value (Approx.)
ACCELE POSI Released accelerator pedal. 0.0/8
Fully depressed accelerator pedal. 8.0/8
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

AT-132
< SERVICE INFORMATION >
DTC P1710 A/T FLUID TEMPERATURE SENSOR CIRCUIT
DTC P1710 A/T FLUID TEMPER ATURE SENSOR CIRCUIT
DescriptionINFOID:0000000001327233
The A/T fluid temperature sensor detects the A/ T fluid temperature and sends a signal to the TCM.
CONSULT-III Reference Value in Data Monitor ModeINFOID:0000000001327234
On Board Diagnosis LogicINFOID:0000000001327235
Diagnostic trouble code “P1710 (A/T), P0710 (ENGINE) ATF TEMP SEN/CIRC” with CONSULT-III or 10th
judgement flicker without CONSULT-III is detected w hen TCM receives an excessively low or high voltage
from the sensor.
Possible CauseINFOID:0000000001327236
 Harness or connectors (Sensor circuit is open or shorted.)
 A/T fluid temperature sensors 1 and/or 2
DTC Confirmation ProcedureINFOID:0000000001327237
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, alw ays turn ignition switch OFF and
wait at least 10 seconds before performing the next test.
After the repair, perform the following proc edure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “SELECTION FROM MENU” in “DATA MONI TOR” mode for “TRANSMISSION” with CONSULT-III
and check monitor “VHCL/S SE-A/T”, “ACCELE POSI” and “SLCT LVR POSI”.
3. Touch “START”.
4. Start engine and maintain the following conditions for at least 10 minutes (Total). (It is not necessary to maintain continuously.)
VHCL/S SE-A/T: 10 km/h (6 MPH) or more
ACCELE POSI: More than 1.0/8
SLCT LVR POSI: “D” position
5. If DTC is detected, go to AT-133, "
Diagnosis Procedure".
WITH GST
Follow the procedure “WITH CONSULT-III”.
Item name Condition °C ( °F) Display value (Approx.)
ATF TEMP SE 1 0 (32) - 20 (68) - 80 (176) 3.3 - 2.7 - 0.9 V
ATF TEMP SE 2 3.3 - 2.5 - 0.7 V
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

DTC P1710 A/T FLUID TEMPERATURE SENSOR CIRCUIT
AT-133
< SERVICE INFORMATION >
D E
F
G H
I
J
K L
M A
B
AT
N
O P
Wiring Diagram - AT - FTSINFOID:0000000001327238
Diagnosis ProcedureINFOID:0000000001327239
1.CHECK A/T FLUID TEMPERATURE SENSOR 1 SIGNAL
With CONSULT-III
1. Start engine.
TCWM0251E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

AT-134
< SERVICE INFORMATION >
DTC P1710 A/T FLUID TEMPERATURE SENSOR CIRCUIT
2. Select “ECU INPUT SIGNALS” in “DATA MONI TOR” mode for “TRANSMISSION” with CONSULT-III.
3. Read out the value of “ATF TEMP SE 1”.
OK or NG
OK >> GO TO 2.
NG >> GO TO 3.
2.CHECK A/T FLUID TEMPER ATURE SENSOR 2 SIGNAL
With CONSULT-III
1. Start engine.
2. Select “ECU INPUT SIGNALS” in “DATA MONI TOR” mode for “TRANSMISSION” with CONSULT-III.
3. Read out the value of “ATF TEMP SE 2”.
OK or NG
OK >> GO TO 8.
NG >> GO TO 5.
3.CHECK A/T FLUID TEMPERATURE SENSOR 1
Check A/T fluid temperature sensor 1. Refer to AT-135, "
Component Inspection".
OK or NG
OK >> GO TO 4.
NG >> Replace the control valve with TCM. Refer to AT-215, "
Control Valve with TCM and A/T Fluid Tem-
perature Sensor 2".
4.CHECK SUB-HARNESS
1. Disconnect park/neutral position switch connector and TCM connector.
2. Check continuity between park/neutral position switch connector terminals and TCM connector terminals.
3. If OK, check harness for short to ground and short to power.
OK or NG
OK >> GO TO 7.
NG >> Replace open circuit or short to ground and short to power in harness or connectors.
5.CHECK A/T FLUID TEMPERATURE SENSOR 2
Check A/T fluid temperature sensor 2. Refer to AT-135, "
Component Inspection".
OK or NG
OK >> GO TO 6.
NG >> Replace the A/T fluid temperature sensor 2. Refer to AT-215, "
Control Valve with TCM and A/T
Fluid Temperature Sensor 2".
6.CHECK TERMINAL CORD ASSEMBLY
1. Disconnect A/T fluid temperature sensor 2 connector and TCM connector.
Item name Condition °C ( °F) Display value (Approx.)
ATF TEMP SE 1 0 (32) - 20 (68) - 80 (176) 3.3 - 2.7 - 0.9 V
Item name Condition °C ( °F) Display value (Approx.)
ATF TEMP SE 2 0 (32) - 20 (68) - 80 (176) 3.3 - 2.5 - 0.7 V
Item Connector Terminal Continuity
Park/neutral position switch
connector F505 6
Ye s
TCM connector F503 19
Park/neutral position switch
connector F505 7
Ye s
TCM connector F503 18
SCIA5461E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
