CONTENTS
AUTO CRUISE CONTROL SYSTEM
ASCD
SERVICE INFORMATION .. ..........................
3
AUTOMATIC SPEED CONTROL DEVICE
(ASCD) ........................................................... .....
3
Description .......................................................... ......3
ICC
SERVICE INFORMATION .. ..........................
4
DTC INDEX ..................................................... .....4
DTC 11 - 65 ......................................................... ......4
DTC 74 - 109 .............................................................4
PRECAUTIONS ...................................................5
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
5
Precaution for ICC System Service ...........................5
PREPARATION ...................................................6
Special Service Tool ........................................... ......6
DESCRIPTION ....................................................7
Outline ................................................................. ......7
Functional Diagram ...................................................7
Component Description .............................................9
CAN Communication .................................................9
Switch Operation .....................................................10
ICC System Display ................................................10
ACTION TEST ....................................................11
ICC System Running Test ................................... ....11
LASER BEAM AIMING ADJUSTMENT .............14
Outline ................................................................. ....14
Preparation ..............................................................14
Outline of Adjustment Procedure ............................14
Setting the ICC Target Board ..................................14
Aiming Adjustment ..................................................16
ELECTRICAL UNITS LOCATION ....................18
Component Parts and Harness Connector Loca-
tion ....................................................................... ....
18
WIRING DIAGRAM ...........................................19
Schematic ................................................................19
Wiring Diagram - ICC - ............................................20
TERMINALS AND REFERENCE VALUE .........27
Terminal and Reference Value for ICC Unit ............27
Terminal and Reference Value for ICC Sensor ... ....28
TROUBLE DIAGNOSIS — GENERAL DE-
SCRIPTION .......................................................
29
Work Flow ................................................................29
CONSULT-III Function (ICC) ...................................29
Self-Diagnostic Function ..........................................32
TROUBLE DIAGNOSIS FOR SELF-DIAG-
NOSTIC ITEMS .................................................
35
Diagnostic Trouble Code (DTC) Chart ....................35
DTC 11 CONTROL UNIT ........................................36
DTC 20 CAN COMM CIRCUIT ................................36
DTC 31 POWER SUPPLY CIR, DTC 34 POWER
SUPPLY CIR 2 ........................................................
37
DTC 41 VHCL SPEED SE CIRC .............................37
DTC 43 ABS/TCS/VDC CIRC .................................38
DTC 45 BRAKE SW/STOP L SW ............................38
DTC 46 OPERATION SW CIRC ......................... ....40
DTC 61 PRESS SEN CIRCUIT ...............................41
DTC 62 BOOSTER SOL/V CIRCUIT .................. ....42
DTC 63 RELEASE SW CIRCUIT ............................43
DTC 65 PRESSURE CONTRO L .............................45
DTC 74 LASER BEAM OFF CNTR ..................... ....45
DTC 90 STOP LAMP RLY FIX ................................46
DTC 92 ECM CIRCUIT ............................................50
DTC 96 NP RANGE ................................................51
DTC 97 AT CIRCUIT ...............................................52
DTC 98 GEAR POSITION .......................................52
DTC 102 RADAR STAIN .........................................53
DTC 103 LASER SENSOR FAIL .............................53
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ACS-2
DTC 104 LASER AIMING INCMP ..........................54
DTC 107 LASER COMM FAIL ...............................54
DTC 109 LASER HIGH TEMP ...............................54
TROUBLE DIAGNOSIS FOR SYMPTOMS .......55
Symptom Chart .................................................... ...55
Symptom 1 MAIN Switch Does Not Turn ON*1,
MAIN Switch Does Not Turn OFF*2 ..................... ...55
Symptom 2 ICC System Cannot Be Set (MAIN
Switch Turns ON/OFF) ........................................ ...
56
Symptom 3 ICC System Cannot Be Operated by
CANCEL Switch, RESUME/ACCELERATE
Switch or DISTANCE Switch ..................................
56
Symptom 4 ICC System Is Not Cancelled When
the A/T Selector Lever Is in Other Than "D" and
"M" Position ............................................................
57
Symptom 5 Chime Does Not Sound .......................57
Symptom 6 Driving Force Is Hunting ......................58
Symptom 7 ICC System Frequently Cannot De-
tect the Vehicle Ahead/ Detection Zone Is Short . ...
58
Symptom 8 the System Does Not Detect the Vehi-
cle Ahead at All .......................................................
59
SELF-DIAGNOSIS BY ICC SYSTEM DISPLAY
WILL NOT RUN ......................................................
59
ELECTRICAL COMPONENT INSPECTION .....63
ICC Steering Switch ............................................. ...63
Booster Solenoid .....................................................63
Release Switch .......................................................63
ICC Brake Switch and Stop Lamp Switch ...............64
ICC Brake Hold Relay .............................................64
REMOVAL AND INSTALLATION .....................65
ICC Unit ............................................................... ...65
ICC Sensor .............................................................65
ICC Steering Switch ................................................66
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

DESCRIPTIONACS-9
< SERVICE INFORMATION > [ICC]
C
D
E
F
G H
I
J
L
M A
B
ACS
N
O P
ACTIVE TEST ITEM LIST
Component DescriptionINFOID:0000000001328807
CAN CommunicationINFOID:0000000001328808
CAN (Controller Area Network) is a serial communication li ne for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tric control units are equipped onto a vehicle, and eac h control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
CAN COMMUNICATION UNIT
Refer to LAN-43, "CAN System Specification Chart".
Output CONSULT-III ICC
[ACTIVE TEST]
Item CAN Description
Combination
meter ICC BUZZER 1
×Able to start ICC warning chime with a driving signal from ICC unit.
METER LAMP ×Able to turn ICC system display ON with a driving signal from ICC unit.
ICC brake hold
relay STOP LAMP Able to start ICC brake hold relay with a driving signal from ICC unit.
Booster sole-
noid BOOSTER SOL/V
3
Able to start booster solenoid with a driving signal from ICC unit.
ComponentVehicle-to-
vehicle
distance
control mode Conventional
(fixed speed)
cruise
control mode Brake assis
(with preview function) Description
ICC unit ××× Operates electric throttle control actuator and brake
booster based on that sensor signals and CAN commu-
nication data, then controls vehicle distance.
ICC sensor ×× Irradiates laser beam, and receives reflected laser beam
to measure distance from preceding vehicle.
ECM ××× Transmits throttle position signal and ICC steering switch
signal to ICC unit through CAN communication.
ABS actuator and electric
unit (control unit) ××× Transmits wheel speed sensor signal to ICC unit through
CAN communication.
Brake pressure sensor ×× Detects fluid pressure in master cylinder.
Brake booster ×× Adjusts brake fluid pressure, based on command from
ICC unit.
BCM × Transmit front wiper request signal to ICC unit through
CAN communication.
TCM ×× Transmits gear position signal and output shaft revolu-
tion signal to ICC unit through CAN communication.
Unified meter and A/C amp. ××× Receives ICC system display signal, ICC warning lamp
signal and buzzer output signal from ICC unit through
CAN communication.
ICC brake switch, stop lamp
switch ××× Transmit operating signal to ICC unit when touching
brake pedal. ICC unit cancels cruise system at driver's
brake operation.
ICC brake hold relay × Receives stop lamp driving signal from ICC unit, and
turns stop lamp ON.
Parking brake switch ×× The cruise system is cancelled when applied.
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ACS-10
< SERVICE INFORMATION >[ICC]
DESCRIPTION
Switch Operation
INFOID:0000000001328809
The system is operated by MAIN switch and four control switches, all mounted on the steering wheel.
ICC System DisplayINFOID:0000000001328810
No. Switch name Description
1 RESUME/ACCELERATE switch Resumes set speed or increases speed incrementally.
2 SET/COAST switch Sets desired cruise speed, reduces speed incrementally.
3 CANCEL switch Deactivates system without erasing set speed.
4 MAIN switch Master switch to activate the system
5 DISTANCE switch Changes the following distance from: Long, Middle, Short.
SKIB8558E
SKIA6177E
No. Display items Description
1 Set vehicle speed indicator Indicates the set vehicle speed.
 For CANADA models: km/h
 For US models: MPH
2 Vehicle ahead detection indicator Indicates whether it detects a vehicle ahead.
3 Set distance indicator Display the selected distance between vehicles set with the DISTANCE switch.
4 Own vehicle indicator Indicates the base vehicle.
5 MAIN switch indicator lamp (Green) Indicates that the MAIN switch is ON.
6 Intelligent cruise control system warning lamp
(Orange) The light comes on if there is a malfunction in the ICC system.
7 SET switch indicator lamp Indicates that the conventional cruise control mode is controlled.
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ACTION TESTACS-11
< SERVICE INFORMATION > [ICC]
C
D
E
F
G H
I
J
L
M A
B
ACS
N
O P
ACTION TEST
ICC System Running TestINFOID:0000000001328811
VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE
Set Checking
1. Press the MAIN switch for less than 1.5 seconds.
2. Drive the vehicle between 40 km/h (25 MPH) and 144 km/h (90 MPH).
3. Push the SET/COAST switch.
4. Confirm that the desired speed is set as hand is released from the SET/COAST switch.
NOTE:
 When there is no vehicle ahead, drive at the set speed steadily.
 When there is a vehicle ahead, control to maintain distance from the vehicle ahead, watching its speed.
 The set vehicle speed is displayed on the ICC system indicator in the combination meter.
Check For Increase Of Cruising Speed
1. Set vehicle-to-vehicle distance control mode at desired speed.
2. Check if the set speed increases by 1 km/h (1 MPH) as RESUME/ACCELERATE switch is pushed.
NOTE:
The maximum set speed of the vehicle-to-vehicl e distance control mode is 144 km/h (90 MPH).
Check For Decrease Of Cruising Speed
1. Set vehicle-to-vehicle distance control mode at desired speed.
2. Check if the set speed decreases by 1 km/h (1 MPH) as SET/COAST switch is pushed.
NOTE:
 Vehicle-to-vehicle distance control mode is automatica lly turned off when the driving speed lowers to 32 km/
h (20 MPH) due to the deceleration of the vehicle ahead.
 The minimum set speed of the vehicle-to-vehicle distance control mode is 40 km/h (25 MPH).
Check For Cancellation Of Vehicle-To-Vehicle Distance Control Mode (Normal Driving Condition) In The Following
Cases:
 When the brake pedal is depressed after the system is turned ON.
 When the selector lever is shifted to the “N” (Neutral) position.
 When the MAIN switch is turned OFF.
 When CANCEL switch is operated.
Check For Restoring Speed That Is Set By Vehicle-To-Vehicle Distance Control Mode Before Cancellation
1. Cancel the system by depressing the foot brake. Then, check that the speed before cancellation is
restored when pressing RESUME/ACCELERATE switch with 40 km/h (25 MPH) or above.
2. Cancel the system by shifting the selector lever to “N” position. Then, check if the speed set before the
cancellation is restored when RESU ME/ACCELERATE switch is pushed up.
3. Check if the speed previously set is restored w hen RESUME/ACCELERATE switch is operated with driv-
ing 40 km/h (25 MPH), after canceling vehicle-to-v ehicle distance control mode by operating the CANCEL
switch.
Check For MAIN Switch
1. Start engine. Then, check if the following operations are per- formed correctly.
2. Vehicle-to-vehicle distance control mode is displayed in combi- nation meter illuminates when MAIN switch is pressed “ON” for
less than 1.5 seconds and ready for operation. The illumination
goes off when MAIN switch is turned to OFF.
3. “CRUISE” illumination and ICC system display go off when the ignition switch is turned to OFF while MAIN switch is ON
(“CRUISE” illumination is ON and vehicle-to-vehicle distance
control mode is ready for operation).
SKIB8559E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ACS-12
< SERVICE INFORMATION >[ICC]
ACTION TEST
Check For RESUME/ACCELERATE, SET/COAST, CANCEL Switches
1. Check if RESUME/ACCELERA
TE, SET/COAST, CANCEL switches are operated smoothly.
2. Check if buttons come up as hand is released from the buttons.
Check For Distance Switch
1. Start engine.
2. Press the MAIN switch for less than 1.5 seconds.
3. Press the DISTANCE switch.
4. Check if the set distance indicator changes display in order of: (Long) →(Middle) →(Short).
NOTE:
The set distance indicator shows (Long) immediately after the engine starts.
CONVENTIONAL (FIXED SPEED) CRUISE CONTROL MODE
Set Checking
1. Press the MAIN switch for more than 1.5 seconds.
2. Drive the vehicle between 40 km/h (25 MPH) and 144 km/h (90 MPH).
3. Push down the SET/COAST switch.
4. Confirm that the desired speed is set as hand is released from the SET/COAST switch.
NOTE:
ICC system display in the combination meter shows nothing.
Check For Increase Of Cruising Speed
1. Set the conventional (fixed speed) cruise control mode at desired speed.
2. Check if the set speed increases by 1.6 km/h (1 MPH) as RESUME/ACCELERATE switch is pushed up.
NOTE:
 If the RESUME/ACCELERATE switch is kept pushing up during cruise control driving, the vehicle speed
increases until the switch is released.
 The maximum set speed is 144 km/h (90 MPH).
Check For Decrease Of Cruising Speed
1. Set the conventional (fixed speed) cruise control mode at desired speed.
2. Check if the set speed decreases by 1.6 km/h (1 MPH) as SET/COAST switch is pushed down.
NOTE:
 Conventional (fixed speed) cruise control mode is automatically turned off when the driving speed lowers to 32 km/h (20 MPH).
 The minimum set speed is 40 km/h (25 MPH).
Check For Cancellation Of Conventional (Fixed Speed) Cr uise Control Mode (Normal Driving Condition) In The Fol-
lowing Cases:
SKIB8746E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ACS-16
< SERVICE INFORMATION >[ICC]
LASER BEAM AIMING ADJUSTMENT
5. Pivot the edge of the target board 20
° to either side.
NOTE:
Approx. 50 mm (1.97 in) shift rates the 20 ° movement.
6. Do not place anything in the space shown in the figure (view from top). NOTE:
In case the space shown in the figure is not availabl e, make space by covering the side of the target board
with a 400 mm (15.75 in)-size frosted black board or black cloth.
Aiming AdjustmentINFOID:0000000001328816
CAUTION:
Never view ICC sensor integrated unit body windo w directly during laser beam aiming adjustment.
NOTE:
Complete all necessary work for laser beam adjustment until the adjustment completes as shown in the proce-
dure. If the procedure does not complete, the ICC system is inoperable.
1. Connect CONSULT-III and select “Work Support” of “ICC”.
2. Select “LASER BEAM ADJUST”.
3. Touch “START”.
NOTE:
If the adjustment screen does not appear on the CO NSULT-III screen in 10 seconds. After touching
“LASER BEAM ADJUST” screen, the following causes may be considered:
 Target is not set accurately.
 There is not enough space beside the target.
 Deformation of vehicle or the surrounding equipm ent unit, bracket, or the surrounding equipment is
causing inappropriate installation of sensor and aiming may be set out of the adjustable range.
 The area is not suitable for the adjustment work.
 ICC sensor is not clean.
 The ICC system warning lamp illuminates.
4. After the CONSULT-III displays “ADJUST THE VER TICAL OF LASER BEAM AIMING” turn the up-down
direction adjusting screw until “U/D CO RRECT” value is set in the range of ±4.
PKIA2589E
SKIA5976E
SKIA1216E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

LASER BEAM AIMING ADJUSTMENTACS-17
< SERVICE INFORMATION > [ICC]
C
D
E
F
G H
I
J
L
M A
B
ACS
N
O P
NOTE:
 Turn the screw slowly. The value change on display is slower than actual movement of the ICC sensor.
Wait for 2 seconds every time the screw is turned half a rotation.
 Turning the screw to the right lowers the aiming and to the left lifts the aiming.
5. When “U/D CORRECT” value indicates ±4, confirm that the margin of value remains within ±4 at least for
2 seconds with no equipment or hand touching the ICC sensor.
When “COMPLETED THE VERTICAL AIMING OF LASER BEAM” appears on screen, touch “END”.
NOTE:
Be sure that the margin of “U/D CORRECT” is within ±4 with ICC sensor unit is untouched.
6. Confirm that “ADJUSTING AUTOMATIC HORIZONT AL LASER BEAM AIMING” is on screen and wait for
a while (maximum: 10 seconds).
7. Confirm that “NORMALLY COMPLETED” is disp layed on CONSULT-III and close the aiming adjustment
procedure by touching “END”.
NOTE:
Complete all the procedures once “LASER BEAM AD JUST” mode is entered in CONSULT-III. When the
procedure is discontinued, the ICC system is inoperable.
CHECK AFTER THE ADJUSTMENT
Test the ICC system operation by running test. Refer to ACS-11, "ICC System Running Test".
SKIA6181E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

TROUBLE DIAGNOSIS — GENERAL DESCRIPTIONACS-29
< SERVICE INFORMATION > [ICC]
C
D
E
F
G H
I
J
L
M A
B
ACS
N
O P
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
Work FlowINFOID:0000000001328822
 Reference 1··· Refer to ACS-32, "Self-Diagnostic Function".
 Reference 2··· Refer to ACS-35, "
Diagnostic Trouble Code (DTC) Chart".
 Reference 3··· Refer to ACS-55, "
Symptom Chart".
 Reference 4··· Refer to GI-35, "
CONSULT-III/GST Data Link Connector (DLC) Circuit"/ACS-32, "Self-Diag-
nostic Function".
CONSULT-III Function (ICC)INFOID:0000000001328823
DESCRIPTION
CONSULT-III can display each diagnostic item us ing the diagnostic test modes shown following.
SKIA1227E
Test mode Function
Self Diagnostic Results Displays malfunctioning system memorized in ICC unit.
Data Monitor Displays real-time input/output data of ICC unit.
Active Test Enables operation check of electrical loads by sending driving signal to them.
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ACS-30
< SERVICE INFORMATION >[ICC]
TROUBLE DIAGNOSIS —
GENERAL DESCRIPTION
WORK SUPPORT
Cause of Auto-Cancel
Display Item List
NOTE:
Last five cancel (system cancel) causes are displayed.
SELF DIAGNOSTIC RESULT
For details, refer to ACS-35, "Diagnostic Trouble Code (DTC) Chart".
DATA MONITOR
×: Applicable
Work Support  Monitors aiming direction to facilitate laser beam aiming operation.
 Indicates causes of automatic cancellation of the ICC system.
Ecu Identification Displays part number of ICC unit. Test mode Function
Operation Function
CAUSE OF AUTO-CANCEL Indicates causes of automatic cancellation of the ICC system.
LASER BEAM ADJUST Outputs laser beam, calculates dislocation of the beam, and indicates adjustment direction.
For details, refer to
ACS-14
.
Cause of cancellation Description
OPERATING WIPER Windshield wipers were operated at HI or LO speed operation.
OPERATING ABS ABS func tion was operated.
OPERATING TCS TCS function was operated.
OPERATING VDC VDC function was operated.
OPE SW VOLT CIRC Outside the standard control switch input voltage was detected.
ECM CIRCUIT ECM did not permit ICC operation.
LASER SUN BEAM Intense light such as sunlight entered ICC sensor light sensing part.
LASER TEMP Temperature around ICC sensor became low.
OP SW DOUBLE TOUCH ICC steering switches were pressed at the same time.
WHL SPD ELEC NOISE Wheel speed sensor signal caught electromagnetic noise.
VDC/TCS OFF SW VDC OFF switch was pressed.
WHEEL SPD UNMATCH Wheel speed became different from AT vehicle speed.
TIRE SLIP Wheel slipped.
PKB SW ON Parking brake is applied.
IGN LOW VOLT Power supply voltage became low.
SNOW MODE SW Snow mode switch was pressed.
NO RECORD —
Monitored Item [unit] ECU INPUT
SIGNALS MAIN
SIGNALS SELECTION
FROM
MENU Description
VHCL SPEED SE
[km/h] or [mph] ××× Indicates vehicle speed calculated from ICC unit through CAN
communication [ABS actuator and
electric unit (control unit)
transmits wheel speed sensor signal through CAN communica-
tion].
SET VHCL SPD
[km/h] or [mph] ××
Indicates set vehicle speed memorized in ICC unit.
THRTL OPENING
[%] ××× Indicates throttle angle read from ICC unit through CAN commu-
nication (ECM transmits throttle angle through CAN communica-
tion).
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
