If a magnet is located near the driver side
instrument panel (the sensor is located in-
side) or the vehicle is driven where the ter-
restrial magnetism is disturbed, the com-
pass display may not indicate the correct
direction.
O The compass may not display correctly
at the following places:
Ð under a bridge
Ð among buildings
Ð on an iron bridge
Ð inside a tunnel
Ð above a subway
Ð on a railway crossing
Ð in an underground parking lot
Ð near a huge vehicle
Ð near a transformer substation
If you carry out correction procedure
at one of the above places, the proce-
dure may not be completed correctly.
O If air conditioner fan speed is
maximum, the compass display may
shake. This is normal. Reduce the fan
speed to avoid shaking the display. Correction functions of the
compass display If the direction is not shown correctly,
carry out the correction procedure below.
1. Push the COMP switch for about 10
seconds. The direction bar starts
blinking.
2. Turn off electrical equipment such as
lights, hazard indicator, air condi-
tioner, etc. Then drive the vehicle
slowly (less than 3 MPH (5 km/h)) and
turn the vehicle one or more times in
an open and safe area. When the com-
pass displays the direction, the proce-
dure is completed.
2-8 Instruments and controls
w 06.1.4/V35-D/V5.0
X

Cruise set switch indicator
lightThe light comes on while the vehicle
speed is controlled by the cruise control
system. If the light blinks while the en-
gine is running, it may indicate the cruise
control system is not functioning prop-
erly. Have the system checked by an
INFINITI dealer.
Front passenger air bag
status lightThe front passenger air bag status light,
located on the center display, will be lit
and the passenger front air bag will be off
depending on how the front passenger
seat is being used.
For front passenger air bag status light
operation, see ªINFINITI advanced air bag
systemº in the ª1. Safety Ð Seats, seat
belts and supplemental restraint systemº
section of this manual.
High beam indicator light
(Blue)This light comes on when the headlight
high beam is on and goes out when the
low beam is selected. Malfunction indicator lamp
(MIL) If the malfunction indicator lamp (MIL)
comes on steady or blinks while the en-
gine is running, it may indicate a poten-
tial emission control malfunction.
The malfunction indicator lamp may also
come on steady if the fuel-filler cap is
loose or missing, or if the vehicle runs out
of fuel. Check to make sure the fuel-filler
cap is installed and closed tightly, and
that the vehicle has at least three gallons
(14 liters) of fuel in the fuel tank.
After a few driving trips, the lamp
should turn off if no other potential emis-
sion control system malfunction exists.
If this indicator lamp comes on steady for
20 seconds and then blinks for 10 sec-
onds when the engine is not running, it
indicates that the vehicle is not ready for
an emission control system inspection/
maintenance test. See ªReadiness for
inspection/maintenance (I/M) testº in the
ª9. Technical and consumer informationº
section of this manual.
Operation
The malfunction indicator lamp will come on in one of two ways:
O Malfunction indicator lamp on steady
Ð An emission control system mal-
function has been detected. Check the
fuel-filler cap. If the fuel-filler cap is
loose or missing, tighten or install the
cap and continue to drive the vehicle.
The lamp should turn off after a
few driving trips. If the lamp
does not turn off after a few driving
trips, have the vehicle inspected by an
INFINITI dealer. You do not need to
have your vehicle towed to the re-
tailer.
O Malfunction indicator lamp blinking Ð
An engine misfire has been detected
which may damage the emission con-
trol system. To reduce or avoid emis-
sion control system damage:
a) Do not drive at speeds above 45
MPH (72 km/h).
b) Avoid hard acceleration or decel-
eration.
c) Avoid steep uphill grades.
d) If possible, reduce the amount of
cargo being hauled or towed.
The malfunction indicator lamp may
stop blinking and come on steady.
Instruments and controls
2-15
w 06.1.4/V35-D/V5.0
X

4 Display screen, heater, air conditioner and
audio systems Safety note ....................................................... 4-2
Control panel buttons Ð with navigation
system ............................................................. 4-2
Names of the components .......................... 4-2
How to use joystick and ªENTERº button ..... 4-3
How to use ªBACKº button .......................... 4-3
Setting up the start-up screen..................... 4-3
How to use ªINFOº button ........................... 4-3
How to use ªSETTINGº button ..................... 4-7
How to use the
button ........................ 4-9
Ventilators........................................................ 4-9
Heater and air conditioner (Automatic)............ 4-10
Automatic operation ................................... 4-11
Manual operation....................................... 4-12
Dual button (if so equipped) ...................... 4-12
Ambient temperature ................................. 4-13
Operating tips............................................ 4-13
In-cabin microfilter..................................... 4-13
Servicing air conditioner ................................. 4-14 Audio system .................................................. 4-14
FM radio reception ..................................... 4-15
AM radio reception .................................... 4-15
Satellite radio reception (if so equipped) ... 4-15
Audio operation precautions ...................... 4-16
FM-AM-satellite radio with compact disc
(CD) changer ............................................. 4-22
CD care and cleaning ................................ 4-27
Steering wheel switch for audio control .... 4-28
Antenna .................................................... 4-29
Car phone or CB radio ................................... 4-29
Bluetooth
Hands-Free Phone System with
INFINITI Voice Recognition .............................. 4-30
Using the system ...................................... 4-32
Control buttons ......................................... 4-34
Getting started .......................................... 4-34
List of voice commands............................. 4-36
Speaker adaptation (SA) mode .................. 4-42
Troubleshooting guide .............................. 4-44
w 06.1.13/V35-D/V5.0
X

WARNINGO Positioning of the heating or air condi-
tioning controls and display controls
should not be done while driving, in
order that full attention may be given to
driving operation.
O Do not disassemble or modify this
system. If you do, it may result in acci-
dents, fire, or electric shock.
O Do not use this system if you notice any
abnormality, such as a frozen screen or
lack of sound. Continued use of the
system may result in accident, fire or
electric shock.
O In case you notice any foreign object in
the system hardware, spill liquid on it, or
notice smoke or smell coming from it,
stop using the system immediately and
contact an INFINITI dealer. Ignoring such
conditions may lead to accidents, fire, or
electric shock. When you use this system, make sure the
engine is running.
If you use the system with the engine not
running (ignition ON or ACC) for a long
time, it will use up all the battery power,
and the engine will not start.
Reference symbols:
ªENTERº button Ð This is a button on the
control panel.
ª Display º key Ð This is a select key on
the screen. By selecting this key you can
proceed to the next function. NAMES OF THE COMPONENTS 1., 2., 5., 6., 9., 10. and 11.
For Navigation control buttons: refer to
the separate Navigation Owner's Manual.
3. ªSETTINGº button (P. 4-7)
4. ªINFOº button (P. 4-3)
7. Joystick and ªENTERº button (P. 4-3)
8. brightness control button
(P. 4-9)
12. ªBACKº button (P. 4-3) SAA1301
SAFETY NOTE
CONTROL PANEL BUTTONS Ð WITH
NAVIGATION SYSTEM
4-2 Display screen, heater, air conditioner and audio systems
w 06.1.4/V35-D/V5.0
X

HOW TO USE JOYSTICK AND
ªENTERº BUTTON Choose an item on the display using the
joystick and push the ªENTERº button for
operation.
HOW TO USE ªBACKº BUTTON This button has two functions.
O Go back to the previous display.
When this button is pushed during setup,
setup will be canceled, and the screen
will return to the previous screen.
O Finish setup.
When this button is pushed after setup is
completed, the settings will be renewed
as directed, and the screen will return to
the map.
SETTING UP THE START-UP
SCREEN When you turn the ignition switch to the
ACC or ON position, the SYSTEM
START-UP warning is displayed on the
screen. Read the warning and select the
ª OK º key then push the ªENTERº button. If you do not push the ªENTERº button,
the Navigation system will not proceed to
the next step display.
To proceed to the next step, refer to the
separate Navigation System Owner's
Manual.
HOW TO USE ªINFOº BUTTON The ª Vehicle Information º screen will ap-
pear when the ªINFOº button is pushed.
Choose an item using the joystick and
push the ªENTERº button.
After viewing or adjusting the information
on the following screens, push the
ªBACKº button to return to the VEHICLE
INFORMATION menu. SAA1304
Display screen, heater, air conditioner and audio systems
4-3
w 06.1.4/V35-D/V5.0
X

Fuel economy information The distance to empty, average fuel
economy and current fuel economy
(shown on the right side bar) will be dis-
played for reference.
To reset the Average Fuel Economy, use
the joystick to highlight the ª Reset º key
and push the ªENTERº button. If the ª View º key is highlighted with the
joystick and the ªENTERº button is
pushed, the average fuel consumption
history will be displayed in graph form
along with the average for the previous
Reset-to-Reset period.
The unit can be converted between ªUSº
and ªMetricº. See ªHow to use SETTING
buttonº later in this section.SAA1074 SAA1075
4-4 Display screen, heater, air conditioner and audio systems
w 06.1.4/V35-D/V5.0
X

Trip computer information Elapsed Time, Driving Distance and Av-
erage Speed will be displayed.
To reset, use the joystick to highlight the
ª Reset º key and push the ªENTERº button
immediately before driving the vehicle.
The unit can be converted between ªUSº
and ªMetricº. See ªHow to use SETTING
buttonº later in this section. Maintenance information To set the maintenance interval for the
Engine Oil or Oil Filter, choose an item
using the joystick and push the ªENTERº
button.
You can also set to display a message to
remind you that the maintenance needs
to be performed.
The following example shows how to set
the engine oil change interval. Use the
same steps to set the other maintenance
information. 1. Reset the driving distance to the new
maintenance schedule.
2. Set the interval (mileage) of the main-
tenance schedule. To determine the
recommended maintenance interval,
refer to your ªINFINITI Service and
Maintenance Guideº.
3. To display the maintenance informa-
tion automatically when the set
trip distance is reached, highlight the
ª Interval Reminder º key with the joy-
stick and push the ªENTERº button.SAA1305 SAA1290 SAA1291
Display screen, heater, air conditioner and audio systems
4-5
w 06.1.4/V35-D/V5.0
X

4. To return the display to the ª Mainte-
nance º screen, push the ªBACKº
button.
ªMaintenanceº display cannot be oper-
ated when the vehicle is moving. Stop the
vehicle in a safe place to see the informa-
tion.
Maintenance notice The ª Maintenance Notice º screen (ªEN-
GINE OILº or ªOIL FILTERº) will be auto-
matically displayed as shown when both
of the following conditions are met:
O the vehicle is driven the set distance
and the ignition switch is turned to
the OFF position.
O the ignition switch is turned to the ON
position the next time the vehicle will
be driven. To return to the previous display after the
ª Maintenance Notice º screen is dis-
played, push the ªBACKº button.
The ª Maintenance Notice º screen displays
each time the ignition switch is turned ON
until one of the following conditions are
met:
O ª Reset Display º is selected.
O ª Interval Reminder º is set OFF.
O the maintenance interval is set again. SAA1332 SAA1292
Engine Oil
q 1
/Oil Filter
q 2
4-6 Display screen, heater, air conditioner and audio systems
w 06.1.4/V35-D/V5.0
X

*: Refer to the separate Navigation
System Owner's Manual.
HOW TO USE ªSETTINGº BUTTON The ª Settings º screen will appear when
the ªSETTINGº button is pushed.
Display settings The following menu will appear when
pushing the ªSETTINGº button, selecting
the ª Display º key and pushing the
ªENTERº button.
Display:
To turn off the screen, select the ª Dis-
play º key and push the ªENTERº button to
turn off the ª ON º indicator. When any
mode button is pushed with the screen
off, the screen turns on for further opera-
tion. The screen will turn off automatically 5 seconds after the operation is finished
on the map display.
To turn on the screen, select the ª Dis-
play º key and turn on the ª ON º indicator.
Brightness/Contrast/Background Color:
To adjust the brightness and contrast of
the screen, select the ª Brightness ºor
ª Contrast º key and push the ªENTERº
button. Then you can adjust the bright-
ness to darker or brighter and the con-
trast to lower or higher using the joystick.
For information on the ª Background
Color º key, refer to the separate Naviga-
tion System Owner's Manual.SAA1293 SAA1294
Display screen, heater, air conditioner and audio systems
4-7
w 06.1.4/V35-D/V5.0
X

Clock settings The following display will appear when
pushing the ªSETTINGº button, selecting
the ª Clock º key and pushing the ªENTERº
button.
On-screen Clock:
When this item is turned to ON, a clock is
always displayed in the upper right corner
of the screen.
This clock will indicate the time almost
exactly because it is always adjusted by
the GPS system. Clock Format:
Choose either the 12-hour clock display or
the 24-hour clock display.
Offset Adjust:
Adjust the time by increasing or de-
creasing per minute.
Daylight Saving Time:
Turn this item to ON for daylight saving
time application.
Time Zone:
Choose the time zone from the following
O Pacific
O Mountain
O Central
O Eastern
O Atlantic
O Newfoundland
Language/Units settings The Language/Units setting screen will
appear when selecting the ª Language/
Units º key and pushing the ªENTERº
button.SAA1091 SAA1295
4-8 Display screen, heater, air conditioner and audio systems
w 06.1.4/V35-D/V5.0
X
