format INFINITI G35 2006 Owners Manual

ForewordYour INFINITI represents a new way of
thinking about vehicle design. It inte-
grates advanced engineering and supe-
rior craftsmanship with a simple, refined
aesthetic sensitivity associated with tra-
ditional Japanese culture.
The result is a different notion of luxury
and beauty. The car itself is important,
but so is the sense of harmony that the
vehicle evokes in its driver, and the
sense of satisfaction you feel with the
INFINITI Ð from the way it looks and
drives to the high level of retailer service.
To ensure that you enjoy your INFINITI to
the fullest, we encourage you to read this
Owner's Manual immediately. It explains
all of the features, controls and perfor-
mance characteristics of your INFINITI; it
also provides important instructions and
safety information.
A separate Warranty Information Booklet
can be found in your Owner's literature
portfolio. The INFINITI Service and Mainte-
nance Guide explains details about main-
taining and servicing your vehicle. Always
carry it with you when you take your
INFINITI to an authorized retailer. The
portfolio contents provide complete infor-
mation about all warranties covering this
vehicle, the periodic maintenance re- quired to keep the warranties in effect as
well as the INFINITI Roadside Assistance
program.
Additionally, a separate Customer Care
and Lemon Law Information Booklet will
explain how to resolve any concerns you
may have with your vehicle, as well as
clarify your rights under your state's
lemon law.
INFINITI is dedicated to providing a satis-
fying ownership experience for as long as
you own your car. Should you have any
questions regarding your INFINITI or an
INFINITI dealer, please contact our Con-
sumer Affairs department at:
In U.S. 1-800-662-6200.
In Canada 1-800-361-4792.
READ FIRST Ð THEN DRIVE
SAFELY Before driving your vehicle please read
your Owner's Manual carefully. This will
ensure familiarity with controls and main-
tenance requirements, assisting you in
the safe operation of your vehicle. WARNINGIMPORTANT SAFETY INFORMATION
REMINDERS FOR SAFETY! Follow these important driving rules to help
ensure a safe and comfortable trip for you and
your passengers!
O Never drive under the influence of alcohol
or drugs.
O Always observe posted speed limits and
never drive too fast for conditions.
O Always use seat belts and child re-
straints. Pre-teen children should be
seated in the rear seat.
O Always provide information about the
proper use of vehicle safety features to all
occupants of the vehicle.
O Always review this Owner's Manual for
important safety information.
w 06.1.4/V35-D/V5.0
X

MODIFICATION OF YOUR VEHICLE This vehicle should not be modified. Modi-
fication could affect its performance,
safety or durability, and may even violate
governmental regulations. In addition,
damage or performance problems re-
sulting from modifications may not be
covered under INFINITI warranties.
WHEN READING THE MANUAL This manual includes information for all
options available on this model. There-
fore, you may find some information that
does not apply to your vehicle.
All information, specifications and illus-
trations in this manual are those in effect
at the time of printing. INFINITI reserves
the right to change specifications or de-
sign at any time without notice. IMPORTANT INFORMATION ABOUT
THIS MANUAL You will see various symbols in this
manual. They are used in the following
ways:
WARNING This is used to indicate the presence of a haz-
ard that could cause death or serious per-
sonal injury. To avoid or reduce the risk, the
procedures must be followed precisely.
CAUTION This is used to indicate the presence of a haz-
ard that could cause minor or moderate per-
sonal injury or damage to your vehicle. To
avoid or reduce the risk, the procedures must
be followed carefully. If you see this symbol, it means Do not do
this or Do not let this happen .
If you see a symbol similar to these in an
illustration, it means the arrow points to
the front of the vehicle.
Arrows in an illustration that are similar
to these indicate movement or action.
Arrows in an illustration that are similar
to these call attention to an item in the il-
lustration. SIC0697
w 06.1.4/V35-D/V5.0
X

CALIFORNIA PROPOSITION 65
WARNING
WARNINGEngine exhaust, some of its constituents, and
certain vehicle components contain or emit
chemicals known to the State of California to
cause cancer and birth defects or other repro-
ductive harm. In addition, certain fluids con-
tained in vehicles and certain products of
component wear contain or emit chemicals
known to the State of California to cause can-
cer and birth defects or other reproductive
harm. BLUETOOTH is a trademark
owned by Bluetooth SIG,
Inc., U.S.A. and licenced to
Xanavi Informatics Corpora-
tion.
2005 NISSAN MOTOR CO., LTD.
TOKYO, JAPANAll rights reserved. No part of this Owner's Manual may
be reproduced or stored in a retrieval system, or trans-
mitted in any form, or by any means, electronic, me-
chanical, photocopying, recording or otherwise, without
the prior written permission of Nissan Motor Co., Ltd.
w 06.1.4/V35-D/V5.0
X

Table of
Contents Illustrated table of contents 0
Safety Ð Seats, seat belts and supplemental restraint system 1
Instruments and controls 2
Pre-driving checks and adjustments 3
Display screen, heater, air conditioner and audio systems 4
Starting and driving 5
In case of emergency 6
Appearance and care 7
Maintenance and do-it-yourself 8
Technical and consumer information 9
Index 10
w 06.1.4/V35-D/V5.0
X

CHILD SAFETY Children need adults to help protect them.
They need to be properly restrained.
In addition to the general information in
this manual, child safety information is
available from many other sources, in-
cluding doctors, teachers, government
traffic safety offices, and community orga-
nizations. Every child is different, so be
sure to learn the best way to transport
your child.
There are three basic types of child re-
straint systems:
O Rear-facing child restraint
O Front-facing child restraint
O Booster seat
The proper restraint depends on the
child's size. Generally, infants (up to
about 1 year and less than 20 lb (9 kg)
should be placed in rear-facing child re-
straints. Front-facing child restraints are
available for children who outgrow rear-
facing child restraints and are at least 1
year old. Booster seats are used to help
position a vehicle lap/shoulder belt on a
child who can no longer use a front-facing
child restraint. WARNING Infants and children need special protection.
The vehicle's seat belts may not fit them
properly. The shoulder belt may come too
close to the face or neck. The lap belt may
not fit over their small hip bones. In an acci-
dent, an improperly fitting seat belt could
cause serious or fatal injury. Always use ap-
propriate child restraints.
All US states and provinces of Canada re-
quire the use of approved child restraints
for infants and small children. (See ªChild
restraintsº later in this section.)
Also, there are other types of child re-
straints available for larger children for
additional protection.
INFINITI recommends that all pre-teens
and children be restrained in the rear seat
if possible. According to accident statis-
tics, children are safer when properly re-
strained in the rear seat than in the front
seat.
This is especially important because your
vehicle has a supplemental restraint
system (air bag system) for the front pas- senger. See ªSupplemental Restraint
Systemº later in this section for precau-
tions.
Infants Infants up to at least 1 year old should be
placed in a rear-facing child restraint.
INFINITI recommends that infants be
placed in child restraints that comply with
Federal Motor Vehicle Safety Standards or
Canadian Motor Vehicle Safety Standards.
You should choose a child restraint that
fits your vehicle and always follow the
manufacturer's instructions for installa-
tion and use.
Small children Children that are over 1 year old and
weigh between 20 lb (9 kg) and 40 lb (18
kg) can be placed in a forward facing
child restraint. Refer to the manufactur-
er's instructions for minimum and
maximum weight and height recommen-
dations. INFINITI recommends that small
children be placed in child restraints that
comply with Federal Motor Vehicle Safety
Standards or Canadian Motor Vehicle
Safety Standards. You should choose a
child restraint that fits your vehicle and
always follow the manufacturer's instruc-
tions for installation and use.
1-12 Safety Ð Seats, seat belts and supplemental restraint system
w 06.1.4/V35-D/V5.0
X

from the buckle and fully retracted. For
additional information, see ªChild re-
straintsº later in this section.
The automatic locking mode should be
used only for child restraint installation.
During normal seat belt use by a pas-
senger, the locking mode should not be ac-
tivated. If it is activated it may cause un-
comfortable seat belt tension. It can also
change the operation of the front pas-
senger air bag. See ªFront passenger air
bag and status lightº later in this section. WARNING When fastening the seat belts, be certain
that the seatbacks are completely secured in
the latched position. If they are not com-
pletely secured, passengers may be injured
in an accident or sudden stop.
Unfastening the seat belts To unfasten the belt, push the button on
the buckle. The seat belt will automati-
cally retract.
Checking seat belt operation Your seat belt retractors are designed to
lock belt movement using two separate
methods:
O when the belt is pulled quickly from
the retractor.
O when the vehicle slows down rapidly.SSS0291A
Rear seat SSS0326
Safety Ð Seats, seat belts and supplemental restraint system
1-15
w 06.1.4/V35-D/V5.0
X

LATCH (Lower Anchors and
Tethers for CHildren) SYSTEM 1. LATCH lower anchor points (right)
2. LATCH lower anchor points (left)
3. LATCH label
The LATCH (Lower Anchors and Tethers for
CHildren) anchor points are located in the
seat cushions of the rear outboard
seating positions only. Do not attempt to
install a child restraint in the center posi-
tion using the LATCH anchors.
The LATCH system anchors are located at
the rear of the seat cushion near the seat-
back. A label is attached to the seatback to
help you locate the LATCH system anchors. WARNING O Attach LATCH system compatible child
restraints only at the locations shown. If
a child restraint is not secured properly,
your child could be seriously injured or
killed in an accident.
O Do not secure a child restraint in the
center rear seating position using the
LATCH system anchors. The child re-
straint will not be secured properly. O The LATCH system anchors are designed
to withstand only those loads imposed
by correctly fitted child restraints. Under
no circumstance are they to be used for
adult seat belts or harnesses.
Some child restraints include two rigid or
webbing-mounted attachments that can
be connected to two anchors located at
certain seating positions in your vehicle.
This system is known as the LATCH
system. This system may also be referred
to as the ISOFIX or ISOFIX compatible sys-
tem. With this system, you do not have to
use a vehicle seat belt to secure the child
restraint. Your vehicle is equipped with
special anchor points that are used with
LATCH system compatible child restraints.
Check your child restraint for a label stat-
ing that it is compatible with the LATCH
system. This information may also be in
the instructions provided by the child re-
straint manufacturer. If you have such a
child restraint, refer to the illustration for
the rear seating positions equipped with
LATCH system anchors which can be used
to secure the child restraint.SSS0369
Sedan SSS0370
Coupe
Safety Ð Seats, seat belts and supplemental restraint system
1-25
w 06.1.4/V35-D/V5.0
X

PRECAUTIONS ON SUPPLEMENTAL
RESTRAINT SYSTEM This Supplemental Restraint System (SRS)
section contains important information
concerning the driver and passenger front
impact supplemental air bags (INFINITI ad-
vanced air bag system), front seat side-
impact supplemental air bags, curtain air
bags and front seat pre-tensioner seat
belts.
Supplemental front-impact air bag system:
The INFINITI advanced air bag system can
help cushion the impact force to the head
and chest of the driver and front pas-
senger in certain frontal collisions.
Supplemental side air bag system: This
system can help cushion the impact force
to the chest area of the driver and front
passenger in certain side impact colli-
sions. The front seat side-impact supple-
mental air bags are designed to inflate on
the side where the vehicle is impacted.
Supplemental curtain side-impact air bag
system: This system can help cushion the
impact force to the head of occupants in
front and rear outboard seating positions
in certain side impact collisions. The cur-
tain side-impact air bags are designed to
inflate on the side where the vehicle is
impacted. These supplemental restraint systems are
designed to supplement the crash protec-
tion provided by the driver and passenger
seat belts and are not a substitute for
them. Seat belts should always be cor-
rectly worn and the occupant seated a
suitable distance away from the steering
wheel, instrument panel and door fin-
ishers. (See ªSeat beltsº earlier in this
section for instructions and precautions
on seat belt usage.)
The supplemental air bags operate only
when the ignition switch is in the ON or
START position.
After turning the ignition switch to the ON
position, the supplemental air bag
warning light illuminates. The supple-
mental air bag warning light will turn off
after about 7 seconds if the systems are
operational.SUPPLEMENTAL RESTRAINT SYSTEM
1-36 Safety Ð Seats, seat belts and supplemental restraint system
w 06.1.4/V35-D/V5.0
X

WARNINGO Never let children ride unrestrained or
extend their hands or face out of the
window. Do not attempt to hold them in
your lap or arms. Some examples of dan-
gerous riding positions are shown in the
previous illustrations.
O Children may be severely injured or
killed when the supplemental front air
bags, side air bags or curtain side-
impact air bags inflate if they are not
properly restrained. Pre-teens and chil-
dren should be properly restrained in the
rear seat, if possible.
O Even with the INFINITI advanced air bag
system, never install a rear-facing child
restraint in the front seat. An inflating
supplemental front air bag could seri-
ously injure or kill your child. For addi-
tional information, see ªChild re-
straintsº earlier in this section.
WARNING Supplemental side air bag and curtain side-
impact air bag:
O The supplemental side air bag and cur-
tain side-impact air bag ordinarily will
not inflate in the event of a frontal im-
pact, rear impact, rollover or lower se-
verity side collision. Always wear your
seat belts to help reduce the risk or se-
verity of injury in various kinds of
accidents. O The seat belts, the supplemental side air
bags and curtain side-impact air bags
are most effective when you are sitting
well back and upright in the seat. The
side air bag and curtain side-impact air
bag inflate with great force. Do not allow
anyone to place their hand, leg or face
near the side air bag on the side of the
seatback of the front seat or near the
side roof rails. Do not allow anyone sit-
ting in the front seats or rear outboard
seats to extend their hand out of the SSS0059A
SSS0188A
1-40 Safety Ð Seats, seat belts and supplemental restraint system
w 06.1.4/V35-D/V5.0
X

1. Crash zone sensor
2. Supplemental front air bag modules
3. Supplemental side air bag modules
4. Occupant classification sensor (pres-
sure sensor) 5. Supplemental curtain side-impact air
bags
6. Supplemental curtain side-impact air
bag modules
7. Diagnosis sensor unit 8. Seat belt pre-tensioner
9. Satellite sensors
10. Occupant classification system control
unit
INFINITI ADVANCED AIR BAG
SYSTEM (front seats) This vehicle is equipped with the INFINITI
advanced air bag system for the driver
and front passenger seats. This system is
designed to meet certification require-
ments under U.S. regulations. It is also
permitted in Canada. However, all of the
information, cautions and warnings in this
manual still apply and must be followed.
The driver supplemental air bag is located
in the center of the steering wheel. The
front passenger supplemental air bag is
mounted in the dashboard above the
glove box. The supplemental front air
bags are designed to inflate in higher se-
verity frontal collisions, although they
may inflate if the forces in another type of
collision are similar to those of a higher
severity frontal impact. They may not in-
flate in certain frontal collisions. Vehicle
damage (or lack of it) is not always an in-
dication of proper supplemental air bag
operation. SSS0416
Sedan
1-42 Safety Ð Seats, seat belts and supplemental restraint system
w 06.1.4/V35-D/V5.0
X
