display INFINITI M35 2006 Factory Service Manual

AV-212
[WITH MOBILE ENTERTAINMENT SYSTEM]
TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT
Revision: 2006 January2006 M35/M45
46
(L/Y)47
(G)RGB signal (B: blue) Output ONStart confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.
47
(G)Ground RGB ground – ON – Approx. 0 V
48
(B)GroundRGB synchronizing sig-
nalOutput ON –
49 – Shield – – – –
50
(G)Ground RGB area (YS) signal Output ONWhen inputting RGB image. Approx. 5 V
Set the selector lever in R
position, and then display
the rear view image.
51
(W)GroundHorizontal synchronizing
(HP) signalInput ON –
52
(R)GroundVertical synchronizing
(VP) signalInput ON –
53
(O/L)GroundCommunication signal
(CONT-DISP)Input ONWhen adjusting display
brightness. Te r m i n a l
(Wire color)
ItemSignal
Input/
outputCondition
Reference value
+–Ignition
switchOperation
SKIB2237J
SKIB3603E
PKIB4948J
SKIB3601E
SKIB3598E
PKIB5039J

TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT
AV-213
[WITH MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2006 January2006 M35/M45
*: With navigation system54
(W/L)GroundCommunication signal
(DISP-CONT)Input ONWhen adjusting display
brightness.
55 – Shield – – – –
61
(LG)Ground Illumination signal Input OFFLighting switch is OFF. Approx. 0 V
Lighting switch is ON. Approx. 12 V
63
(Y/G)Ground Ignition signal Input ON – Battery voltage
64
(P)Ground Parking brake signal Input ONParking brake ON. Approx. 0 V
Parking brake OFF. Approx. 12 V
65
(O)Ground Reverse signal Input ONSelect lever in R position. Approx. 12 V
Other than selector lever in
R position.Approx. 0 V
66
(G)GroundVehicle speed signal
(8-pulse)Input ONWhen vehicle speed is
approx. 40 km/h (25 MPH).
67
(V)GroundCamera-connection rec-
ognition signalInput ONConnected to rear view
camera control unit connec-
tor.Approx. 0 V
Not connected to rear view
camera control unit connec-
tor.Approx. 5 V
69
(W)–Communication signal
(H)Input/
Output–– –
70
(R)–Communication signal
(L)Input/
Output–– –
71
(LG)–CAN-HInput/
Output–– –
72
(P)–CAN-LInput/
Output–– –
107
*Ground GPS signal Input ON Connector is not connected. Approx. 5 V Terminal
(Wire color)
ItemSignal
Input/
outputCondition
Reference value
+–Ignition
switchOperation
PKIB5039J
SKIA6649J

AV-214
[WITH MOBILE ENTERTAINMENT SYSTEM]
TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT
Revision: 2006 January2006 M35/M45
Video DistributorNKS004AP
Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
SwitchOperation
1
(W)–Communication signal
(H)Input/
Output–– –
2
(R)–Communication signal
(L)Input/
Output–– –
3
(W)–Communication signal
(H)Input/
Output–– –
4
(R)–Communication signal
(L)Input/
Output–– –
6 – Shield – – – –
7
(B/R)GroundComposite synchroniz-
ing signal (front)Output ONFront display
DVD image
8
(BR)GroundComposite image signal
(front)Output ONFront display
DVD image
10
(B)12
(W/L)RGB signal (R: red)
(front)Output ONStart confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.
11
(W)12
(W/L)RGB signal (G: green)
(front)Output ONStart confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.
12
(W/L)– RGB ground – ON – Approx. 0 V
13
(R)12
(W/L)RGB signal (B: blue)
(front)Output ONStart confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.
SKIA0187E
SKIB2251J
SKIB2238J
SKIB2236J
SKIB2237J

TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT
AV-215
[WITH MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2006 January2006 M35/M45
14
(L/G)GroundRGB area (YS) signal
(front)Output ONWhen inputting RGB image. Approx. 5 V
Set the selector lever in R
position, and then display
the rear view image.
15
(W/L)GroundHorizontal synchronizing
(HP) signal (front)Input ON –
16
(O/L)GroundVertical synchronizing
(VP) signal (front)Input ON –
17
(L/Y)GroundRGB synchronizing
signal (front)Output ON –
18 – Shield – – – –
19
(R)Ground AUX image signal Input ON AUX image
21 – Shield – – – –
22 – Shield – – – –
23
(L)Ground DVD image signal Input ON DVD image Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
SwitchOperation
PKIB4948J
SKIB3601E
SKIB3598E
SKIA3222J
SKIB2251J
SKIB2251J

AV-216
[WITH MOBILE ENTERTAINMENT SYSTEM]
TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT
Revision: 2006 January2006 M35/M45
25
(B)27
(G)RGB signal (R: red)
(rear)Output ONStart confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.
26
(W)27
(G)RGB signal (G: green)
(rear)Output ONStart confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.
27
(G)Ground RGB ground – ON – Approx. 0 V
28
(R)27
(G)RGB signal (B: blue)
(rear)Output ONStart confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.
29
(W/R)GroundVertical synchronizing
(VP) signal
(rear)Input ON –
30
(W)GroundHorizontal synchronizing
(HP) signal (rear)Input ON –
31 – Shield – – – –
32
(R/L)GroundRGB area (YS) signal
(rear)Output ONWhen inputting RGB image. Approx. 5 V
Rear display
DVD image Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
SwitchOperation
SKIB2238J
SKIB2236J
SKIB2237J
SKIB0823E
SKIB0825E
PKIB4949J

TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT
AV-217
[WITH MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2006 January2006 M35/M45
33
(R)GroundImage synchronizing sig-
nal (rear)Output ONRear display
RGB image
34
(G)GroundComposite image signal
(rear)Output ONRear display
DVD image
35 – Shield – – – –
36
(O)GroundIgnition signal
(rear display)OutputON – Approx. 0 V
ACC – Approx. 5 V
38 – Shield – – – –
39
(W)GroundCommunication signal
(DISP-DIST)Input ON Image quality adjustment
40
(O)GroundCommunication signal
(DIST-DISP)Output ON Image quality adjustment
44
(L/G)47
(G)RGB signal (R: red) Input ONStart confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.
45
(O/L)47
(G)RGB signal (G: green) Input ONStart confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen. Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
SwitchOperation
SKIB0825E
SKIB2251J
PKIB5039J
PKIB5039J
SKIB2238J
SKIB2236J

AV-218
[WITH MOBILE ENTERTAINMENT SYSTEM]
TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT
Revision: 2006 January2006 M35/M45
46
(L/Y)47
(G)RGB signal (B: blue) Input ONStart confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.
47
(G)Ground RGB ground – ON – Approx. 0 V
48
(G)Ground RGB area (YS) signal Input ONWhen inputting RGB image. Approx. 5 V
Set the selector lever in R
position, and then display
the rear view image.
49
(W)GroundHorizontal synchronizing
(HP) signalOutput ON –
50
(R)GroundVertical synchronizing
(VP) signalOutput ON –
51
(B)GroundRGB synchronizing sig-
nalInput ON –
52 – Shield – – – –
53
(B)Ground Ground – ON – Approx. 0 V
54
(L)Ground Battery power supply Input OFF – Battery voltage
55
(V)Ground ACC power supply Input ACC – Battery voltage
56
(G)Ground Ignition signal Input ON – Battery voltage
57
(W)GroundRemote control receiver
VCCOutput ON – Approx. 5 V Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
SwitchOperation
SKIB2237J
PKIB4948J
SKIB0825E
SKIB0823E
SKIB0825E

TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT
AV-219
[WITH MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2006 January2006 M35/M45
Front Display UnitNKS004AQ
58
(B)Ground Remote control signal Output ONRear seat remote controller
operation
59 – Shield – – – –
60
(L)GroundHeadphone amp ON sig-
nalInput ONHeadphone mode is ON. Approx. 4 V
Headphone mode is OFF. Approx. 0 V Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
SwitchOperation
PKIB6988J
Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
switchOperation
1
(B)8
(W/L)RGB signal (R: red) Input ONStart confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.
2
(L/G)Ground RGB area (YS) signal Input ONWhen inputting RGB image. Approx. 5 V
Set the selector lever in R
position, and then display
the rear view image.
3
(W)8
(W/L)RGB signal (G: green) Input ONStart confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.
4
(W/L)GroundHorizontal synchronizing
(HP) signalOutput ON –
SKIB2238J
PKIB4948J
SKIB2236J
SKIB0825E

AV-220
[WITH MOBILE ENTERTAINMENT SYSTEM]
TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT
Revision: 2006 January2006 M35/M45
5
(R)8
(W/L)RGB signal (B: blue) Input ONStart confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.
6
(O/L)GroundVertical synchronizing
(VP) signalOutput ON –
7
(L/Y)GroundRGB synchronizing sig-
nalOutput ON –
8
(W/L)Ground RGB ground – ON – Approx. 0 V
10 – Shield – – – –
11
(Y)Ground Camera image signal Input ONSet the selector in R posi-
tion, and then display the
rear view image.
12 – Shield – – – –
13
(B/R)GroundComposite synchroniz-
ing signalInput ON –
14 – Shield – – – –
15
(BR)Ground Composite image signal Input ON DVD image Te r m i n a l
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
switchOperation
SKIB2237J
SKIB0823E
SKIB0826E
SKIB0827E
SKIA0187E
SKIB2251J

TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT
AV-221
[WITH MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2006 January2006 M35/M45
Rear Display UnitNKS004AR
17
(W/L)GroundCommunication signal
(DISP-CONT)Output ONWhen adjusting display
brightness.
18 – Shield – – – –
19
(O/L)GroundCommunication signal
(CONT-DISP)Input ONWhen adjusting display
brightness.
20
(V)Ground ACC power supply Input ACC – Battery voltage
21
(L)Ground Battery power supply Input OFF – Battery voltage
23
(B)Ground Ground – ON – Approx. 0 V Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
switchOperation
PKIB5039J
PKIB5039J
Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
switchOperation
1
(B/Y)Ground Ground – ON – Approx. 0 V
2
(B/Y)Ground Ground – ON – Approx. 0 V
3
(L/O)Ground Battery power supply Input OFF – Battery voltage
4
(L/Y)Ground Battery power supply Input OFF – Battery voltage
6
(W/L)Ground ACC power supply Input ACC – Battery voltage
8 – Shield – – – –
9
(L)GroundCommunication signal
(DISP-DIST)Output ONWhen adjusting display
brightness.
PKIB5039J
