INFINITI M35 2006 Factory Service Manual

WW-54
HORN
Revision: 2006 January2006 M35/M45
Removal and InstallationNKS003XF
REMOVAL
1. Remove front grille. Refer to EI-16, "FRONT GRILLE" .
2. Disconnect horn (HI) connectors.
3. Remove horn (HI) mounting bolt (A), and remove horn (HI) (1)
from vehicle.
4. Remove fender protector (front) LH to obtain work space between the fender protector and fender.
5. Disconnect horn (LO) connectors.
6. Remove horn (LO) mounting bolts (A), and remove horn (LO) (1)
from vehicle.
INSTALLATION
Tighten horn bolt to specified torque.
SKIB4266E
SKIB4267E
Horn mounting bolt :17.1 Nꞏm (1.7 kg-m, 13 ft-lb.)
