audio INFINITI M35 2006 Factory Workshop Manual

AV-178
[WITH MOBILE ENTERTAINMENT SYSTEM]
SYSTEM DESCRIPTION
Revision: 2006 January2006 M35/M45
Wiring Diagram — AV — / BOSE Surround Audio 5.1ch SystemNKS004AI
TKWT3451E

AV-204
[WITH MOBILE ENTERTAINMENT SYSTEM]
TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT
Revision: 2006 January2006 M35/M45
TERMINALS AND REFERENCE VALUE FOR CONTROL UNITPFP:00000
Audio UnitNKS004AL
Te r m i n a l
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
switch Operation
2
(R/L)3
(W)Audio signal LH Output ON Receive audio signal.
6
(BR)15
(G)Steering switch signal A Input ONKeep pushing SOURCE
switch.approx. 0 V
Keep pushing MENU UP
switch.Approx. 1.2 V
Keep pushing MENU DOWN
switch.Approx. 2.5 V
Keep pushing ENTER
switch.Approx. 3.7 V
Except for above. Approx. 5 V
7
(V)Ground ACC power supply Input ACC
Battery voltage
8
(R/Y)Ground Illumination control signal Input OFFIllumination control switch is
operated by lighting switch
in ON position.Change between approx. 0 V
and approx. 12 V
9
(R)Ground Illumination signal Input OFFLighting switch is OFF. Approx. 0 V
Lighting switch is ON. Approx. 12 V
11
(P)12
(L)Audio signal RH Output ON Receive audio signal.
15
(G)GroundSteering switch signal
ground– ON – Approx. 0 V
16
(O)15
(G)Steering switch signal B Input ONKeep pushing VOL DOWN
switch.Approx. 0 V
Keep pushing VOL UP
switch.Approx. 1.2 V
Keep pushing TEL, PTT
switch.Approx. 2.5 V
Keep pushing BACK switch. Approx. 3.7 V
Except for above. Approx. 5 V
19
(Y)Ground Battery power supply Input OFF
Battery voltage
20
(B)Ground Ground – ON – Approx. 0 V
SKIB3609E
SKIB3609E

TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT
AV-205
[WITH MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2006 January2006 M35/M45
21
(B/R)25
(BR)Sound signal LH
Input ON When playing DVD
22
(B/W)26
(L)Sound signal RH
23
(Y)–Communication signal
(H)Input/
Output–– –
24
(O)–Communication signal
(L)Input/
Output–– –
27 – Shield
––
30
(BR)31
(B/R)TEL voice signal Input ONWhen inputting TEL voice
signal.
37 – Shield – – – –
41
(R)45
(G)Audio signal LH Input ON Satellite radio mode is ON.
42
(B)46
(W)Audio signal RH Input ON Satellite radio mode is ON.
43
(W)GroundCommunication signal
(AUDIO-SAT)Output ON Satellite radio mode is ON.
47 – Shield – – – –
48 – Shield – – – –
50
(B)Ground REQ1 (SAT-AUDIO) Input ON Satellite radio mode is ON. Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
switch Operation
SKIB3609E
SKIB3609E
SKIB3609E
SKIB3609E
SKIB3826E
SKIB3825E

AV-206
[WITH MOBILE ENTERTAINMENT SYSTEM]
TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT
Revision: 2006 January2006 M35/M45
BOSE AmpNKS004AM
51
(R)GroundCommunication signal
(SAT-AUDIO)Input ON Satellite radio mode is ON.
53 Ground Antenna amp ON signal Output ON
Approx.12V
54 – AM-FM main Input – – –
55 – FM sub Input – – –Te r m i n a l
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
switch Operation
SKIB3824E
Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
switchOperation
14
(G)–Communication signal
(L)–– – –
15
(G)–Communication signal
(L)–– – –
16
(BR)Ground ACC power supply Input ACC – Battery voltage
23
*
(L/R)3
*
(L/G)DVD sound signal front
LHInput ON
When playing DVDCAUTION
24*
(B/Y)4
*
(LG)DVD sound signal front
RHInput ON
When playing DVDCAUTION
25*
(B)5
*
(W)DVD sound signal rear
LHInput ON
When playing DVDCAUTION
26*
(P)6
*
(L)DVD sound signal rear
RHInput ON
When playing DVDCAUTION
SKIB3609E
SKIB3609E
SKIB3609E
SKIB3609E

TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT
AV-207
[WITH MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2006 January2006 M35/M45
27*
(G)7
*
(R)DVD sound signal
centerInput ON
When playing DVDCAUTION
28*
(BR)8
*
(Y)DVD sound signal woofer Input ON
When playing DVDCAUTION
29
(P)9
(L)Audio signal LH Input ON Receive audio signal.
30
(R)10
(G)Audio signal RH Input ON Receive audio signal.
31
(L)11
(B/W)MIC. signal Input ON When inputting noise.
32
(B/W)12
(L)Voice guidance signal Input ONWhen inputting voice guid-
ance.
33 – Shield – – – –
34
(R)–Communication signal
(H)–– – –
35
(R)–Communication signal
(H)–– – –
36 – Shield – – – –Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
switchOperation
SKIB3609E
PKIB6116J
SKIB3609E
SKIB3609E
PKIA2104E
SKIB3609E

AV-208
[WITH MOBILE ENTERTAINMENT SYSTEM]
TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT
Revision: 2006 January2006 M35/M45
41
(L)42
(B/W)Audio signal front LH Output ON Receive audio signal.
43
(BR)44
(B/R)Audio signal front RH Output ON Receive audio signal.
45
(BR)46
(B/R)Audio signal woofer Output ON Receive audio signal.
47
(B/W)Ground Ground – ON – Approx. 0 V
50
(Y)Ground Battery power supply Input OFF – Battery voltage
51
(R)Ground Battery power supply Input OFF – Battery voltage
52
(B/W)Ground Ground – ON – Approx. 0 V
54
(LG)49
(B/Y)Audio signal rear LH Output ON Receive audio signal.
56
*
(B/W)69
*
(L)Audio signal passenger
seat LHOutput ON Receive audio signal.
57
(O/B)58
(W/R)Audio signal
centerOutput ON Receive audio signal. Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
switchOperation
SKIB3609E
SKIB3609E
PKIB6116J
SKIB3609E
SKIB3609E
SKIB3609E

TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT
AV-209
[WITH MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2006 January2006 M35/M45
*: BOSE surround 5.1ch system
CAUTION:
When the stereo sound is played, only front RH and LH are input. When the monaural sound is played, only center is input. All
surround sounds are input only when the 5.1 channel surround sound is played. 59
*
(B)72
*
(W)Audio signal rear sur-
round LHOutput ON Receive audio signal.
62
*
(G/Y)73
*
(GY/R)Audio signal rear sur-
round RHOutput ON Receive audio signal.
63
*
(B/W)74
*
(L)Audio signal driver seat
LHOutput ON Receive audio signal.
64
*
(B/R)75
*
(BR)Audio signal driver seat
RHOutput ON Receive audio signal.
68
(O)55
(B/P)Audio signal rear RH Output ON Receive audio signal.
71
*
(Y)70
*
(BR)Audio signal passenger
seat RHOutput ON Receive audio signal. Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
switchOperation
SKIB3609E
SKIB3609E
SKIB3609E
SKIB3609E
SKIB3609E
SKIB3609E

AV-210
[WITH MOBILE ENTERTAINMENT SYSTEM]
TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT
Revision: 2006 January2006 M35/M45
Satellite Radio TunerNKS004AN
Te r m i n a l
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
switchOperation
2
(R)1
(G)Audio signal LH Output ON Receive audio signal.
4
(B)3
(W)Audio signal RH Output ON Receive audio signal.
5 – Shield – – – –
6 – Shield – ON – Approx. 0 V
8
(R/W)Ground REQ1 (SAT-AUDIO) Output ONSet to the satellite radio
mode
9
(B)GroundCommunication signal
(SAT-AUDIO)Output ONSet to the satellite radio
mode
10
(R)GroundCommunication signal
(AUDIO-SAT)Input ONSet to the satellite radio
mode
12
(BR/Y)Ground Battery power supply Input OFF
Battery voltage
16
(BR)Ground ACC power supply Input ACC
Battery voltage
20 – Terrestrial antenna signal Input – – –
21 – Satellite antenna signal Input – – –
SKIB3609E
SKIB3609E
SKIB3825E
SKIB3824E
SKIB3826E

DIAGNOSIS SYSTEM
AV-231
[WITH MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2006 January2006 M35/M45
On Board Diagnosis Item
*: With navigation system
STARTING PROCEDURE
1. Start the engine.
2. Turn the audio system OFF.
3. While pushing the “SETTING” button, turn the volume control
dial clockwise or counterclockwise for 40 clicks or more. (When
the self-diagnosis mode is started, a short beep will be heard.)
Shifting from current screen to previous screen is performed
by pushing “BACK” button.
Mode Description
Self Diagnosis
AV (NAVI) control unit diagnosis and connection diagnosis between
AV (NAVI) control unit and each unit
The DVD-ROM drive diagnosis of NAVI control unit and the connec-
tion diagnosis between NAVI control unit and GPS antenna can be
performed
(DVD-ROM drive will not be diagnosed when no map DVD-ROM is in
it.)
Confirmation/
AdjustmentDisplay DiagnosisThe tint can be confirmed by the color spectrum bar display. The shad-
ing of color can be confirmed by the gradation bar display.
Vehicle SignalsDiagnosis of signals can be performed for vehicle speed, parking brake,
lights, ignition switch, and reverse.
Speaker Test The connection of a speaker can be confirmed by test tone.
Climate Control Start auto air conditioner system self-diagnosis.
Navigation
*
Steering Angle
AdjustmentWhen there is a difference between the actual turning angle and the
vehicle mark turning angle, it can be adjusted.
Speed CalibrationWhen there is a difference between the current location mark and the
actual location, it can be adjusted.
Error HistoryThe system malfunction and the frequency when occurred in the past
are displayed. When the malfunctioning item is selected, the time and
place that the selected malfunction last occurred are displayed.
Synchronizer FES clock –
Vehicle CAN Diagnosis The transmitting/receiving of CAN communication can be monitored.
AV COMM DiagnosisThe communication condition of each unit of Multi AV system can be
monitored.
Handsfree PhoneThe received volume adjustment of hands-free phone, microphone
speaker check, and erase memory can be performed.
Rear DisplayTilt angle adjustment range and automatic retraction ON/OFF when
ignition switch is turned OFF can be selected
Camera Cont.The signal connected to camera control unit can be checked and the
guiding line position that overlaps rear view camera image can be
adjusted.
Bluetooth The passkey and the name of device can be checked and changed
Delete Unit Connection Log Erase the connection history of unit and error history
SKIB3655E

AV-234
[WITH MOBILE ENTERTAINMENT SYSTEM]
DIAGNOSIS SYSTEM
Revision: 2006 January2006 M35/M45
Connection Line Between Units Is Yellow (2 or More Lines)
When 2 or more connection lines between control unit (AV control unit, NAVI control) and each unit are dis-
played in yellow, these communication system lines may be open or shorted. The malfunctioning parts can be
detected by the combination of the connection lines displayed in yellow.
Control unit to Audio unit
Audio unit power supply and ground circuit mal-
function is detected
Malfunction is detected on communication cir-
cuit between audio unit and rear control unit
(Models with rear control switch)
Malfunction is detected on communication cir-
cuit between audio unit and BOSE amp (Mod-
els without rear control switch)
Malfunction is detected on communication sig-
nal between audio unit and AV (NAVI) control
unit
Audio unit power supply and ground circuit
Communication circuit between rear control
switch and audio unit
Audio unit
Rear control switch (with rear control switch)
BOSE amp (without rear control switch)
AV (NAVI) Control unit
Video distributor to Rear Dis-
play
Rear display unit power supply and ground cir-
cuit malfunction is detected
Malfunction is detected on communication cir-
cuit between video distributor and rear display
unit
Malfunction is detected on communication sig-
nal between video distributor and rear display
unit
Rear display unit power supply and ground cir-
cuit
Rear display unit
Video distributor Applicable parts Description Probable malfunction location
Applicable parts Description Probable malfunction location
Control unit to
Amplifier
Rear Switches
Audio unit
Malfunction is detected on communication cir-
cuit between multifunction switch and camera
control unit
Malfunction is detected on communication cir-
cuit between camera control unit and BOSE
amp
Communication circuit between multifunction
switch and camera control unit
Communication circuit between camera control
unit and BOSE amp
Multifunction switch
Camera control unit
BOSE amp
Control unit to
Amplifier
Audio unit
Malfunction is detected on communication cir-
cuit between multifunction switch and camera
control unit
Malfunction is detected on communication cir-
cuit between camera control unit and BOSE
amp
Communication circuit between multifunction
switch and camera control unit
Communication circuit between camera control
unit and BOSE amp
Multifunction switch
Camera control unit
BOSE amp
Control unit to
Rear Switches
Audio unitMalfunction is detected on communication circuit
between BOSE amp and rear control switch
Communication circuit between BOSE amp and
rear control switch
BOSE amp
Rear control switch
