TURN SIGNAL AND HAZARD WARNING LAMPS
Revision: October 20052005 QX56
Bulb Replacement (Front Turn Signal Lamp)EKS00BA1
1. Remove turn/fog lamp assembly. Refer to LT- 7 9 , "Removal and Installation" .
2. Turn bulb socket counterclockwise to remove it from lamp housing.
3. Pull bulb from socket.
Installation is in the reverse order of removal.
Bulb Replacement (Rear Turn Signal Lamp)EKS00BA2
Refer to LT- 1 2 2 , "Bulb Replacement (Turn Signal)" in REAR COMBINATION LAMP.
Removal and Installation of Front Turn Signal LampEKS00BA3
Refer to LT- 3 2 , "Removal and Installation" .
Removal and Installation of Rear Turn Signal Lamp EKS00BA4
Refer to LT- 1 2 2 , "Removal and Installation" in REAR COMBINATION LAMP.

LIGHTING AND TURN SIGNAL SWITCH
LT-95
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: October 20052005 QX56
LIGHTING AND TURN SIGNAL SWITCHPFP:25540
Removal and InstallationEKS00BA5
REMOVAL
1. Remove steering column cover.
2. While pressing tabs, pull lighting and turn signal switch toward
driver door and disconnect from the base.
INSTALLATION
Installation is in the reverse order of removal.
LKIA0013E

LT-96
HAZARD SWITCH
Revision: October 20052005 QX56
HAZARD SWITCHPFP:25290
Removal and InstallationEKS00BA6
REMOVAL
1. Remove cluster lid C. Refer to IP-12, "Cluster Lid C" .
2. Remove screws and remove the hazard switch.
INSTALLATION
Installation is in the reverse order of removal.
WKIA1897E

COMBINATION SWITCH
LT-97
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: October 20052005 QX56
COMBINATION SWITCHPFP:25567
Wiring Diagram — COMBSW —EKS00BA7
WKWA2410E

LT-98
COMBINATION SWITCH
Revision: October 20052005 QX56
Combination Switch Reading FunctionEKS00BA8
For details, refer to BCS-3, "COMBINATION SWITCH READING FUNCTION" .
CONSULT-II Function (BCM)EKS00BA9
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
CONSULT-II OPERATION
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
1. With the ignition switch OFF, connect CONSULT-II and CON-
SULT-II CONVERTER to the data link connector, then turn igni-
tion switch ON.
2. Touch "START (NISSAN BASED VHCL)".
3. Touch "BCM" on "SELECT SYSTEM" screen.
If "BCM" is not indicated, go to GI-39, "
CONSULT-II Data Link
Connector (DLC) Circuit" .
BCM diagnostic
test itemDiagnostic mode Description
Inspection by partWORK SUPPORTSupports inspections and adjustments. Commands are transmitted to the BCM
for setting the status suitable for required operation, input/output signals are
received from the BCM and received data is displayed.
DATA MONITOR Displays BCM input/output data in real time.
ACTIVE TEST Operation of electrical loads can be checked by sending drive signal to them.
SELF-DIAG RESULTS Displays BCM self-diagnosis results.
CAN DIAG SUPPORT MNTR The result of transmit/receive diagnosis of CAN communication can be read.
ECU PART NUMBER BCM part number can be read.
CONFIGURATION Performs BCM configuration read/write functions.
BBIA0369E
BCIA0029E
BCIA0030E

COMBINATION SWITCH
LT-99
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: October 20052005 QX56
4. Touch "COMB SW" on "SELECT TEST ITEM" screen.
DATA MONITOR
Operation Procedure
1. Touch "COMB SW" on "SELECT TEST ITEM" screen.
2. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
3. Touch either "ALL SIGNALS" or "SELECTION FROM MENU" on "SELECT MONITOR ITEM" screen.
4. Touch "START".
5. When "SELECTION FROM MENU" is selected, touch items to be monitored. When "ALL SIGNALS" is
selected, all the signals will be monitored.
6. Touch "RECORD" while monitoring, then the status of the monitored item can be recorded. To stop
recording, touch "STOP".
Display Item List
LKIA0183E
ALL SIGNALS Monitors all the signals.
SELECTION FROM MENU Selects and monitors individual signal.
Monitor item name
"OPERATION OR UNIT"Contents
TURN SIGNAL R "ON/OFF" Displays "Turn Right (ON)/Other (OFF)" status, determined from lighting switch signal.
TURN SIGNAL L "ON/OFF" Displays "Turn Left (ON)/Other (OFF)" status, determined from lighting switch signal.
HI BEAM SW "ON/OFF"Displays status (high beam switch: ON/Others: OFF) of high beam switch judged from lighting
switch signal.
HEAD LAMP SW 1 "ON/OFF" Displays "Headlamp switch 1 (ON)/Other (OFF)" status, determined from lighting switch signal.
HEAD LAMP SW 2 "ON/OFF"Displays status (headlamp switch 2: ON/Others: OFF) of headlamp switch 2 judged from lighting
switch signal.
LIGHT SW 1ST "ON/OFF"Displays status (lighting switch 1st position: ON/Others: OFF) of lighting switch judged from lighting
switch signal.
PASSING SW "ON/OFF"Displays status (flash-to-pass switch: ON/Others: OFF) of flash-to-pass switch judged from lighting
switch signal.
AUTO LIGHT SW "ON/OFF" Displays "Auto light switch (ON)/Other (OFF)" status, determined from lighting switch signal.
FR FOG SW "ON/OFF" Displays "Front fog lamp switch (ON)/Other (OFF)" status, determined from lighting switch signal.
FR WIPER HI "ON/OFF" Displays "Front Wiper HI (ON)/Other (OFF)" status, determined from wiper switch signal.
FR WIPER LOW "ON/OFF" Displays "Front Wiper LOW (ON)/Other (OFF)" status, determined from wiper switch signal.
FR WIPER INT "ON/OFF" Displays "Front Wiper INT (ON)/Other (OFF)" status, determined from wiper switch signal.
FR WASHER SW "ON/OFF" Displays "Front Washer Switch (ON)/Other (OFF)" status, determined from wiper switch signal.
INT VOLUME [1 - 7] Displays intermittent operation knob setting (1 - 7), determined from wiper switch signal.
RR WIPER ON "ON/OFF" Displays "Rear Wiper (ON)/(OFF)" status, determined from wiper switch signal.
RR WIPER INT "ON/OFF" Displays "Rear Wiper INT (ON)/(OFF)" status, determined from wiper switch signal.
RR WASHER SW "ON/OFF" Displays "Rear Washer (ON)/(OFF)" status, determined from wiper switch signal.

LT-100
COMBINATION SWITCH
Revision: October 20052005 QX56
Combination Switch InspectionEKS00BAA
1. SYSTEM CHECK
1. Referring to table below, check which system the malfunctioning switch belongs.
>> GO TO 2.
2. SYSTEM CHECK
With CONSULT-II
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
1. Connect CONSULT-II, and select "COMB SW" on "SELECT
TEST ITEM" screen.
2. Select "DATA MONITOR".
3. Select "START", and confirm that other switches in malfunction-
ing system operate normally.
Example: When auto light switch is malfunctioning, confirm that
"FRONT WIPER LOW" and "FRONT WIPER INT" in System 3,
to which the auto light switch belongs, turn ON-OFF normally.
Without CONSULT-II
Operate combination switch, and confirm that other switches in malfunctioning system operate normally.
Example: When auto light switch is malfunctioning, confirm that "FRONT WIPER LOW" and "FRONT WIPER
INT" in System 3, to which the auto light switch belongs, operate normally.
Check results
Other switches in malfunctioning system operate normally.>>Replace lighting switch or wiper switch.
Other switches in malfunctioning system do not operate normally.>>GO TO 3.
System 1 System 2 System 3 System 4 System 5
— FR WASHER FR WIPER LO TURN LH TURN RH
FR WIPER HI — FR WIPER INT PASSING HEAD LAMP1
INT VOLUME 1 RR WASHER — HEAD LAMP2 HI BEAM
RR WIPER INT INT VOLUME 3 AUTO LIGHT — TAIL LAMP
INT VOLUME 2 RR WIPER ON — FR FOG —
SKIA7075E

COMBINATION SWITCH
LT-101
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: October 20052005 QX56
3. HARNESS INSPECTION
1. Turn ignition switch OFF.
2. Disconnect BCM and combination switch connectors.
3. Check for continuity between BCM harness connector of the suspect system and the corresponding com-
bination switch connector terminals.
4. Check for continuity between each terminal of BCM harness connector in suspect malfunctioning system
and ground.
OK or NG
OK >> GO TO 4.
NG >> Check harness between BCM and combination switch for open or short circuit.
Sus-
pect
systemTe r m i n a l s
Continuity BCM Combination switch
ConnectorTe r m i n a l
(Wire color)ConnectorTe r m i n a l
(Wire color)
1
M18Input 1 6 (V)
M286 (V)
Ye s Output 1 36 (R/W) 1 (R/W)
2Input 2 5 (G/B) 7 (G/B)
Output 2 35 (O/B) 2 (O/B)
3Input 3 4 (Y) 10 (Y)
Output 3 34 (L) 3 (L)
4Input 4 3 (G/Y) 9 (G/Y)
Output 4 33 (R/Y) 4 (R/Y)
5Input 5 2 (SB) 8 (SB)
Output 5 32 (R/G) 5 (R/G)
Suspect
systemTe r m i n a l s
Continuity BCM
Connector Terminal (Wire color)
1
M18Input 1 6 (V)
Ground No Output 1 36 (R/W)
2Input 2 5 (G/B)
Output 2 35 (O/B)
3Input 3 4 (Y)
Output 3 34 (L)
4Input 4 3 (G/Y)
Output 4 33 (R/Y)
5Input 5 2 (SB)
Output 5 32 (R/G)
LKIA0284E

LT-102
COMBINATION SWITCH
Revision: October 20052005 QX56
4. BCM OUTPUT TERMINAL INSPECTION
1. Turn lighting switch and wiper switch to OFF.
2. Set wiper dial to position 4.
3. Connect BCM and combination switch connectors.
4. Turn ignition switch ON.
5. Check combination switch input terminal voltage waveform of
suspect malfunctioning system.
OK or NG
OK >> Open circuit in combination switch, GO TO 5.
NG >> Replace BCM. Refer to BCS-20, "
Removal and Installa-
tion of BCM" .
5. COMBINATION SWITCH INSPECTION
Referring to table below, perform combination switch inspection.
>> Inspection End.
Removal and InstallationEKS00BAB
For details, refer to LT- 9 5 , "Removal and Installation" .
Switch Circuit InspectionEKS00BAC
For details, refer to LT-100, "Combination Switch Inspection" .
Suspect systemTerminals
Combination switch (+)
Connector Terminal (Wire color)
1
M28Input 1 1 (R/W)
2 Input 2 2 (O/B)
3 Input 3 3 (L)
4 Input 4 4 (R/Y)
5 Input 5 5 (R/G)
SKIA4976E
Procedure
12 345 67
Replace
lighting
switch.Confirm
check
results.OK INSPECTION END
Confirm
check
results.OK INSPECTION END
Confirm
check
results.OK INSPECTION END
NGReplace wiper
switch.NGReplace switch
base.NGConfirm symptom
again.

STOP LAMP
LT-103
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: October 20052005 QX56
STOP LAMPPFP:26550
System DescriptionEKS00BAD
Power is supplied at all times

through 10A fuse [No. 20, located in fuse block (J/B)]

to stop lamp switch terminal 3, and

to stop lamp relay terminal 1.
When the brake pedal is pressed, the stop lamp switch is closed and power is supplied

through stop lamp switch terminal 4

to stop lamp relay terminal 3

through stop lamp relay terminal 4

to rear combination lamp LH and RH terminal 2, and

to high-mounted stop lamp terminal +.
Ground is supplied

to rear combination lamp LH terminal 1, and

to high-mounted stop lamp terminal –

through grounds B7 and B19, and

to rear combination lamp RH terminal 1

through grounds B117 and B132.
With power and ground supplied, the stop lamps illuminate.
