Removal and Installation for Front EvaporatorEJS003Z1
Front Heater and Cooling Unit Assembly
REMOVAL
1. Remove the front heater core. Refer to ATC-161, "FRONT HEATER CORE" .
LJIA0138E
1. Heater core cover 2. Heater core pipe bracket 3. Heater core
4. Upper bracket 5. Upper heater and cooling unit case 6. A/C evaporator
7. Lower heater and cooling unit case 8. Blower motor 9. Variable blower control

REFRIGERANT LINES
ATC-187
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: October 20052005 QX56
2. Remove the defroster mode door arm.
3. Separate the heater core and cooling unit case.
4. Remove the evaporator.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Replace the O-rings on the low-pressure flexible hose and the high-pressure pipe with new ones.
Apply compressor oil to the O-rings before installing them.
Removal and Installation for Rear EvaporatorEJS003Z2
Rear Heater and Cooling Unit Assembly
LJIA0135E
1. Front cover 2. Evaporator and heater core case 3. Evaporator
4. Side cover 5. Heater core 6. Rear blower motor
7. Blower motor case 8. Rear blower motor resistor

ATC-188
REFRIGERANT LINES
Revision: October 20052005 QX56
REMOVAL
1. Remove the rear heater and cooling unit assembly from the vehicle. Refer to ATC-158, "REAR HEATER
AND COOLING UNIT ASSEMBLY" .
2. Remove the rear blower motor.
3. Remove the rear blower speed resistor.
4. Remove the rear air mix door motor.
5. Remove the rear duct and blend door assembly. Refer to AT C -
173, "REAR OVERHEAD DUCTS" .
6. Disassemble the rear heater and cooling unit assembly to
remove the evaporator.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:

Replace the O-rings on the rear A/C pipes with new ones. Apply compressor oil to the O-rings
before installing them.

After charging refrigerant, check for leaks.
Removal and Installation for Front Expansion ValveEJS003Z3
REMOVAL
1. Discharge the refrigerant. Refer to ATC-175, "HFC-134a (R-134a) Service Procedure" .
2. Remove the front heater and cooling unit assembly. Refer to ATC-157, "
FRONT HEATER AND COOLING
UNIT ASSEMBLY" .
3. Remove the cooler grommet.
4. Remove the expansion valve.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:

Replace the O-rings on the A/C refrigerant pipes with new ones, then apply compressor oil to them
when installing them.

After charging refrigerant, check for leaks.
Removal and Installation for Rear Expansion ValveEJS003Z4
REMOVAL
1. Discharge the refrigerant. Refer to ATC-175, "HFC-134a (R-134a) Service Procedure" .
2. Remove the rear RH interior side trim panel. Refer to EI-35, "
BODY SIDE TRIM" .
3. Disconnect the A/C refrigerant pipes from the expansion valve.
LJIA0021E
WJIA0582E
Expansion valve bolts : 4 N·m (0.41 kg-m, 35 in-lb)
A/C refrigerant pipe to expansion valve bolt : Refer to ATC-177, "
Components"
.

REFRIGERANT LINES
ATC-189
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: October 20052005 QX56
CAUTION:
Cap or wrap the A/C refrigerant pipe ends with a suitable material such as vinyl tape to avoid the
entry of air and contaminants.
4. Remove the expansion valve.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:

Replace the O-rings on the A/C refrigerant pipes with new ones, then apply compressor oil to them
when installing them.

After charging refrigerant, check for leaks.
Checking for Refrigerant LeaksEJS003Z5
Perform a visual inspection of all refrigeration parts, fittings, hoses and components for signs of A/C lubricant
leakage, damage, and corrosion. Any A/C lubricant leakage may indicate an area of refrigerant leakage. Allow
extra inspection time in these areas when using either an electronic refrigerant leak detector (J-41995) or fluo-
rescent dye leak detector (J-42220).
If any dye is observed using a fluorescent dye leak detector (J-42220), confirm the leak using a electronic
refrigerant leak detector (J-41995). It is possible that the dye is from a prior leak that was repaired and not
properly cleaned.
When searching for leaks, do not stop when one leak is found but continue to check for additional leaks at all
system components and connections.
When searching for refrigerant leaks using an electronic refrigerant leak detector (J-41995), move the probe
along the suspected leak area at 25 - 50 mm (1 - 2 in) per second and no further than 6 mm (1/4 in) from the
component.
CAUTION:
Moving the electronic refrigerant leak detector probe slower and closer to the suspected leak area will
improve the chances of finding a leak.
Checking System for Leaks Using the Fluorescent Dye Leak DetectorEJS003Z6
1. Check the A/C system for leaks using the fluorescent dye leak detector and safety goggles (J-42220) in a
low sunlight area (area without windows preferable). Illuminate all components, fittings and lines. The dye
will appear as a bright green/yellow area at the point of leakage. Fluorescent dye observed at the evapo-
rator drain opening indicates an evaporator core assembly leak (tubes, core or expansion valve).
2. If the suspected area is difficult to see, use an adjustable mirror or wipe the area with a clean shop rag or
cloth, then inspect the shop rag or cloth with the fluorescent dye leak detector (J-42220) for dye residue.
3. After the leak is repaired, remove any residual dye using refrigerant dye cleaner (J-43872) to prevent
future misdiagnosis.
4. Perform a system performance check and then verify the leak repair using a electronic refrigerant leak
detector (J-41995).
NOTE:

Other gases in the work area or substances on the A/C components, for example, anti-freeze, wind-
shield washer fluid, solvents and lubricants, may falsely trigger the leak detector. Make sure the sur-
faces to be checked are clean.

Clean with a dry cloth or blow off with shop air.

Do not allow the sensor tip of the electronic refrigerant leak detector (J-41995) to contact with any sub-
stance. This can also cause false readings and may damage the detector.
Dye InjectionEJS003Z7
NOTE:
This procedure is only necessary when recharging the system or when the compressor has seized and must
be replaced.
1. Check the A/C system static (at rest) pressure. Pressure must be at least 345 kPa (3.52 kg/cm
2 , 50 psi). Expansion valve bolts : 4 N·m (0.41 kg-m, 35 in-lb)
A/C refrigerant pipe to expansion valve bolt : Refer to ATC-177, "
Components"
.

ATC-190
REFRIGERANT LINES
Revision: October 20052005 QX56
2. Pour one bottle 7.4 cc (1/4 ounce) of the HFC-134a (R-134a) fluorescent leak detection dye (J-41447) into
the HFC-134a (R-134a) dye injector (J-41459).
CAUTION:
If repairing the A/C system or replacing a component, pour the HFC-134a (R-134a) fluorescent leak
detection dye (J-41447) directly into the open system connection and proceed with the service
procedures.
3. Connect the refrigerant dye injector (J-41459) to the low-pressure service valve.
4. Start the engine and switch the A/C system ON.
5. When the A/C system is operating (compressor running), inject one bottle 7.4 cc (1/4 ounce) of HFC-134a
(R-134a) fluorescent leak detection dye (J-41447) through the low-pressure service valve using HFC-
134a (R-134a) dye injector (J-41459). Refer to the manufacturer's operating instructions.
6. With the engine still running, disconnect the HFC-134a (R-134a) dye injector (J-41459) from the low-pres-
sure service valve.
7. Operate the A/C system for a minimum of 20 minutes to mix the HFC-134a (R-134a) fluorescent leak
detection dye (J-41447) with the A/C system oil. Depending on the leak size, operating conditions and
location of the leak, it may take from minutes to days for the HFC-134a (R-134a) fluorescent leak detec-
tion dye to penetrate an A/C system leak and become visible.
Electronic Refrigerant Leak DetectorEJS003Z8
PRECAUTIONS FOR HANDLING LEAK DETECTOR
NOTE:
When performing a refrigerant leak check, use a electronic refrigerant leak detector (J-41995) or equivalent.
Ensure that the electronic refrigerant leak detector (J-41995) is calibrated and set properly according to the
manufacturer's operating instructions.
The electronic refrigerant leak detector (J-41995) is a delicate
device. To use the leak detector properly, read the manufacturer's
operating instructions and perform any specified maintenance.
1. Position the probe approximately 5 mm (3/16 in) away from the
point to be checked as shown.
SHA1 96 FA
SHA707EA

REFRIGERANT LINES
ATC-191
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: October 20052005 QX56
2. When checking for leaks, circle each fitting completely with the
probe as shown.
3. Move the probe along each component at a speed of approxi-
mately 25 - 50 mm (1 - 2 in)/second as shown.
CHECKING PROCEDURE
NOTE:
To prevent inaccurate or false readings, make sure there is no refrigerant vapor, shop chemicals, or cigarette
smoke in the vicinity of the vehicle. Perform the leak test in a calm area (low air/wind movement) so that the
leaking refrigerant is not dispersed.
1. Turn the engine OFF.
2. Connect the manifold gauge set (J-39183-C) to the A/C service ports. Refer to ATC-175, "
SETTING OF
SERVICE TOOLS AND EQUIPMENT" .
3. Check if the A/C refrigerant pressure is at least 345 kPa (3.52 kg/cm
2 , 50 psi) above a temperature of
16°C (61°F). If less than specification, recover/evacuate and recharge the system with the specified
amount of refrigerant. Refer to ATC-175, "
HFC-134a (R-134a) Service Procedure" .
NOTE:
At temperatures below 16°C (61°F), leaks may not be detected since the system may not reach 345 kPa
(3.52 kg/cm
2 , 50 psi) pressure.
4. Perform the leak test from the high-pressure side (front A/C compressor discharge “a” to evaporator inlet
“f” or rear piping connection “l”) to the low-pressure side (front A/C evaporator drain hose “g” to shaft seal
“k” and rear A/C evaporator drain hose “o” to piping connection “r”). Refer to ATC-177, "
Components" .
Clean the component to be checked and carefully move the electronic refrigerant leak detector probe
completely around the following connections and components.

Check the compressor shaft seal

Check the high and low-pressure pipe and hose fittings, relief valve, and compressor shaft seal

Check the liquid tank

Check the refrigerant pressure sensor

Check all around the service valves. Check that the service valve caps are screwed tightly on the ser-
vice valves (to prevent leaks).
NOTE:
After removing manifold gauge set (J-39183-C) from the service valves, wipe any residue from the ser-
vice valves to prevent any false readings by the electronic refrigerant leak detector (J-41995).

Evaporator
With engine OFF, turn blower fan on “High” for at least 15 seconds to dissipate any refrigerant trace in
the heater and cooling unit assembly. Wait a minimum of 10 minutes accumulation time (refer to the
manufacturer's recommended procedure for actual wait time) before inserting the electronic refrigerant
leak detector probe into the heater and cooling unit assembly drain hose.
SHA7 06 E
SHA708EA

ATC-192
REFRIGERANT LINES
Revision: October 20052005 QX56
NOTE:
Keep the probe inserted for at least 10 seconds. Use caution not to contaminate the probe tip with
water or dirt that may be in the drain hose.
5. If a leak is detected, verify at least once by blowing compressed air into the area of the suspected leak,
then repeat the leak check.
6. Do not stop when one leak is found. Continue to check for additional leaks at all system components and
connections.
7. If no leaks are found, perform steps 8 - 11.
8. Start the engine.
9. Set the heater A/C controls as follows:
NOTE:
For the automatic system, turn OFF the automatic controls and set the heater A/C controls manually.
a. A/C switch to ON
b. Air flow to VENT mode
c. Intake position to RECIRCULATION mode
d. Temperature to MAX cold
e. Blower speed to HIGH
10. Run the engine at 1,500 rpm for at least 2 minutes.
11. Turn the engine OFF and perform the leak check again following
steps 4 through 6 above.
Refrigerant leaks should be checked immediately after turning
the engine OFF. Begin with the leak detector at the compressor.
The pressure on the high pressure side will gradually drop after
the refrigerant circulation stops and pressure on the low pres-
sure side will gradually rise, as shown in the graph. Some leaks
are more easily detected when the pressure is high.
12. Before connecting the recovery/recycling recharging equipment to the vehicle, check the recovery/recy-
cling recharging equipment gauges. No refrigerant pressure should be displayed. If pressure is displayed,
recover the refrigerant from the equipment lines and then check the refrigerant purity.
13. Confirm refrigerant purity in supply tank using recovery/recycling recharging equipment and refrigerant
identifier equipment (J-41810-NI).
14. Confirm the refrigerant purity in the vehicle's A/C system using recovery/recycling recharging equipment
and refrigerant identifier equipment (J-41810-NI).
15. Discharge the A/C system using recovery/recycling recharging equipment. Repair the leaking fitting or
component as necessary.
16. Evacuate and recharge the A/C system and perform the leak test to confirm that there are no refrigerant
leaks.
17. Conduct the Operational Check to ensure system works properly. Refer to AT C - 5 7 , "
Operational Check
(Front)" and ATC-60, "Operational Check (Rear)" .
SHA8 39 E

SERVICE DATA AND SPECIFICATIONS (SDS)
ATC-193
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: October 20052005 QX56
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Service Data and Specifications (SDS)EJS003Z9
COMPRESSOR
LUBRICANT
REFRIGERANT
ENGINE IDLING SPEED
Refer to EC-77, "Idle Speed and Ignition Timing Check" .
BELT TENSION
Refer to EM-12, "Checking Drive Belts" .
MakeZEXEL VALEO CLIMATE CONTROL
ModelDKS-17D
Typ eSwash plate
Displacement
175.5 cm
3 (10.7 in3 ) / revolution
Cylinder bore × stroke 30.5 mm (1.20 in) x 24.0 mm (0.94 in)
Direction of rotation Clockwise (viewed from drive end)
Drive beltPoly V
MakeZEXEL VALEO CLIMATE CONTROL
ModelDKS-17D
NameNISSAN A/C System Lubricant Type S
Capacity
290 m (9.8 US fl oz, 10.2 Imp fl oz)
Typ eHFC 134a (R-134a)
Capacity1.08 ± 0.05 kg (2.38 ± 0.11 oz)

ATC-194
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: October 20052005 QX56

AV-1
AUDIO, VISUAL, NAVIGATION & TELEPHONE SYS-
TEM
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION AV
A
B
AV
Revision: October 20052005 QX56 PRECAUTIONS .......................................................... 4
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 4
Wiring Diagrams and Trouble Diagnosis .................. 4
PREPARATION ........................................................... 5
Commercial Service Tool ......................................... 5
AUDIO ......................................................................... 6
Component Parts and Harness Connector Location ..... 6
System Description .................................................. 7
REAR AUDIO REMOTE CONTROL UNIT ........... 7
SATELLITE RADIO TUNER (PRE-WIRING) ........ 8
SPEED SENSITIVE VOLUME SYSTEM .............. 8
Schematic ................................................................ 9
Wiring Diagram — AUDIO — ................................. 10
Terminals and Reference Value for Audio Unit ....... 19
Terminals and Reference Value for BOSE Speaker
Amp. ....................................................................... 22
Terminals and Reference Value for Rear Audio
Remote Control Unit ............................................... 24
Terminals and Reference Value for AV Switch ....... 25
AV Switch Self-Diagnosis Function ........................ 27
STARTING THE SELF-DIAGNOSIS MODE ....... 27
EXITING THE SELF-DIAGNOSIS MODE ........... 27
DIAGNOSIS FUNCTION ..................................... 27
Trouble Diagnosis .................................................. 28
MALFUNCTION WITH RADIO AND CD ............. 28
FOR RADIO ONLY .............................................. 28
FOR CD ONLY .................................................... 29
Noise Inspection ..................................................... 29
TYPE OF NOISE AND POSSIBLE CAUSE ........ 29
Power Supply Circuit Inspection ............................ 30
Steering Switch Check ........................................... 32
AV Switch Check .................................................... 33
Audio Communication Line Check ......................... 33
Sound Is Not Heard From Front Door Speaker or
Front Tweeter ......................................................... 34
Sound Is Not Heard From Rear Door Speaker or
Rear Door Tweeter ................................................. 38
Sound Is Not Heard From Center Speaker ............ 41Sound Is Not Heard From Subwoofer .................... 42
Removal and Installation for Audio Unit ................. 45
Removal and Installation for AV Switch .................. 45
Removal and Installation of Front Door Speaker .... 45
Removal and Installation of Rear Door Speaker .... 45
Removal and Installation of Front Tweeter ............. 46
Removal and Installation of Rear Door Tweeter ..... 46
Removal and Installation of Center Speaker .......... 46
Removal and Installation of Subwoofer .................. 46
Removal and Installation of BOSE Speaker Amp. ... 46
Removal and Installation of Rear Audio Remote
Control Unit ............................................................. 47
Removal and Installation of Steering Wheel Audio
Control Switches ..................................................... 47
AUDIO ANTENNA .................................................... 48
System Description ................................................. 48
Wiring Diagram — W/ANT — ................................. 49
Location of Antenna ................................................ 50
Window Antenna Repair ......................................... 50
ELEMENT CHECK .............................................. 50
ELEMENT REPAIR ............................................. 51
DVD ENTERTAINMENT SYSTEM ............................ 52
Component Parts and Harness Connector Location ... 52
System Description ................................................. 53
Schematic ............................................................... 54
Wiring Diagram — DVD — ..................................... 55
Trouble Diagnosis ................................................... 58
Power Supply Circuit Inspection ............................. 59
Removal and Installation of DVD Player ................ 60
Removal and Installation of Video Monitor ............. 60
NAVIGATION SYSTEM ............................................. 61
System Description ................................................. 61
TRAVEL DISTANCE ............................................ 61
TRAVEL DIRECTION .......................................... 61
MAP-MATCHING ................................................. 61
GPS (GLOBAL POSITIONING SYSTEM) .......... 62
COMPONENT DESCRIPTION ............................ 63
BIRDVIEW™ ....................................................... 63
MAP DISPLAY ..................................................... 64
FUNCTION OF CENTER SWITCH ..................... 65
