INFINITI QX56 2006 Factory Service Manual

AT-76
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
41
Slips/Will
Not
Engage While accelerating in
5th, engine races or
slippage occurs.
ON vehicle
1. Fluid level and state
AT- 5 1
2. Line pressure testAT- 5 2
3. Accelerator pedal position sensorAT- 1 2 4
4. CAN communication line AT- 9 6
5. ATF pressure switch 1 and front brake solenoid valveAT- 1 5 9,
AT- 1 4 3
6. Control valve with TCM AT- 2 3 0
OFF vehicle7. Torque converter
AT- 2 6 4
8. Oil pump assemblyAT- 2 8 2
9. Front brake (brake band)AT- 2 6 4
10. Input clutchAT- 2 8 6
11. Gear systemAT- 2 5 0
12. High and low reverse clutchAT- 2 9 6
42Slips at lock-up. ON vehicle1. Fluid level and state
AT- 5 1
2. Line pressure testAT- 5 2
3. Engine speed signalAT- 11 6
4. Turbine revolution sensorAT- 1 0 9
5. Torque converter clutch solenoid valve AT- 11 8
6. CAN communication line AT- 9 6
7. Control valve with TCMAT- 2 3 0
OFF vehicle8. Torque converter
AT- 2 6 49. Oil pump assemblyAT- 2 8 2
43No creep at all.
Refer to
AT-186, "
Vehi-
cle Does Not Creep
Backward In “R” Posi-
tion" , AT-189, "Ve h i-
cle Does Not Creep
Forward In “D” Posi-
tion"
ON vehicle 1. Fluid level and state
AT- 5 1
2. Line pressure testAT- 5 2
3. Accelerator pedal position sensorAT- 1 2 4
4. ATF pressure switch 5 and direct clutch solenoid valveAT- 1 6 3,
AT- 1 4 7
5. PNP switch AT- 1 0 5
6. CAN communication line AT- 9 6
7. Control cable adjustmentAT- 2 2 7
8. Control valve with TCMAT- 2 3 0
OFF vehicle9. Torque converter
AT- 2 6 4
10. Oil pump assemblyAT- 2 8 2
11. 1st one-way clutchAT- 2 9 1
12. Gear systemAT- 2 5 0
13. Reverse brakeAT- 2 6 4
14. Direct clutchAT- 2 9 8
15. Forward one- way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT- 1 7
, AT- 1 8 .) AT- 2 6 4
16. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to
AT- 1 7
, AT- 1 8
.) AT- 2 6 4
No. Items
Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSISAT-77
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX5644
Slips/Will
Not
Engage Vehicle cannot run in
all positions.
ON vehicle1. Fluid level and state
AT- 5 1
2. Line pressure testAT- 5 2
3. PNP switchAT-105
4. Control cable adjustmentAT-227
5. Control valve with TCMAT-230
OFF vehicle6. Oil pump assembly
AT-2827. Gear systemAT-250
8. Output shaftAT-264
45With selector lever in
“
D ” position, driving is
not possible. ON vehicle
1. Fluid level and state
AT- 5 1
2. Line pressure testAT- 5 2
3. PNP switchAT-105
4. Control cable adjustmentAT-227
5. Control valve with TCMAT-230
OFF vehicle6. Torque converter
AT-264
7. Oil pump assembly AT-282
8. 1st one-way clutchAT-291
9. Gear systemAT-250
10. Reverse brakeAT-264
11. Forward one- way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT- 1 7
, AT- 1 8 .) AT-264
12. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT- 1 7
, AT- 1 8
.) AT-264
46
With selector lever in
“
R ” position, driving is
not possible. ON vehicle
1. Fluid level and state
AT- 5 1
2. Line pressure testAT- 5 2
3. PNP switchAT-105
4. Control cable adjustmentAT-227
5. Control valve with TCMAT-230
OFF vehicle6. Gear system
AT-2507. Output shaftAT-264
8. Reverse brakeAT-264
47 OthersShift point is high in
“
D ” position. ON vehicle1. Vehicle speed sensor A/T and vehicle speed sensor MTR
AT- 111
,
AT-132
2. Accelerator pedal position sensor AT-124
3. CAN communication line AT- 9 6
4. ATF temperature sensorAT-127
5. Control valve with TCMAT-230
No. ItemsSymptom Condition Diagnostic ItemReference
page

AT-78
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
48
Others Shift point is low in “
D”
position. ON vehicle1. Vehicle speed sensor A/T and vehicle speed sensor MTR
AT- 111
,
AT- 1 3 2
2. Accelerator pedal position sensor AT- 1 2 4
3. CAN communication line AT- 9 6
4. Control valve with TCMAT- 2 3 0
49Judder occurs during
lock-up. ON vehicle1. Fluid level and state
AT- 5 1
2. Engine speed signalAT- 11 6
3. Turbine revolution sensorAT- 1 0 9
4. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT- 1 3 2
5. Accelerator pedal position sensor AT- 1 2 4
6. CAN communication line AT- 9 6
7. Torque converter clutch solenoid valveAT- 11 8
8. Control valve with TCMAT- 2 3 0
OFF vehicle 9. Torque converter AT- 2 6 4
50Strange noise in “
R”
position. ON vehicle
1. Fluid level and state
AT- 5 1
2. Engine speed signalAT- 11 6
3. CAN communication line AT- 9 6
4. Control valve with TCMAT- 2 3 0
OFF vehicle5. Torque converter
AT- 2 6 4
6. Oil pump assemblyAT- 2 8 2
7. Gear systemAT- 2 5 0
8. High and low reverse clutchAT- 2 9 6
9. Reverse brakeAT- 2 6 4
51Strange noise in “
N”
position. ON vehicle
1. Fluid level and state
AT- 5 1
2. Engine speed signalAT- 11 6
3. CAN communication line AT- 9 6
4. Control valve with TCMAT- 2 3 0
OFF vehicle5. Torque converter
AT- 2 6 46. Oil pump assemblyAT- 2 8 2
7. Gear systemAT- 2 5 0
52Strange noise in “
D”
position. ON vehicle
1. Fluid level and state
AT- 5 1
2. Engine speed signalAT- 11 6
3. CAN communication line AT- 9 6
4. Control valve with TCMAT- 2 3 0
OFF vehicle5. Torque converter
AT- 2 6 4
6. Oil pump assemblyAT- 2 8 2
7. Gear systemAT- 2 5 0
8. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT- 1 7
, AT- 1 8
.) AT- 2 6 4
No. Items
Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSISAT-79
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX5653
Others Vehicle dose not
decelerate by engine
brake.
Refer to
AT-218,
"Vehicle Does Not
Decelerate By Engine
Brake" . ON vehicle
1. PNP switch
AT-105
2. Fluid level and state AT- 5 1
3. Control cable adjustmentAT-227
4. 1st position switchAT-218
5. ATF pressure switch 5AT-163
6. CAN communication line AT- 9 6
7. Control valve with TCMAT-230
OFF vehicle8. Input clutch
AT-2869. High and low reverse clutchAT-296
10. Direct clutchAT-298
54Engine brake does
not operate in
“2 ”
position. ON vehicle1. PNP switch
AT-105
2. Fluid level and state AT- 5 1
3. Control cable adjustmentAT-227
5. ATF pressure switch 6AT-165
6. CAN communication line AT- 9 6
7. Control valve with TCMAT-230
OFF vehicle8. Front brake (brake band)
AT-2649. Input clutchAT-286
10. High and low reverse clutchAT-296
55Engine brake does
not operate in
“1 ”
position. ON vehicle1. PNP switch
AT-105
2. Fluid level and state AT- 5 1
3. Control cable adjustmentAT-227
4. 1st position switchAT-218
5. ATF pressure switch 5AT-163
6. CAN communication line AT- 9 6
7. Control valve with TCMAT-230
OFF vehicle8. Input clutch
AT-2869. High and low reverse clutchAT-296
10. Direct clutchAT-298
No. ItemsSymptom Condition Diagnostic ItemReference
page

AT-80
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
56
Others Maximum speed low.
ON vehicle
1. Fluid level and state
AT- 5 1
2. Line pressure testAT- 5 2
3. Accelerator pedal position sensorAT- 1 2 4
4. CAN communication line AT- 9 6
5. Direct clutch solenoid valveAT- 1 4 7
6. Control valve with TCMAT- 2 3 0
OFF vehicle7. Torque converter
AT- 2 6 4
8. Oil pump assemblyAT- 2 8 2
9. Input clutchAT- 2 8 6
10. Gear systemAT- 2 5 0
11. High and low reverse clutchAT- 2 9 6
12. Direct clutchAT- 2 9 8
13. Forward one- way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT- 1 7
, AT- 1 8 .) AT- 2 6 4
14 Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to
AT- 1 7
, AT- 1 8
.) AT- 2 6 4
57
Extremely large
creep. ON vehicle1. Engine idle speed
EC-76

2. CAN communication line AT- 9 6
3. ATF pressure switch 5AT- 1 6 3
OFF vehicle 4. Torque converter AT- 2 6 4
58With selector lever in
“
P ” position, vehicle
does not enter parking
condition or, with
selector lever in
another position, park-
ing condition is not
cancelled.
Refer to AT-180, "
In
“P” Position, Vehicle
Moves When Pushed"
. ON vehicle
1. PNP switch
AT- 1 0 5
2. Control cable adjustmentAT- 2 2 7
OFF vehicle 3. Parking pawl components AT- 2 5 0
59Vehicle runs with
transmission in
“P ”
position. ON vehicle1. PNP switch
AT- 1 0 5
2. Fluid level and state AT- 5 1
3. Control cable adjustmentAT- 2 2 7
4. Control valve with TCMAT- 2 3 0
5. Parking pawl componentsAT- 2 5 0
OFF vehicle 6. Gear system AT- 2 5 0
No. ItemsSymptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSISAT-81
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
60
Others Vehicle runs with
transmission in
“N ”
position.
Refer to AT-181, "In
“N” Position, Vehicle
Moves" . ON vehicle
1. PNP switch
AT-105
2. Fluid level and state AT- 5 1
3. Control cable adjustmentAT-227
4. Control valve with TCMAT-230
OFF vehicle5. Input clutch
AT-286
6. Gear systemAT-250
7. Direct clutchAT-298
8. Reverse brakeAT-264
9. Forward one- way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT- 1 7
, AT- 1 8 .) AT-264
10. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT- 1 7
, AT- 1 8
.) AT-264
61Engine does not start
in
“N ” or “P ” position.
Refer to AT-179, "Engine Cannot Be
Started In “P” or “N”
Position" . ON vehicle
1. Ignition switch and starter
PG-4
, SC-
10
2. Control cable adjustment
AT-227
3. PNP switchAT-105
62Engine starts in posi-
tions other than “
N” or
“ P ”. ON vehicle1. Ignition switch and starter
PG-4
, SC-
10
2. Control cable adjustment
AT-227
3. PNP switchAT-105
63Engine stall. ON vehicle1. Fluid level and state
AT- 5 1
2. Engine speed signalAT- 11 6
3. Turbine revolution sensorAT-109
4. Torque converter clutch solenoid valve AT- 11 8
5. CAN communication line AT- 9 6
6. Control valve with TCMAT-230
OFF vehicle 7. Torque converter AT-264
64Engine stalls when
select lever shifted
“N ”
→ “ D ”, “ R”. ON vehicle1. Fluid level and state
AT- 5 1
2. Engine speed signalAT- 11 6
3. Turbine revolution sensorAT-109
4. Torque converter clutch solenoid valve AT- 11 8
5. CAN communication line AT- 9 6
6. Control valve with TCMAT-230
OFF vehicle 7. Torque converter AT-264
No. ItemsSymptom Condition Diagnostic ItemReference
page

AT-82
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
65 OthersEngine speed does
not return to idle.
Refer to
AT-208,
"Engine Speed Does
Not Return to Idle" .ON vehicle 1. Fluid level and state
AT- 5 1
2. ATF pressure switch 5 and direct clutch solenoid valveAT- 1 6 3,
AT- 1 4 7
3. ATF pressure switch 1 and front brake solenoid valve AT- 1 5 9,
AT- 1 4 3
4. Accelerator pedal position sensor AT- 1 2 4
5. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 111,
AT- 1 3 2
6. CAN communication line AT- 9 6
7. Control valve with TCMAT- 2 3 0
OFF vehicle8. Front brake (brake band)
AT- 2 6 49. Direct clutchAT- 2 9 8
No. ItemsSymptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSISAT-83
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
TCM Input/Output Signal Reference ValuesECS00CEO
A/T ASSEMBLY HARNESS CONNECTOR TERMINAL LAYOUT
TCM INSPECTION TABLE
Data are reference value and are measured between each terminal and ground.
SCIA1658E
Terminal
No. Wire
color Item
Condition Data (Pyrex.)
1P Power supply
(Memory back-up) Always
Battery voltage
2P Power supply
(Memory back-up) Always
Battery voltage
3 L CAN-H – –
4V K-line (CONSULT-
II signal)
The terminal is connected to the data link connector for CONSULT-II.
–
5 B Ground Always0V
6 Y/R Power supply –
Battery voltage
– 0V
7R Back-up lamp
relay Selector lever in “
R” position. 0V
Selector lever in other positions. Battery voltage
8 P CAN-L ––
9 B/R Starter relay Selector lever in “
N”,“ P ” positions. Battery voltage
Selector lever in other positions. 0V
10 B Ground Always0V

AT-84
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
CONSULT-II Function (A/T)ECS00CEP
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
CONSULT-II REFERENCE VALUE
NOTICE:
1. The CONSULT-II electrically displays shift timing and lock-up timing (that is, operation timing of each sole-
noid).
Check for time difference between actual shift timing and the CONSULT-II display. If the difference is
noticeable, mechanical parts (except solenoids, sensors, etc.) may be malfunctioning. Check mechanical
parts using applicable diagnostic procedures.
2. Shift schedule (which implies gear position) displayed on CONSULT-II and that indicated in Service Man- ual may differ slightly. This occurs because of the following reasons:
–Actual shift schedule has more or less tolerance or allowance,
–Shift schedule indicated in Service Manual refers to the point where shifts start, and
–Gear position displayed on CONSULT-II indicates the point where shifts are completed.
3. Display of solenoid valves on CONSULT-II changes at the start of shifting, while gear position is displayed upon completion of shifting (which is computed by TCM).
TCM diagnostic mode Description
WORK SUPPORT Supports inspections and adjustments. Commands are transmitted to the TCM for setting the status
suitable for required operation, input/output signals are received from the TCM and received data is
displayed.
SELF-DIAG RESULTS Displays TCM self-diagnosis results.
DATA MONITOR Displays TCM input/output data in real time.
CAN DIAG SUPPORT MNTR The result of transmit/receive diagnosis of CAN communication can be read.
ACTIVE TEST Operation of electrical loads can be checked by sending drive signal to them.
FUNCTION TEST Conducted by CONSULT-II instead of a technician to determine whether each system is
“OK ” or
“ NG ”.
ECU PART NUMBER TCM part number can be read.
Item name Condition Display value (Approx.)
ATF TEMP SE 1 0°C (32 ° F) - 20 °C (68 °F) - 80 °C (176 °F) 3.3 - 2.7 - 0.9 V
ATF TEMP SE 2 3.3 - 2.5 - 0.7 V
TCC SOLENOID When perform slip lock-up
0.2 - 0.4 A
When perform lock-up 0.4 - 0.6 A
SLCT LVR POSI Selector lever in
“N ”,“ P ” position. N/P
Selector lever in “R ” position. R
Selector lever in “D ” position. D
Selector lever in “4 ” position. 4
Selector lever in “3 ” position. 3
Selector lever in “2 ” position. 2
Selector lever in “1 ” position. 1
VHCL/S SE ·A/T During driving Approximately matches the
speedometer reading.
ENGINE SPEED Engine running Closely matches the tachometer
reading.
LINE PRES SOL During driving 0.2 - 0.6 A
TURBINE REV During driving (lock-up ON) Approximately matches the
engine speed.
VHCL/S SE ·MTR During driving Approximately matches the
speedometer reading.

TROUBLE DIAGNOSISAT-85
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
ATF PRES SW 1Front brake engaged. Refer to
AT- 2 0ON
Front brake disengaged. Refer to AT- 2 0
OFF
ATF PRES SW 2 Low coast brake engaged. Refer to
AT- 2 0
ON
Low coast brake disengaged. Refer to AT- 2 0
OFF
ATF PRES SW 3 Input clutch engaged. Refer to
AT- 2 0
ON
Input clutch disengaged. Refer to AT- 2 0
OFF
ATF PRES SW 5 Direct clutch engaged. Refer to
AT- 2 0
ON
Direct clutch disengaged. Refer to AT- 2 0
OFF
ATF PRES SW 6 High and low reverse clutch engaged. Refer to
AT- 2 0
ON
High and low reverse clutch disengaged. Refer to AT- 2 0
OFF
I/C SOLENOID Input clutch disengaged. Refer to
AT- 2 0
0.6 - 0.8 A
Input clutch engaged. Refer to AT- 2 0
0 - 0.05 A
FR/B SOLENOID Front brake engaged. Refer to
AT- 2 0
0.6 - 0.8 A
Front brake disengaged. Refer to AT- 2 0
0 - 0.05 A
D/C SOLENOID Direct clutch disengaged. Refer to
AT- 2 0
0.6 - 0.8 A
Direct clutch engaged. Refer to AT- 2 0
0 - 0.05 A
HLR/C SOL High and low reverse clutch disengaged. Refer to
AT- 2 0
0.6 - 0.8 A
High and low reverse clutch engaged. Refer to AT- 2 0
0 - 0.05 A
ON OFF SOL Low coast brake engaged. Refer to
AT- 2 0
ON
Low coast brake disengaged. Refer to AT- 2 0
OFF
STARTER RELAY Selector lever in
“N ”,“ P ” position. ON
Selector lever in other position. OFF
ACCELE POSI Released accelerator pedal.
0.0/8
Fully depressed accelerator pedal. 8/8
CLSD THL POS Released accelerator pedal.
ON
Fully depressed accelerator pedal. OFF
W/O THL POS Fully depressed accelerator pedal.
ON
Released accelerator pedal. OFF
BRAKE SW Depressed brake pedal.
ON
Released brake pedal. OFF
Item name
Condition Display value (Approx.)
