INFINITI QX56 2006 Factory Service Manual

AT-186
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: November 20092006 QX56
Vehicle Does Not Creep Backward In “R” PositionECS00CK8
SYMPTOM:
The vehicle does not creep in the “R” position. Or an extreme lack of acceleration is observed.
DIAGNOSTIC PROCEDURE
1. CHECK SELF-DIAGNOSTIC RESULTS
Perform self-diagnosis. Refer to AT- 8 6 , "
SELF-DIAGNOSTIC RESULT MODE" .
Do the self-diagnostic results indicate accelerator pedal position sensor, ATF pressure switch 6, high and low
reverse clutch solenoid valve, CAN communication line, PNP switch?
YES >> Check the malfunctioning system. Refer to AT- 1 2 4 , "DTC P1705 THROTTLE POSITION SEN-
SOR" , AT- 1 6 5 , "DTC P1846 ATF PRESSURE SWITCH 6" , AT- 1 5 1 , "DTC P1767 HIGH AND
LOW REVERSE CLUTCH SOLENOID VALVE" , AT- 9 6 , "DTC U1000 CAN COMMUNICATION
LINE" , AT- 1 0 5 , "DTC P0705 PARK/NEUTRAL POSITION SWITCH" .
NO >> GO TO 2.
2. CHECK CONTROL CABLE
Check the control cable.

Refer to AT- 2 2 7 , "Checking of A/T Position" .
OK or NG
OK >> GO TO 3.
NG >> Adjust control cable. Refer to AT- 2 2 7 , "
Adjustment of A/
T Position" .
3. CHECK A/T FLUID LEVEL
Check A/T fluid level. Refer to AT- 1 2 , "
Checking Automatic Trans-
mission Fluid (ATF)" .
OK or NG
OK >> GO TO 4.
NG >> Refill ATF.
4. CHECK STALL TEST
Check stall revolution with selector lever in “1” and “R” positions.
Refer to AT- 5 1 , "
STALL TEST" .
OK or NG
OK >> GO TO 6.
OK in “1 ” position, NG in “R ” position>>GO TO 5.
NG in both “1 ” and “R” positions>>GO TO 8.
LCIA0345E
SAT638A
SAT493G

TROUBLE DIAGNOSIS FOR SYMPTOMSAT-187
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
5. DETECT MALFUNCTIONING ITEM
1. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
2. Check the following items:
–Reverse brake. Refer to AT- 2 6 4 , "Disassembly" .
OK or NG
OK >> GO TO 9.
NG >> Repair or replace damaged parts.
6. CHECK LINE PRESSURE
Check the line pressure with the engine idling. Refer to AT- 5 2 , "
LINE
PRESSURE TEST" .
OK or NG
OK >> GO TO 9.
NG - 1 >> Line pressure high. GO TO 7.
NG - 2 >> Line pressure low. GO TO 8.
7. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
OK or NG
OK >> GO TO 9.
NG >> Repair or replace damaged parts.
8. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
–Power train system. Refer to AT- 2 6 4 , "Disassembly" .
–Transmission case. Refer to AT- 2 6 4 , "Disassembly" .
OK or NG
OK >> GO TO 9.
NG >> Repair or replace damaged parts.
SAT494G

AT-188
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: November 20092006 QX56
9. CHECK A/T FLUID CONDITION
1. Remove oil pan. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sensor 2" .
2. Check A/T fluid condition. Refer to AT- 5 1 , "
Fluid Condition
Check" .
OK or NG
OK >> GO TO 10.
NG >> GO TO 13.
10. DETECT MALFUNCTIONING ITEM

Check the malfunction items. If any items are damaged, repair or replace damaged parts. Refer to AT- 6 1 ,
"Symptom Chart" (Symptom No.43).
OK or NG
OK >> GO TO 11.
NG >> Repair or replace damaged parts.
11 . CHECK SYMPTOM
Check again. Refer to AT- 5 5 , "
Check at Idle" .
OK or NG
OK >> INSPECTION END
NG >> GO TO 12.
12. PERFORM TCM INSPECTION
1. Perform TCM input/output signals inspection. Refer to AT- 8 3 , "
TCM Input/Output Signal Reference Val-
ues" .
2. If NG, recheck A/T assembly harness connector terminals for damage or loose connection with harness connector.
OK or NG
OK >> INSPECTION END
NG >> Repair or replace damaged parts.
13. DETECT MALFUNCTIONING ITEM

Check the malfunction items. If any items are damaged, repair or replace damaged parts. Refer to AT- 6 1 ,
"Symptom Chart" (Symptom No.43).
OK or NG
OK >> GO TO 11.
NG >> Repair or replace damaged parts.
SCIA5199E

TROUBLE DIAGNOSIS FOR SYMPTOMSAT-189
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
Vehicle Does Not Creep Forward In “D” PositionECS00CK9
SYMPTOM:
Vehicle does not creep forward when selecting “D” position.
DIAGNOSTIC PROCEDURE
1. CHECK SELF-DIAGNOSTIC RESULTS
Perform self-diagnosis. Refer to AT- 8 6 , "
SELF-DIAGNOSTIC RESULT MODE" .
Do the self-diagnostic results indicate accelerator pedal position sensor, CAN communication line, PNP
switch?
YES >> Check the malfunctioning system. Refer to AT- 1 2 4 , "DTC P1705 THROTTLE POSITION SEN-
SOR" , AT- 9 6 , "DTC U1000 CAN COMMUNICATION LINE" , AT- 1 0 5 , "DTC P0705 PARK/NEU-
TRAL POSITION SWITCH" .
NO >> GO TO 2.
2. CHECK CONTROL CABLE
Check the control cable.

Refer to AT- 2 2 7 , "Checking of A/T Position" .
OK or NG
OK >> GO TO 3.
NG >> Adjust control cable. Refer to AT- 2 2 7 , "
Adjustment of A/
T Position" .
3. CHECK A/T FLUID LEVEL
Check A/T fluid level. Refer to AT- 1 2 , "
Checking Automatic Trans-
mission Fluid (ATF)" .
OK or NG
OK >> GO TO 4.
NG >> Refill ATF.
4. CHECK STALL TEST
Check stall revolution with selector lever in “D” position. Refer to AT-
51, "STALL TEST" .
OK or NG
OK >> GO TO 5.
NG >> GO TO 7.
LCIA0345E
SAT638A
SAT493G

AT-190
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: November 20092006 QX56
5. CHECK LINE PRESSURE
Check line pressure at idle with selector lever in “D” position. Refer
to AT- 5 2 , "
LINE PRESSURE TEST" .
OK or NG
OK >> GO TO 8.
NG - 1 >> Line pressure high. GO TO 6.
NG - 2 >> Line pressure low. GO TO 7.
6. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
OK or NG
OK >> GO TO 8.
NG >> Repair or replace damaged parts.
7. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
–Power train system. Refer to AT- 2 6 4 , "Disassembly" .
–Transmission case. Refer to AT- 2 6 4 , "Disassembly" .
OK or NG
OK >> GO TO 8.
NG >> Repair or replace damaged parts.
8. CHECK A/T FLUID CONDITION
1. Remove oil pan. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sensor 2" .
2. Check A/T fluid condition. Refer to AT- 5 1 , "
Fluid Condition
Check" .
OK or NG
OK >> GO TO 9.
NG >> GO TO 12.
SAT494G
SCIA5199E

TROUBLE DIAGNOSIS FOR SYMPTOMSAT-191
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
9. DETECT MALFUNCTIONING ITEM

Check the malfunction items. If any items are damaged, repair or replace damaged parts. Refer to AT- 6 1 ,
"Symptom Chart" (Symptom No.43).
OK or NG
OK >> GO TO 10.
NG >> Repair or replace damaged parts.
10. CHECK SYMPTOM
Check again. Refer to AT- 5 5 , "
Check at Idle" .
OK or NG
OK >> INSPECTION END
NG >> GO TO 11.
11 . PERFORM TCM INSPECTION
1. Perform TCM input/output signals inspection. Refer to AT- 8 3 , "
TCM Input/Output Signal Reference Val-
ues" .
2. If NG, recheck A/T assembly harness connector terminals for damage or loose connection with harness connector.
OK or NG
OK >> INSPECTION END
NG >> Repair or replace damaged parts.
12. DETECT MALFUNCTIONING ITEM

Check the malfunction items. If any items are damaged, repair or replace damaged parts. Refer to AT- 6 1 ,
"Symptom Chart" (Symptom No.43).
OK or NG
OK >> GO TO 10.
NG >> Repair or replace damaged parts.
Vehicle Cannot Be Started From D1ECS00CKA
SYMPTOM:
Vehicle cannot be started from D1 on cruise test - Part 1.
DIAGNOSTIC PROCEDURE
1. CONFIRM THE SYMPTOM
Check if vehicle creeps in “R” position.
OK or NG
OK >> GO TO 2.
NG >> Refer to AT- 1 8 6 , "
Vehicle Does Not Creep Backward In “R” Position" .
2. CHECK SELF-DIAGNOSTIC RESULTS
Perform self-diagnosis. Refer to AT- 8 6 , "
SELF-DIAGNOSTIC RESULT MODE" .
Is any malfunction detected by self-diagnostic results?
YES >> Check the malfunctioning system.
NO >> GO TO 3.

AT-192
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: November 20092006 QX56
3. CHECK ACCELERATOR PEDAL POSITION (APP) SENSOR
Check accelerator pedal position (APP) sensor. Refer to AT- 1 2 4 , "
DTC P1705 THROTTLE POSITION SEN-
SOR"
OK or NG
OK >> GO TO 4.
NG >> Repair or replace accelerator pedal position (APP) sensor.
4. CHECK A/T FLUID LEVEL
Check A/T fluid level. Refer to AT- 1 2 , "
Checking Automatic Trans-
mission Fluid (ATF)" .
OK or NG
OK >> GO TO 5.
NG >> Refill ATF.
5. CHECK LINE PRESSURE
Check line pressure at the engine stall point. Refer to AT- 5 2 , "
LINE
PRESSURE TEST" .
OK or NG
OK >> GO TO 8.
NG - 1 >> Line pressure high. GO TO 6.
NG - 2 >> Line pressure low. GO TO 7.
6. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
OK or NG
OK >> GO TO 8.
NG >> Repair or replace damaged parts.
SAT638A
SAT494G

TROUBLE DIAGNOSIS FOR SYMPTOMSAT-193
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
7. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
–Power train system. Refer to AT- 2 6 4 , "Disassembly" .
–Transmission case. Refer to AT- 2 6 4 , "Disassembly" .
OK or NG
OK >> GO TO 8.
NG >> Repair or replace damaged parts.
8. CHECK A/T FLUID CONDITION
1. Remove oil pan. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sensor 2" .
2. Check A/T fluid condition. Refer to AT- 5 1 , "
Fluid Condition
Check" .
OK or NG
OK >> GO TO 9.
NG >> GO TO 12.
9. DETECT MALFUNCTIONING ITEM

Check the malfunction items. If any items are damaged, repair or replace damaged parts. Refer to AT- 6 1 ,
"Symptom Chart" (Symptom No.23).
OK or NG
OK >> GO TO 10.
NG >> Repair or replace damaged parts.
10. CHECK SYMPTOM
Check again. Refer to AT- 5 6 , "
Cruise Test - Part 1" , AT- 5 8 , "Cruise Test - Part 2" .
OK or NG
OK >> INSPECTION END
NG >> GO TO 11.
11 . PERFORM TCM INSPECTION
1. Perform TCM input/output signals inspection. Refer to AT- 8 3 , "
TCM Input/Output Signal Reference Val-
ues" .
2. If NG, recheck A/T assembly harness connector terminals for damage or loose connection with harness connector.
OK or NG
OK >> INSPECTION END
NG >> Repair or replace damaged parts.
SCIA5199E

AT-194
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: November 20092006 QX56
12. DETECT MALFUNCTIONING ITEM

Check the malfunction items. If any items are damaged, repair or replace damaged parts. Refer to AT- 6 1 ,
"Symptom Chart" (Symptom No.23).
OK or NG
OK >> GO TO 10.
NG >> Repair or replace damaged parts.
A/T Does Not Shift: D1 → D2ECS00CKB
SYMPTOM:
The vehicle does not shift-up from the D1 to D2 gear at the specified speed.
DIAGNOSTIC PROCEDURE
1. CONFIRM THE SYMPTOM
Check if vehicle creeps forward in “D ” position and vehicle can be started from D
1.
OK or NG
OK >> GO TO 2.
NG >> Refer to AT- 1 8 9 , "
Vehicle Does Not Creep Forward In “D” Position" , AT- 1 9 1 , "Vehicle Cannot Be
Started From D1" .
2. CHECK SELF-DIAGNOSTIC RESULTS
Perform self-diagnosis. Refer to AT- 8 6 , "
SELF-DIAGNOSTIC RESULT MODE" .
Do the self-diagnostic results indicate ATF pressure switch 5, direct clutch solenoid valve, accelerator pedal
position sensor, vehicle speed sensor A/T (revolution sensor) and vehicle speed sensor MTR?
YES >> Check the malfunctioning system. Refer to AT- 1 6 3 , "DTC P1845 ATF PRESSURE SWITCH 5" ,
AT- 1 4 7 , "
DTC P1762 DIRECT CLUTCH SOLENOID VALVE" , AT- 1 2 4 , "DTC P1705 THROTTLE
POSITION SENSOR" , AT- 111 , "DTC P0720 VEHICLE SPEED SENSOR A/T (REVOLUTION
SENSOR)" , AT- 1 3 2 , "DTC P1721 VEHICLE SPEED SENSOR MTR" .
NO >> GO TO 3.
3. CHECK A/T FLUID LEVEL
Check A/T fluid level. Refer to AT- 1 2 , "
Checking Automatic Trans-
mission Fluid (ATF)" .
OK or NG
OK >> GO TO 4.
NG >> Refill ATF.
4. CHECK LINE PRESSURE
Check line pressure at the engine stall point. Refer to AT- 5 2 , "
LINE
PRESSURE TEST" .
OK or NG
OK >> GO TO 7.
NG - 1 >> Line pressure high. GO TO 5.
NG - 2 >> Line pressure low. GO TO 6.
SAT638A
SAT494G

TROUBLE DIAGNOSIS FOR SYMPTOMSAT-195
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
5. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
OK or NG
OK >> GO TO 7.
NG >> Repair or replace damaged parts.
6. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
–Power train system. Refer to AT- 2 6 4 , "Disassembly" .
–Transmission case. Refer to AT- 2 6 4 , "Disassembly" .
OK or NG
OK >> GO TO 7.
NG >> Repair or replace damaged parts.
7. CHECK A/T FLUID CONDITION
1. Remove oil pan. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sensor 2" .
2. Check A/T fluid condition. Refer to AT- 5 1 , "
Fluid Condition
Check" .
OK or NG
OK >> GO TO 8.
NG >> GO TO 11.
8. DETECT MALFUNCTIONING ITEM

Check the malfunction items. If any items are damaged, repair or replace damaged parts. Refer to AT- 6 1 ,
"Symptom Chart" (Symptom No.10).
OK or NG
OK >> GO TO 9.
NG >> Repair or replace damaged parts.
9. CHECK SYMPTOM
Check again. Refer to AT- 5 6 , "
Cruise Test - Part 1" , AT- 5 8 , "Cruise Test - Part 2" .
OK or NG
OK >> INSPECTION END
NG >> GO TO 10.
SCIA5199E
