QUICK REFERENCE CHART: QX56

Drive Belt Deflection and Tension
Spark Plugs (Double Platinum Tipped)
Front Wheel Alignment (Unladen*1 )ELS001QR
*1: Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.
*2: Target value 37° 31′ (37.52° )
*3: Target value 33 ° 59′ (33.98° )
*4: Target value 37 ° 44′ (37.73° )
*5: Target value 33 ° 29′ (33.48° )
Tension of drive belts Auto adjustment by auto tensioner
Make NGK
Standard type PLFR5A-11
Hot type PLFR4A-11
Cold type PLFR6A-11
Gap (nominal) 1.1 mm (0.043 in)
Drive type2WD 4WD
Camber
Degree minute (decimal degree) Minimum -0
° 51′ (-0.85 °)- 0° 33 ′ (-0.55 °)
Nominal -0° 6 ′ (-0.10 °)0 ° 12′ (0.20 °)
Maximum 0° 39′ (0.65 °)0 ° 57′ (0.95 °)
Cross camber 0° 45 ′ (0.75 °) or less 0 ° 45′ (0.75 °) or less
Caster
Degree minute (decimal degree) Minimum
3° 15′ (3.25 °)2 °45′ (2.75 °)
Nominal 4° 0 ′ (4.00 °)3 ° 30′ (3.50 °)
Maximum 4° 45′ (4.75 °)4 ° 15′ (4.25 °)
Cross caster 0° 45′ (0.75 °) or less 0 ° 45′ (0.75 °) or less
Kingpin inclination
Degree minute (decimal degree) 13
° 32′ (13.53° )1 3°13 ′ (13.22 °)
Total toe-in Distance (A
− B) Minimum
1.8 mm (0.07 in) 1.8 mm (0.07 in)
Nominal 2.8 mm (0.11 in) 2.8 mm (0.11 in)
Maximum 3.8 mm (0.15 in) 3.8 mm (0.15 in)
Angle (left side and right side)
Degree minute (decimal degree) Minimum
0° 3 ′ (0.05 °)0 ° 3′ (0.05 °)
Nominal 0° 5 ′ (0.08 °)0 ° 5′ (0.08 °)
Maximum 0° 7 ′ (0.12 °)0 ° 7′ (0.12 °)
Wheel turning angle
(full turn) Inside
Degree minute (decimal degree)
34° 31′
– 38° 31′ *2
(34.52 ° – 38.52 °) 34°
44′ – 38° 44 ′ *4
(34.73° – 38.73° )
Outside
Degree minute (decimal degree) 30° 59′
– 34° 59′ *3
(30.98 ° – 34.98 °) 30°
29′ – 34° 29 ′ *5
(30.48° – 34.48° )
SFA234AC

ACS-12
[ICC]
LASER BEAM AIMING ADJUSTMENT
Revision: November 20092006 QX56
LASER BEAM AIMING ADJUSTMENTPFP:00026
Outline of Laser Beam Aiming Adjustment ProcedureEKS00BLN
CAUTION:

The laser beam aiming adjustment cannot be performed without CONSULT-II.

The laser beam aiming adjustment must be performed every time the ICC sensor is removed,
installed or has been moved as a result of a collision.
1. Prepare the vehicle and the work area.
2. Set up the ICC target board. For details, refer to Technical Service Bulletin.
3. Adjust the sensor following the procedure on CONSULT-II.
4. Check system operation after the adjustment.
PreparationEKS00BLO

Place the vehicle on level ground. Shift the transmission into "P" position and release the parking brake.

Adjust the tire pressure to the specified value.

See that there is no load in the vehicle. Coolant, engine oil and fuel should be filled to correct level.

Check that the vehicle suspension has been adjusted to the standard height by the load leveling rear air
suspension system. Refer to RSU-12, "
Basic Inspection" .

Clean the sensor with a soft cloth.
Setting up the ICC Target BoardEKS00BLP
CAUTION:
Accuracy in setting up the ICC target board is essential for the laser beam aiming adjustment.
For details, refer to Technical Service Bulletin.
ADJUSTING HEIGHT OF THE TARGET
1. Attach a triangle scale as shown.Tool number : KV99110100 (J-45718)
LKIA0632E
WKIA1849E

ON BOARD DIAGNOSTIC (OBD) SYSTEMAT-39
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
If the DTC is being detected currently, the time data will be “0”.
If a 1st trip DTC is stored in the ECM, the time data will be “1t ”.
Freeze Frame Data and 1st Trip Freeze Frame Data
The ECM has a memory function, which stores the driving condition such as fuel system status, calculated
load value, engine coolant temperature, short term fuel trim, long term fuel trim, engine speed and vehicle
speed at the moment the ECM detects a malfunction.
Data which are stored in the ECM memory, along with the 1st trip DTC, are called 1st trip freeze frame data,
and the data, stored together with the DTC data, are called freeze frame data and displayed on CONSULT-II
or GST. The 1st trip freeze frame data can only be displayed on the CONSULT-II screen, not on the GST. For
detail, refer to AT- 3 8 , "
ON BOARD DIAGNOSTIC (OBD) SYSTEM" .
Only one set of freeze frame data (either 1st trip freeze frame data of freeze frame data) can be stored in the
ECM. 1st trip freeze frame data is stored in the ECM memory along with the 1st trip DTC. There is no priority
for 1st trip freeze frame data and it is updated each time a different 1st trip DTC is detected. However, once
freeze frame data (2nd trip detection/MIL on) is stored in the ECM memory, 1st trip freeze frame data is no
longer stored. Remember, only one set of freeze frame data can be stored in the ECM. The ECM has the fol-
lowing priorities to update the data.
Both 1st trip freeze frame data and freeze frame data (along with the DTC) are cleared when the ECM mem-
ory is erased.
HOW TO ERASE DTC
The diagnostic trouble code can be erased by CONSULT-II, GST or ECM DIAGNOSTIC TEST MODE as
described following.

If the battery cable is disconnected, the diagnostic trouble code will be lost within 24 hours.

When you erase the DTC, using CONSULT-II or GST is easier and quicker than switching the mode
selector on the ECM.
The following emission-related diagnostic information is cleared from the ECM memory when erasing DTC
related to OBD-II. For details, refer to EC-49, "
EMISSION-RELATED DIAGNOSTIC INFORMATION ITEMS" .

Diagnostic trouble codes (DTC)

1st trip diagnostic trouble codes (1st trip DTC)

Freeze frame data
SAT015K
SAT016K
Priority Items
1 Freeze frame data Misfire — DTC: P0300 - P0306
Fuel Injection System Function — DTC: P0171, P0172, P0174, P0175
2 Except the above items (Includes A/T related items)
3 1st trip freeze frame data

AIR CONDITIONER CONTROLATC-25
C
DE
F
G H
I
K L
M A
B
AT C
Revision: November 2009 2006 QX56
AIR CONDITIONER CONTROLPFP:27500
DescriptionEJS003X5
The front air control provides automatic regulation of the vehicle's interior temperature. The system is based
on the driver's and passenger's selected "set temperature", regardless of the outside temperature changes.
This is done by utilizing a microcomputer, also referred to as the front air control, which receives input signals
from the following seven sensors:

Ambient sensor

In-vehicle sensor

Intake sensor

Optical sensor (providing one input for driver and one input for passenger side)

PBR (Position Balanced Resistor)

Vehicle speed sensor (via CAN communication)

Engine coolant temperature (via CAN communication)
The front air control uses these signals (including the set temperature) to automatically control:

Outlet air volume

Air temperature

Air distribution
The front air control also provides separate regulation of the vehicle's interior temperature for the rear passen-
ger area. The system is based on the temperature and rear blower settings selected from rear control
switches located on the front air control, or from the temperature and rear blower settings selected from rear
control switches on the rear air control, when the front air control switches are set to the rear position.
The front air control is used to select:

Outlet air volume

Air temperature/distribution
OperationEJS003X6
AIR MIX DOORS CONTROL
The air mix doors are automatically controlled so that in-vehicle temperature is maintained at a predetermined
value by the temperature setting, ambient temperature, in-vehicle temperature and amount of sunload.
BLOWER SPEED CONTROL
Blower speed is automatically controlled by the temperature setting, ambient temperature, in-vehicle tempera-
ture, intake temperature, amount of sunload and air mix door position.
When AUTO switch is pressed, the blower motor starts to gradually increase air flow volume (if required).
When engine coolant temperature is low, the blower motor operation is delayed to prevent cool air from flow-
ing.
INTAKE DOOR CONTROL
The intake door is automatically controlled by the temperature setting, ambient temperature, in-vehicle tem-
perature, intake temperature, amount of sunload and by the ON-OFF operation of the compressor.
MODE DOOR CONTROL
The mode door is automatically controlled by the temperature setting, ambient temperature, in-vehicle temper-
ature, intake temperature and amount of sunload.
DEFROSTER DOOR CONTROL
The defroster door is controlled by: Turning the defroster dial to front defroster.

ATC-94
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
SYSTEM DESCRIPTION
Component Parts
Blower speed control system components are:

Front air control

Variable blower control

Front blower motor relay

Front blower motor

In-vehicle sensor

Ambient sensor

Optical sensor

Intake sensor
System Operation
Automatic Mode
In the automatic mode, the blower motor speed is calculated by the front air control and variable blower control
based on input from the in-vehicle sensor, optical sensor, intake sensor and ambient sensor, and potentio tem-
perature control (PTC).
When the air flow is increased, the blower motor speed is adjusted gradually to prevent a sudden increase in
air flow.
In addition to manual air flow control and the usual automatic air flow control, starting air flow control, low
water temperature starting control and high passenger compartment temperature starting control are avail-
able.
Starting Blower Speed Control
Start up from cold soak condition (Automatic mode).
In a cold start up condition where the engine coolant temperature is below 50°C (122 °F), the blower will not
operate at blower speed 1 for a short period of time (up to 210 seconds). The exact start delay time varies
depending on the ambient and engine coolant temperatures.
In the most extreme case (very low ambient temperature) the blower starting delay will be 210 seconds as
described above. After the coolant temperature reaches 50 °C (122 °F), or the 210 seconds has elapsed, the
blower speed will increase to the objective blower speed.
Start up from usual operating or hot soak condition (Automatic mode).
The blower will begin operation momentarily after the AUTO switch is pushed. The blower speed will gradually
rise to the objective speed over a time period of 3 seconds or less (actual time depends on the objective
blower speed).
WJIA1357E

ATC-132
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
Water Valve CircuitEJS003Y1
COMPONENT DESCRIPTION
Water Valve
The water valve (1) cuts the flow of engine coolant to the front and
rear heater cores to allow for maximum cooling during A/C opera-
tion. It is controlled by the front air control.
DIAGNOSTIC PROCEDURE FOR WATER VALVE
1. CHECK WATER VALVE POWER AND GROUND CIRCUITS
1. Disconnect water valve connector F68.
2. Turn ignition switch ON.
3. Rotate temperature control dial (driver) to 32 °C (90 °F).
4. Check voltage between water valve harness connector F68 ter- minal 1 and terminal 2 while rotating temperature control dial
(driver) to 16 °C (60 °F).
OK or NG
OK >> GO TO 3.
NG >> GO TO 2.
2. CHECK WATER VALVE CONTROL OUTPUT CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect front air control connector M50.
3. Check continuity between water valve harness connector F68 (A) terminal 1 and front air control harness connector M50 (B)
terminal 29.
4. Check continuity between water valve harness connector F68 (A) terminal 1 and ground.
OK or NG
OK >> Replace front air control. Refer to ATC-144, "FRONT AIR CONTROL" .
NG >> Repair harness or connector.
WJIA1791E
Connector Te r m i n a l s
Condition Voltage
(Approx.)
(+) (-)
Water valve: F68 1 2Rotate temperature
control dial Battery
voltage
WJIA1792E
1 - 29 : Continuity should exist.
1 - Ground : Continuity should not exist.
WJIA1793E

HEATER & COOLING UNIT ASSEMBLYATC-155
C
DE
F
G H
I
K L
M A
B
AT C
Revision: November 2009 2006 QX56
4. Drain the coolant from the engine cooling system. Refer to MA-13, "DRAINING ENGINE COOLANT" .
5. Disconnect the front heater hoses from the front heater core.
6. Disconnect the high/low pressure pipes from the front expansion valve.
7. Remove the instrument panel and console panel. Refer to IP-10, "
INSTRUMENT PANEL ASSEMBLY" .
8. Remove the steering column. Refer to PS-10, "
STEERING COLUMN" .
9. Disconnect the instrument panel wire harness at the RH and LH in-line connector brackets, and the fuse block (J/B) electrical connectors. Refer to PG-4, "
POWER SUPPLY ROUTING CIRCUIT" .
10. Disconnect the steering member from each side of the vehicle body.
11. Remove the front heater and cooling unit assembly with it attached to the steering member, from the vehi- cle.
CAUTION:
Use care not to damage the seats and interior trim panels when removing the front heater and
cooling unit assembly with it attached to the steering member.
12. Remove the front heater and cooling unit assembly from the steering member.
Installation
Installation is in the reverse order of removal.
CAUTION:

Replace the O-ring of the low-pressure pipe and high-pressure pipe with a new one, and apply
compressor oil to it when installing it.

After charging the refrigerant, check for leaks.
NOTE:

Fill the engine cooling system with the specified coolant mixture. Refer to MA-14, "REFILLING ENGINE
COOLANT" .

Recharge the A/C system. Refer to ATC-171, "Evacuating System and Charging Refrigerant" .
REAR HEATER AND COOLING UNIT ASSEMBLY
Removal
1. Discharge the refrigerant from the A/C system. Refer to ATC-171, "Discharging Refrigerant" .
2. Drain the coolant from the engine cooling system. Refer to MA-13, "
DRAINING ENGINE COOLANT" .
3. Disconnect the rear heater core hoses from the rear heater core.
4. Disconnect the rear A/C pipes from the rear expansion valve.
5. Remove the luggage side finisher lower RH. Refer to EI-35,
"BODY SIDE TRIM" .
6. Disconnect the following electrical connectors:

Rear blower motor

Rear blower motor resistor

Rear air mix door motor
7. Disconnect the ducts from the rear heater and cooling unit assembly.
8. Remove the rear heater and cooling unit assembly.
Installation
Installation is in the reverse order of removal.
CAUTION:

Replace the O-ring of the low-pressure pipe and high-pressure pipe with a new one, and apply
compressor oil to it when installing it.

After charging the refrigerant, check for leaks.
NOTE:

Fill the engine cooling system with the specified coolant mixture. Refer to MA-14, "REFILLING ENGINE
COOLANT" .

Recharge the A/C system. Refer to ATC-171, "Evacuating System and Charging Refrigerant" .
LJIA0021E

ATC-158
HEATER CORE
Revision: November 20092006 QX56
5. Remove the heater core.
NOTE:
If the in-cabin microfilters are contaminated from coolant leaking
from the heater core, replace the in-cabin microfilters with new
ones before installing the new heater core.
Installation
Installation is in the reverse order of removal.
REAR HEATER CORE
Removal
1. Partially drain the engine cooling system. Refer to MA-13, "DRAINING ENGINE COOLANT" .
2. Remove the luggage side finisher lower RH. Refer to EI-40, "
LUGGAGE FLOOR TRIM" .
3. Disconnect the rear heater hoses from the heater core.
4. Remove the rear heater core bracket.
5. Remove the heater core.
Installation
Installation is in the reverse order of removal.
LJIA0134E
LJIA0069E
LJIA0071E

ATC-180
REFRIGERANT LINES
Revision: November 20092006 QX56
CAUTION:

Replace the O-ring of the high-pressure pipe with a new one, then apply compressor oil to it when
installing it.

After charging refrigerant, check for leaks.
Removal and Installation for Low-pressure PipeEJS003YY
REMOVAL
1. Discharge the refrigerant. Refer to ATC-171, "HFC-134a (R-134a) Service Procedure" .
2. Remove the cowl top and the cowl top extension. Refer to EI-18, "
COWL TOP" .
3. Remove the low-pressure pipe. CAUTION:
Cap or wrap the joint of the pipes with suitable material such as vinyl tape to avoid the entry of air.
INSTALLATION
Installation is in the reverse order of removal.
Refer to ATC-173, "
Components" .
CAUTION:

Replace the O-ring of the high/low-pressure pipe with a new one, then apply compressor oil to it
when installing it.

After charging refrigerant, check for leaks.
Removal and Installation for Rear High- and Low-pressure A/C and Heater Core
Pipes
EJS005Y8
REMOVAL
1. Discharge the refrigerant. Refer to ATC-171, "HFC-134a (R-134a) Service Procedure" .
2. Drain the coolant from the engine cooling system. Refer to CO-10, "
Changing Engine Coolant" .
3. Disconnect the underfloor rear heater hoses (1 and 2) from the rear heater pipes underneath the vehicle.

⇐: Front
4. Remove the rear high- and low-pressure pipes bolt (A) to dis- connect the rear high- and low-pressure pipes from the under-
floor rear high- and low-pressure pipes underneath the vehicle.
CAUTION:
Cap or wrap the joint of the pipes with suitable material
such as vinyl tape to avoid the entry of air.
5. Remove the rear high- and low-pressure pipes nuts (B) under- neath the vehicle.
NOTE:
The remaining steps are performed inside the rear luggage area of the vehicle.
6. Remove the luggage side finisher lower RH. Refer to EI-40, "
LUGGAGE FLOOR TRIM" .
7. Disconnect the rear heater core hoses (1 and 2) from the rear heater core (3).

⇐: Front
WJIA2310E
WJIA2311E

REFRIGERANT LINESATC-181
C
DE
F
G H
I
K L
M A
B
AT C
Revision: November 2009 2006 QX56
8. Remove the rear high- and low-pressure pipes bracket bolt (A)
to release the bracket.

Rear blower motor (1)

⇐: Front
9. Remove the rear high- and low-pressure pipes bolt (A) to dis- connect the rear high- and low-pressure pipes from the rear
expansion valve (1).

⇐: Front
CAUTION:
Cap or wrap the joint of the pipes with suitable material
such as vinyl tape to avoid the entry of air.
10. Disconnect the following electrical connectors:

Rear air mix door motor (1)

Rear blower motor resistor (2)

Rear blower motor (3)

⇐ : Front
11. Disconnect the ducts from the rear heater and cooling unit assembly. Refer to ATC-166, "
Components" .
12. Remove the rear heater and cooling unit assembly. CAUTION:
Cap or wrap the joint of the pipes with suitable material such as vinyl tape to avoid the entry of air.
13. Remove the rear high- and low-pressure A/C pipes.
INSTALLATION
Installation is in the reverse order of removal.
Refer to ATC-173, "
Components" .
CAUTION:

Replace the O-ring of the high/low-pressure pipe with a new one, then apply compressor oil to it
when installing it.

After charging refrigerant, check for leaks.
Removal and Installation for Underfloor Rear High- and Low-pressure A/C and
Heater Core Pipes
EJS005Y9
REMOVAL
1. Drain the coolant from the engine cooling system. Refer to CO-10, "Changing Engine Coolant" .
2. Disconnect the battery negative terminal.
3. Disconnect the generator harness.
4. Discharge the refrigerant. Refer to ATC-171, "
HFC-134a (R-134a) Service Procedure" .
WJIA2312E
WJIA2313E
WJIA2314E
