AT-72
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
32
Slips/Will
Not en-
gageWhen you press the
accelerator pedal and
shift speed D4 → D3
the engine idles or the
transmission slips.ON vehicle1. Fluid level and stateAT- 5 1
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 1 0 5,
AT- 1 2 4
3. ATF pressure switch 3 and input clutch solenoid valveAT- 1 5 2,
AT- 1 3 0
4. ATF pressure switch 1 and front brake solenoid valveAT- 1 5 0,
AT- 1 3 4
5. CAN communication lineAT- 9 1
6. Line pressure testAT- 5 1
7. Control valve with TCMAT- 2 1 0
OFF vehicle8. Torque converter AT- 2 4 0
9. Oil pump assemblyAT- 2 5 8
10. 3rd one-way clutchAT- 2 6 0
11. Gear systemAT- 2 2 8
12. High and low reverse clutchAT- 2 7 2
13. Forward one- way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to AT-
19, AT- 2 0.)AT- 2 4 0
14. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT- 1 9
, AT- 2 0.)AT- 2 4 0
33When you press the
accelerator pedal and
shift speed D3 → D2
the engine idles or the
transmission slips.ON vehicle1. Fluid level and stateAT- 5 1
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 1 0 5,
AT- 1 2 4
3. ATF pressure switch 6, high and low reverse clutch sole-
noid valveAT- 1 5 6,
AT- 1 4 2
4. ATF pressure switch 5 and direct clutch solenoid valveAT- 1 5 4,
AT- 1 3 8
5. CAN communication lineAT- 9 1
6. Line pressure testAT- 5 1
7. Control valve with TCMAT- 2 1 0
OFF vehicle8. Torque converterAT- 2 4 0
9. Oil pump assemblyAT- 2 5 8
10. 3rd one-way clutchAT- 2 6 0
11. Gear systemAT- 2 2 8
12. Direct clutchAT- 2 7 4
13. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT- 1 9
, AT- 2 0.)AT- 2 4 0
No. Items Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSIS
AT-73
< SERVICE INFORMATION >
D
E
F
G
H
I
J
K
L
MA
B
AT
N
O
P
34
Slips/Will
Not En-
gageWhen you press the
accelerator pedal and
shift speed D2 → D1
the engine idles or the
transmission slips.ON vehicle1. Fluid level and stateAT- 5 1
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 1 0 5,
AT-124
3. ATF pressure switch 5 and direct clutch solenoid valveAT- 1 5 4,
AT-138
4. CAN communication lineAT- 9 1
5. Line pressure testAT- 5 1
6. Control valve with TCMAT-210
OFF vehicle7. Torque converterAT-240
8. Oil pump assemblyAT-258
9. 3rd one-way clutchAT-260
10. 1st one-way clutchAT-267
11. Gear systemAT-228
12. Reverse brakeAT-240
13. Forward one- way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to AT-
19, AT- 2 0.)AT-240
14. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT- 1 9
, AT- 2 0.)AT-240
35With selector lever in
“D” position, accelera-
tion is extremely poor.ON vehicle1. Fluid level and stateAT- 5 1
2. Line pressure testAT- 5 1
3. Accelerator pedal position sensorAT- 11 7
4. CAN communication lineAT- 9 1
5. PNP switchAT- 9 9
6. Control cable adjustmentAT-208
7. Control valve with TCMAT-210
OFF vehicle8. Torque converterAT-240
9. Oil pump assemblyAT-258
10. 1st one-way clutchAT-267
11. Gear systemAT-228
12. Reverse brakeAT-240
13. Forward one- way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to AT-
19, AT- 2 0.)AT-240
14. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT- 1 9
, AT- 2 0.)AT-240
No. Items Symptom Condition Diagnostic ItemReference
page

AT-74
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
36
Slips/Will
Not En-
gageWith selector lever in
“R” position, accelera-
tion is extremely poor.ON vehicle1. Fluid level and stateAT- 5 1
2. Line pressure testAT- 5 1
3. Accelerator pedal position sensorAT- 11 7
4. ATF pressure switch 6, high and low reverse clutch sole-
noid valveAT- 1 5 6,
AT- 1 4 2
5. CAN communication lineAT- 9 1
6. PNP switchAT- 9 9
7. Control cable adjustmentAT- 2 0 8
8. Control valve with TCMAT- 2 1 0
OFF vehicle9. Gear systemAT- 2 2 810. Output shaftAT- 2 4 0
11. Reverse brakeAT- 2 4 0
37While starting off by
accelerating in 1st, en-
gine races or slippage
occurs.ON vehicle1. Fluid level and stateAT- 5 1
2. Line pressure testAT- 5 1
3. Accelerator pedal position sensorAT- 11 7
4. CAN communication lineAT- 9 1
5. Control valve with TCMAT- 2 1 0
OFF vehicle6. Torque converterAT- 2 4 0
7. Oil pump assemblyAT- 2 5 8
8. 3rd one-way clutchAT- 2 6 0
9. 1st one-way clutchAT- 2 6 7
10. Gear systemAT- 2 2 8
11. Reverse brakeAT- 2 4 0
12. Forward one- way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to AT-
19, AT- 2 0.)AT- 2 4 0
13. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT- 1 9
, AT- 2 0.)AT- 2 4 0
38While accelerating in
2nd, engine races or
slippage occurs.ON vehicle1. Fluid level and stateAT- 5 1
2. Line pressure testAT- 5 1
3. Accelerator pedal position sensorAT- 11 7
4. CAN communication lineAT- 9 1
5. ATF pressure switch 5 and direct clutch solenoid valveAT- 1 5 4,
AT- 1 3 8
6. Control valve with TCMAT- 2 1 0
OFF vehicle7. Torque converterAT- 2 4 0
8. Oil pump assemblyAT- 2 5 8
9. 3rd one-way clutchAT- 2 6 0
10. Gear systemAT- 2 2 8
11. Direct clutchAT- 2 7 4
12. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT- 1 9
, AT- 2 0.)AT- 2 4 0
No. Items Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSIS
AT-75
< SERVICE INFORMATION >
D
E
F
G
H
I
J
K
L
MA
B
AT
N
O
P
39
Slips/Will
Not En-
gageWhile accelerating in
3rd, engine races or
slippage occurs.ON vehicle1. Fluid level and stateAT- 5 1
2. Line pressure testAT- 5 1
3. Accelerator pedal position sensorAT- 11 7
4. CAN communication lineAT- 9 1
5. ATF pressure switch 6, high and low reverse clutch sole-
noid valveAT- 1 5 6,
AT-142

6. Control valve with TCMAT-210
OFF vehicle7. Torque converterAT-240
8. Oil pump assemblyAT-258
9. 3rd one-way clutchAT-260
10. Gear systemAT-228
11. High and low reverse clutchAT-272
12. Forward one- way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to AT-
19, AT- 2 0.)AT-240
13. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT- 1 9
, AT- 2 0.)AT-240
40While accelerating in
4th, engine races or
slippage occurs.ON vehicle1. Fluid level and stateAT- 5 1
2. Line pressure testAT- 5 1
3. Accelerator pedal position sensorAT- 11 7
4. CAN communication lineAT- 9 1
5. ATF pressure switch 3 and input clutch solenoid valveAT- 1 5 2,
AT-130
6. Control valve with TCMAT-210
OFF vehicle7. Torque converterAT-240
8. Oil pump assemblyAT-258
9. Input clutchAT-262
10. Gear systemAT-228
11. High and low reverse clutchAT-272
12. Direct clutchAT-274
No. Items Symptom Condition Diagnostic ItemReference
page

AT-76
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
41
Slips/Will
Not En-
gage While accelerating in
5th, engine races or
slippage occurs.ON vehicle1. Fluid level and stateAT- 5 1
2. Line pressure testAT- 5 1
3. Accelerator pedal position sensorAT- 11 7
4. CAN communication lineAT- 9 1
5. ATF pressure switch 1 and front brake solenoid valveAT- 1 5 0,
AT- 1 3 4
6. Control valve with TCMAT- 2 1 0
OFF vehicle7. Torque converterAT- 2 4 0
8. Oil pump assemblyAT- 2 5 8
9. Front brake (brake band)AT- 2 4 0
10. Input clutchAT- 2 6 2
11. Gear systemAT- 2 2 8
12. High and low reverse clutchAT- 2 7 2
42 Slips at lock-up.ON vehicle1. Fluid level and stateAT- 5 1
2. Line pressure testAT- 5 1
3. Engine speed signalAT- 1 0 9
4. Turbine revolution sensorAT- 1 0 3
5. Torque converter clutch solenoid valveAT- 111
6. CAN communication lineAT- 9 1
7. Control valve with TCMAT- 2 1 0
OFF vehicle8. Torque converterAT- 2 4 09. Oil pump assemblyAT- 2 5 8
43No creep at all.
Refer to AT-172, "
Ve -
hicle Does Not Creep
Backward in "R" Posi-
tion", AT- 1 7 5 , "Vehicle
Does Not Creep For-
ward in "D" Position"
ON vehicle1. Fluid level and stateAT- 5 1
2. Line pressure testAT- 5 1
3. Accelerator pedal position sensorAT- 11 7
4. ATF pressure switch 5 and direct clutch solenoid valveAT- 1 5 4,
AT- 1 3 8
5. PNP switchAT- 9 9
6. CAN communication lineAT- 9 1
7. Control cable adjustmentAT- 2 0 8
8. Control valve with TCMAT- 2 1 0
OFF vehicle9. Torque converterAT- 2 4 0
10. Oil pump assemblyAT- 2 5 8
11. 1st one-way clutchAT- 2 6 7
12. Gear systemAT- 2 2 8
13. Reverse brakeAT- 2 4 0
14. Direct clutchAT- 2 7 4
15. Forward one- way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to AT-
19, AT- 2 0.)AT- 2 4 0
16. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT- 1 9
, AT- 2 0.)AT- 2 4 0
No. Items Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSIS
AT-77
< SERVICE INFORMATION >
D
E
F
G
H
I
J
K
L
MA
B
AT
N
O
P44
Slips/Will
Not En-
gageVehicle cannot run in
all positions.ON vehicle1. Fluid level and stateAT- 5 1
2. Line pressure testAT- 5 1
3. PNP switchAT- 9 9
4. Control cable adjustmentAT-208
5. Control valve with TCMAT-210
OFF vehicle6. Oil pump assemblyAT-2587. Gear systemAT-228
8. Output shaftAT-240
45With selector lever in
“D” position, driving is
not possible.ON vehicle1. Fluid level and stateAT- 5 1
2. Line pressure testAT- 5 1
3. PNP switchAT- 9 9
4. Control cable adjustmentAT-208
5. Control valve with TCMAT-210
OFF vehicle6. Torque converterAT-240
7. Oil pump assembly AT-258
8. 1st one-way clutchAT-267
9. Gear systemAT-228
10. Reverse brakeAT-240
11. Forward one- way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to AT-
19, AT- 2 0.)AT-240
12. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT- 1 9
, AT- 2 0.)AT-240
46With selector lever in
“R” position, driving is
not possible.ON vehicle1. Fluid level and stateAT- 5 1
2. Line pressure testAT- 5 1
3. PNP switchAT- 9 9
4. Control cable adjustmentAT-208
5. Control valve with TCMAT-210
OFF vehicle6. Gear systemAT-2287. Output shaftAT-240
8. Reverse brakeAT-240
47 OthersShift point is high in
“D” position.ON vehicle1. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 1 0 5
,
AT-124
2. Accelerator pedal position sensorAT- 11 7
3. CAN communication lineAT- 9 1
4. ATF temperature sensorAT- 11 9
5. Control valve with TCMAT-210
No. Items Symptom Condition Diagnostic ItemReference
page

AT-78
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
48
OthersShift point is low in “D”
position.ON vehicle1. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 1 0 5
,
AT- 1 2 4
2. Accelerator pedal position sensorAT- 11 7
3. CAN communication lineAT- 9 1
4. Control valve with TCMAT- 2 1 0
49Judder occurs during
lock-up.ON vehicle1. Fluid level and stateAT- 5 1
2. Engine speed signalAT- 1 0 9
3. Turbine revolution sensorAT- 1 0 3
4. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 1 0 5,
AT- 1 2 4
5. Accelerator pedal position sensorAT- 11 7
6. CAN communication lineAT- 9 1
7. Torque converter clutch solenoid valveAT- 111
8. Control valve with TCMAT- 2 1 0
OFF vehicle 9. Torque converterAT- 2 4 0
50Strange noise in “R”
position.ON vehicle1. Fluid level and stateAT- 5 1
2. Engine speed signalAT- 1 0 9
3. CAN communication lineAT- 9 1
4. Control valve with TCMAT- 2 1 0
OFF vehicle5. Torque converterAT- 2 4 0
6. Oil pump assemblyAT- 2 5 8
7. Gear systemAT- 2 2 8
8. High and low reverse clutchAT- 2 7 2
9. Reverse brakeAT- 2 4 0
51Strange noise in “N”
position.ON vehicle1. Fluid level and stateAT- 5 1
2. Engine speed signalAT- 1 0 9
3. CAN communication lineAT- 9 1
4. Control valve with TCMAT- 2 1 0
OFF vehicle5. Torque converterAT- 2 4 06. Oil pump assemblyAT- 2 5 8
7. Gear systemAT- 2 2 8
52Strange noise in “D”
position.ON vehicle1. Fluid level and stateAT- 5 1
2. Engine speed signalAT- 1 0 9
3. CAN communication lineAT- 9 1
4. Control valve with TCMAT- 2 1 0
OFF vehicle5. Torque converterAT- 2 4 0
6. Oil pump assemblyAT- 2 5 8
7. Gear systemAT- 2 2 8
8. Forward brake (Parts behind drum support is impossible to
perform inspection by disassembly. Refer to AT- 1 9
, AT- 2 0.)AT- 2 4 0
No. Items Symptom Condition Diagnostic ItemReference
page

AT-80
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
56
OthersMaximum speed low.ON vehicle1. Fluid level and stateAT- 5 1
2. Line pressure testAT- 5 1
3. Accelerator pedal position sensorAT- 11 7
4. CAN communication lineAT- 9 1
5. Direct clutch solenoid valveAT- 1 3 8
6. Control valve with TCMAT- 2 1 0
OFF vehicle7. Torque converterAT- 2 4 0
8. Oil pump assemblyAT- 2 5 8
9. Input clutchAT- 2 6 2
10. Gear systemAT- 2 2 8
11. High and low reverse clutchAT- 2 7 2
12. Direct clutchAT- 2 7 4
13. Forward one- way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to AT-
19, AT- 2 0.)AT- 2 4 0
14 Forward brake (Parts behind drum support is impossible to
perform inspection by disassembly. Refer to AT- 1 9
, AT- 2 0.)AT- 2 4 0
57 Extremely large creep.ON vehicle1. Engine idle speed EC-75

2. CAN communication lineAT- 9 1
3. ATF pressure switch 5AT- 1 5 4
OFF vehicle 4. Torque converterAT- 2 4 0
58With selector lever in
“P” position, vehicle
does not enter parking
condition or, with se-
lector lever in another
position, parking con-
dition is not cancelled.
Refer to AT-168, "
In
"P" Position, Vehicle
Moves When
Pushed".ON vehicle1. PNP switchAT- 9 9
2. Control cable adjustmentAT- 2 0 8
OFF vehicle 3. Parking pawl componentsAT- 2 2 8
59Vehicle runs with
transmission in “P” po-
sition.ON vehicle1. PNP switchAT- 9 9
2. Fluid level and stateAT- 5 1
3. Control cable adjustmentAT- 2 0 8
4. Control valve with TCMAT- 2 1 0
5. Parking pawl componentsAT- 2 2 8
OFF vehicle 6. Gear systemAT- 2 2 8
No. Items Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSIS
AT-81
< SERVICE INFORMATION >
D
E
F
G
H
I
J
K
L
MA
B
AT
N
O
P
60
OthersVehicle runs with
transmission in “N” po-
sition.
Refer to AT- 1 6 9 , "In
"N" Position, Vehicle
Moves".ON vehicle1. PNP switchAT- 9 9
2. Fluid level and stateAT- 5 1
3. Control cable adjustmentAT-208
4. Control valve with TCMAT-210
OFF vehicle5. Input clutchAT-262
6. Gear systemAT-228
7. Direct clutchAT-274
8. Reverse brakeAT-240
9. Forward one- way clutch (Parts behind drum support is im-
possible to perform inspection by disassembly. Refer to AT-
19, AT- 2 0.)AT-240
10. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT- 1 9
, AT- 2 0.)AT-240
61Engine does not start
in “N” or “P” position.
Refer to AT- 1 6 8 , "En-
gine Cannot Be Start-
ed in "P" or "N"
Position".ON vehicle1. Ignition switch and starterPG-3
, SC-
9
2. Control cable adjustmentAT-208
3. PNP switchAT- 9 9
62Engine starts in posi-
tions other than “N” or
“P”.ON vehicle1. Ignition switch and starterPG-3
, SC-
9
2. Control cable adjustmentAT-208
3. PNP switchAT- 9 9
63 Engine stall.ON vehicle1. Fluid level and stateAT- 5 1
2. Engine speed signalAT-109
3. Turbine revolution sensorAT-103
4. Torque converter clutch solenoid valveAT- 111
5. CAN communication lineAT- 9 1
6. Control valve with TCMAT-210
OFF vehicle 7. Torque converterAT-240
64Engine stalls when se-
lect lever shifted “N” →
“D”, “R”.ON vehicle1. Fluid level and stateAT- 5 1
2. Engine speed signalAT-109
3. Turbine revolution sensorAT-103
4. Torque converter clutch solenoid valveAT- 111
5. CAN communication lineAT- 9 1
6. Control valve with TCMAT-210
OFF vehicle 7. Torque converterAT-240
No. Items Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSIS
AT-87
< SERVICE INFORMATION >
D
E
F
G
H
I
J
K
L
MA
B
AT
N
O
P
X: Standard, —: Not applicable
Monitored item (Unit)Monitor Item Selection
Remarks ECU IN-
PUT SIG-
NALSMAIN SIG-
NALSSELEC-
TION
FROM
MENU
VHCL/S SE·A/T (km/h) X X X Revolution sensor
VHCL/S SE·MTR (km/h) X — X
ACCELE POSI (0.0/8) X — X Accelerator pedal position signal
THROTTLE POSI (0.0/8) X X XDegree of opening for accelerator recognized by
the TCM
For fail-safe operation, the specific value used
for control is displayed.
CLSD THL POS (ON-OFF display) X — X
Signal input with CAN communications
W/O THL POS (ON-OFF display) X — X
BRAKE SW (ON-OFF display) X — X Stop lamp switch
GEAR — X XGear position recognized by the TCM updated
after gear-shifting
ENGINE SPEED (rpm) X X X
TURBINE REV (rpm) X X X
OUTPUT REV (rpm) X X X
GEAR RATIO — X X
TC SLIP SPEED (rpm) — X XDifference between engine speed and torque
converter input shaft speed
F SUN GR REV (rpm) — — X
F CARR GR REV (rpm) — — X
ATF TEMP SE 1 (V) X — X
ATF TEMP SE 2 (V) X — X
ATF TEMP 1 (°C) — X X
ATF TEMP 2 (°C) — X X
BATTERY VOLT (V) X — X
ATF PRES SW 1 (ON-OFF display) X X X (for FR/B solenoid)
ATF PRES SW 2 (ON-OFF display) X X X (for LC/B solenoid)
ATF PRES SW 3 (ON-OFF display) X X X (for I/C solenoid)
ATF PRES SW 5 (ON-OFF display) X X X (for D/C solenoid)
ATF PRES SW 6 (ON-OFF display) X X X (for HLR/C solenoid)
PNP SW 1 (ON-OFF display) X — X
PNP SW 2 (ON-OFF display) X — X
PNP SW 3 (ON-OFF display) X — X
PNP SW 4 (ON-OFF display) X — X
SLCT LVR POSI — X XSelector lever position is recognized by the TCM.
For fail-safe operation, the specific value used
for control is displayed.
1 POSITION SW (ON-OFF display) X — X 1st position switch
OD CONT SW (ON-OFF display) X — X 4th position switch
