ACS-26
< SERVICE INFORMATION >[ICC]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
CONSULT-II START PROCEDURE
Refer to GI-36, "CONSULT-II Start Procedure".
WORK SUPPORT
Work Item
Cause of Auto-Cancel
1. Touch “WORK SUPPORT” on "SELECT DIAG MODE" screen.
2. Touch “CAUSE OF AUTO-CANCEL” on "SELECT WORK ITEM"
screen.
3. Cause of automatic cancellation screen will be shown.
4. The last five causes of automatic cancellation of ICC system will
be displayed.
Possible Causes of "Auto-Cancel"
Laser Beam Adjust
For details, refer to ACS-12 .
SELF-DIAGNOSTIC RESULTS
For details, refer to ACS-34, "Diagnostic Trouble Code (DTC) Chart" .
DATA MONITOR
CAN DIAG SUPPORT MNTR The results of transmit/receive diagnosis of CAN communication can be read.
ACTIVE TEST Operation of electrical loads can be checked by sending driving signal to them.
ECU PART NUMBER ICC unit part number can be read.ICC diagnostic mode Description
Operation Function
CAUSE OF AUTO-CANCEL Indicates causes of automatic cancellation of the ICC system.
LASER BEAM ADJUST Outputs laser beam, calculates dislocation of the beam, and indicates adjustment direction.
SKIA6191E
Cause of cancellation Description
OPERATING WIPER Windshield wipers were operated at HI or LO speed operation.
OPERATING ABS ABS function was operated.
OPERATING TCS TCS function was operated.
OPERATING VDC VDC function was operated.
ECM CIRCUIT ECM did not permit ICC operation.
OPE SW VOLT CIRC Voltage outside the standard was detected.
LASER SUN BEAM Intense light such as sunlight entered ICC sensor light sensing part.
LASER TEMP Temperature around ICC sensor became low.
WHL SPD ELEC NOISE Wheel speed sensor signal caught electromagnetic noise.
OP SW DOUBLE TOUCH ICC steering switches were pressed at the same time.
VDC/TCS OFF SW VDC OFF switch was pressed.
WHEEL SPD UNMATCH Wheel speed became different from AT vehicle speed.
TIRE SLIP Wheel slipped.
PKB SW ON Parking brake is applied.
IGN LOW VOLT Power supply voltage became low.
NO RECORD—

TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
ACS-27
< SERVICE INFORMATION >[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
N
O
P Operation Procedure
1. Touch “DATA MONITOR” on "SELECT DIAG MODE" screen.
2. Touch “ECU INPUT SIGNALS”, “MAIN SIGNALS“, or “SELEC-
TION FROM MENU” on "SELECT MONITOR ITEM" screen.
Monitored Item
×: Applicable
BCIA0031E
WDIA0084E
Monitored Item [unit] MAIN SIGNALSECU IN-
PUT SIG-
NALSSELECTION
FROM MENUDescription
VHCL SPEED SE
[km/h] or [mph]×××Indicates vehicle speed calculated from
wheel speed sensor signal.
SET VHCL SPD
[km/h] or [mph]××Indicates set vehicle speed stored in ICC
unit.
THRTL OPENING
[%]×××Indicates throttle angle calculated from sig-
nal voltage of throttle position sensor.
ENGINE RPM
[rpm]××Indicates engine speed read by ICC unit via
CAN communication (ECM transmits engine
speed via CAN communication).
DISTANCE ADJ
[SHOR/MID/LONG]×××Indicates set distance stored in ICC unit.
WIPER SW
[OFF/LOW/HIGH]××Indicates wiper [OFF/LOW/HIGH] status.
MAIN SW
[ON/OFF]×××Indicates [ON/OFF] status as judged from
control switch signal.
SET/COAST SW
[ON/OFF]×××Indicates [ON/OFF] status as judged from
control switch signal.
CANCEL SW
[ON/OFF]×××Indicates [ON/OFF] status as judged from
control switch signal.
RESUME/ACC SW
[ON/OFF]×××Indicates [ON/OFF] status as judged from
control switch signal.
CRUISE OPE
[ON/OFF]××Indicates whether vehicle speed is being
controlled or not (ON means “controlling”).
BRAKE SW
[ON/OFF]×××Indicates [ON/OFF] status as judged from
ICC brake switch signal.

ACS-28
< SERVICE INFORMATION >[ICC]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
ACTIVE TEST
CAUTION:
Do not perform the active test while driving. Active test cannot be started while ICC system warning
indicator is illuminated.
Active Test
STOP LAMP SW
[ON/OFF]×××Indicates [ON/OFF] status as judged from
stop lamp switch signal.
RELEASE SW NO
[ON/OFF]
××Indicates [ON/OFF] status as judged from
release switch signal.
ON when brake is depressed.
OFF when brake is not depressed.
RELEASE SW NC
[ON/OFF]
××Indicates [ON/OFF] status as judged from
release switch signal.
OFF when brake is depressed.
ON when brake is not depressed.
IDLE SW
[ON/OFF]
××Indicates [ON/OFF] status of idle switch
read by ICC unit via CAN communication
(ECM transmits ON/OFF status via CAN
communication).
GEAR
[1, 2, 3, 4, 5]××Indicates A/T gear position read by ICC unit
via CAN communication (TCM transmits
gear position via CAN communication).
BUZZER O/P
[ON/OFF] ×Indicates [ON/OFF] status of ICC warning
output.
ICC WARNING×NOTE:
This item is displayed but cannot be moni-
tored.
VHCL SPD AT
[km/h] or [mph]
×Indicates vehicle speed calculated from A/T
vehicle speed sensor by ICC unit via CAN
communication (TCM transmits A/T vehicle
speed sensor signal via CAN communica-
tion).
PRESS SENS
[bar]×××Indicates brake fluid pressure value calculat-
ed from signal voltage of pressure sensor.
PRESS SENS 2
[bar]××NOTE:
This item is displayed but cannot be moni-
tored.
D RANGE SW
[ON/OFF]
××Indicates [ON/OFF] status of “D” position
read by ICC unit via CAN communication
(TCM transmits ON/OFF condition of “D” po-
sition via CAN communication).
A/T OD OFF
[ON/OFF]×Indicates [ON/OFF] status of OD cancel out-
put under control.
NP RANGE SW
[ON/OFF]××Indicates PNP switch signal read by ICC unit
via CAN communication. (TCM transmits
PNP switch signal via CAN communication)
DISTANCE×NOTE:
This item is displayed but cannot be moni-
tored.
RELATIVE SPD×NOTE:
This item is displayed but cannot be moni-
tored.
STP LMP DRIVE
[ON/OFF]××Indicates [ON/OFF] status of brake hold re-
lay drive output. Monitored Item [unit] MAIN SIGNALSECU IN-
PUT SIG-
NALSSELECTION
FROM MENUDescription

ACS-32
< SERVICE INFORMATION >[ICC]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
6. Perform ICC system running test (drive vehicle with ICC system ON), and make sure that ICC system
warning lamp (orange) does not illuminate.
SELF-DIAGNOSIS BY ICC SYSTEM DISPLAY WILL NOT RUN
Self Diagnosis Will Not Run
1.CHECK ICC SYSTEM DISPLAY
When ignition switch is ON, do all displays illuminate?
YES or NO
YES >> GO TO 2.
NO >> GO TO 5.
2.CHECK SELF-DIAGNOSIS
• Disconnect ECM connectors, and check for damaged, bent or loose terminals. Securely connect them
again.
• Can self-diagnosis for ICC system be performed?
YES or NO
YES >> Inspection End.
NO >> GO TO 3.
3.CHECK ICC STEERING SWITCH
Check ICC steering switch. Refer to ACS-54, "
ICC Steering Switch" .
OK or NG
OK >> GO TO 4.
WKIA1985E
Component Possible Cause Specific causes
ICC unit power supply malfunctionNo voltage supply from ignition switchFuse blown
Harness open
Harness shorted
Ground cable not connectedHarness open
Harness shorted
ICC steering switch malfunction No signal transmittedHarness open
Harness shorted
Spiral cable open
Spiral cable shorted
Switch or ECM malfunction
CAN communication system malfunction Signal not transmittedHarness open
Harness shorted
CAN communication outside the standard
Combination meter system malfunction Indication not possibleIndicator malfunction
Indicator segments disappear
ICC unit malfunction Internal malfunction ICC unit

TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
ACS-33
< SERVICE INFORMATION >[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
N
O
P
NG >> Replace ICC steering switch. Refer to ACS-54, "ICC Steering Switch" .
4.CHECK HARNESS BETWEEN ECM AND ICC STEERING SWITCH
Check harness and spiral cable between ECM and ICC steering switch for open or short circuit.
OK or NG
OK >> GO TO 6
NG >> Repair or replace harness or spiral cable between ECM and ICC steering switch.
5.CHECK POWER SUPPLY FOR ICC UNIT
• Check ICC unit power supply, and repair if necessary.
• When ignition switch is ON, do all displays illuminate?
YES or NO
YES >> Perform self-diagnosis again.
NO >> GO TO 6.
6.CHECK CONNECTOR FOR ICC UNIT
• Disconnect connectors ICC unit, and check terminals for bends and looseness. Securely connect them
again.
• When ignition switch is ON, do all displays illuminate?
YES or NO
YES >> Perform self-diagnosis again.
NO >> GO TO 7.
7.CHECK CAN COMMUNICATION
Perform self-diagnosis with CONSULT-II, and check CAN communication system for malfunction.
OK or NG
OK >> Replace combination meter. Refer to DI-21, "Removal and Installation of Combination Meter" .
NG >> CAN communication inspection. Refer to ACS-37, "
DTC 20 CAN COMM CIRCUIT".

ACS-36
< SERVICE INFORMATION >[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
NOTE: DTC 55 will display when no malfunction is detected.
DTC 11 CONTROL UNITINFOID:0000000003533795
1.DIAGNOSTIC CHECK
Are any items other than “DTC 11 CONTROL UNIT” indicated on self-diagnosis display?
YES or NO
YES >> Repair or replace as necessary. Erase DTC and perform ICC system running test. Refer to ACS-
9, "ICC System Running Test" . Then perform self-diagnosis of ICC system again.
NO >> Replace ICC unit. Refer to ACS-55
. Erase DTC and perform ICC system running test. Refer to
ACS-9, "
ICC System Running Test". Then perform self-diagnosis of ICC system again.
DTC 12 VDC CONTROL UNITINFOID:0000000003533796
1.DIAGNOSIS CHECK
With CONSULT-II
Perform self-diagnosis of ABS actuator and electric unit (control unit). Is malfunction indicated?
YES or NO
YES >> Repair or replace as necessary. Erase DTC and perform ICC system running test. Refer to ACS-
9, "ICC System Running Test". Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2.CHECK CONNECTOR ICC UNIT AND ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
1. Turn ignition switch OFF.
2. Disconnect ICC unit, and ABS actuator and electric unit (control unit) connectors, and connect them
securely again. Erase DTC, then perform self-diagnosis of ICC system again.
OK or NG
OK >> Poor connector connection. Check connector housing for disconnected, loose, bent and collapsed
terminals. If any malfunction is detected, repair as necessary. Erase DTC and perform ICC sys-
tem running test. Refer to ACS-9, "
ICC System Running Test". Then perform self-diagnosis of ICC
system again.
NG >> GO TO 3.
3.CHECK HARNESS BETWEEN ICC UNIT AND ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
104 LASER AIMING INCMP×× ×• Laser beam aiming of ICC sensor
is not adjustedACS-48,
"DTC 104
LASER
AIMING
INCMP"
107 LASER COMM FAIL×× ×• CAN data received by ICC sensor
is strange (from ICC unit, combi-
nation meter or ECM)ACS-48,
"DTC 107
LASER
COMM
FA IL"
109 LASER HIGH TEMP×× ×• Temperature around ICC sensor
is excessively highACS-48,
"DTC 109
LASER
HIGH
TEMP"
DTC
No.CONSULT-II screen termsICC sys-
tem
warning
lampFail-safe
Malfunctions detected where...Refer-
ence
page Vehicle-
to-vehi-
cle dis-
tance
control
modeConven-
tional
(fixed
speed)
cruise
control
modeBrake as-
sist (with
preview
function)

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
ACS-37
< SERVICE INFORMATION >[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
N
O
P
1. Turn ignition switch OFF.
2. Disconnect ICC unit and ABS actuator and electric unit (control
unit) connectors.
3. Check continuity between ICC unit harness connector B13 ter-
minal 10, and ABS actuator and electric unit (control unit) con-
nector E125 terminal 7.
OK or NG
OK >> Replace ICC unit. Refer to ACS-55. Erase DTC and per-
form ICC system running test. Refer to ACS-9, "
ICC
System Running Test". Then perform self-diagnosis of ICC system again.
NG >> • Repair harness between ICC unit, and ABS actuator and electric unit (control unit).
• Erase DTC and perform ICC system running test. Refer to ACS-9, "
ICC System Running Test".
Then perform self-diagnosis of ICC system again.
DTC 20 CAN COMM CIRCUITINFOID:0000000003533797
1.CHECK CAN COMMUNICATION
With CONSULT-II
1. Perform self-diagnosis.
2. Print self-diagnostic result.
>> After printing self-diagnostic result, GO TO “CAN system”. Refer to LAN-4, "
CAN Communication
System" .
DTC 31 POWER SUPPLY CIR1, DTC 34 POWER SUPPLY CIR2INFOID:0000000003533798
1.CHECK ICC UNIT CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect ICC unit connectors and connect them securely again. Erase DTC, then perform self-diagno-
sis of ICC system again.
OK or NG
OK >> GO TO 2.
NG >> • Poor connector connection.
• Check connector. Check connector housing for disconnected, loose, bent, and collapsed termi-
nals. If any malfunction is detected, repair as as necessary. Erase DTC and perform ICC system
running test. Refer to ACS-9, "
ICC System Running Test". Then perform self-diagnosis of ICC
system again.
2.CHECK POWER SUPPLY CIRCUIT FOR ICC UNIT
1. Turn ignition switch ON.
2. Check voltage between ICC unit harness connector B17 termi-
nal 33, 42 and ground.
OK or NG
OK >> GO TO 3.
NG >> • Repair ICC unit power supply harness.
• Erase DTC and perform ICC system running test.
Refer to ACS-9, "
ICC System Running Test". Then
perform self-diagnosis of ICC system again.
3.CHECK GROUND CIRCUIT FOR ICC UNITContinuity should exist.
WKIA3616E
Battery voltage should exist.
SKIA1173E

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
ACS-39
< SERVICE INFORMATION >[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
N
O
P
1. Turn ignition switch OFF.
2. Disconnect ICC unit connectors and connect them securely again. Erase DTC, then perform self-diagno-
sis of ICC system again.
OK or NG
OK >> • Poor connector connection.
• Check connectors. Check connectors housing for disconnected, loose, bent, and collapsed ter-
minals. If any malfunction is detected, repair as necessary. Erase DTC and perform ICC system
running test. Refer to ACS-9, "
ICC System Running Test". Then perform self-diagnosis of ICC
system again.
NG >> GO TO 2.
2.CHECK STOP LAMP SWITCH AND ICC BRAKE SWITCH
With CONSULT-II
With data monitor, check if “STOP LAMP SW” and “BRAKE SW” are operating normally.
OK or NG
OK >> Replace ICC unit. Refer to ACS-55. Erase DTC and perform ICC system running test. Refer to
ACS-9, "
ICC System Running Test" . Then perform self-diagnosis of ICC system again.
NG >> • BRAKE SW: GO TO 3.
• STOP LAMP SW: GO TO 5.
3.ICC BRAKE SWITCH INSTALLATION AND ADJUSTMENT INSPECTION
Check ICC brake switch for proper installation and adjust if necessary. Refer to BR-5
.
OK or NG
OK >> GO TO 4.
NG >> After adjustment, erase DTC and perform ICC system running test. Refer to ACS-9, "
ICC System
Running Test" . Then perform self-diagnosis of ICC system again.
4.CHECK ICC BRAKE SWITCH
Check ICC brake switch. Refer toACS-54, "
ICC Brake Switch and Stop Lamp Switch" .
OK or NG
OK >> Replace ICC unit. Refer to ACS-55. Erase DTC and perform ICC system running test. Refer to
ACS-9, "
ICC System Running Test". Then perform self-diagnosis of ICC system again.
NG >> Replace ICC brake switch. Erase DTC and perform ICC system running test. Refer to ACS-9,
"ICC System Running Test". Then perform self-diagnosis of ICC system again.
5.CHECK STOP LAMP ILLUMINATION
Check stop lamp illumination.
OK or NG
OK >> GO TO 6.
NG >> • Check stop lamp circuit. Refer to LT- 7 7
.
• Erase DTC and perform ICC system running test. Refer to ACS-9, "
ICC System Running Test".
Then perform self-diagnosis of ICC system again.
6.CHECK ICC BRAKE HOLD RELAY
1. Turn ignition switch OFF.
2. Remove ICC brake hold relay.
3. Check continuity between ICC brake hold relay terminals.
OK or NG
OK >> GO TO 7.
NG >> Replace ICC brake hold relay. Erase DTC and perform
ICC system running test. Refer to ACS-9, "
ICC System
Running Test". Then perform self-diagnosis of ICC sys-
tem again.
7 - 6 Continuity should not exist.
4 - 3 Continuity should exist.
SKIA6651E

ACS-40
< SERVICE INFORMATION >[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
7.CHECK ICC BRAKE HOLD RELAY CIRCUIT
1. Disconnect ICC unit and stop lamp switch connectors.
2. Check continuity between ICC unit harness connector B17 ter-
minal 38 and ICC brake hold relay harness connector E134 ter-
minal 7.
3. Check continuity between ICC unit harness connector B17 ter-
minal 38 and stop lamp switch harness connector E38 terminal
4.
OK or NG
OK >> Replace ICC unit. Refer to ACS-55. Erase DTC and perform ICC system running test. Refer to
ACS-9, "
ICC System Running Test" . Then perform self-diagnosis of ICC system again.
NG >> • Repair harness between ICC unit and ICC brake hold relay or stop lamp switch.
• Erase DTC and perform ICC system running test. Refer to ACS-9, "
ICC System Running Test".
Then perform self-diagnosis of ICC system again.
DTC 46 OPERATION SW CIRCINFOID:0000000003533802
1.CHECK ECM CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect ECM connector and connect it securely again. Erase DTC, then perform self-diagnosis of ICC
system again.
OK or NG
OK >> • Poor connector connection.
• Check connector. Check connector housing for disconnected, loose, bent, and collapsed termi-
nals. If any malfunction is detected, repair as as necessary. Erase DTC and perform ICC system
running test. Refer to ACS-9, "
ICC System Running Test". Then perform self-diagnosis of ICC
system again.
NG >> GO TO 2.
2.CHECK ICC STEERING SWITCH
Check ICC steering switch. Refer to ACS-54, "
ICC Steering Switch" .
OK or NG
OK >> GO TO 3.
NG >> Replace ICC steering switch assembly. Refer to ACS-54, "
ICC Steering Switch". Erase DTC and
perform ICC system running test. Refer to ACS-9, "
ICC System Running Test". Then perform self-
diagnosis of ICC system again.
3.CHECK ICC STEERING SWITCH SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM and spiral cable connectors.
3. Check continuity between ECM harness connectors E16 and
F54 terminals 67, 99 and spiral cable harness connector M30
terminals 33, 34.
OK or NG
OK >> GO TO 4.Continuity should exist.
Continuity should exist.
WKIA3403E
67 - 33, 99 - 34 Continuity should exist.
WKIA1928E
