AV-12
< FUNCTION DIAGNOSIS >[AUDIO SYSTEM]
AUDIO SYSTEM
Component Description
INFOID:0000000003776771
10. Rear audio remote control unit R204 11. Microphone R109 12. Front door speaker
LH D12
RH D112
13. Rear door tweeter LH D208
RH D308 14. Rear door speaker
LH D207
RH D307 15. Back door speaker
LH D518
RH D716
16. Subwoofer B72 (under driver’s seat) 17. BOSE speaker amp M112, M113 (view behind instrument panel above
accelerator pedal)18. Rear view camera control unit B73
(located behind luggage finisher LHl)
19. Rear view camera D504
Part name Description
AV control unit Controls audio system, NAVI functions and satellite radio system functions
Display unit • Touch screen controls all audio and A/C operations
• Displays all audio and climate control related information
BOSE speaker amp. Receives power (amp ON) and audio signals from AV control unit and out-
puts audio signals to each speaker.
Steering switches • Audio operation can be operated
• Steering switch signal is output to AV control unit
Front door speakers • Outputs audio signal from BOSE speaker amp.
• Outputs high, mid and low range sounds
Front tweeters • Outputs audio signal from BOSE speaker amp.
• Outputs high range sounds
Center speaker • Outputs audio signal from BOSE speaker amp.
• Outputs high range sounds
Rear door speakers • Outputs audio signal from BOSE speaker amp.
• Outputs high, mid and low range sounds
Rear door tweeters • Outputs audio signal from BOSE speaker amp.
• Outputs high range sounds
Back door speakers • Outputs audio signal from BOSE speaker amp.
• Outputs high, mid and low range sounds
Subwoofer • Outputs audio signal from BOSE speaker amp.
• Outputs low range sounds
Satellite antenna Audio signal (satellite radio) is received and output to AV control unit.
Revision: December 20092009 QX56

AV-24
< FUNCTION DIAGNOSIS >[AUDIO SYSTEM]
HANDS-FREE PHONE SYSTEM
HANDS-FREE PHONE SYSTEM
System DiagramINFOID:0000000003776784
System DescriptionINFOID:0000000003776785
Refer to the Owner's Manual for Bluetoot
h telephone system operating instructions.
NOTE:
Cellular telephones must have their wireless connection set up (paired) before using the Bluetooth telephone
system.
Bluetooth telephone system allows users who have a Bluetooth equipped cellular telephone to make a wire-
less connection between their cellular telephone and the AV control unit. Hands-free cellular telephone calls
can be sent and received. Personal memos can be created using the Nissan Voice Recognition system. Some
Bluetooth cellular telephones may not be recognized by t he AV control unit. When a cellular telephone or the
AV control unit is replaced, the telephone must be pair ed with the AV control unit. Different cellular telephones
may have different pairing procedures. Refer to the cellular telephone operating manual and the vehicle
Owner’s Manual for more information.
AV CONTROL UNIT
When the ignition switch is turned to ACC or ON, the AV control unit will power up. During power up, the Blue-
tooth feature is initialized and performs various self checks. Initialization may take up to 10 seconds. If a
phone is present in the vehicle and paired with the AV control unit, Nissan Voice Recognition will then become
active. Bluetooth telephone functions can be turned off using the Nissan Voice Recognition system.
STEERING WHEEL AUDIO CONTROL SWITCHES
When buttons on the steering wheel audio control switch are pushed, the resistance in steering wheel audio
control switch circuit changes depending on which button is pushed. The AV control unit uses this signal to
perform various functions while navigati ng through the voice recognition system.
The following functions can be performed using the steering wheel audio control switch:
• Initiate Self Diagnosis of the Bluetooth telephone system
• Start a voice recognition session
• Answer and end telephone calls
• Adjust the volume of calls
• Record memos
MICROPHONE
The microphone is located in the roof console assembly . The microphone sends a signal to the AV control unit.
The microphone can be actively tested during self-diagnosis.
AWNIA0131GB
Revision: December 20092009 QX56

AV-110
< ECU DIAGNOSIS >[AUDIO SYSTEM]
AV CONTROL UNIT
4
(L) 5
(B/W) Pre-amp. audio signal rear
LH
OutputIgnition
switch ON Audio output
6
(Y) 15 Steering switch signal A Input Ignition
switch
ON Pressing switch
0V
Pressing switch 0.75
Pressing VOL up switch 2V
Except for above 5V
7
(V) Ground ACC power supply
InputIgnition
switch ACC −
Battery voltage
9
(R/L) Ground Illumination signal
Input OFFLighting switch is OFF
0V
Lighting switch is ON Battery voltage
10 — Shield — —— —
11
(BR) 12
(B/R) Pre-amp. audio signal front
RH
OutputIgnition
switch ON Audio output
13
(W) 14
(B) Audio signal rear RH Output Ignition
switch
ON Audio output
15 Ground Steering switch signal
ground —Ignition
switch
ON —0
V
16
(BR) 15 Steering switch signal B Input Ignition
switch ON Pressing switch
0V
Pressing switch 0.75V
Pressing VOL down switch 2V
Except for above 5V
19
(Y) Ground Battery power supply Input Ignition
switch OFF —
Battery voltage
20
(B) Ground Ground
—Ignition
switch
ON —0
V
Terminal
(Wire color) Description
ConditionReference value
(Approx.)
+ – Signal nameInput/
Output
SKIB3609E
SKIB3609E
SKIB3609E
Revision: December 20092009 QX56

AV
MULTI AV SYSTEMAV-155
< SYMPTOM DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
SYMPTOM DIAGNOSIS
MULTI AV SYSTEM
Symptom TableINFOID:0000000003776898
AUDIO SYSTEM
NAVIGATION SYSTEM
HANDS-FREE PHONE SYSTEM
REAR VIEW MONITOR
Symptom Possible causeReference page
Inoperative • AV control unit power and ground circuit
• AV control unit •
AV- 6 8
•AV- 2 7
Steering switch does not operate • Steering switch
• AV control unit •
AV- 4 0•AV- 2 7
All speakers do not sound • AV control unit power and ground circuit
• BOSE speaker amp. ON signal
• BOSE speaker amp. power and ground circuit
• BOSE speaker amp.
• AV control unit •
AV- 6 8
•AV- 1 0 4
•AV- 7 0
•AV- 1 4 8
•AV- 1 0 9
One or several speakers do not sound • Front door speaker
• Front tweeter
• Center speaker
• Rear tweeter
• Rear door speaker
• Back door speaker
• Subwoofer •
AV- 8 4
•AV- 8 7
•AV- 9 0
•AV- 9 5
•AV- 9 2
•AV- 9 8
•AV- 1 0 1
Symptom Possible causeReference page
Inoperative • AV control unit power and ground circuit
• AV control unit •
AV- 6 8
•AV- 2 7
Steering switch does not operate • Steering switch
• AV control unit •
AV- 1 0 5•AV- 2 7
Voice activated control does not operate • Microphone
• Steering switch
• AV control unit •
AV- 1 0 7•AV- 1 0 5
•AV- 2 7
Symptom Possible causeReference page
Inoperative • AV control unit power and ground circuit
• AV control unit •
AV- 6 8
•AV- 2 7
Steering switch does not operate • Steering switch
• AV control unit •
AV- 1 0 5•AV- 2 7
Voice activated control does not operate • Microphone
• Steering switch
• AV control unit •
AV- 1 0 7•AV- 1 0 5
•AV- 2 7
Symptom Possible causeReference page
Inoperative • Rear view camera control unit power and ground circuit
• Reverse signal circuit
• Camera ON signal circuit
• Camera image signal circuit (rear view camera to rear
view camera control unit)
• Camera image signal circuit (rear view camera control unit to AV control unit)
• Rear view camera control unit •
AV- 7 2
•AV- 1 5 1
•AV- 1 5 1
•AV- 1 5 1
•AV- 1 5 1
•AV- 1 5 1
Revision: December 20092009 QX56

AV
PRECAUTIONSAV-165
< PRECAUTION > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000005851882
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and w hether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SR and SB section of this Service Man-
ual.
WARNING:
• To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Un it or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or el ectric power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service.
Precaution Necessary for Steering Wheel Rotation After Battery Disconnect
INFOID:0000000005851883
NOTE:
• This Procedure is applied only to models with Intelligent Key system and NATS (NISSAN ANTI-THEFT SYS-
TEM).
• Remove and install all control units after disconnecti ng both battery cables with the ignition knob in the
″ LOCK ″ position.
• Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NATS , an electrically controlled steering lock mech-
anism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery power is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables. NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ″ACC ″ position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be
rotated.
4. Perform the necessary repair operation.
Revision: December 20092009 QX56

BCS-2
COMB SW .................................................................24
COMB SW : CONSULT-III Function (BCM -
COMB SW) .............................................................
24
IMMU ...................................................................... ...25
IMMU : CONSULT-III Function (BCM - IMMU) .......25
BATTERY SAVER ................................................. ...25
BATTERY SAVER : CONSULT-III Function (BCM
- BATTERY SAVER) ........................................... ...
25
TRUNK ................................................................... ...26
TRUNK : CONSULT-III Function (BCM - TRUNK) ...26
RETAINED PWR .................................................... ...26
RETAINED PWR : CONSULT-III Function (BCM -
RETAINED PWR) ...................................................
26
SIGNAL BUFFER ................................................... ...26
SIGNAL BUFFER : CONSULT-III Function (BCM
- SIGNAL BUFFER) ................................................
26
AIR PRESSURE MONITOR ................................... ...27
AIR PRESSURE MONITOR : Diagnosis Descrip-
tion ..........................................................................
27
AIR PRESSURE MONITOR : CONSULT-III Func-
tion ..........................................................................
28
THEFT ALM ........................................................... ...29
THEFT ALM : CONSULT-III Function (BCM -
THEFT ALM) ..........................................................
29
COMPONENT DIAGNOSIS ........................30
U1000 CAN COMM CIRCUIT ......................... ...30
Description ........................................................... ...30
DTC Logic ...............................................................30
Diagnosis Procedure ..............................................30
U1010 CONTROL UNIT (CAN) .........................31
DTC Logic ............................................................ ...31
Diagnosis Procedure ..............................................31
Special Repair Requirement ...................................31
POWER SUPPLY AND GROUND CIRCUIT .....32
Diagnosis Procedure ............................................ ...32
COMBINATION SWITCH INPUT CIRCUIT .......33
Diagnosis Procedure ............................................ ...33
Special Repair Requirement ...................................34
COMBINATION SWITCH OUTPUT CIRCUIT ...35
Diagnosis Procedure ...............................................35
Special Repair Requirement ...................................35
COMBINATION SWITCH ..................................36
Description ........................................................... ...36
Diagnosis Procedure ...............................................36
ECU DIAGNOSIS .......................................38
BCM (BODY CONTROL MODULE) ............... ...38
Reference Value .................................................. ...38
Terminal Layout ......................................................40
Physical Values .......................................................40
Wiring Diagram .......................................................46
Fail Safe .................................................................50
DTC Inspection Priority Chart ...............................51
DTC Index ..............................................................51
SYMPTOM DIAGNOSIS ............................53
COMBINATION SWITCH SYSTEM SYMP-
TOMS .............................................................. ...
53
Symptom Table .................................................... ...53
PRECAUTION ............................................54
PRECAUTIONS .............................................. ...54
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" .............................................................. ...
54
Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect ..................................
54
ON-VEHICLE REPAIR ...............................56
BCM (BODY CONTROL MODULE) ............... ...56
Removal and Installation ...................................... ...56
Revision: December 20092009 QX56

BCS
POWER CONSUMPTION CONTROL SYSTEMBCS-15
< FUNCTION DIAGNOSIS > [BCM]
C
D
E
F
G H
I
J
K L
B A
O P
N
Component Parts LocationINFOID:0000000003776386
1. Steering column
(view with instru-
ment panel removed) 2. BCM M18, M19, M20 3. Combination meter M24
4. IPDM E/R E119, E120, E121, E122, E123, E124 5. Intelligent Key unit M70 (view with in-
strument panel removed)
ALMIA0418ZZ
Revision: December 20092009 QX56

BCS-54
< PRECAUTION >[BCM]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint S
ystem (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000005851887
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and w hether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SR and SB section of this Service Man-
ual.
WARNING:
 To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISS AN/INFINITI dealer.
 Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
 Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
 When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
 When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery, and wait at least 3 minu tes before performing any service.
Precaution Necessary for Steering W heel Rotation After Battery Disconnect
INFOID:0000000005851888
NOTE:
 This Procedure is applied only to models with Intelli gent Key system and NATS (NISSAN ANTI-THEFT SYS-
TEM).
 Remove and install all control units after disconnecting both battery cables with the ignition knob in the
″LOCK ″ position.
 Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NATS, an electrically controlled steering lock mech-
anism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery pow er is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables. NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ″ACC ″ position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be
rotated.
4. Perform the necessary repair operation.
Revision: December 20092009 QX56

PRECAUTIONSBR-3
< PRECAUTION >
C
DE
G H
I
J
K L
M A
B
BR
N
O P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000005864602
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and w hether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SR and SB section of this Service Man-
ual.
WARNING:
• To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Un it or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or el ectric power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service.
Precaution Necessary for Steering Wheel Rotation After Battery Disconnect
INFOID:0000000005864603
NOTE:
• This Procedure is applied only to models with Intelligent Key system and NATS (NISSAN ANTI-THEFT SYS-
TEM).
• Remove and install all control units after disconnecti ng both battery cables with the ignition knob in the
″ LOCK ″ position.
• Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NATS , an electrically controlled steering lock mech-
anism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery power is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables. NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ″ACC ″ position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be
rotated.
4. Perform the necessary repair operation.
Revision: December 20092009 QX56

BRAKE TUBE AND HOSEBR-21
< ON-VEHICLE REPAIR >
C
DE
G H
I
J
K L
M A
B
BR
N
O P
BRAKE TUBE AND HOSE
Hydraulic CircuitINFOID:0000000004042335
CAUTION:
• All hoses and piping (tubes) must be fr ee from excessive bending, twisting and pulling.
• Make sure there is no interference with other parts when turning the steering wheel both clockwise
and counterclockwise.
• The brake piping is an important safety part. If a brake fluid leak is detected, always disassemble the
parts. Replace applicable part with a new one, if necessary.
• Be careful not to splash brake fluid on painted areas; it may cause paint damage. If brake fluid is
splashed on painted areas, wash it away with water immediately.
• Do not bend or twist brake hose sharply, or strongly pull it.
• When removing components, cover connections so that no dirt, dust, or other foreign matter gets in.
• Refill with new specified brake fluid. Refer to MA-12, "
Fluids and Lubricants".
• Do not reuse drained brake fluid.
Removal and Installation of Fr ont Brake Piping and Brake HoseINFOID:0000000004042332
REMOVAL
1. Remove wheel and tire assembly using power tools.
2. Drain brake fluid. Refer to BR-17, "
Drain and Refill".
1. Actuator 2. Master cylinder3. Brake booster
4. Connector A. Union bolt
18.2 N·m (1.9 kg-m, 13 ft-lb) B. Flare nut M12
18.2 N·m (1.9 kg-m, 13 ft-lb)
C. Flare nut M10 13.0 N·m (1.3 kg-m, 10 ft-lb)
AWFIA0411ZZ
Revision: December 20092009 QX56
