Page 206 of 4171
![INFINITI QX56 2009 Factory Service Manual AV-20
< FUNCTION DIAGNOSIS >[AUDIO SYSTEM]
REAR VIEW MONITOR SYSTEM
Component Description
INFOID:0000000003776779
10. Rear audio remote control unit R204 11. Microphone R109 12. Front door speaker
LH](/img/42/57031/w960_57031-205.png "INFINITI QX56 2009 Factory Service Manual AV-20
< FUNCTION DIAGNOSIS >[AUDIO SYSTEM]
REAR VIEW MONITOR SYSTEM
Component Description
INFOID:0000000003776779
10. Rear audio remote control unit R204 11. Microphone R109 12. Front door speaker
LH")
AV-20
< FUNCTION DIAGNOSIS >[AUDIO SYSTEM]
REAR VIEW MONITOR SYSTEM
Component Description
INFOID:0000000003776779
10. Rear audio remote control unit R204 11. Microphone R109 12. Front door speaker
LH D12
RH D112
13. Rear door tweeter LH D208
RH D308 14. Rear door speaker
LH D207
RH D307 15. Back door speaker
LH D518
RH D716
16. Subwoofer B72 (under driver’s seat) 17. BOSE speaker amp M112, M113 (view behind instrument panel above
accelerator pedal)18. Rear view camera control unit B73
(located behind luggage finisher LHl)
19. Rear view camera D504
Part name Description
AV control unit Communication signal is sent from rear view camera control unit
Rear view camera control unit • Receives reverse signal from back-up lamp relay
• Receives rear view camera image signal
• Sends camera ON signal to rear view camera
• Sends image signal to display unit
Rear view camera • Receives camera ON signal from rear view camera control unit
• Sends image signal to rear view camera control unit
Display unit Recieves and displays image signal from rear view camera control unit
Revision: December 20092009 QX56
Page 343 of 4171
![INFINITI QX56 2009 Factory Service Manual AV
NORMAL OPERATING CONDITIONAV-157
< SYMPTOM DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000003776899
AUDIO SYSTEM
The majority of the au](/img/42/57031/w960_57031-342.png "INFINITI QX56 2009 Factory Service Manual AV
NORMAL OPERATING CONDITIONAV-157
< SYMPTOM DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000003776899
AUDIO SYSTEM
The majority of the au")
AV
NORMAL OPERATING CONDITIONAV-157
< SYMPTOM DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000003776899
AUDIO SYSTEM
The majority of the audio troubles are the result of outside causes (bad CD, electromagnetic interference,
etc.).
Noise
The following noise results from variations in field strength, such as fading noise and multi-path noise, or
external noise from trains and other sources. It is not a malfunction.
• Fading noise: This noise occurs because of variations in the field strength in a narrow range due to moun-
tains or buildings blocking the signal.
• Multi-path noise: This noise results from the waves sent directly from the broadcast station arriving at the antenna at a different time from the waves which reflect off mountains or buildings.
The vehicle itself can be a source of noise if noise prevention parts or electrical equipment is malfunctioning.
Check if noise is caused and/or changed by engine speed, ignition switch turned to each position, and opera-
tion of each piece of electrical equipment, and determine the cause.
NOTE:
The source of the noise can be found easily by listening to the noise while removing the fuses of electrical
components, one by one.
Type of Noise and Possible Cause
NAVIGATION SYSTEM
Basic Operation
Vehicle Mark
Occurrence condition Possible cause
Occurs only when engine is ON. A continuous growling noise occurs. The speed of
the noise varies with changes in the engine speed. • Ignition components
The occurrence of the noise is linked with the operation of the fuel pump. • Fuel pump condenser
Noise only occurs when various
electrical components are oper-
ating. A cracking or snapping sound occurs with the op-
eration of various switches.
• Relay malfunction, audio unit malfunction
The noise occurs when various motors are operat-
ing. • Motor case ground
•Motor
The noise occurs constantly, not just under certain conditions. • Rear defogger coil malfunction
• Open circuit in printed heater
• Poor ground of antenna feeder line
A cracking or snapping sound occurs while the vehicle is being driven, especially when
it is vibrating excessively. • Ground wire of body parts
• Ground due to improper part installation
• Wiring connections or a short circuit
Symptom
Cause Remedy
No image is shown. Display brightness adjustment is set fully to DARK
side. Adjust the display brightness.
No guide sound is heard.
Audio guide volume is too low or
too high. Volume control is set to OFF, MIN or MAX. Adjust the audio guide volume.
Audio guidance is not available while the vehicle is
driving on a dark pink route.
System is not malfunctioning.
Screen is too dark.
Motion of the image is too slow. Temperature inside the vehicle is low.
Wait until the temperature inside the vehicle
reaches the proper temperature.
Small black or bright spots appear
on the screen. Symptom peculiar to a liquid crystal display (dis-
play unit). System is not malfunction.
Revision: December 20092009 QX56
Page 479 of 4171
BRC-2
C1110, C1170 ABS ACTUATOR AND ELEC-
TRIC UNIT (CONTROL UNIT) ...........................
37
DTC Logic ...............................................................37
Diagnosis Procedure ..............................................37
Special Repair Requirement ...................................37
C1111 ABS MOTOR, MOTOR RELAY SYS-
TEM ................................................................. ...
38
Description ........................................................... ...38
DTC Logic ...............................................................38
Diagnosis Procedure ..............................................38
Component Inspection ............................................39
Special Repair Requirement ...................................39
C1113, C1145, C1146 YAW RATE/SIDE/DE-
CEL G SENSOR ............................................. ...
40
Description ........................................................... ...40
DTC Logic ...............................................................40
Diagnosis Procedure ..............................................40
Component Inspection ............................................41
Special Repair Requirement ...................................41
C1115 WHEEL SENSOR ................................ ...43
Description ........................................................... ...43
DTC Logic ...............................................................43
Diagnosis Procedure ..............................................43
Component Inspection ............................................44
Special Repair Requirement ...................................45
C1116 STOP LAMP SWITCH ......................... ...46
Description ........................................................... ...46
DTC Logic ...............................................................46
Diagnosis Procedure ..............................................46
Special Repair Requirement ...................................47
C1120, C1122, C1124, C1126 IN ABS SOL .....48
Description ........................................................... ...48
DTC Logic ...............................................................48
Diagnosis Procedure ..............................................48
Component Inspection ............................................49
Special Repair Requirement ...................................50
C1121, C1123, C1125, C1127 OUT ABS SOL ...51
Description ........................................................... ...51
DTC Logic ...............................................................51
Diagnosis Procedure ..............................................51
Component Inspection ............................................52
Special Repair Requirement ...................................53
C1130, C1131, C1132, C1133, C1136 EN-
GINE SIGNAL ................................................. ...
54
Description ........................................................... ...54
DTC Logic ...............................................................54
Diagnosis Procedure ..............................................54
Special Repair Requirement ...................................54
C1140 ACTUATOR RLY ................................ ...56
Description ........................................................... ...56
DTC Logic ...............................................................56
Diagnosis Procedure ..............................................56
Component Inspection ......................................... ...57
Special Repair Requirement ...................................57
C1142 PRESS SENSOR ...................................58
Description ........................................................... ...58
DTC Logic ...............................................................58
Diagnosis Procedure ...............................................58
Component Inspection ............................................60
Special Repair Requirement ...................................60
C1143, C1144 STEERING ANGLE SENSOR ...61
Description ..............................................................61
DTC Logic ...............................................................61
Diagnosis Procedure ...............................................61
Component Inspection ............................................62
Special Repair Requirement ...................................62
C1155 BRAKE FLUID LEVEL SWITCH ...........64
Description ........................................................... ...64
DTC Logic ...............................................................64
Diagnosis Procedure ...............................................64
Component Inspection ............................................65
Special Repair Requirement ...................................65
C1156 ST ANG SEN COM CIR .........................67
Description ..............................................................67
DTC Logic ...............................................................67
Diagnosis Procedure ...............................................67
C1160 DECEL G SEN SET ...............................68
Description ..............................................................68
DTC Logic ...............................................................68
Diagnosis Procedure ...............................................68
C1163 ST ANGLE SEN SAFE ..........................69
Description ........................................................... ...69
DTC Logic ...............................................................69
Diagnosis Procedure ...............................................69
C1164, C1165, C1166, C1167 CV/SV SYS-
TEM ....................................................................
70
Description ........................................................... ...70
DTC Logic ...............................................................70
Diagnosis Procedure ...............................................70
Component Inspection ............................................71
Special Repair Requirement ...................................72
C1178, C1181, C1184, C1189 ABS ACTIVE
BOOSTER .........................................................
73
Description ........................................................... ...73
DTC Logic ...............................................................73
Diagnosis Procedure ...............................................73
Component Inspection ............................................74
Special Repair Requirement ...................................75
C1179 ABS DELTA S SEN NG .........................76
Description ........................................................... ...76
DTC Logic ...............................................................76
Diagnosis Procedure ...............................................76
Component Inspection ............................................77
Special Repair Requirement ...................................77
Revision: December 20092009 QX56
Page 491 of 4171
![INFINITI QX56 2009 Factory Service Manual BRC-14
< FUNCTION DIAGNOSIS >[VDC/TCS/ABS]
VDC
Component Description
INFOID:0000000003772487
1. Front wheel sensor LH E18
RH E117 2. ABS actuator and electric unit (con-
trol unit) E125 3. Combination](/img/42/57031/w960_57031-490.png "INFINITI QX56 2009 Factory Service Manual BRC-14
< FUNCTION DIAGNOSIS >[VDC/TCS/ABS]
VDC
Component Description
INFOID:0000000003772487
1. Front wheel sensor LH E18
RH E117 2. ABS actuator and electric unit (con-
trol unit) E125 3. Combination")
BRC-14
< FUNCTION DIAGNOSIS >[VDC/TCS/ABS]
VDC
Component Description
INFOID:0000000003772487
1. Front wheel sensor LH E18
RH E117 2. ABS actuator and electric unit (con-
trol unit) E125 3. Combination meter M23, M24
4. Rear wheel sensor LH C11
RH C10 5. Yaw rate/side/decel G sensor M108 6. Steering angle sensor M17
7. VDC OFF switch M253 8. Active booster E499. Delta stroke sensor E114
10. Brake fluid level switch E21 11. Front pressure sensor E31 12. Rear pressure sensor E32
Component parts Reference
ABS actuator and electric unit (control unit) Pump
BRC-38, "
Description"Motor
Actuator relayBRC-56, "
Description"
Solenoid valveBRC-48, "Description"
VDC switch-over valve
(CV1, CV2, SV1, SV2)BRC-70, "Description"
Wheel sensor
BRC-29, "Description"
Yaw rate/side/decel G sensorBRC-40, "Description"
Steering angle sensorBRC-61, "Description"
VDC OFF switchBRC-81, "Description"
ABS warning lampBRC-83, "Description"
Brake warning lampBRC-84, "Description"
VDC OFF indicator lampBRC-85, "Description"
SLIP indicator lampBRC-86, "Description"
Front pressure sensor
BRC-58, "Description"Rear pressure sensor
Active boosterBRC-73, "
Description"
Delta stroke sensorBRC-76, "Description"
Revision: December 20092009 QX56
Page 494 of 4171
![INFINITI QX56 2009 Factory Service Manual TCS
BRC-17
< FUNCTION DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Component DescriptionINFOID:0000000003772491
1. Front wheel sensor LH E18
RH E117 2. ABS actuator and electric unit (c](/img/42/57031/w960_57031-493.png "INFINITI QX56 2009 Factory Service Manual TCS
BRC-17
< FUNCTION DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Component DescriptionINFOID:0000000003772491
1. Front wheel sensor LH E18
RH E117 2. ABS actuator and electric unit (c")
TCS
BRC-17
< FUNCTION DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Component DescriptionINFOID:0000000003772491
1. Front wheel sensor LH E18
RH E117 2. ABS actuator and electric unit (con-
trol unit) E125 3. Combination meter M23, M24
4. Rear wheel sensor LH C11
RH C10 5. Yaw rate/side/decel G sensor M108 6. Steering angle sensor M17
7. VDC OFF switch M253 8. Active booster E499. Delta stroke sensor E114
10. Brake fluid level switch E21 11. Front pressure sensor E31 12. Rear pressure sensor E32
Component parts Reference
ABS actuator and electric unit (control unit)Pump
BRC-38, "
Description"Motor
Actuator relayBRC-56, "
Description"
Solenoid valveBRC-48, "Description"
VDC switch-over valve
(CV1, CV2, SV1, SV2)BRC-70, "Description"
Wheel sensor
BRC-29, "Description"
Yaw rate/side/decel G sensorBRC-40, "Description"
Steering angle sensorBRC-61, "Description"
VDC OFF switchBRC-81, "Description"
ABS warning lampBRC-83, "Description"
Brake warning lampBRC-84, "Description"
VDC OFF indicator lampBRC-85, "Description"
SLIP indicator lampBRC-86, "Description"
Front pressure sensor
BRC-58, "Description"Rear pressure sensor
Active boosterBRC-73, "
Description"
Delta stroke sensorBRC-76, "Description"
Revision: December 20092009 QX56
Page 497 of 4171
![INFINITI QX56 2009 Factory Service Manual BRC-20
< FUNCTION DIAGNOSIS >[VDC/TCS/ABS]
ABS
Component Description
INFOID:0000000003772495
1. Front wheel sensor LH E18
RH E117 2. ABS actuator and electric unit (con-
trol unit) E125 3. Combination](/img/42/57031/w960_57031-496.png "INFINITI QX56 2009 Factory Service Manual BRC-20
< FUNCTION DIAGNOSIS >[VDC/TCS/ABS]
ABS
Component Description
INFOID:0000000003772495
1. Front wheel sensor LH E18
RH E117 2. ABS actuator and electric unit (con-
trol unit) E125 3. Combination")
BRC-20
< FUNCTION DIAGNOSIS >[VDC/TCS/ABS]
ABS
Component Description
INFOID:0000000003772495
1. Front wheel sensor LH E18
RH E117 2. ABS actuator and electric unit (con-
trol unit) E125 3. Combination meter M23, M24
4. Rear wheel sensor LH C11
RH C10 5. Yaw rate/side/decel G sensor M108 6. Steering angle sensor M17
7. VDC OFF switch M253 8. Active booster E499. Delta stroke sensor E114
10. Brake fluid level switch E21 11. Front pressure sensor E31 12. Rear pressure sensor E32
Component parts Reference
ABS actuator and electric unit (control unit) Pump
BRC-38, "
Description"Motor
Actuator relayBRC-56, "
Description"
Solenoid valveBRC-48, "Description"
Wheel sensor BRC-29, "Description"
ABS warning lampBRC-83, "Description"
Brake warning lampBRC-84, "Description"
Revision: December 20092009 QX56
Page 500 of 4171
![INFINITI QX56 2009 Factory Service Manual EBD
BRC-23
< FUNCTION DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Component DescriptionINFOID:0000000003772499
1. Front wheel sensor LH E18
RH E117 2. ABS actuator and electric unit (c](/img/42/57031/w960_57031-499.png "INFINITI QX56 2009 Factory Service Manual EBD
BRC-23
< FUNCTION DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Component DescriptionINFOID:0000000003772499
1. Front wheel sensor LH E18
RH E117 2. ABS actuator and electric unit (c")
EBD
BRC-23
< FUNCTION DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Component DescriptionINFOID:0000000003772499
1. Front wheel sensor LH E18
RH E117 2. ABS actuator and electric unit (con-
trol unit) E125 3. Combination meter M23, M24
4. Rear wheel sensor LH C11
RH C10 5. Yaw rate/side/decel G sensor M108 6. Steering angle sensor M17
7. VDC OFF switch M253 8. Active booster E499. Delta stroke sensor E114
10. Brake fluid level switch E21 11. Front pressure sensor E31 12. Rear pressure sensor E32
Component parts Reference
ABS actuator and electric unit (control unit)Pump
BRC-38, "
Description"Motor
Actuator relayBRC-56, "
Description"
Solenoid valveBRC-48, "Description"
Wheel sensor BRC-29, "Description"
ABS warning lampBRC-83, "Description"
Brake warning lampBRC-84, "Description"
Revision: December 20092009 QX56
Page 502 of 4171
![INFINITI QX56 2009 Factory Service Manual DIAGNOSIS SYSTEM [ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
BRC-25
< FUNCTION DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
RR LH SENSOR
(km/h, MPH) ××× Wheel speed calculated](/img/42/57031/w960_57031-501.png "INFINITI QX56 2009 Factory Service Manual DIAGNOSIS SYSTEM [ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
BRC-25
< FUNCTION DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
RR LH SENSOR
(km/h, MPH) ××× Wheel speed calculated")
DIAGNOSIS SYSTEM [ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
BRC-25
< FUNCTION DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
RR LH SENSOR
(km/h, MPH) ××× Wheel speed calculated by rear LH
wheel sensor signal is displayed.
BATTERY VOLT
(V) ××× Voltage supplied to ABS actuator
and electric unit (control unit) is dis-
played.
N POSI SIG
(ON/OFF) ––
×Shift position (ON/OFF) judged by
transmission range switch signal.
P POSI SIG
(ON/OFF) ––
×Shift position (ON/OFF) judged by
transmission range switch signal.
ACCEL POS SIG
(%) ×
– ×Throttle valve open/close status
judged by CAN communication sig-
nal is displayed.
ENGINE SPEED
(rpm) ×××
Engine speed judged by CAN com-
munication signal is displayed.
STR ANGLE SIG
(deg) ×
– ×Steering angle detected by steering
angle sensor is displayed.
YAW RATE SEN
(d/s) ××× Yaw rate detected by yaw rate sen-
sor is displayed.
SIDE G-SENSOR
(m/s
2) ×
– ×Transverse acceleration detected
by side G-sensor is displayed.
STOP LAMP SW
(ON/OFF) ××× Stop lamp switch (ON/OFF) status
is displayed.
OFF SW
(ON/OFF) ×××
VDC OFF switch (ON/OFF) status
is displayed.
ABS WARN LAMP
(ON/OFF) –
×× ABS warning lamp (ON/OFF) status
is displayed.
SLIP LAMP
(ON/OFF) –
×× SLIP indicator lamp (ON/OFF) sta-
tus is displayed.
FR LH IN SOL
(ON/OFF) –
×× Front LH IN ABS solenoid (ON/
OFF) status is displayed.
FR LH OUT SOL
(ON/OFF) –
×× Front LH OUT ABS solenoid (ON/
OFF) status is displayed.
RR RH IN SOL
(ON/OFF) –
×× Rear RH IN ABS solenoid (ON/
OFF) status is displayed.
RR RH OUT SOL
(ON/OFF) –
×× Rear RH OUT ABS solenoid (ON/
OFF) status is displayed.
FR RH IN SOL
(ON/OFF) –
×× Front RH IN ABS solenoid (ON/
OFF) status is displayed.
FR RH OUT SOL
(ON/OFF) –
×× Front RH OUT ABS solenoid (ON/
OFF) status is displayed.
RR LH IN SOL
(ON/OFF) –
×× Rear LH IN ABS solenoid (ON/OFF)
status is displayed.
RR LH OUT SOL
(ON/OFF) –
×× Rear LH OUT ABS solenoid (ON/
OFF) status is displayed.
OFF LAMP
(ON/OFF) –
×× OFF Lamp (ON/OFF) status is dis-
played.
MOTOR RELAY
(ON/OFF) –
×× ABS motor relay signal (ON/OFF)
status is displayed.
ACTUATOR RLY
(ON/OFF) –
×× ABS actuator relay signal (ON/OFF)
status is displayed.
Item
(Unit) Data monitor item selection
Remarks
ECU INPUT
SIGNALS MAIN
SIGNALS SELE
C
TION
FROM MENU
Revision: December 20092009 QX56
Page 504 of 4171
![INFINITI QX56 2009 Factory Service Manual DIAGNOSIS SYSTEM [ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
BRC-27
< FUNCTION DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
× : Applicable
–: Not applicable
ACTIVE TEST MODE
CAU](/img/42/57031/w960_57031-503.png "INFINITI QX56 2009 Factory Service Manual DIAGNOSIS SYSTEM [ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
BRC-27
< FUNCTION DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
× : Applicable
–: Not applicable
ACTIVE TEST MODE
CAU")
DIAGNOSIS SYSTEM [ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
BRC-27
< FUNCTION DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
× : Applicable
–: Not applicable
ACTIVE TEST MODE
CAUTION:
• Do not perform active test while driving vehicle.
• Make sure to completely bleed air from brake system.
• The active test cannot be performed with the ABS warning lamp, VDC OFF indicator lamp, SLIP indi-
cator lamp or brake warning lamp on.
• ABS warning lamp, VDC OFF indicator lamp, SLIP indicator lamp and brake warning lamp are on
during active test.
NOTE:
• When active test is performed while depressing the pedal, the pedal depression amount will change. This is normal. (Only solenoid valve and ABS motor.)
• “TEST IS STOPPED” is displayed 10 seconds after operation start.
• After “TEST IS STOPPED” is displayed, to perform test again, touch BACK.
Test Item
SOLENOID VALVE
• When performing an active test of the ABS function, select the “MAIN SIGNALS” for each test item. In addi- tion, when performing an active test of the VDC/TCS f unction, select the item menu for each test item.
• For ABS solenoid valve, touch “UP”, “KEEP”, and “D OWN” on the display screen. For ABS solenoid valve
(ACT), touch “UP”, “ACT UP”, “ACT KEEP” and confirm that solenoid valv es operate as shown in the table
below.
RELEASE SW NO
(ON/OFF) ––
×Release switch signal (ON/OFF)
status is displayed. “ON” indicates
that the brake pedal is depressed.
“OFF”“ is that the brake pedal is re-
leased.
RELEASE SW NC
(ON/OFF) ––
×Release switch signal (ON/OFF)
status is displayed. “OFF” indicates
that the brake pedal is depressed
on. “ON” is that the brake pedal is
released.
OHB FAIL
(ON/OFF) ––
×OHB fail status (ON/OFF) is dis-
played.
HBA FAIL
(ON/OFF) ––
×HBA fail status (ON/OFF) is dis-
played.
OHB SIG
(ON/OFF) ––
×OHB operation (ON/OFF) status is
displayed.
HBA SIG
(ON/OFF) ––
×HBA operation (ON/OFF) status is
displayed.
STP OFF RLY
(ON/OFF) ––
×Stop lamp relay signal (ON/OFF)
status is displayed.
Item
(Unit) Data monitor item selection
Remarks
ECU INPUT
SIGNALS MAIN
SIGNALS SELECTION
FROM MENU
Operation ABS solenoid valve
ABS solenoid valve (ACT)
UP KEEP DOWN UP ACTUA-
TOR UP ACTUA-
TOR KEEP
FR RH SOL
FR RH ABS SOLE-
NOID (ACT) FR RH IN SOL
OFF ON ON OFF OFF OFF
FR RH OUT SOL OFF OFF ON* OFF OFF OFF
FR LH SOL
FR LH ABS SOLE-
NOID (ACT) FR LH IN SOL
OFF ON ON OFF OFF OFF
FR LH OUT SOL OFF OFF ON* OFF OFF OFF
Revision: December 20092009 QX56
Page 505 of 4171
![INFINITI QX56 2009 Factory Service Manual BRC-28
< FUNCTION DIAGNOSIS >[VDC/TCS/ABS]
DIAGNOSIS SYSTEM [
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
*: ON for 1 to 2 seconds after the touch, and then OFF
ABS MOTOR• Touch “ON” and “](/img/42/57031/w960_57031-504.png "INFINITI QX56 2009 Factory Service Manual BRC-28
< FUNCTION DIAGNOSIS >[VDC/TCS/ABS]
DIAGNOSIS SYSTEM [
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
*: ON for 1 to 2 seconds after the touch, and then OFF
ABS MOTOR• Touch “ON” and “")
BRC-28
< FUNCTION DIAGNOSIS >[VDC/TCS/ABS]
DIAGNOSIS SYSTEM [
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
*: ON for 1 to 2 seconds after the touch, and then OFF
ABS MOTOR• Touch “ON” and “OFF” on screen. Make sure motor relay and actuator relay operates as shown in table
below.
BOOSTER DRIVE
• Touch “UP” and “DOWN” on the screen. Check that booster drive operates as shown in table below.
CAUTION:
Perform active test subject to the conditions below.
• Do not operate brake pedal during active test.
• Make sure the engine revo lution is over 500 rpm.
• Make sure the vehicle is not moving.
RR RH SOL
RR RH ABS SOLE-
NOID (ACT) RR RH IN SOL
OFF ON ON OFF OFF OFF
RR RH OUT SOL OFF OFF ON* OFF OFF OFF
RR LH SOL
RR LH ABS SOLE-
NOID (ACT) RR LH IN SOL
OFF ON ON OFF OFF OFF
RR LH OUT SOL OFF OFF ON* OFF OFF OFF
REAR SOL RR RH IN SOL
OFF ON ON OFF OFF OFF
RR RH OUT SOL OFF OFF ON* OFF OFF OFF
RR LH IN SOL OFF ON ON OFF OFF OFF
RR LH OUT SOL OFF OFF ON* OFF OFF OFF
Operation ONOFF
MOTOR RELAY ONOFF
ACTUATOR RLY ONON
Operation UPDOWN
STOP LAMP SW ONOFF
BST OPER SIG ONOFF
PRESS SENSOR 50 ± 5 bar 0 bar
PRESS SEN 2 50 ± 5 bar 0 bar
STP OFF RLY OFFOFF
Operation
ABS solenoid valve
ABS solenoid valve (ACT)
UP KEEP DOWN UP ACTUA-
TOR UP ACTUA-
TOR KEEP
Revision: December 20092009 QX56
