RECLINING SWITCHADP-53
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
RECLINING SWITCH
DescriptionINFOID:0000000005147486
Reclining switch is equipped to the power seat switch LH on the seat cushion trim cover. The operation signal
is input to the driver seat control unit when the reclining switch is operated.
Component Function CheckINFOID:0000000005147487
1. CHECK FUNCTION
1. Select “RECLN SW-FR”, “RECLN SW-RR” in “Data monitor” mode with CONSULT-III.
2. Check reclining switch signal under the following conditions.
Is the indication normal?
YES >> Inspection End.
NO >> Perform diagnosis procedure. Refer to ADP-53, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000005147488
Regarding Wiring Diagram information, refer to ADP-119, "Wiring Diagram".
1. CHECK RECLINING SWITCH SIGNAL
1. Turn ignition switch OFF.
2. Check voltage between driver s eat control unit harness connec-
tor and ground.
Is the inspection result normal?
YES >> GO TO 5
NO >> GO TO 2
2. CHECK RECLINING SWITCH CIRCUIT
Monitor item ConditionStatus
RECLN SW-FR Reclining switch (forward) Operate
ON
Release OFF
RECLN SW-RR Reclining switch (backward) Operate
ON
Release OFF
Driver seat
control unit
connector Te r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (–)
B202 12
Ground Reclining
switch Operate
(backward) 0
Release Battery voltage
27 Operate
(forward) 0
Release Battery voltage
PIIA4580E
Revision: April 20092010 QX56

ADP-56
< COMPONENT DIAGNOSIS >
LIFTING SWITCH (FRONT)
LIFTING SWITCH (FRONT)
DescriptionINFOID:0000000005147490
Lifting switch (front) is equipped to the power seat switch LH on the seat cushion trim cover. The operation sig-
nal is input to the driver seat control uni t when the lifting switch (front) is operated.
Component Function CheckINFOID:0000000005147491
1. CHECK FUNCTION
1. Select “LIFT FR SW-UP”, “LIFT FR SW-DN” in “DATA MONITOR” mode with CONSULT-III.
2. Check lifting switch (front) signal under the following conditions.
Is the indication normal?
YES >> Inspection End.
NO >> Perform diagnosis procedure. Refer to ADP-56, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000005147492
Regarding Wiring Diagram information, refer to ADP-119, "Wiring Diagram".
1. CHECK LIFTING SWITCH SIGNAL
1. Turn ignition switch OFF.
2. Check voltage between driver seat control unit harness connec- tor and ground.
Is the inspection result normal?
YES >> GO TO 5
NO >> GO TO 2
2. CHECK LIFTING SW ITCH (FRONT) CIRCUIT
Monitor item ConditionStatus
LIFT FR SW-UP Lifting switch front (up) Operate
ON
Release OFF
LIFT FR SW-DN Lifting switch front (down) Operate
ON
Release OFF
Driver seat
control unit
connector Te r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (–)
B202 13
Ground Lifting
switch (front) Operate
(down) 0V
Release Battery
voltage
28 Operate (up) 0V
Release Battery
voltage
PIIA4583E
Revision: April 20092010 QX56

LIFTING SWITCH (REAR)ADP-59
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
LIFTING SWITCH (REAR)
DescriptionINFOID:0000000005147494
Lifting switch (rear) is equipped to the power seat switch LH on the seat cushion trim cover. The operation sig-
nal is inputted to the driver seat control unit when the lifting switch (rear) is operated.
Component Function CheckINFOID:0000000005147495
1. CHECK FUNCTION
1. Select “LIFT RR SW-UP”, “LIFT RR SW-DN” in “Data monitor” mode with CONSULT-III.
2. Check lifting switch (rear) signal under the following conditions.
Is the indication normal?
YES >> Inspection End.
NO >> Perform diagnosis procedure. Refer to ADP-59, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000005147496
Regarding Wiring Diagram information, refer to ADP-119, "Wiring Diagram".
1. CHECK LIFTING SWITCH (REAR) SIGNAL
1. Turn ignition switch OFF.
2. Check voltage between driver s eat control unit harness connec-
tor and ground.
Is the inspection result normal?
YES >> GO TO 5
NO >> GO TO 2
2. CHECK LIFTING SWITCH (REAR) CIRCUIT
Monitor item ConditionStatus
LIFT RR SW-UP Lifting switch rear (up) Operate
ON
Release OFF
LIFT RR SW-DN Lifting switch rear (down) Operate
ON
Release OFF
Driver seat
control unit
connector Te r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (–)
B202 14
Ground Lifting
switch (rear) Operate (down) 0
Release Battery voltage
29 Operate (up) 0
Release Battery voltage
PIIA4586E
Revision: April 20092010 QX56

ADP-62
< COMPONENT DIAGNOSIS >
TILT SWITCH
TILT SWITCH
DescriptionINFOID:0000000005147498
ADP steering switch is equipped to the steering column. The operation signal is input to the automatic drive
positioner control unit when the ADP steering switch is operated.
Component Function CheckINFOID:0000000005147499
1. CHECK FUNCTION
1. Select “TILT SW-UP”, “TILT SW-DN” in “Data monitor” mode with CONSULT-III.
2. Check tilt switch signal under the following conditions.
Is the indication normal?
YES >> Inspection End.
NO >> Perform diagnosis procedure. Refer to ADP-62, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000005147500
Regarding Wiring Diagram information, refer to ADP-138, "Wiring Diagram".
1. CHECK ADP STEERING SWITCH SIGNAL
1. Turn ignition switch OFF.
2. Check voltage between automatic drive positioner control unit connector and ground.
Is the inspection result normal?
YES >> GO TO 4
NO >> GO TO 2
2. CHECK ADP STEERING SWITCH HARNESS CONTINUITY
Monitor item ConditionStatus
TILT SW-UP Tilt switch (up) Operate
ON
Release OFF
TILT SW-DN Tilt switch (down) Operate
ON
Release OFF
ConnectorTe r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (-)
M33 1
Ground ADP steering switch ON (UP
operation)
0
Other than above 5
17 ADP steering switch ON
(DOWN operation)
0
Other than above 5
LIIA0491E
Revision: April 20092010 QX56

PEDAL ADJUSTING SWITCHADP-65
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
PEDAL ADJUSTING SWITCH
DescriptionINFOID:0000000005147502
Pedal adjusting switch is on the instrument panel. The operation signal is input to the driver seat control unit
when the pedal adjusting switch is operated. The pedal adjusting switch signal is sent to the automatic drive
positioner control unit via UART communication.
Component Function CheckINFOID:0000000005147503
1. CHECK FUNCTION
1. Select “PEDAL SW-FR”, “PEDAL SW-RR” in “Data monitor” mode with CONSULT-III.
2. Check pedal adjusting switch signal under the following conditions.
Is the indication normal?
YES >> Inspection End.
NO >> Perform diagnosis procedure. Refer to ADP-65, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000005147504
Regarding Wiring Diagram information, refer to ADP-119, "Wiring Diagram".
1. CHECK PEDAL ADJUSTING SWITCH SIGNAL
1. Turn ignition switch OFF.
2. Check voltage between driver s eat control unit harness connec-
tor and ground.
Is the inspection result normal?
YES >> GO TO 5
NO >> GO TO 2
2. CHECK PEDAL ADJUSTING SWITCH CIRCUIT
Monitor item ConditionStatus
PEDAL SW-FR Pedal adjusting switch (forward) Operate
ON
Release OFF
PEDAL SW-RR Pedal adjusting switch (backward) Operate
ON
Release OFF
Driver seat
control unit connector Te r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (–)
B202 15
Ground Pedal ad-
justing switch Operate
(backward) 0
Release Battery
voltage
30 Operate
(forward) 0
Release Battery
voltage
PIIA4591E
Revision: April 20092010 QX56

ADP-68
< COMPONENT DIAGNOSIS >
SEAT MEMORY SWITCH
SEAT MEMORY SWITCH
DescriptionINFOID:0000000005147506
The seat memory switch is installed on the front door LH trim. The operation signal is input to the automatic
drive positioner control unit when the memory switch is operated.
Component Function CheckINFOID:0000000005147507
1. CHECK FUNCTION
1. Select “MEMORY SW 1”, “MEMORY SW 2”, "SET SW" in “Data monitor” mode with CONSULT-III.
2. Check seat memory switch signal under the following conditions.
Is the indication normal?
YES >> Inspection End.
NO >> Perform diagnosis procedure. Refer to ADP-68, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000005147508
Regarding Wiring Diagram information, refer to ADP-138, "Wiring Diagram".
1. CHECK MEMORY SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control unit and seat memory switch.
3. Check continuity between automatic drive positioner control unit harness connector and seat memory switch harness connector.
4. Check continuity between automatic drive positioner control unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair or replace harness.
Monitor item ConditionStatus
MEMORY SW1 Memory switch 1 Push
ON
Release OFF
MEMORY SW2 Memory switch 2 Push
ON
Release OFF
SET SW Set switch Push
ON
Release OFF
Automatic drive
positioner control unit connector Te r m i n a l
Seat memory
switch connector Terminal Continuity
M33 9
D5 1
Ye s
24 3
25 2
Automatic drive positioner control unit connector Terminal
GroundContinuity
M33 9
No
24
25
PIIA4576E
Revision: April 20092010 QX56

ADP-70
< COMPONENT DIAGNOSIS >
DOOR MIRROR REMOTE CONTROL SWITCH
DOOR MIRROR REMOTE CONTROL SWITCH
CHANGEOVER SWITCH
CHANGEOVER SWITCH : DescriptionINFOID:0000000005147510
Changeover switch is integrated into door mirror remote control switch.
Changeover switch has three positions (L, N and R).
It changes door mirror motor operation by transmitting cont rol signal to automatic drive positioner control unit.
CHANGEOVER SWITCH : Component Function CheckINFOID:0000000005147511
1. CHECK CHANGEOVER SWITCH FUNCTION
Check the operation on “MIR CHNG SW-R” or “MIR CHNG SW-L” in “DATA MONITOR” mode with CON-
SULT-III.
Refer to ADP-28, "
CONSULT-III Function".
Is the inspection result normal?
YES >> Changeover switch function is OK.
NO >> Refer to ADP-70, "
CHANGEOVER SWITCH : Diagnosis Procedure".
CHANGEOVER SWITCH : Diagnosis ProcedureINFOID:0000000005147512
Regarding Wirng Diagram information, refer to ADP-138, "Wiring Diagram".
1. CHECK CHANGEOVER SWITCH SIGNAL
1. Turn ignition switch to ACC.
2. Check voltage between automatic drive positioner control unit connector and ground.
Is the inspection result normal?
YES >> GO TO 6
NO >> GO TO 2
2. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect automatic drive posit ioner control unit and door mir-
ror remote control switch.
3. Check continuity between automat ic drive positioner control unit
connector and door mirror remote control switch connector.
Te r m i n a l s
Change over switch condition Voltage (V)
(Approx.)
(+)
(-)
Automatic drive
positioner control unit connector Te r m i n a l
M33 2
Ground RIGHT
0
Other than above 5
18 LEFT
0
Other than above 5
PIIA4767E
Automatic drive
positioner control unit connector Te r m i n a lDoor mirror re-
mote control
switch connector Terminal Continuity
M33 (A) 2
D10 (B) 11
Ye s
18 10
ALJIA0201ZZ
Revision: April 20092010 QX56

ADP-72
< COMPONENT DIAGNOSIS >
DOOR MIRROR REMOTE CONTROL SWITCH
CHANGEOVER SWITCH : Component Inspection
INFOID:0000000005147513
1. CHECK CHANGEOVER SWITCH
Check door mirror remote control switch.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace door mirror remote control switch. Refer to ADP-177, "
Removal and Installation".
MIRROR SWITCH
MIRROR SWITCH : DescriptionINFOID:0000000005147514
It operates angle of the door mirror face.
It transmits mirror face adjust operation to automatic drive positioner control unit.
MIRROR SWITCH : Component Function CheckINFOID:0000000005147515
1. CHECK MIRROR SWITCH FUNCTION
Check the operation on “MIR CON SW–UP/DN” and “MIR CON SW–RH/LH” in “DATA MONITOR” mode
with CONSULT-III.
Refer to ADP-28, "
CONSULT-III Function".
Is the inspection result normal?
YES >> Mirror switch function is OK.
NO >> Refer to ADP-72, "
MIRROR SWITCH : Diagnosis Procedure".
MIRROR SWITCH : Dia gnosis ProcedureINFOID:0000000005147516
Regarding Wiring Diagram information, refer to ADP-138, "Wiring Diagram".
1. CHECK MIRROR SWITCH FUNCTION
1. Turn ignition switch to ACC.
2. Check voltage between automatic drive positioner control unit connector and ground.
Te r m i n a l Change over switch
condition Continuity
Door mirror remote control switch
10 7LEFT
Yes
Other than above No
11 RIGHT
Yes
Other than above No
ALJIA0272ZZ
PIIA4771E
Revision: April 20092010 QX56

ADP-76
< COMPONENT DIAGNOSIS >
POWER SEAT SWITCH GROUND CIRCUIT
POWER SEAT SWITCH GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000005147518
Regarding Wiring Diagram information, refer to ADP-119, "Wiring Diagram".
1. CHECK POWER SEAT SWITCH LH GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect power seat switch LH.
3. Check continuity between power seat switch LH connector and ground.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-38, "Intermittent
Incident".
NO >> Repair or replace harness.
Power seat switch LH
connector Te r m i n a l
GroundContinuity
B208 7 Yes
ALJIA0316ZZ
Revision: April 20092010 QX56

DETENTION SWITCHADP-77
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
DETENTION SWITCH
DescriptionINFOID:0000000005147519
Park position switch is installed on A/T shift selector. It is turned OFF when the A/T selector lever is in P posi-
tion. The driver seat control unit judges that the A/T selector lever is in P position if cont\
inuity does not exist in
this circuit.
Component Function CheckINFOID:0000000005147520
1. CHECK FUNCTION
1. Select “DETENT SW” signal in “Data monitor” mode with CONSULT-III.
2. Check park position switch signal under the following conditions.
Is the indication normal?
YES >> Inspection End.
NO >> Perform diagnosis procedure. Refer to ADP-77, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000005147521
Regarding Wiring Diagram information, refer to ADP-119, "Wiring Diagram".
1. CHECK DTC WITH “BCM”
Check “Self Diagnostic Result” for BCM with CONSULT-lll.
Is any other DTC detected?
YES >> Check the DTC.
NO >> GO TO 2
2. CHECK PARK POSITION SWITCH INPUT SIGNAL
1. Turn ignition switch ON.
2. Mechanical key must be removed from the key switch.
3. Check voltage between driver seat control unit harness connec- tor and ground.
Is the inspection result normal?
YES >> GO TO 4
NO >> GO TO 3
3. CHECK PARK POSITION SWITCH CIRCUIT
Monitor item ConditionStatus
DETENT SW A/T selector lever P position
OFF
Other than
above ON
Driver seat
control unit connector Te r m i n a l
ConditionVoltage (V)
(Approx.)
(+) (-)
B202 21 Ground A/T selec-
tor leverP position
Battery volt-
age
Other than
above 0V
ALJIA0193ZZ
Revision: April 20092010 QX56
