3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect rear view camera control unit connector.
3. Check continuity between rear view camera control unit harness connector B31 terminal 3 and ground.
Does continuity exist?
YES >> Inspection End.
NO >> Repair harness or connector.
REAR VIEW CAMERA
REAR VIEW CAMERA : Diagnosis ProcedureINFOID:0000000005146307
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK POWER SUPPLY CIRCUIT (REAR VIEW CAMERA SIDE)
Check voltage between rear view camera harness connector D504
and ground.
Is voltage reading approximately 6 volts?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK POWER SUPPLY CIRCUIT (CONTINUITY)
1. Turn ignition switch OFF.
2. Disconnect rear view camera and rear view camera control unit connectors.
3. Check continuity between rear view camera harness connector D504 (A) terminal 1 and rear view camera control unit harness
connector B73 (B) terminal 8.
4. Check continuity between rear view camera harness connector D504 (A) terminal 1 and ground.
Are continuity test results as specified?
YES >> GO TO 3.
NO >> Repair harness or connector.
(+) (-) Continuity
Connector Terminal
B31 3 Ground Yes
ALLIA0245ZZ
Signal name Connector Terminal Transmission
position Value (Approx.)
Camera ON signal D504 1 Reverse 6V
ALLIA0243ZZ
AB
Continuity
Connector Terminal Connector Terminal
D504 1 B73 8 Yes
A —Continuity
Connector Terminal
D504 1 Ground No
ALLIA0246ZZ
Revision: April 20092010 QX56

AV-74
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
POWER SUPPLY AND GROUND CIRCUIT
3.CHECK POWER SUPPLY CIRCUIT (REAR
VIEW CAMERA CONTROL UNIT SIDE)
1. Connect rear view camera control unit harness connector.
2. Turn ignition switch ON.
3. Check voltage between rear view camera control unit harness connector B73 and ground.
Is voltage reading approximately 6 volts?
YES >> Inspection End.
NO >> Replace rear view camera control unit. Refer to AV-189,
"Removal and Installation".
4.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect rear view camera harness connector.
3. Check continuity between rear view camera harness connector D504 terminal 2 and ground.
Does continuity exist?
YES >> Inspection End.
NO >> Repair harness or connector.
DVD PLAYER
DVD PLAYER : Diagnosis ProcedureINFOID:0000000005146308
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK FUSE
Check that the DVD player fuse is not blown.
Is the fuse OK?
YES >> GO TO 2.
NO >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse.
2.POWER SUPPLY CIRCUIT CHECK
Signal name Connector Terminal Transmission
position Value (Approx.)
Camera ON signal B73 8 Reverse 6V
ALLIA0247ZZ
Signal nameContinuity
Ground Yes
ALLIA0248ZZ
UnitTerminal Signal name Fuse No.
DVD player 21
Battery power 31
24 Ignition switch ACC or ON 4
Revision: April 20092010 QX56

AV
POWER SUPPLY AND GROUND CIRCUITAV-75
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
1. Disconnect DVD player connector M205.
2. Check voltage between the DVD player connector M205 and ground.
Are the voltage results as specified?
YES >> GO TO 3.
NO >> • Check connector housings for disconnected or loose terminals. • Repair harness or connector.
3.GROUND CIRCUIT CHECK
1. Ignition OFF.
2. Check continuity between DVD player harness connector M205 terminal 5 and ground.
Are the continuity results as specified?
YES >> Inspection End.
NO >> Repair DVD player ground.
VIDEO MONITOR
VIDEO MONITOR : Diagnosis ProcedureINFOID:0000000005146309
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK POWER SUPPLY CIRCUIT
Check voltage between video monitor harness connector R202 and
ground.
Does specified voltage exist?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK POWER SUPPLY CIRCUIT
(+) (-) OFF ACC ON
Connector Terminal
M205 21
Ground Batter volt-
age Battery
voltage Battery volt-
age
24 0VBattery
voltage Battery volt-
age
ALNIA0325GB
(+) (-)Continuity
Connector Terminal
M205 5Ground Yes
ALNIA0326GB
Signal name Connector Terminal Ignition switch
position Value (Approx.)
Display B+ R202 11
ACC 12V
12
ALNIA0328GB
Revision: April 20092010 QX56

AV-76
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
POWER SUPPLY AND GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect the video monitor connector R202 and the DVD
player connector M205.
3. Check continuity between the video monitor harness connector R202 (A) and the DVD player connector M205 (B).
4. Check continuity between video monitor harness connector R202 (A) and ground.
Are continuity test results as specified?
YES >> Check DVD player power and ground supply. Refer to AV-68, "AV CONTROL UNIT : Diagnosis
Procedure".
NO >> Repair harness or connector.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect video monitor connector.
3. Check continuity between video monitor harness connector
R202 and ground.
Does continuity exist?
YES >> Inspection end.
NO >> Repair harness or connector.
MICROPHONE
MICROPHONE : Diagnosis ProcedureINFOID:0000000005146310
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK POWER SUPPLY CIRCUIT
Check voltage between microphone harness connector R109 termi-
nal 4 and ground.
Is approximately 5V present?
YES >> GO TO 3.
NO >> GO TO 2.
AB Continuity
Connector Terminal Connector Terminal
R202 11
M205 9
Ye s
12 25
A -Contin u it y
Connector Terminal
R202 11
Ground No
12
AWLIA1600ZZ
Connector Terminal Ignition switch position Continuity
R202 1
OFF Yes
2
ALNIA0329GB
Signal name Connector Terminal Ignition switch
position Value (Approx.)
MIC power R109 4ON 5V
WKIA5796E
Revision: April 20092010 QX56

AV-78
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
RGB (R: RED) SIGNAL CIRCUIT
RGB (R: RED) SIGNAL CIRCUIT
DescriptionINFOID:0000000005146311
Transmit the image displayed with audio control unit with RGB signal to the display unit.
Diagnosis ProcedureINFOID:0000000005146312
Regarding Wiring Diagram information, refer to
AV-116, "Wiring Diagram".
1.CHECK CONTINUITY RGB (R: RED) SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector M93 and AV control unit con- nector M43.
3. Check continuity between display unit harness connector M93 (A) terminal 17 and AV control unit harness connector M43 (B)
terminal 21.
4. Check continuity between display unit harness connector M93 (A) terminal 17 and ground.
Are the continuity results as specified?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK RGB (R: RED) SIGNAL
1. Connect display unit connector M93 and AV control unit connec- tor M43.
2. Turn ignition switch ON.
3. Check signal between display unit harness connector M93 ter- minal 17 and ground.
Are the voltage readings as specified?
YES >> Replace display unit. Refer to AV-171, "Removal and Installation".
NO >> Replace AV control unit. Refer to AV-169, "
Removal and Installation".
AB
Continuity
Connector Terminal Connector Terminal
M9317M4321 Yes
A —Continuity
Connector Terminal
M93 17Ground No
ALNIA0409GB
(+)
(-) Condition Reference signal
Connector Terminal
M93 17 Ground Receive
audio sig-
nal
ALNIA0383GB
SKIB2238J
Revision: April 20092010 QX56

AV
RGB (G: GREEN) SIGNAL CIRCUITAV-79
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
RGB (G: GREEN) SIGNAL CIRCUIT
DescriptionINFOID:0000000005146313
Transmit the image displayed with AV control unit with RGB signal to the display unit.
Diagnosis ProcedureINFOID:0000000005146314
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK CONTINUITY RGB (G: GREEN) SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector M93 and AV control unit con- nector M43.
3. Check continuity between display unit harness connector M93 (A) terminal 6 and AV control unit harness connector M43 (B)
terminal 22.
4. Check continuity between display unit harness connector M93 (A) terminal 6 and ground.
Are the continuity results as specified?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK RGB (G: GREEN) SIGNAL
1. Connect display unit connector M93 and AV control unit connec-
tor M43.
2. Turn ignition switch ON.
3. Check signal between display unit harness connector M93 ter- minal 6 and ground.
Are voltage readings as specified?
YES >> Replace display unit. Refer to AV-171, "Removal and Installation".
NO >> Replace AV control unit. Refer to AV-169, "
Removal and Installation".
AB
Continuity
Connector Terminal Connector Terminal
M93 6M43 22 Yes
A —Contin u it y
Connector Terminal
M93 6Ground No
ALNIA0410GB
(+)
(-) Condition Reference signal
Connector Terminal
M93 6 Ground Receive
audio sig-
nal
ALNIA0385GB
SKIB2236J
Revision: April 20092010 QX56

AV-80
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
RGB (B: BLUE) SIGNAL CIRCUIT
RGB (B: BLUE) SIGNAL CIRCUIT
DescriptionINFOID:0000000005146315
Transmit the image displayed with AV control unit with RGB signal to the display unit.
Diagnosis ProcedureINFOID:0000000005146316
Regarding Wiring Diagram information, refer to
AV-116, "Wiring Diagram".
1.CHECK CONTINUITY RGB (B: BLUE) SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector M93 and AV control unit con- nector M43.
3. Check continuity between display unit harness connector M93 (A) terminal 18 and AV control unit harness connector M43 (B)
terminal 23.
4. Check continuity between display unit harness connector M93 (A) terminal 18 and ground.
Are continuity results as specified?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK RGB (B: BLUE) SIGNAL
1. Connect display unit connector M93 and AV control unit connec- tor M43.
2. Turn ignition switch ON.
3. Check signal between display unit harness connector M93 ter- minal 18 and ground.
Are voltage readings as specified?
YES >> Replace display unit. Refer to AV-171, "Removal and Installation".
NO >> Replace AV control unit. Refer to AV-169, "
Removal and Installation".
AB
Continuity
Connector Terminal Connector Terminal
M9318M4323 Yes
A —Continuity
Connector Terminal
M93 18Ground No
ALNIA0411GB
(+)
(-) Condition Reference signal
Connector Terminal
M93 18 Ground Receive
audio sig-
nal
ALNIA0387GB
SKIB2237J
Revision: April 20092010 QX56

AV
RGB SYNCHRONIZING SIGNAL CIRCUITAV-81
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
RGB SYNCHRONIZING SIGNAL CIRCUIT
DescriptionINFOID:0000000005146317
Transmit the RGB synchronizing signal to the display uni t so as to synchronize the RGB image displayed with
AV control unit.
Diagnosis ProcedureINFOID:0000000005146318
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK CONTINUITY RGB SYNCHRONIZING SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector M93 and AV control unit con- nector M43.
3. Check continuity between display unit harness connector M93 (A) terminal 19 and AV control unit harness connector M43 (B)
terminal 25.
4. Check continuity between display unit harness connector M93 (A) terminal 19 and ground.
Are continuity results as specified?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK RGB SYNCHRONIZING SIGNAL
1. Connect display unit connector M93 and AV control unit connec-
tor M43.
2. Turn ignition switch ON.
3. Check signal between display unit harness connector M93 ter-
minal 19 and ground.
Are voltage readings as specified?
YES >> Replace display unit. Refer to AV-171, "Removal and Installation".
NO >> Replace AV control unit. Refer to AV-169, "
Removal and Installation".
AB
Continuity
Connector Terminal Connector Terminal
M9319M4325 Yes
A —Continuity
Connector Terminal
M93 19Ground No
ALNIA0412GB
(+)
(-) Condition Reference signal
Connector Terminal
M93 19 Ground Receive
audio sig-
nal
ALNIA0389GB
SKIB3603E
Revision: April 20092010 QX56

AV-82
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
RGB AREA (YS) SIGNAL CIRCUIT
RGB AREA (YS) SIGNAL CIRCUIT
DescriptionINFOID:0000000005146319
Transmits the display area of RGB image displayed by
AV control unit with RGB area (YS) signal to display
unit.
Diagnosis ProcedureINFOID:0000000005146320
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK CONTINUITY RGB AREA (YS) SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector M93 and AV control unit con- nector M43.
3. Check continuity between display unit harness connector M93 (A) terminal 9 and AV control unit harness connector M43 (B)
terminal 27.
4. Check continuity between display unit harness connector M93 (A) terminal 9 and ground.
Are continuity results as specified?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK RGB SYNCHRONIZING SIGNAL
1. Connect display unit connector M93 and AV control unit connec- tor M43.
2. Turn ignition switch ON.
3. Check signal between display unit harness connector M93 ter-
minal 9 and ground.
Are voltage readings as specified?
YES >> Replace display unit. Refer to AV-171, "Removal and Installation".
NO >> Replace AV control unit. Refer to AV-169, "
Removal and Installation".
AB
Continuity
Connector Terminal Connector Terminal
M939M4327 Yes
A —Continuity
Connector Terminal
M93 9Ground No
ALNIA0413GB
(+)
(-) Condition Reference signal
Connector Terminal
M93 9 Ground Receive
audio sig-
nal
ALNIA0391GB
PKIB4948J
Revision: April 20092010 QX56

AV
HORIZONTAL SYNCHRONIZING (HP) SIGNAL CIRCUITAV-83
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
HORIZONTAL SYNCHRONIZING (HP) SIGNAL CIRCUIT
DescriptionINFOID:0000000005146321
In composite image (AUX image, camera image), transmi t the vertical synchronizing (VP) signal and horizon-
tal synchronizing (HP) signal from display unit to AV control unit so as to synchronize the RGB images dis-
played with AV control unit such as the image quality adjusting menu, etc.
Diagnosis ProcedureINFOID:0000000005146322
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK CONTINUITY HORIZONTAL SYNCHRONIZING (HP) SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector M93 and AV control unit con- nector M43.
3. Check continuity between display unit harness connector M93
(A) terminal 8 and AV control unit harness connector M43 (B)
terminal 28.
4. Check continuity between display unit harness connector M93 (A) terminal 8 and ground.
Are continuity results as specified?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK HORIZONTAL SYNCHRONIZING (HP) SIGNAL
1. Connect display unit connector M93 and AV control unit connec-
tor M43.
2. Turn ignition switch ON.
3. Check signal between display unit harness connector M93 ter- minal 8 and ground.
Are voltage readings as specified?
YES >> Replace AV control unit. Refer to AV-169, "Removal and Installation".
NO >> Replace display unit. Refer to AV-171, "
Removal and Installation".
AB Continuity
Connector Terminal Connector Terminal
M93 8M43 28 Yes
A —Contin u it y
Connector Terminal
M93 8Ground No
ALNIA0414GB
(+)
(-) Condition Reference signal
Connector Terminal
M93 8 Ground Receive
audio sig-
nal
ALNIA0396GB
SKIB3601E
Revision: April 20092010 QX56
