wiring diagram INFINITI QX56 2010 Factory Workshop Manual

AV
AV-3
C
DE
F
G H
I
J
K L
M B
A
O P
Description ..........................................................
....
81
Diagnosis Procedure ...............................................81
RGB AREA (YS) SIGNAL CIRCUIT ..................82
Description .......................................................... ....82
Diagnosis Procedure ...............................................82
HORIZONTAL SYNCHRONIZING (HP) SIG-
NAL CIRCUIT ................................................. ....
83
Description .......................................................... ....83
Diagnosis Procedure ...............................................83
VERTICAL SYNCHRONIZING (VP) SIGNAL
CIRCUIT ......................................................... ....
84
Description .......................................................... ....84
Diagnosis Procedure ...............................................84
FRONT DOOR SPEAKER .................................85
Description .......................................................... ....85
Diagnosis Procedure ...............................................85
FRONT TWEETER .............................................88
Description .......................................................... ....88
Diagnosis Procedure ...............................................88
CENTER SPEAKER ...........................................91
Description .......................................................... ....91
Diagnosis Procedure ...............................................91
REAR DOOR SPEAKER ....................................93
Description .......................................................... ....93
Diagnosis Procedure ...............................................93
REAR DOOR TWEETER ...................................96
Description .......................................................... ....96
Diagnosis Procedure ...............................................96
BACK DOOR SPEAKER ...................................99
Description .......................................................... ....99
Diagnosis Procedure ...............................................99
SUBWOOFER ..................................................102
Description .......................................................... ..102
Diagnosis Procedure .............................................102
AMP ON SIGNAL CIRCUIT .............................105
Description .......................................................... ..105
Diagnosis Procedure .............................................105
STEERING SWITCH ........................................106
Description .......................................................... ..106
Diagnosis Procedure .............................................106
MICROPHONE SIGNAL CIRCUIT ...................108
Description .......................................................... ..108
Diagnosis Procedure .............................................108
ECU DIAGNOSIS .......................................110
AV CONTROL UNIT ....................................... ..110
Reference Value ................................................. ..110
Wiring Diagram .....................................................116
DTC Index ........................................................... ..144
DISPLAY UNIT ................................................146
Reference Value ....................................................146
BOSE SPEAKER AMP ...................................149
Reference Value ....................................................149
REAR VIEW CAMERA CONTROL UNIT .......152
Reference Value ....................................................152
DVD PLAYER ..................................................154
Reference Value ....................................................154
SYMPTOM DIAGNOSIS ............................156
MULTI AV SYSTEM ........................................156
Symptom Table ................................................... ..156
NORMAL OPERATING CONDITION .............158
Description .............................................................158
PRECAUTION ............................................166
PRECAUTIONS ...............................................166
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ..
166
Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect .................................
166
PREPARATION .........................................168
PREPARATION ...............................................168
Commercial Service Tools ................................... ..168
ON-VEHICLE REPAIR ...............................169
AV CONTROL UNIT ........................................169
Removal and Installation ..................................... ..169
DISPLAY UNIT ................................................171
Removal and Installation .......................................171
FRONT TWEETER ..........................................172
Removal and Installation .......................................172
CENTER SPEAKER ........................................173
Removal and Installation .......................................173
FRONT DOOR SPEAKER ..............................174
Removal and Installation .......................................174
REAR DOOR SPEAKER ................................175
Removal and Installation .......................................175
BACK DOOR SPEAKER ................................176
Removal and Installation .......................................176
SUBWOOFER .................................................177
Removal and Installation .......................................177
DVD PLAYER ..................................................178
Removal and Installation .......................................178
Revision: April 20092010 QX56

AV-60
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
U1243 DISPLAY UNIT
U1243 DISPLAY UNIT
DescriptionINFOID:0000000005146286
DTC LogicINFOID:0000000005146287
Diagnosis ProcedureINFOID:0000000005146288
Regarding Wiring Diagram information, refer to
AV-116, "Wiring Diagram".
1.CHECK DISPLAY UNIT POWER SUPPLY AND GROUND CIRCUIT
Check display unit power supply and ground circuit. Refer to AV-69, "
DISPLAY UNIT : Diagnosis Procedure".
Is inspection result OK?
YES >> GO TO 2.
NO >> Repair malfunctioning parts.
2.CHECK CONTINUITY CO MMUNICATION CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector M93 and AV control unit connector M43.
3. Check continuity between display unit harness connector M93 (A) terminals 11, 22 and AV control unit harness connector M43
(B) terminals 30, 31.
4. Check continuity between display unit harness connector M93 (A) terminals 11, 22 and ground.
Part name Description
DISPLAY UNIT • Display image is controlled by the serial communication from AV control unit.
• RGB image signal is input from AV control unit (RGB, RGB area and RGB syn-
chronizing). Auxiliary image signal is input from the auxiliary input jack. Cam-
era image signal is input from the camera control unit.
• Synchronize signal (HP, VP) is output to AV control unit.
• Touch panel function can be operated for each system by touching a display directly.
DTC Display contents of
CONSULT-III DTC Detection Condition
Possible causes
U1243 FRONT DISP CONN
[U1243] • Display unit power supply and ground circuit malfunc-
tion is detected.
• Malfunction is detected on communication circuit be- tween display unit and AV control unit.
• Malfunction is detected on communication signal be-
tween display unit and AV control unit. • Display unit power supply and
ground circuit.
• Communication circuit between display unit and AV control unit.
AB Continuity
Connector Terminal Connector Terminal
M93 11
M43 30
Ye s
22 31
A —Contin u it y
Connector Terminal
M93 11
Ground No
22
ALNIA0397GB
Revision: April 20092010 QX56

AV-62
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
U1244 GPS ANTENNA
U1244 GPS ANTENNA
DescriptionINFOID:0000000005146289
DTC LogicINFOID:0000000005146290
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000005146291
Regarding Wiring Diagram information, refer to
AV-116, "Wiring Diagram".
1.GPS ANTENNA CHECK
Inspect GPS antenna and antenna feeder for damage or poor connection.
Is the GPS antenna and feeder clean and undamaged?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning parts.
2.CHECK AV CONTROL UNIT VOLTAGE
1. Turn ignition switch ON.
2. Check voltage between AV control unit connector M124 terminal 116 and ground.
Is the voltage reading as specified?
YES >> Replace GPS antenna. Refer to AV-186, "Removal and
Installation".
NO >> Replace AV control unit. Refer to AV-169, "
Removal and
Installation".
Part Name Description
GPS ANTENNA GPS signal is detected and transmitted to the AV control unit.
DTC CONSULT-III display Detection condition
U1244 GPS ANTENNA CONN
[U1244]
GPS antenna connection malfunction is detected.
116 - Ground
: Approx. 5V
ALNIA0400GB
Revision: April 20092010 QX56

AV
U1250 CAMERA CONTROL UNITAV-63
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
U1250 CAMERA CONTROL UNIT
DescriptionINFOID:0000000005146292
DTC LogicINFOID:0000000005146293
Diagnosis ProcedureINFOID:0000000005146294
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK CAMERA-CONNECTION RECOGNITION SIGNAL CIRCUIT
1. Disconnect AV control unit connector and camera control unit connector.
2. Check continuity between AV control unit harness connector M45 (A) terminal 84 and camera control unit harness connector
B73 (B) terminal 5.
3. Check continuity between AV control unit harness connector M45 (A) terminal 84 and ground.
Are the continuity results as specified?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK AV CONTROL UNIT VOLTAGE
Part name Description
CAMERA CONTROL UNIT • Camera image signal is input from rear view camera, and camera image is in-
dicated on the display.
• Power (camera ON signal) is sent to rear view camera.
• Controlled by audio communication sent from AV control unit.
• AV control unit recognizes the presence of camera system with camera con- nection recognition signal.
DTC Display contents of
CONSULT-III DTC Detection Condit
ion Possible causes
U1250 CAMERA CONT. CONN
[U1250] A malfunction is detected in camera-connection recogni-
tion signal circuit. Camera-connection recognition sig-
nal circuit.
AB
Continuity
Connector Terminal Connector Terminal
M45 84 B73 5 Yes
A —Con tin uit y
Connector Terminal
M45 84Ground No
ALNIA0401GB
Revision: April 20092010 QX56

AV
U1258 SATELLITE RADIO ANTENNAAV-65
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
U1258 SATELLITE RADIO ANTENNA
DescriptionINFOID:0000000005146295
DTC LogicINFOID:0000000005146296
Diagnosis ProcedureINFOID:0000000005146297
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.SATELLITE RADIO ANTENNA CHECK
Visually check satellite radio antenna and antenna feeder.
Is inspection result OK?
YES >> GO TO 2.
NO >> Repair malfunctioning parts.
2.CHECK AV CONTROL UNIT VOLTAGE
1. Disconnect AV control unit connector M125.
2. Turn ignition switch ON.
3. Check voltage between AV control unit connector M125 termi- nal 118 and ground.
Is voltage approximately 5 volts?
YES >> Inspection end.
NO >> Replace AV control unit. Refer to AV-169, "
Removal and
Installation".
Part name Description
SATELLITE RADIO ANTENNA Satellite radio signal is received and sent to audio control unit.
DTCDisplay contents of
CONSULT-III DTC Detection Condit
ion Possible causes
U1258 XM ANETNNA CONN
[U1258] Satellite radio antenna connection malfunction is detect-
ed.
Satellite radio antenna disconnection.
118 - Ground
: Approx. 5 V
ALNIA0403GB
Revision: April 20092010 QX56

AV-68
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
AV CONTROL UNIT
AV CONTROL UNIT : Diagnosis ProcedureINFOID:0000000005146301
Regarding Wiring Diagram information, refer to
AV-116, "Wiring Diagram".
1.CHECK FUSES
Check that the following AV control unit fuses are not blown.
Are the fuses OK?
YES >> GO TO 2.
NO >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse.
2.POWER SUPPLY CIRCUIT CHECK
1. Disconnect AV control unit connectors M42 and M45.
2. Check voltage between the AV control unit connectors M42 and M45 and ground.
Are the voltage results as specified?
YES >> GO TO 3.
NO >> • Check connector housings for disconnected or loose
terminals.
• Repair harness or connector.
3.GROUND CIRCUIT CHECK
Unit Terminals Signal name Fuse No.
AV c o n t r o l u n i t 19
Battery power 31
66
68
7 Ignition switch ACC or ON 4
69
79 Ignition switch ON or START 12
(+)
(-) OFF ACC ON
Connector Terminal
M42 7Ground0V
Battery
voltage Battery
voltage
19 Ground Battery
voltage Battery
voltage Battery
voltage
M45 66 Ground
Battery
voltage Battery
voltage Battery
voltage
68 Ground Battery
voltage Battery
voltage Battery
voltage
69 Ground 0V Battery
voltage Battery
voltage
79 Ground 0V 0V Battery
voltage
AWNIA1554ZZ
Revision: April 20092010 QX56

AV
POWER SUPPLY AND GROUND CIRCUITAV-69
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
1. Ignition OFF.
2. Check continuity between AV control unit harness connectors M42 and M45 and ground.
Are the continuity results as specified?
YES >> Inspection End.
NO >> Repair AV control unit ground.
DISPLAY UNIT
DISPLAY UNIT : Diagnosis ProcedureINFOID:0000000005146302
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch to ACC
2. Check voltage between display unit harness connector M93 and ground.
Does specified voltage exist?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector.
3. Check continuity between display unit harness connector M93 and ground.
Does continuity exist?
YES >> Inspection end.
Connector (+)
(-)Continuity
Te r m i n a l
M42 20
Ground Yes
M45 65
67
86
87
AWNIA1555ZZ
Signal name Connector Terminal
Ignition switch
position Value (Approx.)
B+ M932
ACC Battery voltage
ACC 3
ALNIA0317GB
(+)
(-)Continuity
Connector Terminal
M93 1
Ground Yes
13
ALNIA0407GB
Revision: April 20092010 QX56

AV-70
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
POWER SUPPLY AND GROUND CIRCUIT
NO >> Repair harness or connector.
A/C AND AV SWITCH ASSEMBLY
A/C AND AV SWITCH ASSEMBLY : Diagnosis ProcedureINFOID:0000000005146303
Regarding Wiring Diagram information, refer to
AV-116, "Wiring Diagram".
1.CHECK FUSE
Check that the A/C and AV switch assembly fuse is not blown.
Is the fuse OK?
YES >> GO TO 2.
NO >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse.
2.POWER SUPPLY CIRCUIT CHECK
1. Disconnect A/C and AV switch assembly connector M98.
2. Check voltage between the A/C and AV switch assembly con- nector M98 and ground.
Are the voltage results as specified?
YES >> GO TO 3.
NO >> • Check connector housings for disconnected or loose
terminals.
• Repair harness or connector.
3.GROUND CIRCUIT CHECK
1. Ignition OFF.
2. Check continuity between A/C and AV switch assembly harness connector M98 and ground.
Are the continuity results as specified?
YES >> Inspection End.
NO >> Repair A/C and AV switch assembly ground.
BOSE SPEAKER AMP
BOSE SPEAKER AMP : Diagnosis ProcedureINFOID:0000000005146304
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK FUSE
Check that the BOSE speaker amp. fuse is not blown.
Unit Terminal Signal name Fuse No.
A/C and AV switch assembly 2Ignition switch ACC or ON 4
(+)
(-) OFF ACC ON
Connector Terminal
M98 2 Ground 0V Battery
voltage Battery
voltage
ALNIA0315GB
(+) (-) Continuity
Connector Terminal
M98 1 Ground Yes
ALNIA0316GB
Revision: April 20092010 QX56

AV
POWER SUPPLY AND GROUND CIRCUITAV-71
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
Are the fuses OK?
YES >> GO TO 2.
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BOSE speak er amp. connector.
3. Check voltage between BOSE speaker amp. harness connector M112 terminal 11 and ground.
Is battery voltage present?
YES >> GO TO 3.
NO >> Check harness between BOSE speaker amp. and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BOSE speak er amp. connector.
3. Check continuity between BOSE speaker amp. harness connec-
tor M112 terminal 12 and ground.
Does continuity exist?
YES >> Inspection End.
NO >> Repair harness or connector.
WOOFER
WOOFER : Diagnosis ProcedureINFOID:0000000005146305
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK FUSE
Check that the subwoofer fuse is not blown.
Is the fuse OK?
YES >> GO TO 2.
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUIT
Unit Terminal Signal name Fuse No.
BOSE speaker amp. 11Battery power 31
(+)
(-) Voltage (approx.)
Connector Terminal
M112 11 Ground Battery voltage
ALNIA0339GB
(+) (-)Continuity
Connector Terminal
M112 12Ground Yes
ALNIA0340GB
Unit Terminal Signal name Fuse No.
Subwoofer 6Battery power 17
Revision: April 20092010 QX56

AV-72
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
POWER SUPPLY AND GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect subwoofer connector.
3. Check voltage between subwoofer harness connector B72 ter-
minal 6 and ground.
Is battery voltage present?
YES >> GO TO 3.
NO >> Check harness between subwoofer and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between subwoofer harness connector B72 terminal 5 and ground.
Does continuity exist?
YES >> Inspection End.
NO >> Repair harness or connector.
REAR VIEW CAMERA CONTROL UNIT
REAR VIEW CAMERA CONTRO L UNIT : Diagnosis ProcedureINFOID:0000000005146306
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK FUSE
Check that the following fuses of the rear view camera control unit are not blown.
Are the fuses OK?
YES >> GO TO 2.
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUIT
Check voltage between rear view camera control unit harness con-
nector B73 and ground.
Are the voltage readings as specified?
YES >> GO TO 3.
NO >> Check harness between rear view camera control unit and fuse.
(+) (-) Voltage (approx.)
Connector Terminal
B72 6 Ground Battery voltage
ALNIA0367GB
(+) (-)Continuity
Connector Terminal
B72 5Ground Yes
ALNIA0368GB
Unit Terminals Signal name Fuse No.
Rear view camera control unit 1
Battery power 31
2 Ignition switch ACC or ON 4
Signal name Connector TerminalIgnition switch
position Value (Approx.)
Battery power supply B731OFF
Battery voltage
ACC power supply 2 ACC
ALLIA0244ZZ
Revision: April 20092010 QX56
