DOOR LOCK FUNCTION
When all doors are locked, ignition switch is in OFF
position and key switch is OFF, doors are unlocked with
door request switch
When BCM does not receive the following signals within 60 seconds, all doors are locked.
• Door switch is ON (door is opened)
• Door is locked
• Ignition switch is ON (ignition switch is pressed)
• Key switch is ON
Auto door lock mode can be changed by “AUTO LOCK SET” mode in “WORK SUPPORT”. Refer to DLK-55,
"INTELLIGENT KEY : CONSULT-III Function (BCM - INTELLIGENT KEY)".
ROOM LAMP OPERATION
When the following conditions are met:
• Condition of interior lamp switch is in DOOR position
• Door switch OFF (all the doors are closed)
Intelligent Key system turns on interior lamp (for up to 30 seconds maximum) by receiving UNLOCK signal
from door request switch. For detailed description, refer to DLK-14, "
DOOR LOCK AND UNLOCK SWITCH :
System Description".
LIST OF OPERATION RELATED PARTS
Parts marked with × are the parts related to operation.
Door lock function
Intelligent Key
Ignition key switch
Remote keyless entry receiver
Door switch
Door request switch (Driver, Passenger)
Door lock actuator
Inside key antenna
Outside key antenna (Driver, Passenger)
Intelligent Key warning buzzer
CAN communication system
BCM
Hazard warning lamp
Door lock/unlock function by request switch ×××××××× ××
Hazard and buzzer reminder function for door lock/unlock
operation ××××
Key reminder function ××××××××××××
Selective unlock function by request switch
(Driver side) ×
×××× ××
Selective unlock function by request switch
(Passenger side) ×
×××× ××
Auto door lock function ×× ×××××
Revision: April 20092010 QX56

DOOR LOCK FUNCTIONDLK-19
< FUNCTION DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR REQUEST SWITCH : Component Parts LocationINFOID:0000000005146877
