service INFINITI QX56 2011 Factory Service Manual

PREPARATIONDLN-149
< PREPARATION > [FRONT FINAL DRIVE: R180A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
PREPARATION
PREPARATION
Special Service ToolINFOID:0000000006222374
The actual shapes of Kent-Moore t ools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.)
Tool name Description
ST3127S000
(J-25765-A)
Preload gauge Measuring pinion bearing preload and total
preload
KV381054S0
(J-34286)
Puller Removing front oil seal
ST30720000
(J-25405)
Drift
a: 77 mm (3.03 in) dia.
b: 55.5 mm (2.185 in) dia.  Installing front oil seal
 Installing side oil seal
 Installing pinion front bearing outer race
ST27863000
(—)
Drift
a: 74.5 mm (2.933 in) dia.
b: 62.5 mm (2.461 in) dia.  Installing front oil seal
 Installing side oil seal
K V 1 0 1111 0 0
(J-37228)
Seal cutter Removing carrier cover
ZZA0806D
ZZA0601D
ZZA0811D
ZZA1003D
S-NT046
Revision: 2010 May2011 QX56

PREPARATIONDLN-151
< PREPARATION > [FRONT FINAL DRIVE: R180A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
Commercial Service ToolINFOID:0000000006222375
ST30901000
(J-26010-01)
Drift
a: 79 mm (3.11 in) dia.
b: 45 mm (1.77 in) dia.
c: 35.2 mm (1.386 in) dia. Installing drive pinion rear bearing inner race
ST33200000
(J-26082)
Drift
a: 60 mm (2.36 in) dia.
b: 44.5 mm (1.752 in) dia. Installing drive pinion front bearing inner race
—
(J-34309)
Differential shim selector tool Adjusting bearing preload and pinion gear
height
—
(J-25269-18)
Side bearing disc (2 Req ′d) Selecting pinion height adjusting washer
Tool number
(Kent-Moore No.)
Tool name
Description
ZZA0978D
ZZA1002D
NT134
NT135
Tool name
Description
Power tool Loosening bolts and nuts
Flange wrench Removing and installing drive pinion lock nut
PBIC0190E
NT035
Revision: 2010 May2011 QX56

FRONT OIL SEALDLN-157
< REMOVAL AND INSTALLATION > [FRONT FINAL DRIVE: R180A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
CAUTION:
Make a stamping after replacing front oil seal.
 After replacing front oil seal, make a stamping on t he stamping point in accordance with the table below in
order to identify replacement frequency.
CAUTION:
Make a stamping from left to right.
1. Make a judgement if a collapsible spacer replace is required.
2. Drain gear oil. Refer to DLN-155, "
Draining".
3. Remove the drive shafts from the front final drive assembly. Refer to FAX-22, "
Removal and Installation".
4. Remove the front propeller shaft from the front final drive assembly. Refer to DLN-129, "
Removal and
Installation".
5. Measure the total preload torque using preload gauge (A) [SST: ST3127S000 (J-25765-A)].
NOTE:
Record the total preload torque measurement.
6. Put matching mark (B) on the end of drive pinion. The matching mark should be in line with the matching mark (A) on companion
flange (1).
CAUTION:
For matching, marks use paint. Never damage companion
flange and drive pinion.
7. Remove the drive pinion lock nut using flange wrench (commer- cial service tool).
Stamp before stamping Stamping on the far right Stamping
No stamp 00
“0”
(Front oil seal was replaced once.) 101
“01”
(Collapsible spacer and front oil seal were replaced last time.) 0010
“0” is on the far right.
(Only front oil seal was replaced last time.) 1...01
“1” is on the far right.
(Collapsible spacer and front oil seal were replaced last time.) 0 ...010
PDIA1002E
PDIA0799J
PDIA1004E
Revision: 2010 May2011 QX56

DLN-158
< REMOVAL AND INSTALLATION >[FRONT FINAL DRIVE: R180A]
FRONT OIL SEAL
8. Remove the companion flange using puller (commercial service
tool).
9. Remove front oil seal using the puller [SST: KV381054S0 (J- 34286)].
INSTALLATION
1. Drive the front oil seal in evenl y until it becomes flush with the
gear carrier using drifts (A and B).
CAUTION:
 Never reuse oil seal.
 Never incline oil seal when installing.
 Apply multi-purpose grease to the lips and differential
gear oil to the circumference of oil seal.
2. Install companion flange (1). NOTE:
When reusing drive pinion, align the matching mark (B) of drive
pinion with the matching mark (A) of companion flange, and then
install companion flange (1).
LDIA0171E
LDIA0172E
A: Drift [SST: ST30720000 (J-25405)]
B: Drift [SST: ST27863000 ( — )]
WDIA0147E
PDIA0799J
Revision: 2010 May2011 QX56

FRONT OIL SEALDLN-159
< REMOVAL AND INSTALLATION > [FRONT FINAL DRIVE: R180A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
3. Apply anti-corrosion oil to the thread and seat of new drive pin- ion lock nut, and temporarily tighten drive pinion lock nut to drive
pinion, using flange wrench (commercial service tool).
CAUTION:
Never reuse drive pinion lock nut.
4. Tighten drive pinion lock nut within the limits of specified torque so as to keep the pinion bearing preload within a standard val-
ues, using preload gauge (A) [SST: ST3127S000 (J-25765-A)].
CAUTION:
 Adjust to the lower limit of the drive pinion lock nut tight-
ening torque first.
 If the preload torque exceeds the specified value, replace collapsible spacer and tighte n it again to adjust. Never
loosen drive pinion lock nut to adjust the preload torque.
5. Fit a dial indicator onto the companion flange face (inner side of the propeller shaft mounting bolt holes).
6. Rotate the companion flange to check for runout.
7. Fit a test indicator to the inner side of the companion flange (socket diameter).
8. Rotate the companion flange to check for runout.
9. If the runout value is outside the repair limit, follow the procedure below to adjust.
a. Check for runout while changing the phase between companion flange and drive pinion gear by 90 ° step,
and search for the position where the runout is the minimum.
b. If the runout value is still outside of the limit after the phase has been changed, possible causes are be an
assembly malfunction of drive pinion and pinion bear ing and malfunction of pinion bearing. Check for
these items and repair if necessary.
c. If the runout value is still outsi de of the limit after the check and repair, replace companion flange.
10. Install front propeller shaft. Refer to DLN-129, "
Removal and Installation".
11. Install drive shaft. Refer to FAX-22, "
Removal and Installation".
12. Refill gear oil to the final drive and check oil level. Refer to DLN-155, "
Refilling".
13. Check the final drive for oil leakage. Refer to DLN-155, "
Inspection".
Total preload torque: A value
that add 0.1 – 0.4 N·m
(0.01 – 0.04 kg-m, 1 – 3 in-lb) to
the measured value when re-
moving.
PDIA1003E
Companion flange runout : Refer to DLN-185, "Com-
panion Flange Runout".
Companion flange runout : Refer to DLN-185, "
Com-
panion Flange Runout".
JSDIA0116ZZ
Revision: 2010 May2011 QX56

DLN-168
< UNIT DISASSEMBLY AND ASSEMBLY >[FRONT FINAL DRIVE: R180A]
DIFFERENTIAL ASSEMBLY
Disassembly
INFOID:0000000006222392
1. Remove bushing with drift (commercial service tool).
2. Remove differential side shaft assembly. Refer to DLN-165, "
Disassembly".
3. Remove side oil seal (left side) from gear carrier with a suitable tool.
4. For proper reinstallation, paint matching marks on one side of the side bearing cap and gear carrier.
CAUTION:
 For matching marks, use paint. Never damage side bear-ing cap and gear carrier.
 Bearing caps are manufactured as integral molding. Use the matching marks to them in their original positions.
5. Remove the side bearing caps.
6. Lift the differential case assembly out of the gear carrier with sliding hammer (commercial service tool).
7. Remove the differential case assembly with the side bearing outer race and side bearing adjusting washer.
CAUTION:
 Keep side bearing outer races together with side bearing
inner races. Do not mix them up.
 Keep side bearing adjusting washers together with side
bearings.
: Apply Genuine Silicone RTV or equivalent. Refer to GI-22, "Recommended Chemical Products and Sealants".
: Apply Genuine High Strength Thread Locking Sealant or equivalent. Refer to GI-22, "
Recommended Chemical Products
and Sealants".
Refer to GI-4, "
Components" for symbols not described above.
SDIA1795E
PDIA0701E
PDIA0547E
SPD919
Revision: 2010 May2011 QX56

DIFFERENTIAL ASSEMBLYDLN-171
< UNIT DISASSEMBLY AND ASSEMBLY > [FRONT FINAL DRIVE: R180A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
10. Check and adjust drive gear runout, tooth contac t, backlash, and total preload torque. Refer to DLN-171,
"Adjustment".
Recheck above items. Readjust the above description, if necessary.
11. Apply sealant to match surface of carrier cover.  Use Genuine Silicone RTV or equivalent. Refer to GI-22,
"Recommended Chemical Products and Sealants".
CAUTION:
Remove any old sealant adheri ng to the mating surfaces.
Also remove any moisture, oil, or foreign material adhering
to the application and mating surfaces.
12. Install the carrier cover to the gear carrier. Tighten the bolts to the specified torque.
13. Install side shaft. Refer to DLN-166, "
Assembly".
14. Install bushing with drift (commercial service tool).
AdjustmentINFOID:0000000006222394
TOTAL PRELOAD TORQUE
1. Install the differential side shaft. Refer to DLN-166, "Assembly".
2. Rotate the drive pinion back and forth 2 to 3 times to check for unusual noise and rotation malfunction.
3. Rotate the drive pinion at least 20 times to check for smooth operation of the bearings.
4. Measure total preload torque with the preload gauge [SST: ST3127S000 (J-25765-A)].
NOTE:
Total preload torque = Drive pinion bearing preload torque +
Side bearing preload torque
 If the measured value is out of the specification, check and adjust each part. Adjust the drive pinion
bearing preload torque first, then adjust the side bearing preload torque.
DRIVE GEAR RUNOUT
1. Remove carrier cover. Refer to DLN-168, "Disassembly".
PDIA0712E
Total preload torque : Refer to DLN-185, "Pre-
load Torque".
PDIA0697E
When the preload torque is large
On drive pinion bear ings: Decrease the drive pinion bear ing adjusting washer and drive
pinion adjusting washer thi ckness. For selecting adjusting
washer, refer to the latest parts information.
On side bearings: Increase the side bear ing adjusting washer thickness. For se-
lecting adjusting washer, refer to the latest parts information.
When the preload torque is small On drive pinion bearings: Increase the drive pi nion bearing adjusting washer and drive
pinion adjusting washer thi ckness. For selecting adjusting
washer, refer to the latest parts information.
On side bearings: Decrease the side bear ing adjusting washer thickness. For se-
lecting adjusting washer, refer to the latest parts information.
Revision: 2010 May2011 QX56

DRIVE PINIONDLN-177
< UNIT DISASSEMBLY AND ASSEMBLY > [FRONT FINAL DRIVE: R180A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
DisassemblyINFOID:0000000006222397
1. Remove the side shaft. Refer to DLN-165, "Disassembly".
2. Remove the differential assembly. Refer to DLN-168, "
Disassembly".
3. Remove the drive pinion lock nut with a flange wrench (commer- cial service tool).
4. Put matching mark (B) on the end of drive pinion. The matching mark should be in line with the matching mark (A) on companion
flange (1).
CAUTION:
For matching, marks use paint. Never damage companion
flange and drive pinion.
5. Remove the companion flange with the puller (commercial ser- vice tool).
6. Press the drive pinion assembly. CAUTION:
Never drop drive pinion assembly.
: Apply Genuine Silicone RTV or equivalent. Refer to GI-22, "Recommended Chemical Products and Sealants".
: Apply Genuine High Strength Thread Locking Sealant or equivalent. Refer to GI-22, "
Recommended Chemical Products
and Sealants".
Refer to GI-4, "
Components" for symbols not described above.
PDIA0702E
PDIA0799J
PDIA0703E
PDIA0704E
Revision: 2010 May2011 QX56

DLN-178
< UNIT DISASSEMBLY AND ASSEMBLY >[FRONT FINAL DRIVE: R180A]
DRIVE PINION
7. Remove the front oil seal with a suitable tool.
CAUTION:
Never damage gear carrier.
8. Remove the drive pinion front bearing inner race.
9. Remove the collapsible spacer.
10. Remove the drive pinion rear bearing inner race and drive pinion height adjusting washer with the replacer (commercial service
tool).
11. Remove the drive pinion front and rear bearing outer races by tapping them uniformly with a suitable tool.
CAUTION:
Never damage gear carrier.
12. Perform inspection after disassembly. Refer to DLN-184,
"Inspection".
PDIA0716E
S-PD179
PDIA0705E
Revision: 2010 May2011 QX56

DLN-180
< UNIT DISASSEMBLY AND ASSEMBLY >[FRONT FINAL DRIVE: R180A]
DRIVE PINION
7. Using drift [SST: ST33200000 (J-26082)], press the pinion front
bearing inner race to drive pinion as far as drive pinion nut can
be tightened.
8. Install front oil seal as shown in figure with the drifts (A and B). CAUTION:
 Never reuse oil seal.
 When installing, n ever incline oil seal.
 Apply multi-purpose grease onto oil seal lips, and gear oil
onto the circumference of oil seal.
9. Install companion flange (1). NOTE:
When reusing drive pinion, align the matching mark (B) of drive
pinion with the matching mark (A) of companion flange, and then
install companion flange (1).
10. Temporarily tighten drive pinion lock nut to drive pinion. CAUTION:
 Apply anti-corrosion oil to th e thread and seat of the drive
pinion lock nut
 Never reuse drive pinion lock nut.
11. Tighten to drive pinion lock nut using flange wrench (A), while adjusting pinion bearing preload torque using preload gauge (B).
CAUTION:
 Adjust to the lower limit of the drive pinion lock nut tight-
ening torque first.
 After adjustment, rotate dri ve pinion back and forth 2 to 3
times to check for unusual no ise, rotation malfunction,
and other malfunctions.
12. Install differential case assembly. Refer to DLN-169, "
Assem-
bly".
CAUTION:
PDIA0709E
A: Drift [SST: ST30720000 (J-25405)]
B: Drift [SST: ST27863000 ( — )]
PDIA0717E
PDIA0799J
A: Flange wrench (commercial service tool)
B: Preload gauge [SST: ST3127S000 (J-25765-A)]
Pinion bearing preload : Refer to DLN-185, "Pre-
load Torque".
WDIA0382E
Revision: 2010 May2011 QX56
